PRODUCT SAFETY
WARNING: Some dust created by
power sanding, sawing, grinding,
drilling and other construction activities
contains chemicals known to the state of
California to cause cancer, birth defects or
other reproductive harm. Some examples of
these chemicals are:
• Lead from lead-based paints;
• Crystalline silica from bricks and cement
and other masonry products;
• Arsenic and chromium from chemically-
treated lumber.
Your risk from these exposures varies,
depending on how often you do this type
of work. To reduce your exposure to these
chemical: work in a well ventilated area,
and work with approved safety equipment,
such as those dust masks that are specially
designed to filter out microscopic particles.
WARNING: This product can expose
you to chemicals including lead and Di
(2-ethylhexyl) phthalate (DEHP) which
are known to the State of California to cause
cancer and birth defects or other reproductive
harm. For more information go to www.
P65Warnings.ca.gov.
2
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING: Read all safety warnings and
instructions.
and instructions may result in electric shock,
fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to your
mains-operated (corded) power tool or batteryoperated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.
or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
tools create sparks which may ignite the dust or
fumes.
c) Keep children and bystanders away while
operating a power tool.
cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
Failure to follow the warnings
Distractions can
Cluttered
Power
(grounded) power tools.
Unmodified plugs
and matching outlets will reduce risk of electric
shock.
b) Avoid body contact with earthed or
grounded surfaces such as pipes,
radiators, ranges and refrigerators.
an increased risk of electric shock if your body is
earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the
power tool. Keep cord away from heat,
oil, sharp edges or moving parts.
or entangled cords increase the risk of electric
shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply.
of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication.
inattention while operating power tools may
result in serious personal injury.
b) Use personal protective equipment.
Always wear eye protection.
Water entering a power tool will
There is
Damaged
Use
A moment of
Protective
equipment such as dust mask, non-skid safety
shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal
injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or battery
pack, picking up or carrying the tool.
Carrying power tools with your finger on the
switch or energising power tools that have the
switch on invites accidents.
d) Remove any adjusting key or wrench
before turning the power tool on.
A wrench
or a key left attached to a rotating part of the
power tool may result in personal injury.
e) Do not overreach. Keep proper footing
and balance at all times.
This enables
better control of the power tool in unexpected
situations.
f) Dress properly. Do not wear loose clothing
or jewellery. Keep your hair, clothing and
gloves away from moving parts.
clothes, jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
Loose
Cordless Pole Hedge Trimmer EN
Page 3
used.
Use of dust collection can reduce dust-
related hazards.
4) Power tool use and care
a) Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job better and
safer at the rate for which it was designed.
b) Do not use the power tool if the switch
does not turn it on and off.
Any power tool
that cannot be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the power
source and/or the battery pack from the
power tool before making any adjustments,
changing accessories, or storing power
Such preventive safety measures reduce
tools.
the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tools operation.
If damaged, have the power tool repaired before
use. Many accidents are caused by poorly
maintained power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.
g) Use the power tool, accessories and
tool bits etc., in accordance with these
instructions and in the manner intended for
the particular type of power tool, taking
into account the working conditions and
the work to be performed.
tool for operations different from those intended
Use of the power
could result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified
by the manufacturer.
for one type of battery pack may create a risk of
fire when used with another battery pack.
b) Use power tools only with specifically
designated battery packs.
battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it
away from other metal objects, like paper
clips, coins, keys, nails, screws or other
small metal objects, that can make a
connection from one terminal to another.
Shorting the battery terminals together may
cause burns or a fire.
d) Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
A charger that is suitable
Use of any other
seek medical help.
battery may cause irritation or burns.
6) Service
a) Have your power tool serviced by a
qualified repair person using only identical
replacement parts.
Liquid ejected from the
This will ensure that the
safety of the power tool is maintained.
HEDGE TRIMMER SAFETY
WARNINGS
1. Keep all parts of the body away from the
cutter blade. Do not remove cut material
or hold material to be cut when blades
are moving. Make sure the switch is off
when clearing jammed material. Blades
coast after turn off. A moment of inattention
while operating the hedge trimmer may result in
serious personal injury.
2. Carry the hedge trimmer by the handle
with the cutter blade stopped. When
transporting or storing the hedge trimmer
always fit the cutting device cover. Proper
handling of the hedge trimmer will reduce
possible personal injury from the cutter blades.
3. Hold the power tool by insulated gripping
surfaces only, because the cutter blade
may contact hidden wiring or its own cord.
Cutter blades contacting a”live”wire may make
exposed metal parts of the power tool ”live”and
could give the operator an electric shock.
4. Keep hands away from blade. Contact with
blade will result in serious personal injury.
5. Use both hands when operating the hedge
trimmer. Using one hand could cause loss
of control and result in serious personal
injury.
6. Only use with handle and guard properly
assembled to hedge trimmer. The use of
the hedge trimmer without the proper
guard or handle provided may result in
serious personal injury
7. Check the hedge for foreign objects, e.g.
wire fences.
EXTENDED-REACH HEDGE
TRIMMER SAFETY WARNINGS
1. Do not use the extended-reach hedge
trimmer in bad weather conditions,
especially when there is a risk of lightning.
This decreases the risk of being struck by
lightning.
2. To reduce the risk of electrocution, never
use near any electrical power lines. Contact
with or use near power lines may cause serious
injury or electric shock resulting in death.
3. Always use two hands when operating the
3
Cordless Pole Hedge Trimmer EN
Page 4
extended-reach hedge trimmer. Hold the
extended-reach hedge trimmer with both hands
to avoid loss of control.
4. Always use head protection when
operating the extended-reach hedge
trimmer overhead. Falling debris can result in
serious personal injury.
5. Keep bystanders, especially children at a
safe distance during the operation of the
extended reach hedge trimmer.
6. Keep a firm footing and balance during
operating.
SAFETY WARNINGS FOR
BATTERY PACK
a) Do not dismantle, open or shred battery
pack.
b) Do not expose battery pack to heat or fire.
Avoid storage in direct sunlight.
c) Do not short-circuit a battery pack. Do not
store battery packs haphazardly in a box
or drawer where they may short-circuit
each other or be short-circuited by other
metal objects. When battery pack is not in use,
keep it away from other metal objects, like paper
clips, coins, keys, nails, screws or other small
metal objects, that can make a connection from
one terminal to another. Shorting the battery
4
terminals together may cause burns or fire.
d) Do not remove battery pack from its
original packaging until required for use.
e) Do not subject battery pack to mechanical
shock.
f) In the event of battery leaking, do not
allow the liquid to come in contact with
the skin or eyes. If contact has been
made, wash the affected area with copious
amounts of water and seek medical advice.
g) Observe the plus (+) and minus (–) marks
on the battery back and equipment and
ensure correct use.
h) Do not use any battery pack which is not
designed for use with the equipment.
i) Keep battery pack out of the reach of
children.
j) Seek medical advice immediately if a cell
or battery has been swallowed.
k) Always purchase the battery pack
recommended by the device manufacturer
for the equipment.
l) Keep battery pack clean and dry.
m) Wipe the battery pack terminals with a
clean dry cloth if they become dirty.
n) Battery pack needs to be charged before
use. Always use the correct charger and
refer to the manufacturer’s instructions
or equipment manual for proper charging
instructions.
o) Do not leave battery pack on prolonged
charge when not in use.
p) After extended periods of storage, it may
be necessary to charge and discharge
the battery pack several times to obtain
maximum performance.
q) Battery pack gives its best performance
when it is operated at normal room
temperature (20 °C ± 5 °C)/ (68 °F ± 9 °F).
r) When disposing of battery packs, keep
battery packs of different electrochemical
systems separate from each other.
s) Recharge only with the charger specified
by WORX. Do not use any charger other
than that specifically provided for use with
the equipment. A charger that is suitable for
one type of battery pack may create a risk of fire
when used with another battery pack.
t) Retain the original product literature for
future reference.
u) Use only the battery pack in the
application for which it was intended.
v) Remove the battery pack from the
equipment when not in use.
w) Dispose of properly.
SYMBOLS
To reduce the risk of injury, user must
read instruction manual
Warning
Wear ear protection
Wear eye protection
Wear dust mask
Do not expose to rain
DANGER – Keep hands away from blade
Wear head protection
Cordless Pole Hedge Trimmer EN
Page 5
DANGER – Keep sufficient distance
away from electrical power lines
Li-Ion battery, battery must be recycled
Do not burn.
Do not expose to rain or water
POSITEC Inc. has established a
partnership with the RBRC Corporation
to recycle any Positec batteries with
the RBRC-call2recycle seal. For
environmental protection, please do not
discard batteries in the trash. After the
batteries’ life cycle is ended, then please
call 1-800-822-8837 for a free service that
will properly dispose of the battery.
Remove battery from the socket before
carrying out any adjustment, servicing
or maintenance.
5
Wear protective gloves
Lock
Unlock
Cordless Pole Hedge Trimmer EN
Page 6
6
5
4
3
6
12
2
9
1
10
11
7
8
13
Cordless Pole Hedge Trimmer EN
Page 7
COMPONENT LIST
1. Extension pole handle
2. Lock-off button
Rotating lock button for extension pole
3.
4. Locking projections
5. Rotational button
6. Blade
Trimmer head release lever
7.
8. Inner pole
9. Inner pole release lever
10. On/Off switch
11. Battery pack *
12. Battery pack release button *
13. Blade sheath
*Not all the accessories illustrated or
described are included in standard delivery.
TECHNICAL DATA
Type WG252 WG252.9 (250-299- designation
of machinery, representative of cordless hedge
trimmer)
WG252 WG252.9
Voltage
No-load speed 1340/min
Blade length
Blade gap 5/8" (16mm)
Machine length
Trimmer head
rotation angle
Handle rotation
angle
Total reach 12’ (3.6m)
Battery capacity 2.0Ah (WA3575) /
Battery type Lithium-Ion /
Charger model WA3881 /
Charger rating
Charging time
(approx.)
Machine Weight 7.6 lbs (3.44kg) 6.8 lbs (3.1kg)
20V Max**
20” (51cm)
From 51 inch (130cm) to 79 inch
(200cm) (fully extended)
-45 to 90 degrees (10 positions)
180 degrees total
Input: 120V~60Hz
Output: 20V
,
2.0A
1 hr /
/
7
**Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal
voltage is 18 volts.
ACCESSORIES
WG252 WG252.9
Battery pack (WA3575) 1 /
Charger (WA3881) 1 /
Blade sheath 1
Only use the appropriate accessories intended for
this tool. Accessory information can be found on
the product packaging, at a WORX dealer or on our
website at www.worx.com
Cordless Pole Hedge Trimmer EN
Page 8
A1
CLICK
1
1
2
1
3
2
2
3
1
1
2
2
2
2
C
D
E
F
G
H1
A2
2
1
A4A3
0%
B2
100 %
8
B1
CLICK
3
2
1
3
2
2
1
Page 9
CLICK
1
1
2
2
3
2
C
2
D
1
1
3
2
2
E
G
F
9
H1
1
2
Page 10
2
1
3
1
1
2
2
2
E
F
G
H1
H2
I
10
Page 11
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the instruction
book carefully.
Intended Use
The machine is intended for cutting and trimming
hedges and bushes in domestic use.
ASSEMBLY & OPERATION
ACTION FIGURE
BEFORE OPERATION
Installing the battery pack See Fig. A1
Removing the battery pack
Checking the battery condition
NOTE: Fig. A3 only applies for the
battery pack with the battery indicator
light.
Charging the battery pack
More details can be found in charger’s
manual
ASSEMBLY
Attaching and releasing the extension
pole
Extending the inner pole
Adjusting the cutting angle
NOTE: The cutting angle can be
adjusted between 0
WARNING: Always make sure
that the handle is locked in the
desired position before
operation. Do not rotate the handle
when the trimmer is being operated.
Adjusting the head angle
WARNING: Failure to properly
secure the trimmer head may
result in personal injury and/or
property damage.
OPERATION
0
-900 left or right.
See Fig. A2
See Fig. A3
See Fig. A4
See Fig. B1,
B2
See Fig. C
See Fig. D
See Fig. E
Top cutting
WARNING: If any parts are
missing, damaged or broken, do
not operate your hedge trimmer
until all damaged parts have been
replaced or repaired. Failure to do so
could result in serious personal injury.
Side cutting
WARNING: Stop operating the
trimmer before rotating the
handle.
Lubricating the cutting blade
NOTE: It is important to use only the
recommended standard lubricating oil
(WD-40) to avoid damage to the blade.
See Fig. H1
See Fig. H2
See Fig. I
HOW TO USE YOUR HEDGE
TRIMMER
Before cutting an area, inspect it first and remove
any foreign objects that could become thrown or
entangled in the blades.
Always hold the trimmer with both hands and with
the blade away from you before turning it on.
When trimming new growth, use a wide sweeping
action so that the stems are fed directly into the
blade.
Allow the cutting blades to reach full speed before
cutting. When operating, keep the cutting blades
away from people and objects such as walls, large
stones, trees, vehicles, etc.
If the blade stalls, immediately stop the trimmer.
Release the two Switch Levers before attempting to
clear jammed debris from the cutting blades.
Wear gloves when trimming thorny or prickly
growth.
Do not attempt to cut stems that are too thick for the
cutting blade.
Top cutting
Use a wide sweeping motion. A slight downward tilt
of the cutting blades in the direction of motion gives
the best cutting results.
Side cutting
When trimming the sides of the hedge, begin at the
bottom and cut upwards, tapering the hedge inward
at the top. This shape will expose more of the hedge,
resulting in a more uniformed growth.
11
Removing the blade sheath See Fig. F
Starting and Stopping See Fig. G
MAINTENANCE
Remove the battery from Hedge trimmer
before carrying out any adjustment, servicing
or maintenance.
There are no user serviceable parts in your power
tool. Never use water or chemical cleaners to clean
your power tool. Wipe clean with a dry cloth. Always
Cordless Pole Hedge Trimmer EN
Page 12
store your power tool in a dry place. Keep the motor ventilation slots clean. Keep all working controls free of
dust.
12
Positec USA, Inc. Charlotte, NC 28216 USA
Cordless Pole Hedge Trimmer EN
Loading...
