Wittco 1826-5-BC-IS Specifications

UL Listed to Canadian safety standards

Classified by UL to NSF Std. #4

Specifications

Wittco Model 1826-5-BC-IS heated holding and
transport cabinets. Blower motor for gentle and even
temperature distribution. Complete with full perimeter
bumper and 5 ” heavy duty casters ( 2 swivel with
brakes and 2 rigid ) . Recessed control panel
containing dual indicator light, thermometer, and full
range thermostat for temperatures up to 190ºF
( 8 8ºC ) . Cabinet capacity is 5 each 18 ” x 26 ” sheet
pans, 10 each 12 ” x 20 ” x 2½ ” steam table pans, or
a combination of both on 3” centers. Complete with 3
pairs of universal tray slides adjustable on 1½ ”
centers. Cabinet interior and exterior are both
constructed out of 20 gauge stainless steel. Recessed
side-mounted lift handles, magnetic action door latch,
and full insulation; 1½ ” in side walls and 2 ” in top.
Welded tubular steel frame for maximum strength.
Lifetime warranty on heating elements. Complete with
top mounted cord, cord wrap, and plug: NEMA 5-15 for
120 volts and NEMA 6-15 for 208-240 volts. 120 volts,
1,200 watts, 10 amps.

Item#

MODEL 1826-5-BC-IS

Holding & Transport Cabinets

Standard Features

• Holding and Transport Capacity
5 each 18 ” x 26 ” sheet pans
10 each 12 ” x 20 ” x 2½” pans
Or a combination of both on 3 ” centers

• Blower motor for gentle and even temperature
distribution

• Full perimeter bumper

• 5 ” Heavy duty casters ( 2 with swivel with brakes

and 2 rigid )

• Recessed side mounted lift handles

• Recessed control panel

• Dual indicator lights

• Thermometer

• Full range thermostat for temperatures up to 190ºF

(88ºC)

• 3 Pairs of universal tray slides adjustable on 1½ ”
centers

• Interior and exterior are both constructed out of 20
gauge stainless steel

• Fully insulated with 1½ ” in side walls and 2 ” in top

• Welded tubular steel frame for maximum strength

• Magnetic action door latch

• Lifetime warranty on heating elements

• Top mounted cord

• Complete with cord and plug: NEMA 5-15 for 120

volts and NEMA 6-15 for 208-240 volts

• 120 volts, 1,200 watts, 10 amps

• Cord wrap

Options

• 208/240 volts

• Left hand hinged door

• Additional universal tray slides

• Humidity pan

Approved by:

Date:

Holding & Transport Cabinets Model 1826-5BC-IS

Wittco Foodservice Equipment 7737 N 81st Street Milwaukee, WI 53223 USA

F-41131 ( 10/10)

414-354-3080 800-367-8413 FAX [phone]

MODEL 1826-5-BC-IS

Holding & Transport Cabinets

Holding & Transport Cabinets Model 1826-5-BC-IS

Capacity

Model No

1826-5-BC-IS 10 5

12 ” x 20 ” x2½ ”

Note: In line with its policy to continually improve its products, Wittco Foodservice Equipment

reserves the right to change materials and specifications without notice.

Wittco Foodservice Equipment 7737 N 81st Street Milwaukee, WI 53223 USA

F-41131 ( 10/10)

Capacity

18 ” x 26 ” High Deep Wide

33.5 ”

851mm

33.75 ”

857mm

29 ”

737mm

Shipping

Weight Volts Watts Amps

201#

91kg

120 1200 10

414-354-3080 800-367-8413 FAX [phone]

© 2009 Wittco Foodservice Equipment

Printed in the USA
