WMF Cook Assist Operating Manual
WMF Cook Assist
Operating instructions
WMF Cook Assist
Page Content
3 Safety instructions
4 Product description
5 Function description
1. Start-up
19 1.1. Prior to first use
19 1.1.1 Charge the sensor
19 1.1.2. First coupling of the sensor with the smartphone
19 1.1.3. Install the app
19 1.1.4. First setup
2. Cooking in the WMF Vitalis + Cook Assist
8 2.1. Select ingredients
10 2.2. Specify details
11 2.3. Start cooking process
12 2.3.1. Preparations
13 2.3.2. Heating
14 2.3.3. Add ingredients
15 2.4. Cooking
17 2.5. End of the cooking process
18 3. Tips on cleaning and storage
19 Error management
20 Disposal
20 Guarantee
20 Disclaimer
WMF CookAssist Operating instructions
| 2
WMF Cook Assist
Congratulations on your selection,
You have chosen a quality WMF product. The sophisticated functionality ensures
high performance.
Safety instructions
Prior to the start-up of the WMF Cook Assist, please read the user manual for
the WMF Vitalis steamer, which you will want to use together with the sensor!
Please note the following safety instructions when using the WMF Cook Assist:
• Respond if the sensor flashes red or the application / smartphone calls
you to act: via sound, vibration or message.
• The sensor is not suitable for temperatures above 60°C. This may cause
damage (e.g. dishwasher).
• Do not use the sensor in the oven.
• Do not place the sensor in boiling water, as otherwise the battery
will be damaged.
• Do not plug the sensor into a household socket for power.
• If you leave the room during the cooking process, please reduce the
energy supply on the cooker. Do not leave the WMF Vitalis on the cooker
unattended for a long period of time.
• Do not continue to use a damaged sensor, e.g. after falling on a hard
surface. Please contact customer service.
• The measuring pin of the sensor becomes hot during the cooking process.
Let it cool before removing it or use pan holders/gloves.
WMF CookAssist Operating instructions
| 3
NL
IT
ES
1
2
5
5a
6
4
FR
EN
DE
NL
IT
ES
4
FR
EN
DE
NL
IT
ES
1
5a
4
FR
EN
DE
NL
IT
ES
4
FR
EN
DE
WMF Cook Assist
Product description
The WMF Cook Assist consists of a sensor for the WMF Vitalis steamer and
the charger for the battery. The battery is integrated in the sensor and cannot
be replaced. If the battery is defective, please replace the sensor.
The WMF Cook Assist is available separately or as a set with the WMF Vitalis
steamer. The WMF Cook Assist only works in combination with the WMF Vitalis.
It cannot be combined with other cookware.
This device corresponds to the European directives 2004/108/EC, 2006/95/EC,
1999/5/EC, 2011/65/EU and 2009/125/EC.
1
4
EN
3
2
0470
DE
ES
FR
NL
IT
5a
5
6
| 4WMF CookAssist Operating instructions
1 Front side of the sensor
2 Rear side of the sensor with button
3 Charger (100-240V; 50/60Hz; 150mA)
Maximum power: 2-3 W, 40 mW standby power
4 Brief operating instructions
(DE, EN, FR, ES, IT, NL)
5 WMF Vitalis steamer
5a Insert opening
6 Thermometer
WMF Cook Assist
Functional description
Sensor button for manually switching on or off
The sensor has a button on the back side that can be used to manually
switch it on (press briefl y) or off (press for 3 seconds).
Normally, the sensor is switched off via the app.
Sensor operating display
The operating display on the sensor shows the changing light and fl ash intervals
depending on the operating mode. The fl ashing intervals repeat approximately
every four seconds.
The most important fl ashing indicators
1. SWITCH ON
(>0.3 seconds of pressing the button)
2. ESTABLISHING
Android/Google blue/green colour signal
iOS/Apple blue/green colour signal
3. CHARGE STATUS OF THE BATTERY:
Charging: Flashes 2 x green
Charging complete: Flashes 2 x white
4. ERROR
Battery empty: Flashes 2 x red
Charging break: Flashes 3 x red
WMF CookAssist Operating instructions
| 5
WMF Cook Assist
1. Start-up
1.1. Prior to first use
1.1.1. Charge the sensor
• Clean the sensor with a dry, soft cloth.
• Insert the sensor in the charger.
• Plug the charger with the sensor into a socket.
• Once the operating display flashes white, pull the charger with
the sensor out of the socket.
• Pull the sensor out of the charger.
1.1.2. First coupling of the sensor with the smartphone
• Activate the sensor by briefly pressing the button on the reverse.
• The sensor is set at the factory for the Android/Google operating system.
• To change to iOS/Apple, hold the button for approximately 1 second
(blue / white colour signal).
• Activate Bluetooth on your smartphone.
• Search for “Cook Assist xxxx“ in the Bluetooth settings.
Here, xxxx stands for the designation of your sensor.
WMF CookAssist Operating instructions
| 6
WMF Cook Assist
1.1.3. Install the app
To be able to work with the app, it must fi rst be loaded onto the smartphone from
the respective store. Use the following address or the QR code displayed below:
http://m.wmf.de/cookassist/uebersicht
Select your operating system (iOS or Android). You will be taken to the respective store entry. Install the app on your smartphone. Start the app. The WMF Cook
Assist homepage appears on your smartphone. Follow the initial set-up dialogue.
WMF Cook Assist app free for
your iPhone. Made for iPhone 5,
iPhone 4S and iPhone 4
1.1.4. First setup
• Download database
• Enter sea level either manually or by pressing „Use location“.
• Select your WMF Vitalis (versions WMF Vitalis 6.5 l, WMF Vitalis 6.5 l Asia
or WMF Vitalis 3.5 l Compact).
The installation is completed once confi rmed. The WMF Cook Assist page
“Cooking selection“ appears on your smartphone.
2. Cooking with the WMF Vitalis + Cook Assist
Follow the instructions on your smartphone for a successful preparation.
The preparation takes place in the following steps:
WMF Cook Assist app free for
your Android mobile device
• Select ingredients.
• Specify details.
• Make preparations for cooking.
• Heat.
• Add ingredients.
• Start cooking process.
• Monitor and complete.
| 7WMF CookAssist Operating instructions
