Woosim System WSP R241 User Manual

MODEL WSP-R241

WOOSIM SYSTEMS Inc.

(#501, Daerung Technotown 3th)

115, Gasan digital 2-ro, Geumcheon-gu, Seoul, 153-772 Rep. of KOREA Tel : +82-2-2107-3700 Fax : +82-2-2107-3707 URL: http://www.woosim.com

(2inch Mobile Printer) Rev. 1.0

All specifications are subjected to change without notice

http://www.woosim.com

 Copyright

WSP-R241 2inch mobile printer operator’s manual.

Copyright ⓒ2014 by Woosim Systems Inc. All rights reserved. The information contained in this manual is the property of Woosim Systems Inc. And may not be reproduced in whole or in part without the prior written permission of Woosim Systems Inc.

 Trademark

a registered trademark of Woosim Systems Inc.

All other trademark are the properties of their respective companies.

 Caution

Some semiconductor devices are easily damaged by static electricity. You should

turn the printer “OFF”, before you connect or removed the cable on the rear side, in

order to guard the printer against the static electricity. If the printer is damaged by the static electricity, you should turn the printer “OFF”.

 Notice

The contents of this manual are subject to change without notice.

WSP-R241 Rev. 1.0

http://www.woosim.com

 Introduction

The WSP-R241 is suitable designed for use with a growing variety of mobile devices. Bluetooth/Serial interfaces make the WSP-R241 the perfect comrade for applications such as point of transaction warehousing, distribution, point of sales, hospitality, gaming and healthcare.

The general features of WSP-R241 printer are as follows:

 Pocket size (79.5 X 114.3 X 43.5mm)  Light weight (201g) for true mobility.  Very silent printing thru direct thermal printing method.  High speed(100mm/sec, MAX)  High resolution(203dpi : 8dots/mm)  USB, Bluetooth Ver 3.0 + EDR  Intuitive LED’s indicate Power(on/off),Error, Bluetooth status, Battery status

 Support Magnetic Stripe Reader [option].

 Support text and graphic printing.  Easier paper loading by CLAMSHELL design.  One touch paper cover  Printer door open & Paper-out sensor  Easier maintenance with self-diagnostics.  In field programming – Update Firmware, Download Fonts and Logos

 Microsoft Windows XP/VISTA/7-32bit/7-64bit/CE/Linux/Android compatible.

 Free fall: 1.5M drop resistance  Flow control : Software (XON/XOFF)

※ Hardware flow control not supported in printer.

WSP-R241 Rev. 1.0

http://www.woosim.com

 Operating Precautions

Please follow the precautions below to enjoy and maintain the full performance

of the printer.

 Using the Printer

● Be careful not to drop or bump the printer on a hard surface.

● Do not install the printer in direct sunlight or such areas.

Suitable environment for the use of the printer is as follows:

◆ Operating temperature :-10°C to 50°C

◆ Relative humidity : 30% to 80%

● Do not install the printer near devices that generate strong

electromagnetic fields such as a copy machine.

● Do not open the platen cover during printing .

● Do not remove or reinstall the communication cable during printing

or transmission.

● Do not touch the connectors of the communication during printing.

● Switch the POWER OFF when not in use.

● Do not use other solvent.

● The AC adapter, the battery charger and the battery pack may

become warm when in use. This is normal and is not a malfunction.

● When the battery pack is used at low temperature, the length of time

the printer can be used may be shortened.

 Thermal Paper Handling

● Store the thermal paper in a cool, dry and dark place.

● Do not rub the paper with hard object.

● Do not leave the paper with hard object.

● Do not allow plastic film, erasers, or adhesive tape to touch the paper

for long periods.

● Do not stack the thermal paper with diazo copies immediately

after copying or wet-type copies.

● Do not use chemical glue.

● Always use the clean thermal paper.

WSP-R241 Rev. 1.0

http://www.woosim.com

Federal Communications Commission

Radio Frequency Interference Statement

FCC ID : QDDWSP-R241

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

CAUTION: Changes or modifications not expressly approved by the party responsible for

compliance could void the user’s authority to operate the equipment.

Note: This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

ㆍReorient or relocate the receiving antenna.

ㆍIncrease the separation between the equipment and receiver.

ㆍConnect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

ㆍConsult the dealer or an experienced radio/TV technician for help.

Modifications not expressly approved by the manufacturer could void the user's authority to

operated the equipment under FCC rules.

WSP-R241 Rev. 1.0

http://www.woosim.com

WSP-R241 Rev. 1.0

CONTENTS

1. Outline...........................................................................................................................................7

1.1. Model classifications ..........................................................................................................7

1.2. Product Part Number System ...........................................................................................7

1.3. Specifications. ......................................................................................................................8

2. Setting up the printer ............................................................................................................. 10

2.1. Printer & Accessories ....................................................................................................... 10

2.2. Printer Features ................................................................................................................. 11

2.3. Dimensions ........................................................................................................................ 12

2.4. Replacing the paper roll .................................................................................................. 14

2.5. Power supply ..................................................................................................................... 15

2.5.1. Internal power supply............................................................................................. 15

2.5.2. Installing the Battery .............................................................................................. 15

2.5.3. Recharging the battery .......................................................................................... 16

2.6. Set operation mode ......................................................................................................... 17

3. Interface ...................................................................................................................................... 22

3.1. USB ...................................................................................................................................... 22

3.2. Bluetooth ............................................................................................................................ 23

3.3. Card Reading ..................................................................................................................... 23

4. Using the printer ...................................................................................................................... 24

4.1. Control panel ..................................................................................................................... 24

4.2. The self test ....................................................................................................................... 25

4.3. Using the Belt clip ............................................................................................................ 26

5. Consumable Parts .................................................................................................................... 27

5.1. Recommended paper....................................................................................................... 27

5.2. Printing position ............................................................................................................... 27

6. Revision History ....................................................................................................................... 28

http://www.woosim.com

11.. OOuuttlliinnee

11..11.. MMooddeell ccllaassssiiffiiccaattiioonnss

11..22.. PPrroodduucctt PPaarrtt NNuummbbeerr SSyysstteemm

WSP-R241 ( ) ( )

Model

Interface

A1:USB/Bluetooth

Power

None : DC 8.4V

Model name / Interface Spec.

Example) 1. Porti-S40 UART/Bluetooth Part No. ⇒ S40/A1

2. Porti-SC30 Bluetooth Only Part No. ⇒ SC30/Z1

Note) The above table is the interface format which is supported.

But some of the interfaces are not supported according to the product and please contact us, if you have any questions regarding the interface.

S40

SC30

W25

. .

Wired

Wireless

RS-232C

Bluetooth

TTL 2 IrDA

USB

None

RS-485

Parallel Z None

WSP-R241 Rev. 1.0

http://www.woosim.com

11..33.. SSppeecciiffiiccaattiioonnss..

Item

Specification

Printing method

Direct thermal line printing

Character size

- Font Size A: 12X24 / Font Size B : 9X24 / Font Size C : 8X16

- KOR : 24X24(16X24) / CHN, JPN : 24X24

Characters per line

- Font A : 32cpl / Font B : 42cpl / Font C : 48cpl

- KOR, CHN, JPN : 16cpl

Character set

Alphanumeric:95, Extended Graphics:128X50 pages, International:10,

Simplified/Traditional Chinese, Japanese, Korean(optional)

Resolution

203dpi, 8dots/mm

Print width

2-inch (48mm, 384dots)

Printing speed

100mm / sec (MAX)

Dimensions

79.5 X 114.3 X 43.5mm

79.5 X 118.2 X 43.5mm (MSR model)

Weight

(Including battery)

201g / 217g (MSR model)

Interface

USB, Bluetooth Ver3.0 + EDR

Paper supplied

Thermal roll paper, Label roll (58mm wide, 40ø)

Barcode supplied

1-dimension : UPC-A, UPC-E, EAN-8, EAN-13, CODE-39, CODE-93,

CODE-128, ITF, CODABAR

2-dimension : PDF417, Micro PDF417, Truncated PDF417, QR-CODE,

DATA Matrix, Maxicode

Etc :GS1 databar

Driver

Microsoft Widows XP / VISTA / 7-32bit / 7-64bit

Windows CE, Linux, Android OS driver compatible

H/W spec.

MCU : RX-32bit, RAM : 128M bit, FLASH : 64M bit

Receive buffer size

1M bytes

Sensor

Support Cover open, Paper

(Continue…)

WSP-R241 Rev. 1.0

http://www.woosim.com

Item

Specification

MSR [option]

Triple tracks (1&2&3 Tracks Reading)

*Supports 3DES & AES encryption

Battery

Rechargeable 7.4V DC , 1100mAh (Li-ion)

Battery duration

1 hour continuous printing

Battery Charger

Output(8.4VDC/0.8A), 4hours full charge time

Environment Conditions

Temperature

-10°C ~ 50°C (operating)

-10°C ~ 70°C (storage)

Humidity

30% - 80% (operating)

10% - 90% (storage)

Limited Warranty of Life

Head

100Km

< Table 1 >

WSP-R241 Rev. 1.0

Input (100~240V AC 50/60Hz)
