Page 1

Wolf Ventilation

All information is subject to change. Refer to www.wolfappliance.com for current information

Page 2

VENTILATION SYSTEMS

Behind the sculpted lines of Wolf ventilation units, there’s a lot of hard-nosed functional thinking. Brilliant halogen lighting illuminates your cooking surface. Powerful multispeed blowers whisk away smoke and odors. Five-layer mesh ﬁlters remove easily for cleaning.

Wall-mount and island hoods are available in Classic Stainless, downdraft units in Classic Stainless, Carbon and Platinum ﬁnishes.*

Professional heritage shines through in Wolf professional-style ventilation. Exteriors are heavy-duty, welded stainless steel, so ﬁnely hand-ﬁnished that they appear seamless. Stainless steel bafﬂe ﬁlters and halogen lighting extend the professional look and back it up with pro-level performance.

*Carbon and Platinum ﬁnishes not available on 45” downdraft.

All information is subject to change. Refer to www.wolfappliance.com for current information

Page 3

COOKTOP VENTILATION

WALL AND ISLAND HOODS Classic Stainless ﬁnish Internal, inline, or remote blower options Front-mounted controls with LED indicators Heavy-duty, stainless steel welded seams Three-speed blower control Filter clean timer Delay-off feature Halogen lighting with three settings Stainless steel ﬁlter cover with dishwasher-safe aluminum mesh ﬁlter Heat sentry to automatically turn unit on when heat is sensed Transition with built-in backdraft damper

DOWNDRAFT VENTILATION Classic, *Platinum, and *Carbon Stainless ﬁnishes available on top cover and controls 10’ wired remote-mounted controls Internal, inline, or remote blower options Three-speed blower control Filter clean timer Delay-off feature to automatically turn off unit Stainless steel ﬁlter cover with dishwasher-safe aluminum mesh ﬁlter LED indicators

All information is subject to change. Refer to www.wolfappliance.com for current information

COOKTOP WALL HOOD DOWNDRAFT

COOKTOP ISLAND HOOD

Page 4

PRO VENTILATION SYSTEMS

WALL, ISLAND, CHIMNEY AND LINER Internal, inline, or remote blower options Heavy-duty, 16-gauge stainless steel with enclosed liner Continually welded seams with hemmed edges and sides Recessed easy-access controls Inﬁnite-speed ventilator control Heat sentry to turn unit on when unsafe temp is sensed Easy-to-clean stainless steel bafﬂe ﬁlters Halogen lighting with two settings Transition with backdraft damper included (not on low

proﬁle hoods)

ACCESSORIES Platinum or brass decorative rails with standoffs 38”-high stainless steel backsplash (with or without warming

racks) 6,” 12,” 18,” and 24” duct covers Internal, inline, or remote blower options from 500 to 1,500 cfm

All information is subject to change. Refer to www.wolfappliance.com for current information

PRO 27” DEEP WALL HOOD

PRO WALL CHIMNEY HOOD

PRO ISLAND HOOD

LINER

Page 5

PRO 24” DEEP WALL HOOD

PRO WALL HOODS

Standard features include heat sentry and dual setting halogen lighting. All Wolf Pro Wall Hoods have the classic stainless steel ﬁnish with the option of a decorative rail. While a classic stainless steel rail is standard on (R) models, platinum or brass rails are available to match the bezels of our Dual Fuel Ranges and Sealed Burner Rangetops.

PRO ISLAND HOODS

A Wolf Pro Island Hood is the ﬁnal touch to complete your stage featuring professional cooking equipment. This premier ventilation system complements your cooking appliance of choice, guaranteeing you’ll look the part, no matter what new cooking challenges you take on. Wolf Pro Island Hoods are recommended for use with all Wolf working appliances.

PRO CHIMNEY HOODS

Wolf Pro Wall Chimney Hoods provide the ultimate in ventilation. With standard elements like heat sentry and dual setting halogen lighting, Wolf elevates the need for ventilation to an enjoyable perk.

PRO LOW-PROFILE HOOD

PRO HOOD LINERS

Whether you prefer French country or moder nist, the Wolf Pro Hood Liners allow you to incorporate superior ventilation within your kitchen design. All you have to do is decide what it will look like. Sometimes referred to as power packs, these liners bring all of the controls, lighting and convenience of our Pro ventilation line for those applications with a custom exterior treatment.

All information is subject to change. Refer to www.wolfappliance.com for current information

Page 6

CHOOSING VENTILATION

Dual Fuel Ranges, Sealed Burner Rangetops (SRT), Gas Ranges, Gas Range Top (GRT)

30” and 36” Appliances

BLOWER AND RECOMMENDED MINIMUM CFMs

PRODUCT HOOD RECOMMENDATION Internal In-Line External/Remote

30” PRO Low-Proﬁle Wall Hood 500 600 600

36” PRO Low-Proﬁle Wall Hood 500 600 600

30” PRO Deep Wall Hood (24” or 27”) 600 600 600

36” PRO Deep Wall Hood (24” or 27”) 600 1100 900

30” Dual Fuel, 30” Gas Range, 30” SRT

36” Dual Fuel, 36” Gas Range, 36” SRT, 36” GRT

36” PRO Wall Chimney Hood 600 1100 900

42” PRO Wall Chimney Hood 600 1100 900

34” PRO Hood Liner 1200 1100 900

40” PRO Hood Liner 1200 1100 900

36” PRO Island Hood 1200 1100 900

42” PRO Island Hood 1200 1100 900

36” PRO Low-Proﬁle Wall Hood 500 600 600

42” PRO Low-Proﬁle Wall Hood n/a 600 600

36” PRO Deep Wall Hood (24” or 27”) 600 1100 900

42” PRO Deep Wall Hood (24” or 27”) 600 1100 900

36” PRO Wall Chimney Hood 600 1100 900

42” PRO Wall Chimney Hood 600 1100 900

34” PRO Hood Liner 1200 1100 900

40” PRO Hood Liner 1200 1100 900

36” PRO Island Hood 1200 1100 900

42” PRO Island Hood 1200 1100 900

All information is subject to change. Refer to www.wolfappliance.com for current information

Page 7

Dual Fuel Ranges, Sealed Burner Rangetops (SRT), Gas Ranges, Gas Rangetops (GRT)

48” and 60” Appliances

BLOWER AND RECOMMENDED MINIMUM CFMs

PRODUCT HOOD RECOMMENDATION Internal In-Line External/Remote

48” PRO Low-Proﬁle Wall Hood n/a 600 600

48” PRO Deep Wall Hood (24” or 27”) 1200 1100 900

54” PRO Deep Wall Hood (24” or 27”) 1200 1100 900

48” Dual Fuel, 48” Gas Range, 48” SRT, 48” GRT

60” Dual Fuel, 60” Gas Range

48” PRO Wall Chimney Hood 1200 1100 900

54” PRO Wall Chimney Hood 1200 1100 900

46” PRO Hood Liner 1200 1100 900

52” PRO Hood Liner 1200 1100 900

54” PRO Island Hood 1200 1100 900

60” PRO Deep Wall Hood (24” or 27”) 1200 1100 1200

66” PRO Deep Wall Hood (24” or 27”) 1200 1100 1200

58” PRO Hood Liner 1200 1100 900

66” PRO Island Hood 1200 1100 1200

All information is subject to change. Refer to www.wolfappliance.com for current information

Page 8

CHOOSING VENTILATION

Cooktops and Integrated Modules

15”, 30” and 36” Appliances

BLOWER AND RECOMMENDED MINIMUM CFMs

PRODUCT HOOD RECOMMENDATION Internal In-Line External/Remote

30” Cooktop Wall Hood 450 600 600

36” Cooktop Wall Hood 600 600 600

15” Induction, 15” Electric Cooktop,

15” Gas Cooktop, 15” Integrated Modules

30” Induction, 30” Electric Cooktop, 30” Gas Cooktop

36” Induction, 36” Electric Cooktop, 36” Gas Cooktop

30” Sealed Burner Rangetop,

36” Sealed Burner Rangetop

42” PRO Island Hood 600 600 600

30” Downdraft included 1100 900

36” Downdraft Included 1100 900

45” Downdraft Included 1100 900

30” Cooktop Wall Hood 450 600 600

36” Cooktop Wall Hood 600 600 600

42” PRO Island Hood 600 600 600

30” Downdraft Included 1100 900

36” Downdraft Included 1100 900

45” Downdraft Included 1100 900

36” Cooktop Wall Hood 600 600 600

42” PRO Island Hood 600 600 600

36” Downdraft Included 1100 900

30” Downdraft Included 1100 900

36” Downdraft Included 1100 900

All information is subject to change. Refer to www.wolfappliance.com for current information

Page 9

VENTILATION MODEL NUMBERS

MODEL # BY CFM

HOOD MODEL #

PRO LOW-PROFILE WALL HOODS

30” PW302210

36” PW362210

42” PW422210

48” PW482210 808331 801640 801641

PRO 24” DEEP WALL HOODS

30” PW302418 810559 811131 808331 808332 801640 801641 801642 804701

36” PW362418 810559 811131 808332 801641 801642 804701

42” PW422418 810559 811131 808332 801641 801642 804701

48” PW482418

54” PW542418 810316 808332 801641 801642 804701

60” PW602418 810316 808332 801642 804701

66” PW662418 810316 808332 801642 804701

PRO 27” DEEP WALL HOODS

30” PW302718 810559 811131 808331 808332 801640 801641 801642 804701

36” PW362718

42” PW422718

48” PW482718

54” PW542718

60” PW602718

66” PW662718

PRO WALL CHIMNEY HOODS

36” PWC362418

42” PWC422418

48” PWC482418

54” PWC542418

500 600 900 1200 600 1100 600 900 1200 1500

810991 808331 801640 801641

INTERNAL BLOWER IN-LINE BLOWER EXTERNAL/REMOTE BLOWER

808331 801640 801641

810316 808332 801641 801642 804701

810559 811131 808332 801641 801642 804701

810316 808332 801641 801642 804701

801644 801645 808332 801641 801642 804701

804703 808332 801641 801642 804701

All information is subject to change. Refer to www.wolfappliance.com for current information

Page 10

VENTILATION MODEL NUMBERS

MODEL # BY CFM

HOOD MODEL #

450 600 900 1200 600 1100 600 900 1200 1500

PRO HOOD LINERS

34” PL342212

40” PL402212

46” PL462212

52” PL522212 805087 808332 801641 801642 804701

58” PL582212 805087 808332 801641 801642 804701

COOKTOP HOODS

30” CTWH30 801643 808331 808332 801640 801641 801642 804701

36” CTWH36 801644 804645 808331 808332 801640 801641 801642 804701

42” IH4227 801644 801645 808331 808332 801640 801641 801642 804701

DOWNDRAFTS

30” PW302718 included

36” PW362718

42” PW422718

48” PW482718

54” PW542718

66” PW662718

INTERNAL BLOWER IN-LINE BLOWER EXTERNAL/REMOTE BLOWER

805087 808332 801641 801642 804701

808332 801641 801642 804701

Included

808332 801641 801642 804701

Included

808332 801641 801642 804701

All information is subject to change. Refer to www.wolfappliance.com for current information

Page 11

GLOSSARY

Blower: Air-intake and exhaust assemblies that remove fumes and odor produced by cooking indoors.

Internal Blower:t Mounted inside the hood canopy or downdraft blower box.

In-Line Blower:t Mounted between the hood and the exterior of the home. Ducting runs from the hood and connects the

blower. More ducting is attached to the other side of the blower and runs to the exterior of the home. An in-line blower is a

good option for those who do not want the blower mounted inside the hood by cannot, or prefer not to, mount a remote blower

on the exterior of the home.

Remote or External Blower:t Mounted on the roof or an exterior wall. A remote-mounted blower will minimize the amount of

blower noise but will not eliminate the noise completely.

Liner:

Hood liner for custom hoods, stainless steel with easy-access controls and halogen lighting.

CFM:

Common abbreviation for “cubic feet per minute”. Measures the power and ability of the blower to intake and exhaust air. Larger cooking surfaces require a blower that has a higher CFM.

Downdraft:

Wolf ventilation that rises up from the countertop and draws cooking vapors away from the cooking surface.

PRO Series:

Wolf PRO Wall and Island Ventilation hoods are recommended for use with all Wolf cooking appliance. Pro ventilation hoods are heavy-duty, 16-gauge brushed stainless steel in the classic finish and have a stainless steel enclosed liner.

Recirculation Kit:

Recirculating ventilation units are installed on top of a ventilation hood; no ductwork is required. Wolf recirculation units are for use

with certain PRO wall hoods and recycle the air through a filter and return it to the kitchen. This type of ventilation will not remove hear, moisture, or combustion gases from the air, and will be less effective in reducing odors and smoke.
