Wittco 1826-7-DBL-IS Specifications

UL Listed to Canadian safety standards

Classified by UL to NSF Std. #4

Specifications

Wittco Model 1826-7-DBL-IS heated holding and
transport cabinets feature two ( 2 ) separately
controlled compartments in one ( 1 ) f ull size cabinet.
Blower motor for gentle and even temperature
distribution
swivel with brakes and 2 rigid ) . Each compartment
has a recessed control panel containing dual indicator
light, thermometer, and full range thermostat for
temperatures up to 190ºF ( 8 8ºC ) . Individual
compartment capacity is 7 each 18 ” x 26 ” sheet
pans, 14 each 12 ” x 20 ” x 2½ ” steam table pans, or
a combination of both on 3” centers. Each
compartment comes with 5 pairs of universal tray slides
adjustable on 1½ ” centers. Cabinet interior and
exterior are both constructed out of 20 gauge stainless
steel. Recessed side-mounted push/pull handles,
magnetic action door latch, and full insulation; 1½ ” in
side walls and 2 ” in top. Welded tubular steel frame
for maximum strength. Lifetime warranty on heating
elements. Complete with cord and plug: NEMA 5-20
for 120 volts and NEMA 6-20 for 208-240 volts. 120
Volts, 1,000 Watts, 8.3 Amps per compartment

. Complete with 5 ” heavy duty casters ( 2

Item#

MODEL 1826-7-DBL-IS

Holding & Transport Cabinets

Standard Features

• Holding and Transport Cabinet with two ( 2 )
compartments. Each compartment has the following
capacity

7each 18 ” x 26 ” sheet pans
14 each 12 ” x 20 ” x 2½” pans
Or a combination of both on 3 ” centers

• Blower motor for gentle and even temperature
distribution

• 5 ” Heavy duty casters ( 2 with swivel with brakes
and 2 rigid )

• Recessed side mounted push/pull handles

• Two ( 2 ) recessed control panels

• Two ( 2 ) dual indicator

• Two ( 2 ) thermometers

• Two ( 2 ) full range thermostats for temperatures up

to 190ºF ( 88ºC )

• 5 Pairs of universal tray slides adjustable on 1½ ”
centers per compartment

• Interior and exterior are both constructed out of 20
gauge stainless steel

• Fully insulated with 1½ ” in side walls and 2 ” in top

• Welded tubular steel frame for maximum strength

• Magnetic action door latches

• Lifetime warranty on heating elements

• Complete with cord and plug: NEMA 5-20 for 120

volts and NEMA 6-20 for 208-240 volts

• 120 Volts, 1,000 Watts, 8.3 Amps per compartment

Options

• Left hand hinged door

• Additional universal tray slides

• Humidity pan

• Full perimeter bumper

• Cord wrap

• Glass Doors

Approved by:

Holding & Transport Cabinets Model 1826-7-DBL-IS

Wittco Foodservice Equipment 7737 N 81st Street Milwaukee, WI 53223 USA

F-41060 ( 09/10)

Date:

414-354-3080 800-367-8413 FAX [phone]

MODEL 1826-7-DBL-IS

Holding & Transport Cabinets

Holding & Transport Cabinets Model 1826-7-DBL-IS

Capacity Per

Compartment

Model No

1826-7-DBL-IS 14 7

12 ” x 20 ” x2½ ”

Note: In line with its policy to continually improve its products, Wittco Foodservice Equipment

reserves the right to change materials and specifications without notice.

Wittco Foodservice Equipment 7737 N 81st Street Milwaukee, WI 53223 USA

F-41060 ( 09/10)

Capacity Per

Compartment

18 ” x 26 ” High Deep Wide

72.5 ”

1852mm

31.75 ”

807mm

24.75 ”

629mm

Shipping

Weight

342#

155kg

Volts Per

Compartment

120 1000 8.3

Compartment

414-354-3080 800-367-8413 FAX [phone]

© 2009 Wittco Foodservice Equipment

Watts Per

Amps Per

Compartment

Printed in the USA
