Worx WX842, WX842.X User guide

20V Cordless 18 Gauge Brad Nailer
20V Akku-Bolzensetzer 18 Gauge

Cloueuse sans l 20 V de calibre 18
Sparachiodi a batteria per chiodi con testa a scomparsa calibro 18 da 20 V
Clavadode cristalero de calibre 18 sin cable de 20V
Pistola de 20 V sem os para pregos Brad de calibre 18

20V snoerloze 18-gauge spijkerpistool
20 V, 18 gauge akku-stiftpistol
20V trådløs 18-gauge dykkertpistol
20V sladdlös 18-storleks spikpistol

Bezprzewodowa sztyfciarka o rozmiarze gwoździ sztyftowych 18 mm 20 V
Καρφωτικό μπαταρίας 20V 18 Gauge
20V-os akkumulátoros 18 mm-es szögbelövő
Pistol de bătut cuie fără cap de calibru 18, cu acumulator de 20 V
20 V bezšňůrová hřebíkovačka na hřebíčky tloušťky 18
20 V akumulátorová nastreľovačka klincov bez hlavičky veľ. 18
20 V brezžični 18 iglični zabijalnik žebljev
Аккумуляторный гвоздезабивной пистолет для гвоздей размера 18, 20 В

WX842 WX842.X

EN

ES
PT
NL
DK

NOR

SV
PL
GR

HU
RO

CZ
SK

SL

RU

P08
P15

D

P23

F

P31

I

P39
P47
P55
P63
P70
P77
P84

P92
P101
P108
P115
P122
P129
P136

Original Instruction

Originalbetriebsanleitung
Notice originale

Istruzioni originali

Manual original

Manual original

Oorspronkelijke gebruiksaanwijzing
Original brugsanvisning

Original driftsinstruks

Bruksanvisning i original

Instrukcja oryginalna

ΜΕΤΑΦΡΑΣΗ ΤΩΝ ΠΡΩΤΟΤΥΠΩΝ ΟΔΗΓΙΩΝ

Eredeti használati utasítás

Instrucţiuni originale

Původní návod k používání

Pôvodný návod na použitie

Izvirna navodila

Оригинальное руководство по эксплуатации

EN

D

F

I

ES

PT

NL
DK

NOR

SV

PL

GR

HU

RO

CZ

SK

SL

RU

2

1

5

4

3

13

6

7

8

9

10

11

12

14

A1

A2

1

2

A3

B

C2C1

2

1

15mm

20mm

25mm

32mm

35mm

38mm

40mm

45mm

50mm

2

1

D

E1

2

1

E2

G

F

1

2

H1

H2

H3

1

2

TABLE OF CONTENT

1. SAFETY INSTRUCTIONS

2. COMPONENT LIST

3. TECHNICAL DATA

4. INTENDED USE

5. OPERATING INSTRUCTIONS

6. MAINTENANCE

7. ENVIRONMENTAL PROTECTION

8. TROUBLESHOOTING

9. DECLARATION OF CONFORMITY

1. SAFETY INSTRUCTIONS
GENERAL POWER TOOL

SAFETY WARNINGS

WARNING: Read all safety warnings and all

instructions. Failure to follow the warnings and

instructions may result in electric shock, re and/or

serious injury.

Save all warnings and instructions for future
reference.

The term “power tool” in the warnings refers to your

8

mains-operated (corded) power tool or battery­operated (cordless) power tool.

1) Work area safety

a) Keep work area clean and well lit. Cluttered or

dark areas invite accidents.

b) Do not operate power tools in explosive

atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools

create sparks which may ignite the dust or fumes.

c) Keep children and bystanders away while

operating a power tool. Distractions can cause
you to lose control.

2) Electrical safety
a) Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power

tools. Unmodied plugs and matching outlets will

reduce risk of electric shock.

b) Avoid body contact with earthed or grounded

surfaces, such as pipes, radiators, ranges and

refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.

c) Do not expose power tools to rain or wet

conditions. Water entering a power tool will

increase the risk of electric shock.

d) Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges

or moving parts. Damaged or entangled cords

increase the risk of electric shock.

e) When operating a power tool outdoors, use an

extension cord suitable for outdoor use. Use of a

cord suitable for outdoor use reduces the risk of
electric shock.

f) If operating a power tool in a damp location is

unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk

of electric shock.

3) Personal safety

a) Stay alert, watch what you are doing and use

common sense when operating a power tool. Do
not use a power tool while you are tired or under
the inuence of drugs, alcohol or medication. A

moment of inattention while operating power tools
may result in serious personal injury.

b) Use personal protective equipment. Always wear

eye protection. Protective equipment such as dust

mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will
reduce personal injuries.

c) Prevent unintentional starting. Ensure the switch

is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool. Carrying power tools with your nger on

the switch or energising power tools that have the
switch on invites accidents.

d) Remove any adjusting key or wrench before

turning the power tool on. A wrench or a key left

attached to a rotating part of the power tool may
result in personal injury.

e) Do not overreach. Keep proper footing and

balance at all times. This enables better control of

the power tool in unexpected situations.

f) Dress properly. Do not wear loose clothing or

jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery

or long hair can be caught in moving parts.

g) If devices are provided for the connection of dust

extraction and collection facilities, ensure these
are connected and properly used. Use of dust

collection can reduce dust-related hazards.

4) Power tool use and care
a) Do not force the power tool. Use the correct

power tool for your application. The correct power

tool will do the job better and safer at the rate for
which it was designed.

b) Do not use the power tool if the switch does not

turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must
be repaired.

c) Disconnect the plug from the power source and/

or the battery pack from the power tool before
making any adjustments, changing accessories,

or storing power tools. Such preventive safety
measures reduce the risk of starting the power

20V Cordless 18 Gauge Brad Nailer

EN

tool accidentally.

d) Store idle power tools out of the reach of children

and do not allow persons unfamiliar with the
power tool or these instructions to operate the

power tool. Power tools are dangerous in the
hands of untrained users.

e) Maintain power tools. Check for misalignment or

binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused

by poorly maintained power tools.

f) Keep cutting tools sharp and clean. Properly

maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits etc.

in accordance with these instructions, taking
into account the working conditions and the
work to be performed. Use of the power tool for

operations different from those intended could
result in a hazardous situation.

5) Battery tool use and care
a) Recharge only with the charger specied by the

manufacturer. A charger that is suitable for one

type of battery pack may create a risk of re when

used with another battery pack.

b) Use power tools only with specically designated

battery packs. Use of any other battery packs may

create a risk of injury and re.

c) When battery pack is not in use, keep it away

from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal to
another. Shorting the battery terminals together

may cause burns or a re.

d) Under abusive conditions, liquid may be ejected

from the battery; avoid contact. If contact
accidentally occurs, ush with water. If liquid
contacts eyes, additionally seek medical help.

Liquid ejected from the battery may cause irritation
or burns.

6) Service
a) Have your power tool serviced by a qualied

repair person using only identical replacement

parts. This will ensure that the safety of the power
tool is maintained.

NAILER SAFETY WARNINGS

1. Always assume that the tool contains fasteners.

Careless handling of the nailer can result in

unexpected ring of fasteners and personal injury.

2. Do not point the tool towards yourself or anyone
nearby. Unexpected triggering will discharge the

fastener causing an injury.

3. Do not actuate the tool unless the tool is placed

rmly against the workpiece. If the tool is not in

contact with the workpiece, the fastener may be

deected away from your target.

4. Disconnect the tool from the battery when
the fastener jams in the tool.While removing a

jammed fastener, the nailer may be accidentally
activated if it is plugged in.

5. Use caution while removing a jammed fastener.

The mechanism may be under compression and
the fastener may be forcefully discharged while
attempting to free a jammed condition.

6. Do not use this nailer for fastening electrical
cables. It is not designed for electric cable

installation and may damage the insulation of
electric cables thereby causing electric shock or

re hazards.

SAFETY WARNINGS FOR
BATTE RY PACK

a) Do not dismantle, open or shred cells or battery

pack.

b) Do not short-circuit a battery pack. Do not store

battery packs haphazardly in a box or drawer
where they may short-circuit each other or be
short-circuited by conductive materials. When

battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that
can make a connection from one terminal to
another. Shorting the battery terminals together

may cause burns or a re.

c) Do not expose battery pack to heat or re. Avoid

storage in direct sunlight.

d) Do not subject battery pack to mechanical

shock.

e) In the event of battery leaking, do not allow

the liquid to come into contact with the skin
or eyes. If contact has been made, wash the
affected area with copious amounts of water
and seek medical advice.

f) Keep battery pack clean and dry.
g) Wipe the battery pack terminals with a clean dry

cloth if they become dirty.

h) Battery pack needs to be charged before use.

Always refer to this instruction and use the
correct charging procedure.

i) Do not maintain battery pack on charge when

not in use.

j) After extended periods of storage, it may

be necessary to charge and discharge the
battery pack several times to obtain maximum
performance.

k) Recharge only with the charger specied

by Worx. Do not use any charger other than
that specically provided for use with the
equipment.

l) Do not use any battery pack which is not

9

20V Cordless 18 Gauge Brad Nailer

EN

designed for use with the equipment.
m) Keep battery pack out of the reach of children.
n) Retain the original product literature for future

reference.
o) Remove the battery from the equipment when

not in use.
p) Dispose of properly.

q) Do not mix cells of different manufacture,

capacity, size or type within a device.
r) Keep the battery away from microwaves and

high pressure.

SYMBOLS

To reduce the risk of injury, user must
read instruction manual

Warning

Wear ear protection

10

Wear eye protection

Wear dust mask

Make sure the battery is removed prior
to changing accessories or making
any adjustments to the tool.

Wear protective gloves

Li-Ion battery. This product has been
marked with a symbol relating to
‘separate collection’ for all battery
packs and battery pack. It will then

Li-I on

be recycled or dismantled in order to
reduce the impact on the environment.
Battery packs can be hazardous
for the environment and for human
health since they contain hazardous
substances.

Waste electrical products must not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your local authorities or
retailer for recycling advice.

2. COMPONENT LIST

1. WORKPIECE CONTACT

2. NO-MAR PAD

3. LED WORKLIGHTS

4. SPARE NO-MAR PAD

5. MAGAZINE RELEASE BUTTON

6. LOW NAIL INDICATOR WINDOW

7. SIDE-LOADING MAGAZINE

8. ON/OFF TRIGGER

9. MODE SELECTOR SWITCH

10. BATTERY PACK RELEASE BUTTON *

11. BATTERY PACK *

12. BELT HOOK

13. TOOL-FREE DEPTH OF DRIVE ADJUST­MENT

14. TOOL-FREE JAM RELEASE

* Not all the accessories illustrated or described are
included in standard delivery.

Do not burn

Batteries may enter water cycle if
disposed improperly, which can be
hazardous for ecosystem. Do not dis­pose of waste batteries as unsorted
municipal waste.

3. TECHNICAL DATA

Type WX842 WX842.X (842 - designation of
machinery, representative of brad nailer)

Voltage

Magazine capacity 100 nails

Nailer speed 80 nails/min

20V Cordless 18 Gauge Brad Nailer

WX842 WX842.X **

20 V Max. ***

EN

Nail type 18 gauge

Nail length (brad nails) 15 mm - 50 mm

Machine weight(bare
tool)

** X=1-999, A-Z, M1-M9 there are only used for
different customers, there are no safe relevant
changes between these models.
***Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal
voltage is 18 volts.

2.8 kg

SUGGESTED BATTERIES
AND CHARGERS

Category

20V Battery WA3639 2.0 Ah

20V Charger

We recommend that you purchase your accessories
from the same store that sold you the tool. Refer to
the accessory packaging for further details. Store
personnel can assist you and offer advice.

Type Capacity

WA3880 2.0 A

is used dependant on the following examples and other
variations on how the tool is used:
How the tool is used and the materials being cut or
drilled.
The tool being in good condition and well maintained
The use the correct accessory for the tool and ensuring
it is sharp and in good condition.
The tightness of the grip on the handles and if any anti
vibration accessories are used.
And the tool is being used as intended by its design
and these instructions.

This tool may cause hand-arm vibration syndrome if
its use is not adequately managed.

WARNING: To be accurate, an estimation of
exposure level in the actual conditions of use

should also take account of all parts of the operating
cycle such as the times when the tool is switched off
and when it is running idle but not actually doing the

job. This may signicantly reduce the exposure level

over the total working period.
Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades
Maintain this tool in accordance with these instructions
and keep well lubricated (where appropriate)
If the tool is to be used regularly then invest in anti
vibration accessories.
Plan your work schedule to spread any high vibration
tool use across a number of days.

11

NOISE INFORMATION

A weighted sound pressure LpA= 79.8 dB(A)

A weighted sound power L

K

pA&KwA

Wear ear protection.

= 90.8 dB(A)

wA

3 dB(A)

VIBRATION INFORMATION

Vibration total values (triax vector sum) determined
according to EN 60745:

a

= 3.802 m/s

Vibration
emission value:

The declared vibration total value may be used for
comparing one tool with another, and may also be used
in a preliminary assessment of exposure.

WARNING: The vibration emission value during
actual use of the power tool can differ from the

declared value depending on the ways in which the tool

h

Uncertainty K = 1.5 m/s²

2

4. INTENDED USE

This tool is intended for nishing and trimming (interior

and exterior), such as door & window casing, door
jambs, baseboard, crown molding, cabinetry, cap and
shoe molding, molding, staircases, door & window

trimming, chair rail, brickmolding, hardwood ooring,

paneling, furniture, etc..

5. OPERATING
INSTRUCTIONS

NOTE: Before using the tool, read the

instruction book carefully.

WARNING: Keep the tool pointed away from
yourself and others when loading nails. Always

remove the nails and battery pack when tool is not in
use. Failure to do so could result in possible serious

personal injury

20V Cordless 18 Gauge Brad Nailer

EN

ASSEMBLY AND OPERATION

ACTION FIGURE

BEFORE OPERATION

Installing/removing the battery

pack

Charging the battery pack See Fig. A3

ASSEMBLY

Installing the belt hook
NOTE: The belt hook can be
installed on the left or right side
of the nail gun.

Loading the tool with brad nails

1. Remove the battery pack if
installed.

2. Squeeze the magazine release
button located on the rear of
the magazine and slide the
magazine cover open

3. Place brad nails in the upper
left corner of channel

4. Push the magazine cover
closed until it securely snaps
into place, you may now reinstall
battery pack

12

WARNING: Use safety

gloves. Keep the tool
pointed away from yourself and
others when loading nails.
Failure to do so could result in
possible serious personal injury.

OPERATION

Selecting the nailing mode

Single sequential actuation
mode: Provides accurate nail
placement
Contact actuation mode: Allows
for fast repetitive nail placement

if the selector is not securely
seated in either position. Always
assure the selector is seated
properly to avoid an unexpected
nail discharge and possible
serious personal injury.

WARNING: The nail gun

will not function properly

See Fig. A1, A2

See Fig. B

See Fig. C1, C2

See Fig. D

Using the on/off trigger in two
different modes
Single sequential actuation
mode:

-Push the workpiece contact

against the work surface rst
and then squeeze the on/off

trigger

-Relase the on/off trigger and

the workpiece contact.

Contact actuation mode:

-Squeeze and hold the trigger.
Push the tool against the
work surface to depress the
workpiece contact and drive a
nail.

-Release the workpiece contact
once after each nailing action.

-Move the tool and then push the
workpiece contact again.
NOTE: The nail gun will operate

only when squeezing the on/

off trigger and pushing the work
piece contact against the work
surface simultaneoulsly
NOTE: If there is no nailing
action within 5 seconds after

pressing the on/off trigger or

pushing the workpiece contact,

release the on/off trigger or the

workpiece contact once and
then operate again.

WARNING: Never wedge or
hold back the workpiece contact
mechanism during operation of
the tool. Doing so could result in
possible serious injury.

Depth of drive adjustment
Turn the depth of drive
adjustment knob up or down to
change the driving depth.
NOTE: Drive a test nail after
each adjustment until the
desired depth is set.

LED worklight
NOTE: The LED worklights will
be activated when pressing the

on/off trigger or pushing the

workpiece contact.
NOTE: The LED Worklights
provide feedback to indicate
whether the tool is functioning
properly.(See troubleshooting)

See Fig. E1, E2

See Fig. F

See Fig. G

20V Cordless 18 Gauge Brad Nailer

EN

Removing a jammed nail
Try to operate the tool for two

more times to conrm the nail is

jammed.
NOTE: Before removing
a jammed nail, open the

magazine(see g. C1) and

remove all the nails.

WARNING: Always
remove the battery pack

rst and wear safety gloves.

• Keep the magazine open.

• Pull up on the tool free jam

release and unhook the latch

• Make sure the tip of the driving
mechanism is in the initial

position, if not, insert a at head

screwdriver into the tip of the
driving mechanism and push
back.

• Remove any bent nails

• Close the jam release and latch

• Reinstall brad nails and

reactivate the tool

See Fig. H1,
H2, H3

6. MAINTENANCE

Remove the battery pack from the tool before
carrying out any adjustment, servicing or
maintenance.

There are no user serviceable parts in your power
tool. Never use water or chemical cleaners to clean
your power tool. Wipe clean with a dry cloth. Always
store your power tool in a dry place. Keep the motor
ventilation slots clean. Keep all working controls free
of dust. Occasionally you may see sparks through the
ventilation slots. This is normal and will not damage
your power tool.

13

7. ENVIRONMENTAL
PROTECTION

Waste electrical products must not be
disposed of with household waste. Please
recycle where facilities exist. Check with your

local authorities or retailer for recycling advice.

20V Cordless 18 Gauge Brad Nailer

EN

8. TROUBLESHOOTING

Symptom Possible Causes Possible Solution

Tool does not operate properly:

LED light ashing 5 times No nails Replenish nails

LED light ashing 2 times Battery is low Charge the battery pack

LED light ashing 3 times Tool is hot Wait until the tool cools down

Tool operates properly, but
fasteners do not drive fully

Tool operates properly, but
fasteners are driven too deep

Frequent empty nailing

Tool jams frequently Incorrect nails

14

9. DECLARATION OF
CONFORMITY

We,
Positec Germany GmbH
Postfach 32 02 16, 50796 Cologne, Germany

Declare that the product
Description WorxNITRO Cordless Brad Nailer
Type WX842 WX842.X (842 - designation of

machinery, representative of brad nailer)

Function Fastening various materials

Complies with the following Directives:

2006/42/EC
2014/30/EU
2011/65/EU&(EU)2015/863

Depth of drive isn’t deep enough
Nail is too long for wood
hardness

Depth of drive is too deep Adjust depth of drive

Jammed nails or damaged
nails

Damaged nails
Dirty magazine

2023/02/07

Allen Ding

Deputy Chief Engineer, Testing & Certication

Positec Technology (China) Co., Ltd
18, Dongwang Road, Suzhou Industrial
Park, Jiangsu 215123, P. R. China

Adjust depth of drive
Use nail length that is appropriate for
wood

Pull up on the tool free jam release
and unhook the latch. Check whether
there are jammed nails or damaged
nails inside. If so, remove the jammed
nails or damaged nails in time.

Verify that nails are the correct size
Replace nails
Clean magazine

Standards conform to

EN 60745-1, EN 60745-2-16, EN IEC 55014-1, EN
IEC 55014-2, EN IEC 63000

The person authorized to compile the technical le,

Name Marcel Filz
Address Positec Germany GmbH
Postfach 32 02 16, 50796 Cologne, Germany

20V Cordless 18 Gauge Brad Nailer

EN

www.worx.com

Copyr ight © 2023, Positec. All Rig hts Reserve d.
AR01698400
