Wittco 1220-7-BC Specifications

Model 1220-7-BC

UL Listed to Canadian safety standards

Classified by UL to NSF Std. #4

Specifications

Wittco Model 1220-7-BC heated holding and transport
cabinets with a narrow footprint designed specifically to

hold 7 each 12 ” x20 ” x2½” pans on fixed racking.

Blower motor for gentle and even temperature
distribution. A full perimeter bumper and 5 ” heavy
duty casters ( 2 swivel with brakes and 2 rigid ) are
standard. Recessed control panel containing dual
indicator light, thermometer, and full range thermostat
for temperatures up to 190ºF ( 88ºC ) . Cabinet
interior and exterior are both constructed out of 20
gauge stainless steel. Recessed side-mounted lift
handles, magnetic action door latch, and full insulation;
1½ ” in side walls and 2 ” in top. Welded tubular steel
frame for maximum strength. Lifetime warranty on
heating elements. Complete with top mounted cord,
cord wrap, and plug: NEMA 5-15 for 120 volts and
NEMA 6-15 for 208-240 volts. 120 volts, 600 watts, 5
amps.

Item#

MODEL 1220-7-BC

Holding & Transport Cabinets

Models:

• 1220-7-BC ( Bumper & Casters )

Standard Features

• Holding and Transport Capacity
Narrow footprint designed specifically to hold

7 each 12 ” x 20 ” x2½ ” pans on fixed racking

• Blower motor for gentle and even temperature
distribution

• A full perimeter bumper and 5 ” heavy duty casters
( 2 swivel with brakes and 2 rigid ) Recessed side
mounted lift handles

• Recessed control panel

• Dual indicator lights

• Thermometer

• Full range thermostat for temperatures up to 190ºF

(88ºC)

• Interior and exterior are both constructed out of 20
gauge stainless steel

• Fully insulated with 1½ ” in side walls and 2 ” in top

• Welded tubular steel frame for maximum strength

• Magnetic action door latches

• Lifetime warranty on heating elements

• Top mounted cord

• Cord Wrap

• Complete with cord and plug: NEMA 5-15 for 120

volts and NEMA 6-15 for 208-240 volts

• 120 volts, 600 watts, 5 amps

Options

• 208/240 volts

• Left hand hinged door

• Humidity pan

Approved by:

Holding & Transport Cabinets Model 1220-7-bc

Wittco Foodservice Equipment 7737 N 81st Street Milwaukee, WI 53223 USA

F-41036 ( 09/10)

Date:

414-354-3080 800-367-8413 FAX [phone]

MODEL 1220-7

Holding & Transport Cabinets

Holding & Transport Cabinets Model 1220-7-BC

Model No

1220-7-BC 7

Note: In line with its policy to continually improve its products, Wittco Foodservice Equipment

12 ” x 20 ” x2 ½ ” High Deep Wide

reserves the right to change materials and specifications without notice.

Wittco Foodservice Equipment 7737 N 81st Street Milwaukee, WI 53223 USA

F-41036 ( 09/10)

Capacity

36.75 ”

933mm

26.75 ”

679mm

21 ”

533mm

Shipping

Weight Volts Watts Amps

140#

64kg

414-354-3080 800-367-8413 FAX [phone]

© 2009 Wittco Foodservice Equipment

120 600 5

Printed in the USA
