Bluetooth wireless technology allows you to connect
compatible communication devices without cables.
A Bluetooth connection does not require that the phone
and the headset be in line of sight, but both devices should
be within 10meters(33 feet) of each other. Connections can
be subject to interference from obstructions, such as walls,
or other electronic devices.
The headset is compliant with the Bluetooth Specification
2.0 supporting the following profiles : headset profile and
Hands-Free Profile. Check with the manufacturers of other
devices to determine their compatibility with this device.
There may be restrictions on using Bluetooth technology in
some locations. Check with your authorities or service
provider.
3
User ManualHand strap
CradleEarloop pack(option)
Car Holder
Travel Charger
Extra Ear-rubber
(Small, Large)
Headset
2
WB120 PACKAGE CONTENTSINTRODUCTION
Bluetooth wireless technology
1
Make sure that your headset is fully charged
before you start using it.
2
Plug the charger cable into the Charging
Socket.
-
The red LED turns on when the headset is charging (If the
headset is completely discharged, It may take a couple of
minutes for the LED to turn on). When the headset is fully
charged (about 2hours), The red LED turns off.
-
When battery power is low, the red LED starts to flash and
you can hear beep.
54
WB120 Overview
Charge your Headset
GETTING STARTED
To turning on : Press and hold for 3 seconds the call button
until the LED flashes Blue.
To turning off : Press and hold for 5 seconds the Call Button
until the LED flashes Red.
Before you use the headset, you need to pair it
with your phone.
1
Turing on the headset.
2
Fold the earpiece and then you can see the
LED flashes alternately Blue and Red.
3
When the LED starts to flash‘Blue and RedF,
set your phone to discover “ WB120”
76
Pair it with your phone
Turning your headset on and off
3 sec
5 sec
1
To wear the headset, Fold the
earpiece.
2
Plug the headset into your ear and
point the headset toward your
mouth.
For optimal performance, wear the
Headset and your phone on the same
side of your body.
4
Set your Bluetooth phone to discover the
WB120
A) Follow your phone instruction guide
•
Going to Bluetooth menu on your phone and selecting the
option todiscoverorconnecta Bluetooth device
(and select theHandsfree mode if your phone ask).
B) Your phone will find theWB120
•
If you want to pair with it, pressYESorOKon the phone.
•
Enter the passkey or PIN = 0000(4 zeros) and press
YESorOKon the phone.
•
Once connected to your Bluetooth phone, The LED flashes
Blue.
•
Your headset is now set up and ready to be used.
98
Wearing the Headset
1) It is better to try pair your headset with the phone close-by.
2) Once you have paired your headset with the phone, You
dont need to pair it again until you want to use it with
another phone.
3) In case of unsuccessful pairing, repeat steps 2 to 3.
4) Blue and Red flashing (Pairing Mode) will return to Standby mode (the LED flashes Blue) if not paired in 10minutes.
Note
Pair it with your phone
1110
Using your Headset
1
Hold
Call button is locked when the earpiece is unfolded.
It can prevent unwished call.
All the functions except power On/Off do not work
in “Hold” Mode.
Hold Mode
2
Answer a call
Fold the earpiece or tap the call button to answer
an incoming call.
3
End a call
Unfold the earpiece or tap the call button to end
an active call.
1312
Using your Headset
7
Reject a call (Phone dependent)
Press and hold for 2 seconds the Call Button when the
phone rings to reject an incoming call.
6
Activate voice dialing (Phone dependent)
1) Tap the Call Button.
2) You can hear the Audio signal.
3) Speak the name of the person that you want to call.
※
To cancel Voice Dialing, Tap the Call Button.
※
Please consult your phone's user manual for more information
about using this feature.
5
Adjust Volume
Press the Volume Up or Down Button to adjust the volume
4
Make a call
Enter number on your phone and press send, and the call
is automatically transferred to the headset. If your phone
does not support this function, Press and hold for 2 seconds
the Call Button after entering number on your phone.
2s
1514
Using your Headset
Some features are phone/network dependent. See
your phone s user manual for more information
Note
12
Transfer an active call
From the phone to the headset : Press and hold for 3
seconds the Call Button during a call.
From the headset to the phone : Press and hold for 3
seconds the Call Button during a call.
10
3way call (Phone dependent)
Press and hold for 6 seconds the volume up button
to place the active call on hold and answer the waiting call.
Press and hold for 6 seconds the volume up button
to switch between the two calls.
Press and hold for 6 seconds the volume down button
to end the active call.
11
Auto reconnection
After successful pairing, the headset automatically
reconnects to your phone when the headset is turned on.
8
Redial last call (Phone dependent)
Press and hold for 2 seconds to call back the last
number.
9
Mute a call
Mute on : Press and hold for 2 seconds the Volume up
or down Button
Mute off : Tap the Volume up or down Button
2s
2s
2
Hand strap
You can carry the headset with your phone
1) Hook on the cradle with the hand strap.
2) Tie to your phone with the hand strap.
The headset is supplied with a cradle, a hand
strap and a car holder. When you do not keep the
headset on your ear, you can carry it conveniently
using the Accessory.
1
Cradle
1716
1) Place the headset into the cradle until it locks and you
can put it on your shirt.
2) To release the headset, push down release point and
take the headset out.
3
Car Holder
1) Adhere the car holder to dashboard or proper place in your car.
2) Folding the earpiece and place the headset in the car holder.
Using Accessory
Push
18 19
Product Type
Bluetooth Version
Bluetooth Prole
Frequency Range
Dimension
Weight
Operating Range
Talking Time
Standby time
Charging
Battery
Charger Rated Input
Charger Rated Output
Bluetooth Mono Headset
Bluetooth 2.0
Headset & Hands-free prole
2402 ~ 2480 MHz
52 x 18 x 11 mm
9.8g
Up to 10meters (33feet)
Up to 5.5 hours(HV
3 Packet)
Operating Temperature
-20°C ~ 55°C
Up to 100 hours
2 hour/full charging
Rechargeable Li-Polymer
AC100~240V, 50/60Hz
DC 5.0V / 700mA
Specication
※
Talk Time and Standby time are dependent on phone models.
4
Changing faceplate
Two faceplates are provided.
As shown in the pictures, take the faceplate out and place
a faceplate.
Using Accessory
20
�
Keep all accessories and enhancements out of the reach of
small children.
�
Keep the device dry. Precipitation, humidity, and all types of
liquids or moisture can contain minerals that will corrode
electronic circuits. If your device does get wet, allow it to dry
completely.
�
Do not use or store the device in dusty, dirty areas. Its
moving parts and electronic components can be damaged.
�
Do not store the device in hot areas. High temperatures can
shorten the life of electronic devices, damaged batteries,
and warp or melt certain plastics.
�
Do not store the device in cold areas. When the device
returns to its normal temperature, moisture can from inside
the device and damage electronic circuit boards.
�
Do not attempt to open the device
�
Do not drop, knock, or shake the device. Rough handling
can break internal circuit boards and ne mechanics.
�
Do not use harsh chemicals, cleaning solvents, or strong
detergents to clean the device.
Taking care of your headset
Troubleshooting
If you cannot connect the headset to your phone,
do as follows :
�
Ensure that the headset is charged, switched on, and
paired with and connected to your phone.
�
Ensure that the Bluetooth feature is activated on your
phone.
�
Check that the headset is within 10 meters (33 feet) of
your phone and that there are no obstructions between
the headset and the phone, such as walls or other
electronic devices.
21
WARNING: This equipment may generate or use radio
frequency energy. Changes or modifications to this
equipment may cause harmful interference unless the
modifications are expressly approved in the instruction
manual. The user could lose the authority to operate this
equipment if an unauthorized change or modification is
made.
22
•
This warranty gives you specic rights and you may have other
rights which vary from area to area
•
Unless otherwise instructed in the User Guide, the user may
not, under any circumstances, attempt to perform service,
adjustments or repairs on this unit, whether in or out of
warranty. It must be returned the purchase point, factory or
authorized service agency for all such work
•
Wise & Blue will not assume any responsibility for any loss or
damage incurred in shipping. Any repair work on Wise & Blue
products unauthorized third parties voids any warranty
FCC
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:(1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation
CE
Hereby, Wise & Blue Co., Ltd. declares that this WB120 is in compliance
with the essential requirements and other relevant provisions of
directive 1999/5/EC.
Bluetooth
The Bluetooth word mark and logos are owned by the Bluetooth
SIG, Inc. and any use of such marks by Wise & Blue is under
license.
23
Wise & Blue warrants this product against all defects
in material and workmanship for period of one year
from the date of original purchase. The conditions of
this warranty and our responsibilities under this
warranty are as follows:
•
The warranty is limited to the original purchaser.
•
A copy of your receipt or other proof of purchase is required.
•
The warranty is void if the serial number, date code label or
product label is removed, or if the product has been subject to
physical abuse, improper installation, modication, or repair by
unauthorized parties
•
The responsibility of Wise & Blue products shall be limited to
the repair or replacement of the product at its sole discretion
•
Any implied warranty on Wise & Blue products is limited to one
year from the date of purchase on all parts, including any cords
and connectors
•
Specically exempt from any warranty are limited-life
consumable components subject to normal wear and tear,
such as microphone windscreens, ear cushions, decorative
nishes, batteries, and other accessories
•
Wise & Blue is not liable for any incidental or consequential
damages arising from the use or misuse of any Wise & Blue
product
Warranty
Certication
