SAFETY AND OPERATING MANUAL
Hedge Trimmer WG212E
GENERAL POWER TOOL
SAFETY WARNINGS
WARNING: Read all safety warnings
and all instructions. Failure to follow
the warnings and instructions may result in
electric shock, fire and/or serious injury.
suitable for outdoor use reduces the risk of
electric shock.
f) If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected
supply. Use of an RCD reduces the risk of
electric shock.
Save all warnings and instructions for
future reference.
The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in
explosive atmospheres, such as in the
presence of flammable liquids, gases
or dust. Power tools create sparks which
may ignite the dust or fumes.
c) Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the
outlet. Never modify the plug in any
way. Do not use any adapter plugs
with earthed (grounded) power tools.
Unmodified plugs and matching outlets
will reduce risk of electric shock.
b) Avoid body contact with earthed or
grounded surfaces, such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric shock
if your body is earthed or grounded.
c) Do not expose power tools to rain or
wet conditions. Water entering a power
tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use
the cord for carrying, pulling or
unplugging the power tool. Keep
cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool
outdoors, use an extension cord
suitable for outdoor use. Use of a cord
3) PERSONAL SAFETY
a) Stay alert, watch what you are
doing and use common sense when
operating a power tool. Do not use
a power tool while you are tired or
under the influence of drugs, alcohol
or medication. A moment of inattention
while operating power tools may result in
serious personal injury.
b) Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, nonskid safety shoes, hard hat, or hearing
protection used for appropriate conditions
will reduce personal injuries.
c) Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your finger
on the switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotating
part of the power tool may result in
personal injury.
e) Do not overreach. Keep proper
footing and balance at all times. This
enables better control of the power tool in
unexpected situations.
f) Dress properly. Do not wear loose
clothing or jewellery. Keep your
hair, clothing and gloves away from
moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use
of these devices can reduce dust-related
hazards.
Hedge Trimmer WG212E
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use
the correct power tool for your
application. The correct power tool will
do the job better and safer at the rate for
which it was designed.
b) Do not use the power tool if the
switch does not turn it on and off.
Any power tool that cannot be controlled
with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power
source and/or the battery pack from
the power tool before making any
adjustments, changing accessories,
or storing power tools. Such preventive
safety measures reduce the risk of starting
the power tool accidentally.
d) Store idle power tools out of the
reach of children and do not allow
persons unfamiliar with the power
tool or these instructions to operate
the power tool. Power tools are
dangerous in the hands of untrained users.
e) Maintain power tools. Check for
misalignment or binding of moving
parts, breakage of parts and any other
condition that may affect the power
tool’s operation. If damaged, have the
power tool repaired before use. Many
accidents are caused by poorly maintained
power tools.
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to bind
and are easier to control.
g) Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
ADDITIONAL SAFETY
POINTS FOR YOUR HEDGE
TRIMMER
1. Keep all parts of the body away from
the cutter blade. Do not remove
cut material or hold material to
be cut when blades are moving.
Make sure the switch is off when
clearing jammed material. A moment
of inattention while operating the hedge
trimmer may result in serious personal
injury.
2. Carry the hedge trimmer by the
handle with the cutter blade stopped.
When transporting or storing the
hedge trimmer always fit the cutting
device cover. Proper handling of the
hedge trimmer will reduce possible
personal injury from the cutter blades.
3. Hold the power tool by insulated
gripping surfaces only, because the
cutter blade may contact hidden
wiring or its own cord. Cutter blades
contacting a “live” wire may make exposed
metal parts of the power tool “live” and
could give the operator an electric shock.
4. Keep cable away from cutting area.
During operation the cable may be hidden
in shrubs and can be accidentally cut by
the blade.
5. Check the hedge for foreign objects,
e.g. wire fences
6. Hold the hedge trimmer properly, e.g.
with both hands if two handles are
provided
32
5) SERVICE
a) Have your power tool serviced by
a qualified repair person using only
identical replacement parts. This will
ensure that the safety of the power tool is
maintained.
Hedge Trimmer WG212E
SYMBOLS
To reduce the risk of injury, user
must read instruction manual
Wear ear protection
Wear eye protection
Wear dust mask
Do not expose to moisture
Remove plug from the mains
immediately if the cable is
damaged or cut
Double insulation
Keep hands away
RCM marking
Hedge Trimmer WG212E
1
2
4
3
5
6
54
7
1. REAR HANDLE
2. REAR SWITCH LEVER
3. FRONT SWITCH LEVER
4. FRONT HANDLE
5. SAFETY GUARD
6. BLADE
7. BLADE SHEATH*
* Not all the accessories illustrated or described are included in standard delivery.
Hedge Trimmer WG212E
TECHNICAL DATA
Rated voltage 230-240V ~ 50Hz
Rated power 500W
Rated no load speed 2600/min
Blade length 51cm
Cutting diameter 17mm
Machine weight 2.4kg
Protection class
/ II
ACCESSORIES
Safety guard 1
Blade sheath 1
We recommend that you purchase your accessories from the same store that sold you the tool.
Use good quality accessories marked with a well-known brand name. Choose the type according
to the work you intend to undertake. Refer to the accessory packaging for further details. Store
personnel can assist you and offer advice.
Hedge Trimmer WG212E
OPERATING INSTRUCTIONS
E
F
G
H
I
WARNING! Do not use the product without
attaching the guard and front handle.
INTENDED USE
This machine is intended to be used domestically for
cutting and trimming hedges and bushes.
1. ASSEMBLY OF THE GUARD (See Fig. A)
Insert the Safety Guard (5) into the slot as illustrated in
Fig A;
Use two screws to fix the guard securely; making sure it
is securely attached.
2. FRONT HANDLE ASSEMBLY
The Front Handle (4) must be assembled before
use:
1) Attach the Front Handle to the housing. Push the
small button (a) inside first. Make sure the protruding
marks on the Front Handle fit perfectly into the
matching indentation on the housing. (See Fig. B & C)
2) Insert and tighten the 4 screws.
3) Check whether handle is firmly secured, if not
retighten the screws.
Make sure the handle is securely attached in
place.
3. MAINS SUPPLY CABLE STRAIN RELIEF
(See Fig .D)
An extension cord retainer is supplied to reduce strain
on the power cord. To use this feature, form a loop at the
end of the extension cable and bring this through the
opening at the bottom of the Extension Cord Retainer,
then wrap the end of the loop around the hook and pull
to tighten.
A
B
76
C
D
Hedge Trimmer WG212E
4. STARTING AND STOPPING (See fig E, F)
I
BEFORE STARTING YOUR HEDGE TRIMMER
Remove Blade Sheath (7).
TO START YOUR HEDGE TRIMMER
There are two switch levers fitted in your Hedge
trimmer (2&3).
Both switch levers need to be depressed for the product
to START. Depress and hold the Front Switch Lever (3)
and depress the Rear Switch Lever (2). (See Fig. E)
TO STOP YOUR HEDGE TRIMMER
E
F
G
H
Move Hedge trimmer away from cutting area before
stopping.
To STOP, release one of the switch levers. (See Fig. F)
WARNING: If any parts are missing, damaged or
broken, do not operate your Hedge trimmer until
all damaged parts have been replaced or repaired.
Failure to do so could result in serious personal injury.
DO NOT USE WITHOUT HANDLE AND GUARD
5. HOW TO USE YOUR HEDGE TRIMMER
Inspect the area to be cut before each use, remove
objects which can be thrown or become entangled in
the cutting blades.
Always hold the Hedge trimmer with both hands and
with the blade away from you before turning it on.
Always keep the power cord behind the Hedge
trimmer when in use. Do not place it over the
hedge that you are trimming where it may be cut
by the blade.
When trimming new growth, use a wide sweeping
action so that the stems are fed directly into the blade.
Allow the cutting blades to reach full speed before
entering the material to be cut.
Always work going away from people and solid objects
such as walls, large stones, trees, vehicles etc.
If the blade stalls, immediately stop the Hedge trimmer.
Disconnect the Hedge trimmer from the mains and clear
the jammed debris from the cutting blades.
Wear gloves when trimming thorny or prickly growth.
Move the Hedge trimmer to feed the branches directly
into the blade cutting edges.
Do not try to cut stems that are too large to feed into the
cutting blade.
TOP CUTTING (See G)
Use a wide sweeping motion. A slight downward tilt of
the cutting blades in the direction of motion gives the
best cutting results.
SIDE CUTTING (See H)
When trimming the sides of the hedge, begin at the
bottom and cut upwards, tapering the hedge inward
Hedge Trimmer WG212E
at the top. This shape will expose more of the hedge,
resulting in a more uniformed growth.
WARNING: Check extension cords before each
use. If damaged replace immediately. Never use
your tool with a damaged cord since touching the
damaged area could cause electrical shock resulting in
serious injury.
If the supply cord is damaged, it should be replaced by
a local approved Service Centre.
Take care not to expose this tool to rain.
MAINTENANCE
CLEANING
Disconnect from mains electrics supply. Using a soft
brush-remove debris from all air intakes and cutting
blade.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Wipe over surface of your Hedge trimmer with a dry
cloth.
WARNING! Never use water for cleaning your
Hedge trimmer. Do not clean with chemicals,
including petrol, or solvents as this can damage your
hedge trimmer.
LUBRICATING THE CUTTING BLADE
For easier operation and longer life, lubricate the cutting
blades before and after each use. Before lubricating,
make sure your Hedge trimmer is disconnected from
the mains electricity supply. Apply the oil so that it runs
between the two blades. (See Fig. I)
Your trimmer should be stopped, disconnected and
oiled occasionally during use.
I
98
AT THE END OF THE CUTTING SEASON
Clean your Hedge trimmer thoroughly.
Check that all nuts and bolts are secure.
Visually inspect the Hedge trimmer for any worn or
damaged parts.
TO STORE YOUR HEDGE TRIMMER
Store the hedge trimmer in a secure, dry place out of
the reach of children. Do not place other objects on top
of the machine.
Hedge Trimmer WG212E
Copyright © 2013, Positec. All Rights Reserved.
2GHT13EPK11001A0
Loading...
