WWW.VULCANHART.COM
VACB SERIES
MODEL
VACB25 ML-710563
VACB36 ML-710564
VACB47 ML-710565
VACB60 ML-710566
VACB72 ML-498068
CATALOG OF
REPLACEMENT PARTS
ACHIEVER CHARBROILER
MODEL VACB47
MODEL ACB47
TECHNICAL SERVICE AND PARTS ASSISTANCE
ITW Food Equipment Group, LLC
An Illinois Tool Works Company
3600 North Point Blvd., Baltimore, MD 21222
WWW.WOLFRANGE.COM
ACB SERIES
MODEL
ACB25 ML-710563
ACB36 ML-710564
ACB47 ML-710565
ACB60 ML-710566
ACB72 ML-498068
1-800-814-2028
FORM 37122 ( Feb. 2008)
ACHIEVER CHARBROILER REPLACEMENT PARTS
1
3
2
4
5
6
2
7
ACHIEVER CHARBROILER
ILLUS. PART
NO. NAME OF PART AMT.
1 00-410601-0FLAT Flat Heat Deflector ........................................................................................................... AR
2 00-710513 Bracket, Tray Guide ........................................................................................................... 2
3 00-710501 Burner Wire ...................................................................................................................... AR
4 00-410601 Heat Deflector ..................................................................................................................AR
5 00-710510 Plate, Supercharger .......................................................................................................... AR
6 00-410600-000G2 Burner Assy. Casting ........................................................................................................ AR
7 00-710503 Leg, 2" OD X 4" L Adjustable ............................................................................................. 4
– 2 –
REPLACEMENT PARTS ACHIEVER CHARBROILER
1
11
10
2
3
4
5
9
8
7
6
– 3 –
ACHIEVER CHARBROILER REPLACEMENT PARTS
ACHIEVER CHARBROILER
ILLUS. PART
NO. NAME OF PART AMT.
1 00-720971-00024 Grate, 7 Rib Cast Diamond .............................................................................................. AR
00-412852-00001 Grate, 7 Rib Slanted ......................................................................................................... AR
2 00-498207-00025 Front Panel (VACB25, ACB25) .......................................................................................... 1
00-498207-00036 Front Panel (VACB36, ACB36) .......................................................................................... 1
00-498207-00047 Front Panel (VACB47, ACB47) .......................................................................................... 1
00-498207-00060 Front Panel (VACB60, ACB60) .......................................................................................... 1
00-498207-00072 Front Panel (VACB72, ACB72) .......................................................................................... 1
3 00-723204 Logo, Small Wolf ................................................................................................................1
00-417700-00003 Logo, Vulcan ...................................................................................................................... 1
4 00-719255-00012 Knob, Wolf (Red) ................................................................................................................4
00-428300-00001 Knob, Vulcan (Black) .......................................................................................................... 4
5 00-788908-00001 Guard, Knob ....................................................................................................................... 1
6 00-404060-00001 Burner Air Mixer (Shutter) ................................................................................................... 4
7 00-719221 Burner Valve (Adj.) ........................................................................................................... AR
* 00-719951-00051 Orifice Hood #51 (Nat. Gas) (Sea Level to 3999') ............................................................. AR
* 00-719951-00056 Orifice Hood #56 (LP Gas) (Sea Level to 3999') ............................................................... AR
* 00-719951-00052 Orifice Hood #52 (Nat. Gas) (4000' to 4999') .................................................................... AR
* 00-719951-00057 Orifice Hood #57 (LP Gas) (4000' to 4999') ...................................................................... AR
8 00-719189 Pilot Valve (Single) ........................................................................................................... AR
00-719190 Pilot Valve (Double) .......................................................................................................... AR
00-719370
1
/8" Hex Head Plug ............................................................................................................ AR
9 00-719124 Tube, Pilot, 3/16" X 10" ....................................................................................................... AR
00-710409 Brack et, Pilot (Double) ..................................................................................................... AR
00-719135 Pilot Tip (S/S) ................................................................................................................... AR
10 00-788919 Tray, Crumb (25, 47 & 60 Models) ..................................................................................... 1
00-788919 Tray, Crumb (72 Model) ..................................................................................................... 2
00-788920 Tray, Crumb (36 and 72 Models) ........................................................................................ 1
11 00-410602-00001 Casting, Radiant ............................................................................................................... AR
Not Shown
00-408279-00021 Pressure Regulator (LP Gas) ............................................................................................. 1
00-408279-00025 Pressure Regulator (Nat. Gas) ........................................................................................... 1
00-710413 Brush, Charbroiler ..............................................................................................................1
* For units with standard burner orifices. For optimum performance for units with mixed burner orifices, see orifice
chart on page 5.
– 4 –
REPLACEMENT PARTS ACHIEVER CHARBROILER
ACB/VACB ORIFICE CHART SEA LEVEL TO 1999 FT
(UNITS WITH MIXED BURNER ORIFICES FOR OPTIMUM PERFORMANCE)
ORIFICE POSITIONS FROM LEFT TO RIGHT- NATURAL GAS
Model Number
12345 678910111213
ACB25/VACB25
719951-48 719951-50 719951-50 719951-48
ACB36/VACB36
719951-49 719951-51 719951-51 719951-49 719951-47 719951-47
ACB47/VACB47
719951-46 719951-48 719951-52 719951-51 719951-49 719951-52 719951-49 719951-46
ACB60/VACB60
719951-46 719951-49 719951-50 719951-51 719951-50 719951-50 719951-51 719951-51 719951-51 719951-48 719951-46
ACB72/VACB72
719951-46 719951-49 719951-50 719951-51 719951-50 719951-50 719951-51 719951-50 719951-51 719951-50 719951-51 719951-48 719951-46
ORIFICE POSITIONS FROM LEFT TO RIGHT- PROPANE GAS
Model Number
12345 678910111213
ACB25/VACB25
719951-55 719951-56 719951-56 719951-56
ACB36/VACB36
719951-55 719951-56 719951-57 719951-57 719951-56 719951-56
ACB47/VACB47
719951-55 719951-56 719951-56 719951-58 719951-57 719951-58 719951-55 719951-55
ACB60/VACB60
719951-55 719951-56 719951-56 719951-57 719951-57 719951-57 719951-57 719951-57 719951-56 719951-56 719951-55
ACB72/VACB72
719951-55 719951-56 719951-56 719951-56 719951-57 719951-57 719951-57 719951-57 719957-57 719951-57 719951-56 719951-56 719951-55
– 5 –
ACHIEVER CHARBROILER REPLACEMENT PARTS
RECOMMENDED SPARE PARTS LIST
PART
NO. NAME OF PART AMT.
00-408279-00025 Pressure Regulator (Nat. Gas) ....................................................................................................... 1
00-408279-00021 Pressure Regulator (LP Gas) ......................................................................................................... 1
00-719190 Pilot Valve (Double) ....................................................................................................................... 2
00-719189 Pilot Valve (Single) ......................................................................................................................... 2
00-719221 Gas Valve ...................................................................................................................................... 2
00-719951-00051 Orifice, #51 (Nat. Gas) ................................................................................................................... 2
00-719951-00056 Orifice, #56 (LP Gas) ...................................................................................................................... 2
00-719255-00012 Knob, Red Wolf .............................................................................................................................. 2
00-428300-00001 Knob, Black Vulcan ........................................................................................................................ 2
00-719124 10" Pilot Tube ................................................................................................................................ 2
00-719135 SS Pilot Tip .................................................................................................................................... 2
00-720971-00024 Cast Diamond Grate ...................................................................................................................... 1
00-404060-00001 Burner Shutter Assy. ...................................................................................................................... 2
– 6 –
NOTES
REPLACEMENT PARTS ACHIEVER CHARBROILER
– 7 –
ACHIEVER CHARBROILER REPLACEMENT PARTS
NOTES
– 8 –
