Wohler VMQ4 User Manual

CONFIDENCE IS EVERYTHING.™

World Leader of In-Rack, Audio, Video, Data Monitoring, and Closed Captioning Solutions

VMQ-4

1RU Monitor Speaker

User Guide

Part Number 821031, Revision A

This publication is protected by federal copyright law. No part of this publication may be copied or distributed, stored in a retrieval system, or translated into any human or computer language in any form or by any means electronic, mechanical, manual, magnetic, or otherwise, or disclosed to third parties without the express written permission of Wohler Technologies.

Reproduction

Licensed users and authorized distributors of Wohler Technologies, Inc. products may copy this document for use with Wohler Technologies., Inc. products provided that the copyright notice above is included in all reproductions.

Customer Support

Wohler Technologies, Inc. 31055 Huntwood Avenue Hayward, CA 94544 www.wohler.com

Phone: 510-870-0810 FAX: 510-870-0811 US Toll Free: 1-888-596-4537 (1-888-5-WOHLER) Web: www.wohler.com Sales: sales@wohler.com Support: support@wohler.com

Disclaimers

Even though Wohler Technologies, Inc. has tested its equipment and software, and reviewed the documentation, Wohler Technologies, Inc. makes no warranty or representation, either express or implied, with respect to software, documentation, their quality, performance, merchantability, or fitness for a particular purpose.

Wohler Technologies, Inc. reserves the right to change or improve our products at any time and without notice.

In no event will Wohler Technologies, Inc. be liable for direct, indirect, special, incidental, or consequential damages resulting from any defect in the hardware, software, or its documentation, even if advised of the possibility of such damages.

Some states do not allow the exclusion or limitation for incidental or consequential damages, so the above exclusion or limitation may not apply to you.

Printing

This document is intended to be printed on a duplex printer, such that the copy appears on both sides of each page. This ensures that all new chapters start on a right-facing page.

This document looks best when printed on a color printer since some images may be indistinct when printed on a black and white printer.

Other Technologies and Products

Dolby, Dolby Digital, Dolby D, and Dolby E are registered trademark of Dolby Laboratories, Inc.

Microsoft Windows, and Internet Explorer are registered trademarks of Microsoft Corporation.

Last Update

February 03, 2010

VMQ-4 User Guide

Introduction

Overview

The single-rack space VMQ-4 permits simultaneous monitoring of up to four audio sources with “voice quality” fidelity. Because each channel has its own dedicated power amplifier and speaker, the audio sources remain completely separate from analog input to output. When listening within “Ultra Near Field” distances of 1 to 3 feet, these discrete speaker outputs provide enhanced source distinction when compared to designs with four inputs mixed into a single output.

Topics

Topics Page

Introduction 1 Safety Instructions 2 Installation Recommendations 3 Applications 5 Features 5 Specifications 6 Front Panel Controls 7 Rear Panel Connectors 8 Technical Functional Overview 9

VMQ-4 User Guide

Safety Instructions

1. Read, keep, and follow all of these instructions; heed all warnings.

2. Do not use this equipment near water or moisture.

3. Use only a dry cloth to clean the equipment.

4. Do not block any ventilation openings. Install only in accordance

with the instructions in the section entitled, “Installation

Recommendations” on page 6.

5. Do not install near any heat source such as a radiator, heat register,

amplifier, or stove.

6. Do not attempt to plug the unit into a two-blade outlet (with only

two prongs of equal width).

IMPORTANT:

By design, these monitors will only plug into a three-prong outlet for your safety. If the plug does not fit into your outlet, contact an electrician to replace the obsolete outlet.

7. Protect the power cord from being walked on or pinched,

particularly at plug’s source on the equipment and at the socket.

8. Use only the attachments/accessories specified by the

manufacturer.

9. Unplug the equipment during lightning storms or when unused

for long periods of time.

10. Refer all servicing to qualified service personnel. Servicing will be

required under all of the following conditions:

• The equipment has been damaged in any way, such as when

the power-supply cord or plug is damaged.

• Liquid had been spilled or objects have fallen onto the

equipment.

• The equipment has been exposed to rain or moisture.

• The equipment does not operate normally.

• The equipment has been dropped.
