Page 1
Conductor Bare Copper
Construction 1,13
Stranded Dia. (+/-0.02mm) 1,13
Insulation Layer Gas Injection Foam PE
Thickness(mm) 1,835
Insulation Dia. (±0.15mm) 4,80
Insulation Color Nature
Al-Foil-Al Shielded >=120%
Thickness(µ) 9/23/9
Construction 0.12Al×16×8
Braid Coverage(%) 80%
Mylar Spiral >=115%
Inner Jacket PVC
Thickness(mm) >=0.85
Dia.(±0.15mm) Jacket Color
6.80 × 4C
Red/White/Grey/Blue
Total Mylar Spiral >=115%
A Rip Cord 500D
Outer Jacket PVC
Thickness(mm) >=1.10
Dia.(±0.30mm) Jacket Color 18,30
White
Min. Bending radius 10× OD
Quattrokabel
Design
Part NO:
Product Code: KA-077-2
Product Description
Application:
For communication and signal control systems.
Reference Standard
Customer's sample spec.and the general standard
Electrical Characteristics
Multi-construction
Max.Conductor DC Resistance at 20℃（Ω/Km）
Min.Insulation DC Resistance at 20 ℃（MΩ*Km） Rated
Temperature(℃)
Rated Voltage(V) Velocity ratio (%) Impedance(Ω)
Capacitance(pF/m)
1
Cable Construction
1 Singles
Attenuation at 20℃ ( - dB/100m) (+/-10%)
50 MHz
100 MHz
200 MHz
300 MHz
470 MHz
860 MHz
1000 MHz
1350 MHz
1750 MHz
2050 MHz
2250 MHz
2400 MHz
SCREENING EFFECTIVENESS ( - dB) 50-1000MHz
1000-2400MHz
Braiding(mm)
Return loss ( - dB/100m)
5 1000 MHz
1000 2000 MHz
2000 ---- 3000 MHz
Marking (For KTH)
RoHS GUIDELINE
KTH 79 class A +xxxxM…….
We operate according to the following standards
PACKAGING
250M/Wooden Drum
500M/Wooden Drum
According to customer
A0-1
Page 2
Revision History
Page 3
>30
>27
>25
<19.2
>1000
70
30
80%
75
50
4,00
4,90
7,20
9,10
11,60
16,90
18,90
22,20
26,60
28,20
29,50
31,40
>95
>90
