P06
P12
P19
WG255 WG255.5
HELPLINE NUMBER
1-866-354-WORX (9679)
HELPLINE NUMBER
Cordless Li-ion hedge trimmer EN
Taille-haie Li-ion sans fil F
Cortasetos inalámbrico con batería de iones de litio ES
9
8
4
3
2
1
5
7
6
F
B
E
A
D
C
10
F
G
B
E
H
A
D
C
I
J
K
L
M
Cordless Li-ion hedge trimmer EN
76
1. BATTERY PACK
2. REAR HANDLE
3. FRONT HANDLE
4. SAFETY GUARD
5. FRONT SWITCH LEVER (ALL AROUND SWITCH FUNCTION)
6. REAR SWITCH LEVER
7. BATTERY PACK RELEASE BUTTON
8. BLADE
9. BLADE SHEATH
10. WALL MOUNT BRACKET (See Fig. L)
TECHNICAL DATA
ACCESSORIES
Only use the appropriate accessories intended for this tool. Accessory information can be found
on the product packaging, at a WORX dealer or on our website at www.worxtools.com.
Model No. WG255 WG255.5
Voltage 20V Max* 20V Max*
No load speed 2200/min 2200/min
Cutting length 20” 20”
Cutting diameter 9/16” 9/16”
Charging time 3hr 45minutes
Machine weight 5.1 lbs 5.1 lbs
*Voltage measured without workload. Initial battery voltage reaches maximum of 20 volts.
Nominal voltage is 18 volts.
Model No. WG255 WG255.5
Blade sheath 1 1
Safety guard 1 1
Charger 1(WA3732) 1(WA3847)
Battery pack 1(WA3520) 1(WA3520)
Wall mount bracket 1 1
76
76
Cordless Li-ion hedge trimmer EN
SAFETY INSTRUCTIONS
WARNING: Some dust created by
power sanding, sawing, grinding,
drilling and other construction activities
contains chemicals known to the state of
California to cause cancer, birth defects or
other reproductive harm. Some examples of
these chemicals are:
● Lead from lead-based paints;
● Crystalline silica from bricks and cement
and other masonry products and
● Arsenic and chromium from chemically-
treated lumber.
Your risk from these exposures varies,
depending on how often you do this type
of work. To reduce your exposure to these
chemical:
• Work in a well ventilated area,
• Work with approved safety equipment,
such as those dust masks that are specially
designed to filter out microscopic particles.
READ ALL INSTRUCTIONS
WARNING! When using cordless
hedge trimmers, basic safety
precautions should always be followed to
reduce the risk of fire, electric shock, and
personal injury, including the following:
Important safety instructions
1. FOR ALL HEDGE TRIMMERS
1) Avoid dangerous environment – don’t use
hedge trimmers in damp or wet location.
2) Don’t use in rain.
3) Keep children away – all visitors should be
kept at a distance from work area.
4) Dress properly – do not wear loose clothing
or jewelry. They can be caught in moving
parts. Use of rubber gloves and substantial
footwear is recommended when working
outdoors. Wear protective hair covering to
contain long hair.
5) Use safety glasses – always use face or
dust mask if operation is dusty.
6) Ground fault circuit interrupter (gfci)
protection should be provided on the
circuit(s) or outlet(s) to be used for the
hedge trimmer. Receptacles are available
having built-in gfci protection and may be
used for this measure of safety.
7) Use right appliance – do not use appliance
for any job except that for which it is
intended.
8) Avoid unintentional starting – don’t carry
plugged-in hedge trimmer with finger on
switch. Be sure switch is off when plugging
in.
9) Danger – risk of cut – keep hands away
from blades – keep both hands on handles
when power is on.
Exception: This statement is not required
for a shrub clipper.
Do not attempt to remove cut material
nor hold material to be cut when blades
are moving. Make sure trimmer switch is
off when clearing jammed material from
blades. Do not grasp the exposed cutting
blades or cutting edges when picking up
or holding the hedge trimmer. Caution –
blades coast after turn off.
10) Don’t force hedge trimmer – it will do the
job better and with less likelihood of a
risk of injury at the rate for which it was
designed.
11) Don’t overreach – keep proper footing and
balance at all times.
12) Stay alert – watch what you are doing. Use
common sense. Do not operate hedge
trimmer when you are tired.
13) Remove the battery pack when not in
use, before servicing, when changing
accessories such as blades, and the like.
14) Store idle hedge trimmer indoors – when
not in use, hedge trimmer should be stored
indoors in dry, and high or locked-up place
– out of reach of children.
15) Maintain hedge trimmer with care – keep
cutting edge sharp and clean for best
performance and to reduce the risk of
injury. Follow instructions for lubricating
and changing accessories. Inspect hedge
trimmer cord periodically, and if damaged,
have it repaired by an authorized service
facility. Inspect extension cords periodically
and replace if damaged. Keep handles dry,
clean, and free from oil and grease.
16) Check damaged parts – before further use
of the hedge trimmer, a guard or other
part that is damaged should be carefully
checked to determine that it will operate
Cordless Li-ion hedge trimmer EN
98
properly and perform its intended function.
Check for alignment of moving parts,
binding of moving parts, breakage of parts,
mounting, and any other condition that
may affect its operation. A guard or other
part that is damaged should be properly
repaired or replaced by an authorized
service center unless indicated elsewhere
in this manual.
ASSEMBLY INSTRUCTIONS
WARNING – If the hedge trimmer is shipped
without handle or guard in place, DO NOT
USE WITHOUT HANDLE AND GUARD.
1) Refers the operator to the Important Safety
Instructions.
2) The trimmer shall not be used to cut stems
greater than 9/16” inch thick.
Warning tag
WARNING – TO guard against injury, observe
the following:
Read operator’s manual before using
Keep hanks away from blades
Don’t overreach
Do not leave switch locked on (where
applicable)
CAUTION – Blades coast after turn off
save operator’s manual
BATTERY-OPERATED HEDGE TRIMMERS
For all battery-operated hedge trimmers:
1) Do not charge hedge trimmer in rain, or in
wet location.
2) Do not use battery-operated hedge trimmer
in rain.
3) When replacing batteries, all batteries
should be replaced at the same time.
Mixing fresh and discharged batteries
could increase internal cell pressure and
rupture the discharge battery(ies). (Applies
to products employing more than one
separately replaceable primary battery.)
4) When inserting batteries into this product,
the proper polarity or direction must be
observed. Reverse insertion of batteries
can result in leakage or explosion. (Applies
to product employing more than one
separately replaceable primary battery.)
5) Remove or disconnect battery before
servicing, cleaning, or removing material
from the hedge trimmer.
For all battery-operated products employing a
detachable or separable battery:
1) Use only the following type and size
battery(ies): WA3520.
2) Do not dispose of the battery (ies) in a
fire. The cell may explode. Check with
local codes for possible special disposal
instructions.
3) Do not open or mutilate the battery (ies).
Released electrolyte is corrosive and may
cause damage to the eyes or skin. It may
be toxic if swallowed.
4) Exercise care in handling batteries in order
not to short the battery with conducting
materials such as rings, bracelets, and
keys. The battery or conductor may
overheat and cause burns.
For a battery-operated hedge trimmer
employing a vented wet cell battery supply
intended to be initially or periodically filled by
the user :
CAUTION: The electrolyte is a dilute sulfuric
acid that is harmful to the skin and eyes. It
is electrically conductive and corrosive. The
following procedures should be observed:
1) Wear full eye protection and protective
clothing.
2) If electrolyte contacts the skin, wash it off
immediately with water.
3) If electrolyte contacts the eyes. Flush
thoroughly and immediately with water.
Seek medical attention.
SAFE OPERATION PRACTICES FOR
HEDGE TRIMMER
1. Safety Instructions
1.1 Training
1) Read the operating and service instruction
manual carefully. Be thoroughly familiar
with the controls and the proper use of the
equipment.
2) Never allow children to operate the hedger
trimmer.
3) Keep the area of operation clear of all
persons, particularly small children, and
pets.
98
98
Cordless Li-ion hedge trimmer EN
4) Do not use the hedger trimmer for any job
except that for which it is intended.
1.2 Preparation
1) Trimming only in daylight or in good
artificial light.
2) Never operate the equipment on wet
brush. Always be sure of your footing.
Keep a firm hold on the handle and walk,
never run.
1.3 Operation
1) Do not put hands or feet near or under
moving parts.
2) If the equipment should start to vibrate
abnormally, stop the motor and check
immediately for the cause. Vibration is
generally a warning of trouble.
3) Stop the motor and unplug whenever you
leave the equipment, and before making
any repairs or inspections.
4) Never operate the hedger trimmer without
proper guards, plates, or other safety
protective devices in place.
5) Do not wash with a hose, avoid getting
water in motor and electrical connections.
1.4 Maintenance
1) Check the blade at frequent intervals for
proper tightness.
2) Keep al nuts, bolts, and screws tight to
be sure the equipment is in safe working
condition.
3) Replace the blade if it is bent or cracked.
An unbalanced blade causes vibration
that could damage the motor drive unit or
cause personal injury.
4) Sharpen a dull blade equally at each end to
maintain the balance.
5) Clear the blade thoroughly.
SYMBOLS
Warning
Read the manual
Do not expose to rain or water
Do not burn
Always charge the battery pack
between temperatures 40°F
(4.5°C)-105°F (40.5°C).
Do not dispose of batteries.
Return exhausted batteries to
your local collection or recycling
point.
Battery pack removal and
preparation for recycling.
To preserve natural resources,
please recycle or dispose of
batteries properly. This product
contains lithium-ion batteries.
Local, state or federal laws may
prohibit disposal of lithiumion batteries in ordinary trash.
Consult your local waste authority
for information regarding
available recycling and/or
disposal options.
To avoid possibility of electric
shock, do not use in damp or wet
conditions
Keep hands away from blades
40-105°F
