WIZNET WIZ63OWI Users Manual

WizFi630 User Manual

(Version 1.1)

For more information, please visit our website at http://www.wiznet.co.kr

Certification Information

CE for Class B ITE

INFORMATION TO THE USER

Hereby, WIZnet. Declares that this WizFi630 is in compliance with the essential requirements and other relevant provisions of directive 1999/5/EC and other relevant provisions of directive 1999/5/EC.

WARNING: This is a class B product. In a domestic environment this product may cause radio

interference in which ca se the user may be require d to take adequate measures

FCC for Class B ITE

INFORMATION TO THE USER

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio freque ncy energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no Guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one more of the following measures

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit dif ferent from that to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

:

WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made

Document Revision History

Date Revision Changes

2012-07-02 1.0 Release

Change WizFi630’s picture at P10 Modify error sentence

2012-07-17 1.1

- P6, P18,P19 : WIZ630wi Æ WizFi630

- P24 : DNS server Æ DNS server address

- P38 : WDS Æ WPS

1. Introduction .................................................................................. 6

1.1. Features .............................................................................................................................................. 7

1.2. Wireless Specifications ................................................................................................................. 8

1.3. Hardware Specifications ............................................................................................................... 9

1.4. Software Specifications ............................................................................................................. 10

1.4.1. Contents ............................................................................................................................................ 10

1.5. Block Diagram ............................................................................................................................... 11

2. Operation Mode and Description of Menu ......................... 12

2.1. Operation Mode .......................................................................................................................... 12

2.1.1. Access Point .................................................................................................................................. 12

2.1.2. Gateway ........................................................................................................................................... 13

2.1.3. Client (Station) .............................................................................................................................. 13

2.1.4. AP-Client Mode ........................................................................................................................... 14

2.1.5. Ad-hoc Mode ............................................................................................................................... 14

2.2. Menu List by Operation Mode .............................................................................................. 15

2.2.1. Access Point (Bridge) Mode .................................................................................................. 15

2.2.2. Gateway (Router) Mode ........................................................................................................... 16

2.2.3. Client (Station) Mode ................................................................................................................ 17

2.2.4. AP-Client Mode ........................................................................................................................... 18

2.2.5. Ad-hoc Mode ............................................................................................................................... 20

2.3. Internet Setting ............................................................................................................................. 22

2.3.1. Internet connection setting ................................................................................................... 22

2.3.2. Local network setting ............................................................................................................... 24

2.3.3. DHCP Client Information ......................................................................................................... 25

2.3.4. VPN setting .................................................................................................................................... 25

2.3.5. Static Routing Setting .............................................................................................................. 26

2.3.6. QoS(802.1p) Setting ................................................................................................................... 27

2.3.7. VLAN(802.1p) ................................................................................................................................ 28

2.4. Wireless setting ............................................................................................................................ 29

2.4.1. Basic settings ................................................................................................................................ 29

2.4.2. Advanced Wireless Settings .................................................................................................. 31

2.4.3. Wireless Security ......................................................................................................................... 34

2.4.4. WDS(Wireless Distribution System) Setting ..................................................................... 37

2.4.5. WPS Setting

2.4.6. Wireless network status ............................................................................................................ 40

2.4.7. AP Wireless Statistics ................................................................................................................. 41

2.4.8. Station QoS/DLS(Direct Link Setup) Configurations ..................................................... 43

2.4.9. Profile ............................................................................................................................................... 44

2.4.10. Link Status ...................................................................................................................................... 45

2.4.11. Site Survey ..................................................................................................................................... 46

2.4.12. WI-FI Multi-Bridge settings ..................................................................................................... 47

2.5. Serial to LAN(Wired and Wireless) ....................................................................................... 48

2.5.1. Main Connection settings ....................................................................................................... 49

2.5.2. Aux Connection Settings ......................................................................................................... 49

................................................................................................................................... 38

2.5.3. Packing Condition (Incoming serial data packing condition) ................................... 50

2.5.4. Ethernet Data Tagging Option .............................................................................................. 50

2.6. Firewall settings ............................................................................................................................ 51

2.6.1. DMZ .................................................................................................................................................. 51

2.6.2. Port forwarding ............................................................................................................................ 52

2.6.3. Packet filtering .............................................................................................................................. 53

2.6.4. Contents filtering ........................................................................................................................ 54

2.6.5. System Security ............................................................................................................................ 55

2.7. Managements ............................................................................................................................... 56

2.7.1. System Management ................................................................................................................. 56

2.7.2. Firmware ......................................................................................................................................... 57

2.7.3. Config Settings ............................................................................................................................ 58

2.7.4. Port Setting .................................................................................................................................... 59

2.7.5. Packet Statistics ............................................................................................................................ 60

2.7.6. System Status ................................................................................................................................ 61

2.7.7. System Log .................................................................................................................................... 62

3. Hardware Information ............................................................. 63

3.1. WizFi630 Pin Map ........................................................................................................................ 63

3.2. Dimensions ..................................................................................................................................... 65

4. Important Notice ...................................................................... 66

1. Introduction

WizFi630 is a gateway module that transforms the RS-232 protocol and TCP/IP protocol into

IEEE802.11 b/g/n wireless LAN protocol. WizFi630 enables a device with RS-232 serial interface to

connect to LAN or WLAN for remotely control, measuring, and administration. WizFi630 can also work

as an IP router because of its internally embedded switch.

WizFi630 uses interfaces like Serial(UART), LAN, Wi-Fi(WLAN) to perform functions such as

Serial(UART)-To-Wi-Fi, Serial-To-Ethernet, Ethernet-To-Wi-Fi. Users can connect to WizFi630’s internal

web server or use serial commands for simple Wi-Fi settings; not only serial devices but 8/16/32 bit

micro controllers can also use UART for simple Wi-Fi settings.

WizFi630 can significantly reduce the processes for wireless module design, testing, and certification.

Therefore, WizFi630 can be the best solution for users who lack wireless network experience.

WizFi630 follows the 802.11b/g/n standard and support up to 150Mbps speed in wireless interface.

WizFi630 provides a test board, pc software, and documents so that anyone can develop a wireless

solution.

1.1. Features

 Complies with IEEE802.11b/g/n.  Gateway/AP(Bridge)/AP-Client/Client(Station)/Ad-hoc Mode , WDS/Repeater supports  1T1R RF Interface  Physical link rate up to 150Mpbs  Built-in 3 Ethernet Ports  2 Serial Ports supports  Working as Wi-Fi Router  WEP 64/128bit, WPA/WPA2-PSK TKIP, AES  802.1x (Only in AP mode)  802.11e and WMM (Wi-Fi Multimedia)  Router and Firewall function supports

Figure 1. Example of WizFi630’s Application

1.2. Wireless Specifications

Type Description

Wireless Standard IEEE802.11b/g/n

USA: 2.400 ~ 2.483GHz

Frequency Range

Operating Channels

Europe: 2.400 ~ 2.483GHz Japan: 2.400 ~ 2.497GHz China: 2.400 ~ 2.483GHz

USA/Canada: 11(1 ~ 11) Major Europe Countries: 13(1 ~ 13) France: 4(10 ~ 13) Japan: 14 for 802.11b(1 ~ 14), 13 for 802.11g(1 ~ 13) Korea/China: 13(1 ~ 13)

Output Power

(Tolerance(+/-1dBm)

Receive Sensitivity

Data Rates

Modulation Type

802.11b: 17dBm@11Mbps

802.11g: 14dBm@54Mbps

802.11n: 14dBm@150Mbps/72Mbps

802.11b: -89dBm@11Mbps

802.11g: -74dBm@54Mbps

802.11n(40MHz): -66dBm@150Mbps

802.11n(20MHz): -70dBm@72Mbps

802.11b: 1,2,5.5,11Mbps

802.11g: 6,9,12,18,24,36,48,54Mbps

802.11n(20MHz): 7,14.5,21.5,28.5,43.5,57.5,65,72Mbps

802.11n(40MHz): 29.5,86.5,115,130,144,150Mbps

11g: OFDM(64QAM, 16QAM, QPSK, BPSK) 11b: DSS(CCK, DQPSK, DBPSK)

Table 1. Wi-Fi Specifications

1.3. Hardware Specifications

Type Description

Serial port : 2 EA

Interface

Temperature Operation: -10℃~70℃

Humidity

Serial

Input Power DC 3.3V / 1A

Power Consumption Max : 3.3V / 600mA

Dimension 33mm X 43mm X 4.5mm

LAN port : 3EA USB port : 1 USB Host Port ( Reserved )

U.FL(wireless)

Operation: 10% to 90%, Non-Condensing Storage: 5% to 90%, Non-Condensing

Baud Rate : 1200 ~ 921,600bps

Stop bits: 1, 2

Parity: None, Odd, Even

Flow Control:

UART1: XON/XOFF(software), CTS/RTS(hardware), none UART2: XON/XOFF, none

Weight 6g

Antenna specification

Model Number WSL205

Monopole

Manufacturer

Antenna

Gain 4.00 dBi gain

Model Number W5E-WO-07-F245

Internal Antenna

Manufacturer WINiZEN Co., Ltd.

Gain 2.50 dBi gain

Model Number 3A-EEW01C1-011

PIFA Antenna

Manufacturer Wistron NeWeb Corporation

Gain 3.38 dBi gain

Table 2. WizFi630 Module Specifications

WANSHIH ELECTRONIC

CO., LTD.

1.4. Software Specifications

Type Description

Operation Mode Access Point(Bridge), Client(Station), Gateway, AP-Client, ad-hoc

Protocol TCP, UDP, ARP, ICMP, DHCP, PPPoE, HTTP

WEP 64/128bit

Security

Configuration Web Configuration, Serial Command, Configuration Tool

Notification Event Logging

Serial To Wi-Fi 2 Serial Port supports

WPA/WPA2-PSK AES/TKIP

802.1x ( Only in AP Mode )

Table 3. SW Specifications

1.4.1. Contents

Section Qnt. Contents

WizFi630

WizFi630 1ea

1.5. Block Diagram

Figure 1. WizFi630 Block Diagram

2. Operation Mode and Description of Menu

2.1. Operation Mode

 User can select the operation mode.  The default setting of WizFi630 is AP Mode. (DHCP Server Enabled)  DHCP Server is usually disabled in AP mode, but for the user’s convenience, DHCP Sever will be

enabled.

2.1.1. Access Point

In this mode, all Ethernet ports and the wireless interface are bridged together. Wired/Wireless

interface has the same IP address space with its top mesh. DHCP Server function is disabled and

WizFi630 does not assign an IP. Wireless (LAN Port included) sending periodic Broadcast Packet to

Station and maintains a connection with Station.

2.1.2. Gateway

When operating in router mode, interfaces are separated into WAN I/F (Top Internet Business

Network), LAN I/F (Sub Private Network: 192.168.16.xxx), and Wireless I/F (Sub Private Network:

192.168.16.xxx). Port # 0 will be assigned to the WAN Port. WizFi630 periodically sends Broadcast

Packet to Sub-LAN (LAN Port included) and maintains connection with Station.

2.1.3. Client (Station)

Wireless I/F is assigned as WAN Port and all Ethernet Ports are bound to LAN Port. Set the profile and

the WizFi630 is automatically connected to the AP when re-booting in the future. Devices that are

connected through the LAN port are assigned a private IP. WizFi630 periodically sends PING Packet to

AP Gateway and maintains connection with AP.

2.1.4. AP-Client Mode

Wireless I/F is assigned as WAN Port and all Ethernet Ports are bound to LAN Port. This mode is

similar to Station mode, however the difference is that the Wireless I/F will operate as client with AP

simultaneously. WizFi630 periodically sends Broadcast Packet to Sub-LAN (LAN Port included) and

maintains connection with Station.

2.1.5. Ad-hoc Mode

This mode is similar to Gateway mode. The Wireless I/F operates as ad-hoc and connects to Station

Point-to-Point. There is no communication between the LAN Port and Wireless I/F (ad-hoc).

WAN ÅÆ ad-hoc: OK

WAN ÅÆ LAN: OK

ad-hoc ÅÆ ad-hoc: OK

ad-hoc ÅÆ LAN: No Communication

2.2. Menu List by Operation Mode

2.2.1. Access Point (Bridge) Mode

Menu Detailed Menu Description ( Link ) List Number

Internet

Setting

Wireless

Setting

Serial

Setting

System IP Internet connection setting

LAN Local network setting 2.3.2

DHCP Clients DHCP Client Information 2.3.3

VPN Config VPN setting 2.3.4

QoS(802.1p) QoS(802.1p) Setting 2.3.6

Basic Basic settings

Advanced Advanced Wireless Settings ( AP Mode ) 2.4.2.1

Security Wireless Security setting 2.4.3

WDS WDS Setting 2.4.4

WPS WPS Setting ( AP Mode ) 2.4.5.1

Station List Wireless network status 2.4.6

Packet Statistics AP Wireless Statistics ( AP Mode ) 2.4.7.1

Serial Port #1

Serial to LAN(Wired and Wireless) 2.5

Serial Port #2

System Mgmt System Management

Firmware Mgmt Firmware 2.7.2

2.4.1

2.3.1

2.7.1

Config Mgmt Config Settings 2.7.3

Managements

Port Mgmt Port Setting 2.7.4

Packet Statistics Packet Statistics 2.7.5

System Status System Status 2.7.6

System Log System Log 2.7.7

2.2.2. Gateway (Router) Mode

Menu Detailed Menu Description ( Link ) List Number

Internet

Setting

Wireless

Setting

Serial

Setting

WAN Internet connection setting

LAN Local network setting 2.3.2

DHCP Clients DHCP Client Information 2.3.3

VPN Config VPN setting 2.3.4

Routing Static Routing Setting 2.3.5

Qos(802.1p) QoS(802.1p) Setting 2.3.6

VLAN(802.1q) VLAN(802.1p) 2.3.7

Basic Basic settings

Advanced Advanced Wireless Settings ( AP Mode ) 2.4.2.1

Security Wireless Security setting 2.4.3

WDS WDS Setting 2.4.4

WPS WPS Setting ( AP Mode ) 2.4.5.1

Station List Wireless network status 2.4.6

Packet Statistics AP Wireless Statistics ( AP Mode ) 2.4.7.1

Serial Port #1

Serial to LAN(Wired and Wireless) 2.5

Serial Port #2

2.4.1

2.3.1

Firewall

Managements

DMZ DMZ

Port Forwarding Port forwarding 2.6.2

Packet Filtering Packet filtering 2.6.3

Contents

Filtering

System Security System Security 2.6.5

System Mgmt System Management

Firmware Mgmt Firmware 2.7.2

Config Mgmt Config Settings 2.7.3

Port Mgmt Port Setting 2.7.4

Packet Statistics Packet Statistics 2.7.5

System Status System Status 2.7.6

System Log System Log 2.7.7

2.6.1

Contents filtering 2.6.4

2.7.1

2.2.3. Client (Station) Mode

 WizFi630 works as a Wi-Fi client(station) which is always paired with a Wi-Fi AP.  Users can take Client Mode as an opposite of Gateway Mode

Menu Detailed Menu Description ( Link ) List Number

Internet

Setting

Wireless

Setting

Serial

Setting

WAN Internet connection setting

LAN Local network setting 2.3.2

DHCP Clients DHCP Client Information 2.3.3

VPN Config VPN setting 2.3.4

Routing Static Routing Setting 2.3.5

Qos(802.1p) QoS(802.1p) Setting 2.3.6

VLAN(802.1q) VLAN(802.1p) 2.3.7

Profile Profile

Link Status Link Status 2.4.10

Site Survey Site Survey 2.4.11

Packet Statistics AP Wireless Statistics ( Client Mode ) 2.4.7.2

Advance Advanced Wireless Settings(Client Mode) 2.4.2.2

QoS

WPS WPS Settings ( Client Mode ) 2.4.5.2

Serial Port #1

Serial Port #2

2.4.9

Station QoS/DLS(Direct Link Setup)

Configurations

Serial to LAN(Wired and Wireless) 2.5

2.3.1

2.4.8

2.6.1

Contents filtering 2.6.4

2.7.1

Firewall

Managements

DMZ DMZ

Port Forwarding Port for warding 2.6.2

Packet Filtering Packet filtering 2.6.3

Contents

Filtering

System Security System Security 2.6.5

System Mgmt System Management

Firmware Mgmt Firmware 2.7.2

Config Mgmt Config Settings 2.7.3

Port Mgmt Port Setting 2.7.4

Packet Statistics Packet Statistics 2.7.5

System Status System Status 2.7.6

System Log System Log 2.7.7

2.2.4. AP-Client Mode

 AP-Client Mode Settings are very similar to the Gateway Mode Settings.  The table below shows the added features of AP-Client mode.  One module can operate as both AP and Station.  The wireless module connects to a different AP and functions as WAN port.  The channel of WizFi630 must be identical to the channel of AP to be connected  Support wireless bridge.

Menu Detailed Menu Description ( Link ) List Number

Internet

Setting

Wireless

Setting

Serial

Setting

WAN

LAN

DHCP Clients

VPN Config

Routing

Qos(802.1p)

Basic

Advanced

Security

WDS

WPS

WIFI Multi Bridge

Station List

Packet Statistics

Serial Port #1

Serial Port #2

Internet connection setting 2.3.1

Local network setting 2.3.2

DHCP Client Information 2.3.3

VPN setting 2.3.4

Static Routing Setting 2.3.5

QoS(802.1p) Setting 2.3.6

Basic settings 2.4.1

Advanced Wireless Settings ( AP Mode ) 2.4.2.1

Wireless Security setting 2.4.3

WDS Setting 2.4.4

WPS Setting ( AP Mode ) 2.4.5.1

WIFI Multi-Bridge settings 2.4.12

Wireless network status 2.4.6

AP Wireless Statistics ( AP Mode ) 2.4.7.1

Serial to LAN(Wired and Wireless) 2.5

Firewall

Managements

DMZ

Port For warding

Packet Filtering

Contents Filtering

System Security

System Mgmt

Firmware Mgmt

Config Mgmt

Port Mgmt

Packet Statistics

DMZ 2.6.1

Port forwarding 2.6.2

Packet filtering 2.6.3

Contents filtering 2.6.4

System Security 2.6.5

System Management 2.7.1

Firmware 2.7.2

Config Settings 2.7.3

Port Setting 2.7.4

Packet Statistics 2.7.5

System Status

System Log

System Status 2.7.6

System Log 2.7.7

2.2.5. Ad-hoc Mode

 Settings for ad-hoc mode are almost the same as settings for Client (Station) Mode as previously

shown.

 The difference with Client mode is that Client mode is used to connect AP.  Client Mode connects to AP, whereas ad-hoc Mode connects with stations that use the same SSID.  Both 1:1 connection and 1:N connection are possible

 In case of 1:N, N is possible up to 255

Menu Detailed Menu Description ( Link )

List Number

Internet

Setting

Wireless

Setting

Serial

Setting

WAN

LAN

DHCP Clients

VPN Config

Routing

Qos(802.1p)

Profile

Link Status

Site Survey

Packet Statistics

Advance

QoS

WPS

Serial Port #1

Serial Port #2

DMZ

Internet connection setting 2.3.1

Local network setting 2.3.2

DHCP Client Information 2.3.3

VPN setting 2.3.4

Static Routing Setting 2.3.5

QoS(802.1p) Setting 2.3.6

Profile 2.4.9

Link Status 2.4.10

Site Survey 2.4.11

AP Wireless Statistics ( Client Mode ) 2.4.7.2

Advanced Wireless Settings(Client Mode) 2.4.2.2

Station QoS/DLS(Direct Link Setup) Configurations 2.4.8

WPS Settings ( Client Mode ) 2.4.5.2

Serial to LAN(Wired and Wireless) 2.5

DMZ 2.6.1

Firewall

Managements

Port For warding

Packet Filtering

Contents Filtering

System Security

System Mgmt

Firmware Mgmt

Config Mgmt

Port Mgmt

Packet Statistics

System Status

Port forwarding 2.6.2

Packet filtering 2.6.3

Contents filtering 2.6.4

System Security 2.6.5

System Management 2.7.1

Firmware 2.7.2

Config Settings 2.7.3

Port Setting 2.7.4

Packet Statistics 2.7.5

System Status 2.7.6

System Log

System Log 2.7.7

2.3. Internet Setting

2.3.1. Internet connection setting

 Select the internet service type and WizFi630 can connect to the internet  If users would like access to Internet, Gateway Mode should be selected.

Type Description

WAN Connection

Type

Host Name

Mac Clone

Type Description

DHCP(Auto

config)

Select the communication ways for Internet’s connection

- Static(Fixed IP)

- DHCP (Auto config)

- PPPoE

Settings about module’s host name

Some ISPs require that you register a MAC address. Users can directly enter MAC address or use the MAC Clone function

User should choose DHCP Mode when the user connects to the internet service such as FTTH, cable modems, VDSL, or IP-ADSL

Static(Fixed IP) Static IP setting window. If user receives static IP from ISP, user should set the Fixed IP

Input the network information that got from ISP

(such as IP, Subnet, Gateway, DNS)

PPPoE(ADSL)

-. User Name: Setting the User Name received from ISP

-. Password: Password assigned by ISP

-. Operation Mode: This mode is used for re-connecting when connection is bad

2.3.2. Local network setting

 WizFi630 internal IP setting, DHCP server setting and DHCP.

Type Description

IP Address

Subnet Mask

MAC Address

DHCP Server

Start IP Address

End IP Address

Subnet Mask

Primary DNS Server

Secondary DNS Server

Lease Time

Statically Assigned

Enter the module’s IP. (Default Value : 192.168.16.254)

Enter the module’s subnet mask.

MAC Address of module’s LAN port (Wireless included). (Read Only)

Decide whether the module’s DHCP server will be used.

Set the start IP address that will be assigned from the DHCP server

Set the end IP address that will be assigned from the DHCP server.

Enter the value of subnet mask.

Enter the primary DNS server address.

Enter the secondary DNS server address.

Enter the lease time when IP address is assigned.

Maximum of three IP can be statically assigned when IP address is assigned.

2.3.3. DHCP Client Information

 The IP information that is assigned from the DHCP server is shown.

Type Description

Host name

Mac Address

IP Address

Expires in

Client’s host name is shown

Client’s MAC address is shown.

Client’s IP address is shown.

The usable time of client’s IP address is shown.

2.3.4. VPN setting

 This section will explain on VPN packet settings.

Type Description

L2TP Pass-through

IPSec Pass-through

PPTP Pass-through

Enable : VPN L2TP packet is passed through WAN. Disable : VPN L2TP packet is not passed through WAN. (Default value)

Enable : VPN IPSec packet is passed through WAN. Disable : VPN IPSec packet is not passed through WAN. (Default value)

Enable : VPN PPTP packet is passed through WAN. Disable : VPN PPTP packet is not passed through WAN. (Default value)

2.3.5. Static Routing Setting

 User can modify the routing table at static routing settings.  We do not recommend any modification.

Type Description

Destination

Range

Netmask

Gateway

Interface

Enter the Target IP address or network address.

Select whether the routing table is HOST or NETWORK

If Range is NETWORK, enter subnet mask.

Enter the gateway address to be passed when communicating with target.

Select whether the target is LAN or WAN.

2.3.6. QoS(802.1p) Setting

 Settings for QoS / DLS in Station mode.

Type Description

Port #0 ~ Port#5

Port #6(WLAN)

Set a QoS value from 0~7

2.3.7. VLAN(802.1p)

 Settings for VLAN ID value and Tag/Untag.

Type Description

VLANID

Tagging

ID for connection with VLAN.

Select to add information related to VLAN.

2.4. Wireless setting

2.4.1. Basic settings

 This chapter is about basic setting for wireless LAN.

Type Description

Radio On/Off

Network Mode

SSID

Broadcast Network

Name

Frequency(Channel)

Channel Bandwidth

Reverse Direction

Grant(RDG)

Decide radio on/off of wireless AP function.

11b/g/n mixed mode: 802.11b/g/n are supported. 11b/g mixed mode: 802.11b/g are supported. 11b only: only 802.11b is supported. 11g only: only 802.11g is supported. 11n only: only 802.11n is supported

Enter the name of the wireless network.

AP or Wireless network status can be checked by notifying the SSID to the wireless device. AP cannot be searched if this function is disabled.

Select the channel of wireless network.

Fix bandwidth channel to 20MHz. Use 40MHz as bandwidth in case connection with wireless station that supports 11n channel bonding..

The wireless performance can be improved using Reverse Direct Grant, 11n’s RDG technology.

Type Description

Extension Channel

HT TxStream

HT RxStream

Setting for the other 20MHz area when channel bandwidth is set to 40MHz

Setting for number of Tx antennas of 2T2R system.

Setting for number of Rx antennas of 2T2R system.

2.4.2. Advanced Wireless Settings

2.4.2.1. Advanced Wireless Settings ( AP Mode )

 Only works at the AP Mode, Gateway Mode, and AP-Client Mode  This chapter is about higher-level setting for wireless LAN.

Type Description

Tx Power

Tx Burst

Packet Aggregate

Short Slot

Short Preamble

RTS Threshold

Fragmentation

Controls the range of wireless radio being sent. The range of wireless radio being sent gets larger as the value is larger.

The wireless speed can be maximized by enabling this function. However, it is recommended to disable this function for stable connection when numerous stations are connected together..

Numerous packets can be transmitted in one MPDU by enabling this function

The performance of wireless station connected to 11g can be improved by enabling Short Slot. However, it is recommended to disable Short Slot if there is a wireless station with unstable connection.

If user enables Short Preamble, performance might slightly improve. However, the compatibility with wireless LAN card when connecting could decrease. It is recommended to disable Short Preamble for best compatibility.

When a data is larger than the threshold size, it can be sent RTS/CTS. Smaller threshold size may enable more stable wireless communication; however the maximum speed is lower. Smaller threshold size is recommended in case of more wireless stations are connected at the same time. The setting range is 1~2347.

When a data is larger than the threshold size, it is fragmented and sent. Smaller

Threshold

BG Protection

Beacon Interval

Country Code

WMM

(Wi-Fi Multimedia)

DLS

threshold size may enable more stable wireless communication; however the maximum speed is lower. Smaller threshold size is recommended in case of many interruptions from surrounding signals. The setting range is 256~2346.

Setting for wireless communication when using both 11b and 11g LAN cards. Recommended for automatic settings in general.

Controls the interval of sending beacon. The setting range is 20~999 and 100ms is usually used.

Setting for country code. Example: KR(Republic of Korea), US(United State), FCC(Europe), JP(Japan), FR(France), ES(Spain)

Decide whether or not to use WMM function.

Decide whether or not to use DLS (Direct Link Setup) function.

2.4.2.2. Advanced Wireless Settings ( Client Mode )

 Set Station advanced configurations in station mode.

Type Description

RADIO OFF

Wireless Mode

Country

Region Code

B/G Protection

Enable / Disable wireless LAN.. User cannot use wireless LAN if user clicks RADIO OFF.

Selects wireless mode.

Selects the country / regional code.

Setting for better wireless communication when both 11b and 11g LAN cards are used.

We recommend Auto.

HT

BW

GI

MCS

Tx Antenna

Rx Antenna

MPDU

Aggregation

MPDU density

Select whether the PHY Mode of wireless to be Mixed Mode or GreenField Mode.

Fix the channel bandwidth to 20MHz: 20MHz. 20/40MHz: Use 40MHz when wireless station that supports 11n channel bonding.

Long: 800nsec, short: 400nsec

Controls link rate.

Select number of Tx antenna in 2T2R system.

Select number of Rx antenna in 2T2R system.

Aggregates multiple MPDU to a single MPDU.

MPDU Variable Factor

Aggregation

MSDU

Aggregates multiple MPDU to a single MPDU.

(A-MSDU)

2.4.3. Wireless Security

 This chapter is about settings for wireless network security

Type Description

SSID choice

Security Mode

Access Policy

Add a station MAC

If multiple SSID are in use, choose the corresponding SSID for security.

Select security mode.

Disable : Access Control function will be disabled.. Allow Listed : allows communication with listed MAC client. Reject Listed: blocks communication with listed MAC client.

Enter the client’s MAC address for controlling.

2.4.3.1. Wireless Security setting

 Authentication settings

Type Description

OPENWEP

SHAREDWEP

WEPAUTO

WPA-PSK

WPA2-PSK

WPAPSKWPA2PSK

WPA

WPA2

WPA1WPA2

802.1x

All users are authorized.

Users only with correct network key are authorized.

OPEN/SHARED Mode is selected automatically.

WPA certified standard with improved security.

Improved WPA certified standard

Both WPZ-PSK and WPZ2-PSK are supported.

WPA certified standard including 802.1x.

Improved WPA certified standard.

Both WPA and WPA2 are supported.

Radius authentication through WEP Key.

2.4.3.2. Wireless Authentication Setting

Encryption Type Description

None

WEP64

WEP128

TKIP

AES

TKIP/AES

OPEN Encryption algorithm is not used.

SHARED/ WEPAUTO/802.1x

WPA/WPA2/ WPA-PSK/ WPA2-PSK/ WPA1WPA2/ WPAPSKWPA2PSK

WEP encryption algorithm is used with 64bit key.

WEP encryption algorithm is used with 128 bit key.

More complex encryption algorithm than WEP Is used.

New encryption algorithm is used.

Support TKIP/AES simultaneously

2.4.3.2.1. WEP

 Enter key for WEP64 or WEP128 network.  Use either character string or hex character when entering key.  Select 1~4 for ‘Default Key..  Enter at least one WEP Key.  The entered WEP key is used for connection from wireless terminal.

2.4.3.2.2. TKIP/AES authentication

 Enter at least 8 characters of character string for the network key value.

2.4.3.2.3. Wireless 802.1x authentication

 Enter the value for linking with the Radius Server.  The values related to the Radius Server are provided by the internet service company.

2.4.4. WDS(Wireless Distribution System) Setting

 Connection with different AP is possible with WDS (Wireless Distribution System) function.  Maximum of four APs can connect through WDS function.  2 APs must use the same channel and authentication / encryption method

Type Description

Disable

Lazy Mode

Bridge Mode

Repeater Mode

WDS function is not used. (Default disable)

Do not register the MAC of AP to be connected. Connect the AP’s MAC to the registered AP. AP function is provided.

Register the MAC of AP to be connected. Connect the registered MAC to the AP. AP function is not provided.

Register the MAC of AP to be connected. Connect the registered MAC to the AP. AP function is provided. (The performance of WDS is best in Repeater Mode.)

2.4.5. WPS Setting

2.4.5.1. WPS Setting ( AP Mode )

 Only work at the AP Mode, Gateway Mode and AP-Client Mode  The WPS function enables easier wireless network setting.

Type Description

WPS

WPS Current Status

WPS Configured

WPS SSID

WPS Auth Mode

WPS Encrypt Type

WPS Default Key Index

WPS Key(ASCII)

AP PIN

WPS Mode

Enable / Disable WPS.

Shows whether WPS is used or not for the connection with station.

Shows whether WPS is configured or not.

Shows the SSID connected to the station.

Shows the authentication used with WPS.

Shows the Encryption used with WPS.

Shows the default key ID used with WPS.

Shows the WPS Key.

Shows the PIN value used when connecting to station.

Select PIN or PBC.

2.4.5.2. WPS Settings ( Client Mode )

 WPS settings in Station Mode.

Type Description

Refresh

PIN Start

PBC Start

Cancel

Renew PIN

Searches for WPS function activated AP.

Attempts connection with AP using PIN value.

Attempts connection with AP by virtually clicking the PBC button.

Cancels the AP connection attempt.

Renews the PIN value of WizFi630.

2.4.6. Wireless network status

 The status of the station that is connected to WizFi630 is shown.  The surrounding wireless AP’s status are shown.

Type Description

Channel

SSID

BSSID

Security

Signal

W-Mode

Type

Channel information of AP

SSID of AP

MAC address of AP

Encryption method of AP

Signal strength with AP

Wireless mode of AP

Network Type of finding AP In: Infrastructure, Ad: ad-hoc

2.4.7. AP Wireless Statistics

 The Statistics of wireless communication is shown.

2.4.7.1. AP Wireless Statistics ( AP Mode )

 Only work at the AP Mode, Gateway Mode and AP-Client Mode

Type Description

Tx Success

Tx Retry Count

Tx Fail after retry

RTS Successfully Receive CTS

RTS Fail To Receive CTS

Frames Receive Successfully

Frames Received With CRC Error

SNR

Number of successfully transmitted frames

Number of retransmitted frames

Number of failed frames

Number of frames that successfully received CTS

Number of frames that failed to receive CTS

Number of frames successfully received

Number of frames that failed due to CRC error

Receiving signal strength

2.4.7.2. AP Wireless Statistics ( Client Mode )

 Station statistics shows the information of wireless data packet in station mode.

Type Description

Frames Transmitted Successfully

Frames Transmitted Successfully Without Retry

Frames Transmitted Successfully After Retry(s)

Frames Fail To Receive ACK After All Retries

RTS Frames Successfully Receive CTS

RTS Frames Fail To Receive CTS

Frames Received Successfully

Frames Received With CRC Error

Frames Dropped Due To Out-of-Resources

Duplicate Frames Received

Number of frames successfully transmitted.

Number of frames successfully transmitted without a retry.

Number of frames transmitted successfully after retry.

Number of frames failed to receive ACK after all retries.

Number of RTS frames that successfully received CTS

Number of RTS frames failed to receive CTS.

Number of frames successfully received.

Number of frames received with CRC error.

Number of frames dropped due to out of resources.

Number of duplicate frames received.

2.4.8. Station QoS/DLS(Direct Link Setup) Configurations

 Set Station QoS / DLS configurations in station mode

Type Description

WMM(Wi-Fi

Multimedia)

WMM Power Saving

Direct Link Setup

MAC Address

Timeout Value

Enable WMM function or not.

Enable Power Saving function or not.

Enable Direct Link function or not. In order to use Direct Link function, the AP connected to WizFi630 and the Station to be connected must support Direct Link function.

Enter the MAC Address of the station to be connected using direct link function.

Cancels the link if there are no traffic between stations for a period of time.

2.4.9. Profile

 Shows the profile of the connected AP.

The profile information can be modified.

By using “Site Survey”, it is very convenient to find and connect with an AP.

 Administration of maximum of two AP is possible after adding to profile.  The module automatically connects to the active AP (selected AP) upon booting.

Type Description

Profile Profile Name

SSID SSID of AP to be connected

Channel

Authentication Authentication method of AP to be connected.

Encryption Encryption method of AP to be connected.

Network Type Select AP / ad-hoc.

Channel information of AP to be connected. Channel information is needed only when

connecting with ad-hoc.

2.4.10. Link Status

 Shows the link status between wireless LAN and AP.

Type Description

Status SSID and BSSID of connected AP.

Extra Info Link status.

Channel Channel information of connected AP.

Link Speed Link speed rate of connected AP. Throughput Real performance through communication. Link Quality Link quality of connected AP.

Signal Strength Signal strength of connected AP.

Noise Level Noise level of connected AP.

 The HT section only appears when connected with 802.11n AP.

Type Description

BW Channel Bandwidth. 20MHz or 40MHz.

GI

STBC Supported only when value of MCS is 0-7.

MCS Shows link rate.

SNR Shows the receiving signal strength.

Guard Interval Long: 800nsec, Short: 400nsec

2.4.11. Site Survey

 Site Survey searches for AP surrounding WizFi630.  Select an AP and click the connect button (If the module is rebooted, the module will connect to

the previous profile).

 Click “Add Profile” if user wishes to add to profile.

Type Description

SSID SSID of searched AP

BSSID Wireless MAC Address of searched AP.

RSSI Signal strength of searched AP.

Channel Channel of searched AP.

Encryption Encryption method of searched AP.

Authentication Authentication method of searched AP.

Network Type

Connected SSID of AP connected with WizFi630.

Connect Connects with AP.

Rescan Rescans for surrounding AP.

Add Profile Adds to profile.

Network type of searched AP. In: Infrastructure, Ad: ad-hoc

2.4.12. WIFI Multi-Bridge settings

 Set WI-FI Multi Bridge Mode in AP-Client mode.

Type Description

Operation Mode

SSID

Frequency

(Channel)

MAC Address

Security

Select Gateway or Bridge Mode. Wi-Fi is WAN: operates in Gateway Mode. Multi-Bridge Mode: operates in Bridge Mode.

SSID of AP to be connected.

Channel of AP to be connected.

MAC Address of AP to be connected. (optional)

Select the same security option with AP to be connected.

2.5. Serial to LAN(Wired and Wireless)

 Individual settings for serial #1 and serial #2 are possible.  Set the serial parameters for serial to wireless (Ethernet) function.  Set two channels (Main connection, Aux connection) for each serial port  Setting management of Serial #1 and #2 (Main connection, Aux connection)

2.5.1. Main Connection settings

Type Description

Status

Protocol

Mode

Server IP

Server Port

Reconnect Interval

Connection

Baud rate

Enable checked : Serial to LAN is used. Enable un-check: Serial to LAN is not used.

Protocol used in Serial to LAN communication

-TCP

-UDP

Serial to LAN operation mode. ( Client Mode recommended)

- Server : waits for connection.

- Client : connected to the remote server of WizFi630

- Mixed : not recommended

Enter the IP address for WizFi630 setting.

Enter the port number for remote serial data server host PC.

Interval of TCP reconnection.

Connection Type of WizFi630’s Serial LAN. ( TCP Only ) System Bootup : connected to the remote server upon bootup. Serial Data In : once serial data comes in, connect to remote server. (end connection after inactive time)

Select the serial communication speed.

Databits

Parity

Stopbits

FlowControl

Select the databits.

Select the method for parity check.

Select the stopbits.

Select the method for flow control. (Option: none, Xon/Xoff, RTS/CTS)

2.5.2. Aux Connection Settings

Type Description

Status

Protocol

Mode

Server IP

Server Port

Select whether to enable serial port or not.

Protocol used in Serial to LAN communication.

Select Server or Client Mode.

Enter the IP address for WizFi630 setting.

Enter the port number for remote serial data server host PC.

2.5.3. Packing Condition (Incoming serial data packing condition)

Type Description

Time

Size

Character

Inactivity Time:

H/W CMD switch

Data packing until the set time and then sent to server after the set time.

Data packing until the set size and then sent to the server.

Data packing until the set character and then sent to the server.

TCP/IP connection is discontinued if there is neither serial data nor network data during the set time.

-. Enable/Disable the H/W CMD switch pin.

-. H/W CMD switch pin is the switch for sending commands from CPU to WizFi630.

2.5.4. Ethernet Data Tagging Option

This option is used to help serial device to identify who is the received serial data’s source; the

received serial data comes from Main Port or Aux Port.

Type Description

Status

Main Port

Aux Port

Enable or disable this option (Checked : Enable, Un-Check : Disable)

Before sending data from Main port to serial port, WizFi630 added a TAG in the front of payload. For example: In-come LAN Data : “abcdegf” Output data to Serial Port : “!MAIN!abcdegf”

Before sending data from Aux port to serial port, WizFi630 added a TAG in the front of payload. For example: In-come LAN Data : “abcdegf” Output data to Serial Port : “!AUX!abcdegf”

2.6. Firewall settings

2.6.1. DMZ

 Enable/Disable DMZ function.  A DMZ allows a single computer on your LAN to expose ALL of its unused ports to the Internet.

When doing this, the exposed computer is no longer behind the firewall.

 Sometimes TCP/IP applications require very specialized IP configurations that are difficult to set up

or not supported by your router. In this case, placing your computer in the DMZ is the only way to

get the application working.

Type Description

DMZ Settings

DMZ IP Address

Disable/Enable DMZ

Input the IP address that you would like to expose all of its unused ports to the Internet

2.6.2. Port forwarding

When a computer on the internet sends data to the external IP address of the router (WizFi630), the

router (WizFi630) needs to know what to do with the data. Port Forwarding simply tells the WizFi630

which computer on the local area network to send the data to. When you have port forwarding rules

set up, your router takes the data off of the external IP address:port number and sends that data to an

internal IP address:port number. Port Forwarding rules are created per port. Thus, a rule set up for

port 53 will only work for port 53.

Type Description

Port Forwarding

IP Address

Service Port

Protocol

Internal Port

Disable/Enable Port Forwarding

Internal IP address

External ports range

Supports TCP and UDP

Internal port

2.6.3. Packet filtering

 WizFi630 can accept or block Internet packets according to pre-defined MAC or IP address  First, please do the basic settings

Type Description

Source MAC

Dest IP Address

Source IP Address

Protocol

Dest Port Range

Source Port Range

Action

Pre-defined source MAC address for MAC filtering function

Destination IP address

Source IP address

Supports TCP, UDP, ICMP

Destination port range

Source port range

Enable/Disable MAC/IP/Port filtering function

2.6.4. Contents filtering

 Used to block certain websites (IP or domain names).

Type Description

Block all the websites whose domain is the input text

URL Filter

Host Filter

For example, if you input “sex”, the websites like www.sex.com

www.sexgood.com

domain name contains the input text, please use Host Filter function

Block all the websites whose domain name contains the input text. For example, if you input “game”, the websites like www.hangame.com, www.hangame.co.kr are blocked

is not blocked. If you would like to block all the websites whose

is blocked. But

2.6.5. System Security

 Defense from external attack.

Type Description

Remote management

Telnet management

Ping from WAN Filter

Broadcast Storm filter

Block Port Scan

Block SYN Flood

Settings about accessing methods from WAN to WizFi630’s embedded web server

Settings about accessing methods from WAN to WizFi630’s telnet

Disable/Enable the WizFi630’s Ping response

Block/Accept the Broadcast packets

Block WizFi630’s port-scan function

Block SYN flood

2.7. Managements

2.7.1. System Management

Type Description

Language

Administrator

NTP

(Network Time

Protocol)

Green AP

DDNS

Provider

Account

Password

DDNS

Select language in the list

Pre-defined ID/Password for webpage or Telnet login

Set NTP server

Low power consumptive AP

Once the DDNS server registers yours MAC address, your device can connect to the internet regardless of your address. DDNS service can be provided by DynDNS, freeDNS, zoneedit, no-ip. To use DynDNS, users should go to www.dyndns.org to create user name and domain name. And then, set related configurations by using WizFi630’s webpage. Similarly, to use freeDNS zoneedit, or no-ip,users should go to their homepage first to create user name and domain name. And then, set related configurations by using WizFi630’s webpage.

DynDNS, freeDNS, zoneedit, no-ip

ID for DDNS.

Password for DDNS

Host name for DDNS

2.7.2. Firmware

 Upgrade firmware and bootloader.  WizFi630 do not support upgrading by Remote URL..

2.7.3. Config Settings

 Save the setting value of WizFi630 to the PC.

Type Description

Export Settings

Import Settings

Logo Export Settings

Logo Import Settings

Load Factory Defaults

Reboot

The setting files from the PC file are applied to the module.

The system’s setting information is saved as a file in the PC.

User’s company logo file is saved in the PC.

User’s company logo from the PC is applied to the system. ( GIF file size : 10K , 126x42)

Change the module’s setting to default setting.

Reboots the system.

2.7.4. Port Setting

 Settings about wired port. In case of Gateway Mode, WAN port is set here  In case of Gateway Mode, it is better to use the default WAN port number (Port #0)  If you are not the administrator, we do not recommend changing this.

Type Description

WAN Port Select the WAN Port in case of Gateway Mode.

Port #0 Enable / Disable Port #0.

Port #1 Enable / Disable Port #1.

Port #2 Enable / Disable Port #2.

Port #3 Enable / Disable Port #3.

Port #4 Enable / Disable Port #4.

2.7.5. Packet Statistics

 System Statistics shows the system’s memory information and system’s data transmission size.

Type Description

Memory Total System Memory Size

Memory left System Free Memory

Rx Packet Rx Packets counts

Rx Byte Rx Bytes Counts

Tx Packet Tx Packet Counts

Tx Byte Tx Bytes Counts

2.7.6. System Status

System Status shows the status of the system, status of the system’s network information, and the link

status of LAN port.

Type Description

F/W Version Shows the firmware version. System Up Time Shows the system up time. Operation Mode Shows the operation mode currently being used.

Internet Configuration Shows the internet configuration information.

Local Network Shows the local network information.

2.7.7. System Log

 The operation history of WizFi630 can be checked by using System Log.  If the system log exceeds 24Kbyte, more recent log record is added.

3. Hardware Information

3.1. WizFi630 Pin Map

No T Name Shared Description

1 GND 2 3.3V 3 GND 4 3.3V 5 I/O, IPD CTS_N GPIO9 UART1 CTS-N 6 I/O, IPD RTS_N GPIO7 UART1 RTS-N 7 I/O, IPD RIN GPIO14 UART1 RIN 8 I/O, IPD DTR_N GPIO11 UART1 DTR-N

9 I/O, IPD RxD GPIO10 UART1 RXD 10 I/O, IPD TxD GPIO8 UART1 TXD 11 I/O, IPD DSR_N GPIO13 UART1 DSR-N 12 I/O, IPD DCD_N GPIO12 UART1 DCD-N 13 O WLAN_LED Wireless Init On/ Active Data:blinking 14 NC 15 I/O VBUS USB OTG VBUS pin;Connect VBUS pin of the USB 16 NC 17 I/O PADP USB OTG data pin Data+ 18 I/O, IPD UART_RX UART2 RxD 19 I/O PADM USB OTG data pin Data- 20 I/O, IPD UART_TX UART2 TxD 21 O TXOP0 10/100 PHY Port #0 TXP 22 I RXIM0 10/100 PHY Port #0 RXN 23 O TXOM0 10/100 PHY Port #0 TXN 24 I RXIP0 10/100 PHY Port #0 RXP 25 I RXIM1 10/100 PHY Port #1 RXN 26 O TXOP1 10/100 PHY Port #1 TXP 27 I RXIP1 10/100 PHY Port #1 RXP 28 O TXOM1 10/100 PHY Port #1 TXN 29 I RXIP2 10/100 PHY Port #2 RXP 30 O TXOM2 10/100 PHY Port #2 TXN 31 I RXIM2 10/100 PHY Port #2 RXN 32 O TXOP2 10/100 PHY Port #2 TXP 33 O LINK_LED_0 LAN port 0 Link LED 34 O LINK_LED_2 LAN port 2 Link LED 35 O LINK_LED_1 LAN port 1 Link LED 36 I/O, IPD GPIO0 WPS Button Push 37 I, IPU CPURST_N 38 I/O, IPD EJT_TDO Reset Button Push(GPIO17)

39 I/O, IPD EJT_TRSTN GPIO21 UART2 Tx/Rx LED 40 I/O, IPD EJT_TMS Serial Command Mode #1(GPIO19) 41 I/O, IPD EJT_TDI GPIO18 UART1 Tx/Rx LED 42 I/O, IPD EJT_TCK WPS LED(GPIO20) 43 NC 44 NC 45 NC 46 NC 47 I/O, IPD I2C_SCLK Serial Command Mode #2(GPIO2) 48 I/O, IPD I2C_SD RUN LED(GPIO1) 49 GND 50 3.3V 51 GND 52 3.3V

Table 1. WizFi630 Pin Map

3.2. Dimensions

4. Important Notice

WIZnet reserves the right to make corrections, modifications, enhancements, improvements and other

changes to its products and services at any time, and to discontinue any product or service without

notice. Customers should obtain the latest relevant information before placing orders, and should

verify that such information is current and complete. All products are sold subject to WIZnet’s terms

and conditions of sale, supplied at the time of order acknowledgment. Information relating to device

applications, and the like, is intended as suggestion only and may be superseded by updates. It is the

customer’s responsibility to ensure that their application meets their own specifications. WIZnet makes

no representation and gives no warranty relating to advice, support or customer product design.

WIZnet assumes no responsibilities or liabilities for the use of any of its products, conveys no license

or title under any patent, copyright or mask work rights to these products, and makes no

representations or warranties that these products are free from patent, copyright or mask work

infringement, unless otherwise specified.

WIZnet products are not intended for use in life support systems/appliances or any systems where

product malfunction can reasonably be expected to result in personal injury, death, severe property

damage or environmental damage. WIZnet customers using or selling WIZnet products for use in such

applications do so at their own risk and agree to fully indemnify WIZnet for any damages resulting

from such use.

All trademarks are the property of their respective owners.

FCC Certification Requirements

Caution:

approved by the party responsible for compliance could void the user's authority to operate the

equipment.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired

operation.

NOTE:

unauthorized modifications to this equipment. Such modifications could void the user’s authority to

operate the equipment.

NOTE:

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates uses and

can radiate radio frequency energy and, if not installed and used in accordance with the instructions

may cause harmful interference to radio communications.

Any changes or modifications in construction of this device which are not expressly

The manufacturer is not responsible for any radio or TV interference caused by

This equipment has been tested and found to comply with the limits for a Class B digital

However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

-Consult the dealer or an experienced radio/TV technician for help.

WARNING: This equipment may generate or use radio frequency energy. Changes or modifications

to this equipment may cause harmful interference unless the modifications are expressly approved in

the instruction manual. The user could lose the authority to operate this equipment if an unauthorized

change or modification is made.

This device complies with Part 15 of the FCC rules. Operation is subject to following two conditions: 1.

this device may not cause harmful interference and 2. This device must accept any interference

received including interference that may cause undesired Operation of this device.

The changes or modifications not expressly approved by the party responsible for Compliance could

void the user’s authority to operate the equipment.

To comply with the FCC RF exposure compliance requirements, this device and its antenna must not

be co-located or operating to conjunction with any other antenna or transmitter, except if installed in

compliance with FCC Multi Transmitter procedures.

To inherit the modular approval, the antennas for this transmitter must be installed to provide a

separation distance of 20cm from all persons and must not be co-located or operating in Conjunction

with any other antenna or transmitter.

Note:

Pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable Protection against harmful interference in a residential

installation. This equipment generates Uses and can radiate radio frequency energy and, if not

installed and used in accordance With the instructions, may cause harmful interference to radio

communications.

However, there is no guarantee that interference, Will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an Outlet on a circuit different from that to which the receiver is

connected.

This equipment has been tested and found to comply with the limits for a Class B digital device,

To OEM Installer

1. FCC ID on the final system must be labeled with “Contains FCC ID: XR2WIZ63OWI” and

“Contains transmitter Module FCC ID: XR2WIZ63OWI “

2. In the user manual, final system integrator must ensure that there is no instruction provided in the

user Manual to install or remove the transmitter module.

3. Transmitter module must be installed used in strict accordance with the Manufacturer’s instructions

as described in the user documentation that comes with the product. The user manual of the final

host system must contain the following statements: This device complies with Part 15 of the FCC rules.

Operation is subject to following

Two conditions: 1. this device may not cause harmful interference and 2. This device Must accept any

interference received including interference that may cause undesired operation of this device.

The changes or modifications not expressly approved by the party responsible for

Compliance could void the user’s authority to operate the equipment.

To comply with the FCC RF exposure compliance requirements, this device and its antenna must not

be co-located or operating to conjunction with any other antenna or transmitter, except if installed In

compliance with FCC Multi Transmitter procedures.

To inherit the modular approval, the antennas for this transmitter must be installed to provide a

Separation distance of at least 20cm from all persons and must not be co-located or operating in

Conjunction with any other antenna or transmitter.

Note:

The buyer of the module who will incorporate this module into his host must submit the final product

to the Manufacturer of the module and the MANUFACTURER OF THE MODULE WILL VERIFY that the

product is incorporated in host equipment in a way that is represented by the testing as shown in the

test report.

Note:

The module is used AP, Gateway, Household. (except PC.)

FCC RF Radiation Exposure Statement

This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled

environment. This device and its antenna must not be co-located or operating in conjunction with any

other antenna or transmitter.

“To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile

Configurations. The antennas used for this transmitter must be installed to provide a separation

distance of at least 20 cm from all persons and must not be co-located or operating in conjunction

with any other antenna or transmitter.”

Manual Information to the End User

he OEM integrator has to be aware not to provide information to the end user regarding how to

T

install or remove this RF module in the user’s manual of the end product which integrates this module.

The end user manual shall include all required regulatory information/warning as show in this manual.

Note:

1. The module is limited to OEM installation ONLY.

2. The module is limited to installation in mobile or fixed applications.

3. Separate approval is required for all other operating configurations,

including portable configuration with respect to Part 2.1093 and different

antenna configuration.

WIZNET WIZ63OWI Users Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
