Ver. 16.02.01
User Manual/ Manual de uso
CPRO 4
CPRO 8
CPRO 8 SUB
CPRO 6
PURE PRO Series
EN
CPRO 4
CEILING SPEAKER
Dimensions
Output selector
- 1 -
User Manual / Manual de uso PURE PRO SERIES
Power Taps (70V)......................................
Power Taps (100V)....................................
Low Impedance position.......................... 8Ω(20W)
Sensitivity (1W/1m) .................................. 87 dB
Frequency Response .............................. 90Hz - 20kHz
Dimensions .............................................. Ø 204 x 137 mm
Mounting Hole .......................................... Ø 180 mm
Material (front baffle) ............................... ABS
Material (grille) ......................................... Iron
Weight ....................................................... 2,1 Kg
1,25W / 2,5W / 5W / 10W /20W
2.5W / 5W / 10W / 20W
Specifications are subject to change without notice
137
204
1.25W
2.5W
2.5W
5W
5W
10W
10W
20W
20W
PURE PRO Series
EN
Dimensions
Power Taps (70V)......................................
Power Taps (100V)....................................
Low Impedance position.......................... 8Ω (30W)
Sensitivity (1W/1m) .................................. 88 dB
Frequency Response .............................. 60Hz - 20kHz
Dimensions .............................................. Ø 267 x 162 mm
Mounting Hole .......................................... Ø 240 mm
Material (front baffle) ............................... ABS
Material (grille) ......................................... Iron
Weight ....................................................... 2,7 Kg
1,5W / 3,75W / 7,5W / 15W / 30W
3,75W / 7,5W / 15W / 30W
Specifications are subject to change without notice
┐╠Â╚
25.400
267
162
Output selector
1.5W
3.75W
3.75W
7.5W
7.5W
15W
15W
30W
30W
CPRO 6
CEILING SPEAKER
- 2 -
User Manual / Manual de uso PURE PRO SERIES
PURE PRO Series
EN
Dimensions
Power Taps (100V).................................... 10
Low Impedance position.......................... 8Ω (40W)
Sensitivity (1W/1m) .................................. 90 dB
Frequency Response .............................. 58Hz - 20kHz
Dimensions .............................................. Ø 281 x 110 mm
Mounting Hole .......................................... Ø 250 mm
Material (front baffle) ............................... ABS
Material (grille) ......................................... Iron
Weight ....................................................... 3,1 Kg
W / 20W / 40W
Specifications are subject to change without notice
110
281
281
CPRO 8
CEILING SPEAKER
- 3 -
User Manual / Manual de uso PURE PRO SERIES
PURE PRO Series
Dimensions
Power Taps (100V).................................... 10
Low Impedance position.......................... 8Ω (160W continuous)
Sensitivity (1W/1m) .................................. 90 dB
Frequency Response .............................. 78Hz - 250Hz (+/-3dB)
Dimensions .............................................. Ø 281 x 110 mm
Mounting Hole .......................................... Ø 250 mm
Material (front baffle) ............................... ABS
Material (grille) ......................................... Iron
Weight ....................................................... 3,1 Kg
W / 20W / 40W
Specifications are subject to change without notice
110
281
281
CPRO 8 SUB
CEILING SUBWOOFER
- 4 -
User Manual / Manual de uso PURE PRO SERIES
PURE PRO Series
ENEN
CPRO 4
ALTAVOZ DE TECHO
Dimensiones
Selector de salida
- 5 -
User Manual / Manual de uso PURE PRO SERIES
Posic. de potencia (70V)..........................
Posic. de potencia (100V)........................ POsición baja
impedancia................................................ 8Ω (20W)
Sensibilidad (1W/1m) .............................. 87 dB
Respuesta en Frecuencia ....................... 90Hz - 20kHz
Dimensiones ............................................ Ø 204 x 137 mm
Dimensiones de montaje ........................ Ø 180 mm
Material .................................................... ABS
Material (rejilla) ........................................ Hierro
Peso .......................................................... 2,1 Kg
1,25W / 2,5W / 5W / 10W /20W
2.5W / 5W / 10W / 20W
Especificaciones sujetas a cambio sin previo aviso
137
204
1.25W
2.5W
2.5W
5W
5W
10W
10W
20W
20W
PURE PRO Series
ES
Dimensiones
Posic. de potencia (70V)..........................
Posic. de potencia (100V)........................ 3,75W / 7,5W / 15W / 30W
Posición baja impedancia........................ 8Ω (40W)
Sensibilidad (1W/1m) .............................. 88 dB
Respuesta en frecuencia ........................ 60Hz - 20kHz
Dimensiones ............................................ Ø 267 x 162 mm
Dimensiones de montaje ........................ Ø 240 mm
Material ..................................................... ABS
Material (rejilla) ........................................ Hierro
Peso .......................................................... 2,7 Kg
1,5W / 3,75W / 7,5W / 15W / 30W
Especificaciones sujetas a cambio sin previo aviso
┐╠Â╚
25.400
267
162
Selector de salida
1.5W
3.75W
3.75W
7.5W
7.5W
15W
15W
30W
30W
CPRO 6
ALTAVOZ DE TECHO
- 6 -
User Manual / Manual de uso PURE PRO SERIES
PURE PRO Series
ES
Dimensiones
Posic. de potencia (100V)........................ 10
Posición baja impedancia........................ 8Ω (40W)
Sensibilidad(1W/1m) ............................... 90 dB
Respuesta en frecuencia ........................ 58Hz - 20kHz
Dimensiones ............................................ Ø 281 x 110 mm
Dimensiones de montaje ........................ Ø 250 mm
Material ..................................................... ABS
Material (rejilla) ........................................ Hierro
Peso .......................................................... 3,1 Kg
W / 20W / 40W
Especificaciones sujetas a cambio sin previo aviso
110
281
281
CPRO 8
ALTAVOCES DE TECHO
- 7 -
User Manual / Manual de uso PURE PRO SERIES
PURE PRO Series
ES
Dimensiones
Posic. de potencia (100V)........................ 10
Posición baja impedancia........................ 8Ω (160W continuos)
Sensibilidad(1W/1m) ............................... 90 dB
Respuesta en frecuencia ........................ 78Hz - 250Hz (+/- 3dB)
Dimensiones ............................................ Ø 281 x 110 mm
Dimensiones de montaje ........................ Ø 250 mm
Material ..................................................... ABS
Material (rejilla) ........................................ Hierro
Peso .......................................................... 3,1 Kg
W / 20W / 40W
Especificaciones sujetas a cambio sin previo aviso
110
281
281
CPRO 8 SUB
SUBWOOFER DE TECHO
- 8 -
User Manual / Manual de uso PURE PRO SERIES
PURE PRO Series
ES
EQUIPSON, S.A.
Avda. El Saler, 14 - Pol. Ind. L´Alteró,
46460 - Silla (Valencia) Spain
Tel. +34 96 121 63 01 Fax + 34 96 120 02 42
www.workproaudio.com support@work.es
