Work Hero CD1 Owner's Manual

DRY CANISTER

CD1

Features:

- 10L Capacity

- Gulper Floor Tool

- 10m Cable

- Cloth Filter Bag

INTRODUCTION

Congratulations on the purchase of your new Work Hero vacuum cleaner. There are many
useful features built into your cleaner and we recommend that you carefully read this
instruction manual so that you may take best advantage of them.

Before you begin

This product must be operated in accordance with these instructions and used only for
cleaning to remove DRY dirt and dust from carpets, ooring and fabrics.

Safety reminders and taking care of your cleaner

PLEASE READ THESE INSTRUCTIONS THOROUGHLY. This will ensure you obtain full benet
from your new cleaner. Keep this instruction manual in a handy place for future reference.

IMPORTANT SAFETY
INSTRUCTIONS

This appliance was not designed for use
with water Dry vacuum only. Do not use for
any purpose other than described in this
user’s guide. When using your Vacuum,
basic safety precautions should always
be observed, including the following:

Read all instructions before using this
vacuum.

1. Do not leave vacuum cleaner

unattended when it is plugged in.
Unplug from outlet when not in use and
before removing lters.

2. Do not immerse the vacuum into water

or other liquids.

3. Do not pickup building materials such as

plaster dust, wood shavings, sand etc.

4. Use only as described in this manual.
Use only manufacturer’s recommended
accessories.

5. Do not use with damaged cord or plug.
Do not use vacuum cleaner if it has
been dropped, damaged, left outdoors,
or dropped into water. Return appliance
to authorised service centre for
examination, repair or adjustment.

6. Do not pull or carry by cord. Do not use
cord as a handle, close a door on cord, or
pull cord around sharp edges or corners.
Do not run appliance over cord. Keep
cord away from heated surfaces.

7. Do not unplug by pulling on cord. To

unplug, grasp the plug, not the cord.

8. Do not handle plug or vacuum cleaner

with wet hands.

9. Do not use the vacuum cleaner to pick

up large objects or objects that are
likely to damage the vacuum cleaner.

10. Keep hair, loose clothing, ngers, feet
and all parts of body away from openings,
rotating agitator and other moving parts.
Do not operate cleaner in bare feet or
when wearing open toe shoes.

11. Do not pick up hot coals, cigarette

butts, matches or any hot, smoking,
or burning objects.

12. Do not pick up hard or sharp objects

such as glass, nails, screws, coins, etc.

13. Do not use without all lters in place.

Use ONLY lters and accessories
provided by manufacturer. Failure to
do so will void the warranty.

14. Turn o all controls before plugging

or unplugging vacuum cleaner into
electrical outlet.

15.

Use ex tra care when vacuuming on stairs.

16. Do not pick up ammable or

combustible materials (lighter uid,
gasoline, kerosene, etc.) or use in the
presence of explosive liquids or vapour.

17. Do not pick up toxic material (chlorine

bleach, ammonia, drain cleaner, etc.).

18. Do not use in an enclosed space lled

with vapours given o by oil based
paints, paint thinner, moth proong
substances, ammable dust, or other
explosive or toxic vapours.

WORK HERO DRY CANISTER – CD1 01

19. Use only on dry, indoor surfaces.

20. Do not put any objects into openings.
Do not use with any opening blocked.
Keep free of dust, lint, hair and
anything else that may reduce air ow.

21. Always store your appliance indoors

in a cool, dry area.

22. Keep your work area well lit.

23. Keep end of hose, wands and other
openings away from your face and body.

24. This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience
and knowledge, unless they have
been given supervision or instruction
concerning use of the appliance By a
person responsible for their safety.
Children should be supervised to ensure
they do not play with the appliance.

02 WORK HERO DRY CANISTER – CD1

KNOW YOUR PRODUCT

1. Flexible Hose

2. Deluxe Chrome Rod

3. Handy Carry Handle

4. On/O Switch

5. Gulper Floor Tool

6. 4 Robust Castor Wheels

7. Air Flow Indicator

8. On-Board Tools

9. Cable 10m (not shown)

Due to continual development in improving product some
parts may vary from those pictured. The manufacturer
reserves the right to change specications without notice.

1. Flexible Hose

2. Deluxe
Chrome Rod

3. Handy Carry Handle

4. On/O Switch

5. Gulper
Floor Tool

6. 4 Robust Castor
Wheels

7. Air Flow
Indicator

8. On-Board Tool
Accessories
Holder

WORK HERO DRY CANISTER – CD1 03

CARE AND MAINTENANCE

Caution:

Power cable

Always disconnect the cleaner from the power outlet by pulling out the plug directly,
NEVER by pulling on the power cable.

Faults

Do not continue to use this appliance if it appears to be faulty or the power cable is damaged.
If damaged, return the cleaner for repair by an authorised service centre in order to avoid a
safety hazard. Consult the troubleshooting guide in this manual if your vacuum cleaner fails
to operate properly. Contact an authorised service agent if the problem persists.

After use

Switch the cleaner o and remove the plug form the mains power supply.

Protecting the environment

Once you have unpacked the unit, please consider the environment when disposing of
the packaging. Where possible please recycle the packaging.

ACCESSORIES

Your Work Hero vacuum cleaner has been
designed to handle a number of cleaning
chores - eortlessly and eciently.
Accessories including a crevice tool and
dusting brush are conveniently located on
the top of the cleaner. Always switch o
and remove the plug before attaching any
accessories or cleaning the appliance.

NOTE: When removing the power cord from the electrical outlet, grasp the plug, not the cord.

PROBLEM CAUSE REMEDY

Motor does not start or stops No power supply Check cable, plug and socket. If

still inoperative see service agent

Suction force is gradually
decreasing

Canister is full, suction hose is
blocked or dir ty lters

Disconnect cleaner from power
then empty canister. Remove
objects from hose, replace lters

TROUBLESHOOTING

AIR FLOW

INDICATOR

Carpet Hard Floors

Gulper Floor Tool

The Gulper Floor Tool is ideal for
cleaning carpets and hard oors.

04 WORK HERO DRY CANISTER – CD1

EMPTYING CANISTER / CHANGING FILTER

Empty the canister when full. The canister must
be emptied when the suction starts to decrease or
when the air ow indicator located on top turns red.
Disconnect cleaner from power and uncouple hose
from inlet duct. Release the dust compartment latches
located at the sides of the cleaner.

1 UNDO LATCH

Remove the top housing from the canister (Fig. 1).

2. REMOVE TOP HOUSING

Empty the contents of the canister into a rubbish
bin. Before replacing top housing remove the motor
protection lter cover and shake out any dust. You
can now access the second motor lter located under
the grille (Fig. 2).

3. REMOVE MOTOR FILTER

It is advisable to check the second motor lter located
under the motor grille - a dirty lter will restrict motor
performance and cleaning eciency (Fig. 3).

4. UNSCREW FILTER HOUSING

Undo the 2 screws, remove lter grille and replace
dirty lter. Reassemble grille. Ret motor protection
lter cover and replace top housing onto canister
making sure that the 2 latches are rmly closed
(Fig. 4).

CUSTOMER CARE

Please contact customer care 1800 815 270 to nd your local spare parts provider.

PRODUCT NUMBER PRODUCT DESCRIPTION

33400122 Cloth Filter Bag

33500266 Wheel Assembly

32200334 Inlet Filter

31210021 Hose Assembly

Fig. 1

Fig. 2

Fig. 3

Fig. 4

WORK HERO DRY CANISTER – CD1 05

This warranty commences from the original date of
purchase and is not transferable; please retain your
original proof of purchase for any warranty claims.
This warranty is valid only in the country where the
cleaner is purchased.

The cleaner must be operated in accordance with
these instructions. This cleaner is not designed for the
collection of vitreous building material including particle
board, construction products and similar products
such as wood/fibres, cement, fillers, fibre glass etc or
excessive or frequent sand. The infrequent pick-up
of these materials in these circumstances may be
harmful to your cleaner and may void the
manufacturer’s warranty.

Accessories and consumables including dust bags
and filters, unless defective in manufacture, are not
subject to this warranty. In order to prolong the life of
accessories and consumables, regular care and
maintenance is recommended.

When properly used and cared for, your cleaner
will render excellent service; refer to the instruction
manual for further details, as misuse or failure to
follow the instructions makes this warranty void.
In the event of service or advice being needed,
please contact International Cleaning Solutions Pty
Ltd, ACN 119 462 798, Level 1, Building 2 Brandon
Business Park, 530 Springvale Rd, Glen Waverley,
VIC 3150. Customer Care: 1800 815 270.

The decision to repair or replace the cleaner is at the
sole discretion of International Cleaning Solutions Pty
Ltd. If International Cleaning Solutions Pty Ltd decide to
repair or replace the cleaner, it will do so at its own cost.

International Cleaning Solutions Pty Ltd is unable to
accept responsibility under this warranty for any repair
work not carried out by an authorised International
Cleaning Solutions Service Agent or from the use of
non-genuine parts. If any part is no longer available
or manufactured, International Cleaning Solutions will
replace it with a genuine functional replacement part.
This warranty does not apply to the cost of replacing
any parts of the product due to normal wear and tear,
alterations, improper installation, physical abuse, misuse
or accidental damage. Any transportation costs
involved in the repair of defective parts shall be borne
by the claimant.

If proof of purchase cannot be provided at the time of
a warranty claim or service, any work carried out on
the cleaner is chargeable. The repair or replacement
of the cleaner under this warranty does not extend
the original period of warranty.

The benefits conferred by this warranty are in addition to
all other rights and remedies in respect of the product
as outlined under the Competition and Consumer Act
and other State and Territory laws.

“Our goods come with guarantees that cannot be
excluded in the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure
and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail
to be of acceptable quality and the failure does not
amount to a major failure.”

Keep this Guarantee and your receipt as proof of purchase

Purchase Date ......./......../.........

Our policy is one of continuous development and accordingly we reserve the right

to change specifications without prior knowledge.

International Cleaning Solutions Pty Ltd.

(ACN 119 462 798)

Level 1, Building 2, Brandon Business Park,

530 Springvale Road, Glen Waverley, Victoria, 3150.

This is a parts and labour warranty against product defects

and failures, when the product is used in accordance

with the terms and conditions of this warranty statement.

WARRANTY

3 Month

EXCLUSIVELY TO

12 M NTH

WARRANTY

EXCLUSIVELY TO

12 M NTH

WARRANTY

12 M NTH

WARRANTY

Product Code: 11120455

International Cleaning
Solutions Pty Ltd

(ACN 119 462 798)
Level 1, Building 2
Brandon Business Park
530 Springvale Rd
Glen Waverley, VIC 3150

Customer Care: 1800 815 270

Made in China

V3 1213

TECHNICAL INFORMATION

Model: CD1
220-240V~50Hz
1200-1400W MAX

APP. No: 19333

N127
