Workrite PA4000 User Manual
Installation Instructions
Workrite Poise™ HD
PA3000 / PA4000
#1500157 - Rev. A
Workrite Poise™ HD
FLAT SCREEN MONITOR ARM
Contents
Important Safety Instructions ............................2
Components and Fasteners ................................3
Poise HD Assembly Instructions .......................... 4
LCD Monitor Attachment ....................................5
Cable Management ........................................... 6
Arm Adjustment ............................................... 7
Desk Base Template ..........................................8
Important Safety Instructions
Read and understand all these safety
instructions before using the product.
Do not mount the Desk Base or Wall Mounted Bracket
of the Arm on an unstable surface or any surface that
could not mount the Desk Base rmly.
For safety reasons, the internal gas-strut of the LCD
Arm product was pre-adjusted in the factory to the
lowest force to prevent the Arm body from being recoiled during installation.
During installation, beware of the recoil of the Arm
body when attaching or detaching the LCD monitor to
the Arm. To prevent damage or injury when changing
the LCD monitor, always readjust the gas-strut to the
lowest force level to control the recoil of the Arm body
when the LCD monitor is detached.
Do not attempt to disassemble, service or modify the
product by yourself.
Use only a slightly damp cloth to clean the Arm sur-
face. Never apply ammable solvents like alcohol,
benzene, thinner, etc. to the product.
Do not use or mount any unsuitable/oversized/nonstandard monitors on the product.
2 Workrite Ergonomics 800.959.9675 www.workriteergo.com
Fasteners
a
Plastic Spacer
x1
b
Round Head Cap Screw
x1
c
Washer
x2
d
Disc Spring Washer
x1
e
M5 Hex Wrench
x1
f
M8 Thread Rod
x1
g
Wing Nut
x1
i
M8 Flat Head Cap Screw
x1
h
M4 Hex Wrench
x2
x2
j
Round Head Cap Screw
x4
k
M4 6mm Screw
x4
l
M4 10mm Screw
q
M4 8mm Screw
r
M4 Washer
x1
Components
A
Desk Base with Clamp
x1
x1
B
Arm Assembly
C
Plastic Cap
D
Base Cushion
E
U Bracket
x1
x1
x1
x2
x2
m
Cable Clip
x1
x1
n
M5 10mm Set Screw
x2
o
M3 6mm Screw
x1
x1
x1
p
M2.5 Hex Wrench
x8
F
Holding Tab A
G
Holding Tab B
H
Hook and Loop Strips
J
PA TWIN-B
Workrite Poise™ Twin
Workrite Poise™ Twin
PA TWIN-B
(PA4000 units only)
Workrite Ergonomics 800.959.9675 www.workriteergo.com 3
