Witti Beddi Glow User Manual

Instruction Manual

for

BEDDI Glow

Ver. 5 20/3/2017

BEDDI Glow Instruction Manual

Understanding BEDDI Glow Controls

Smart Button ‒ You can customize the smart button via the App to trigger commands such

1

as “phone finder”, “play Spotify music”, etc. The Button has three modes ‒ single press,
double press, and long press.

Light Mode Button ‒ You can customize the Light Mode button via the App to trigger commands such

2

as “Mood Light On/Off”, “Turn on the Fade mooding”, etc. The Button has three modes ‒ single press,
double press, and long press.

Snooze/Dimmer ‒ Press to snooze the alarm, or to adjust the clock brightness.

3

Long Press to wake up the clock face for 5s (Support on Firmware v3.1.2 or later)

Play/Pause/Alarm off | Bluetooth button ‒ Play/pause when music is playing. Turn off alarm.

4

Long press to connect/disconnect Bluetooth audio.

Volume Control ‒ Let you adjust the volume when music is playing. Can be used to skip tracks in

5

advance control mode (configurable in app General Settings).

Bluetooth (Audio) status light ‒ If Bluetooth audio is connected, the status light will be on.

6

The Bluetooth control (BLE) is always connected when in range (unless your phone’s Bluetooth is off,
or BEDDI app is not running).

High Quality Speaker

7

Limited Warranty 1 year

http://www.wittidesign.com/warranty

The WITTI logo and BEDDI are trademarks of D&S Creation Limited. All other trademarks are properties of their respective owners.

Assembled in China www.wittidesign.com ©2017 D&S Creation Ltd. All Rights Reserved

Page: 1/6

8

Mood Light ︳Wake up Light ‒ 16 Million Color mood light with various light effects. You can press
the Light mode button to turn it on/off. Settings can be customized via app.
Wake Up light ‒ Warm white light mimics sunlight in the morning to wake you up gradually, and
peacefully. You can press the Light mode button to turn it on/off. Settings can be customized via app.

9

10

11

Service Port ‒ This is only needed if firmware update is required.

5V 3A Power Input ‒ Plug in the provided adaptor.

Aux in/FM Antenna ‒ Plug in the provided FM Antenna if you wish to listen to FM radio, or use as
Aux in port (Aux in cable not included).

12

2x USB Charging Port 2A share ‒ Charge your phone/tablet or other devices.

Setting Up BEDDI Glow

Plug in the BEDDI Glow with the provided power adaptor
Download the BEDDI Glow app on iOS or Android (keyword: BEDDI)
Run the BEDDI app, and follow the setup wizard to configure your BEDDI Glow

Setting the Time

BEDDI Glow time is automatically synced to your smartphone once you are connected

Connecting Bluetooth

BEDDI Glow has two Bluetooth connections. Bluetooth Classic (Audio) for playing your music,
and Bluetooth Low Energy (BLE) for controlling your phone.

Bluetooth Audio

After pairing the first time, you can press and hold the “play/pause” button to connect to BEDDI Glow when in
range.
The Bluetooth indicator light will start flashing when BEDDI Glow is trying to connect to your phone, and
will stay on once it is connected.
User can also connect using the phone Bluetooth settings. Please note that BEDDI Glow Bluetooth is always on
and waiting for connection.

Bluetooth Control

BEDDI Glow uses BLE for control. Once your app is connected to BEDDI Glow, it remains connected as long as
your phone is in range, unless you a) turn off your Bluetooth on your phone, b) stop the BEDDI App, or c) use
the app to disconnect the connection.
Please note that the BLE connection must be active for some of the smart functions to work (i.e., Spotify
as your alarm sound, weather, traffic update.

Limited Warranty 1 year http://www.wittidesign.com/warranty

The WITTI logo and BEDDI are trademarks of D&S Creation Limited. All other trademarks are properties of their respective owners.

Assembled in China www.wittidesign.com ©2017 D&S Creation Ltd. All Rights Reserved

Page: 2/6
