Wire wizard HHSS Instruction Manual

Model HHSS
Handheld Contact
LCD Digital Wire Speed Sensor

Range and Accuracy

Using the master wheel and proper mode selector switch,
the following industrial units of measurement are achieved.

R: REVOLUTIONS SINGLE RANGE ACCURACY RESOLUTION

Contact RPM (rev./min.) 0.10 - 999.99 ± 0.06 0.01

Wire Feed >

Top View

Tension Knob >

Features

The Wire Wizard HHSS is a battery operated, handheld,
microprocessor- control led contact type tachometer. It
incorporates the latest micro-circuit technology and offers:

• Multi-mode capability – measures RPM, FPM, YPM, mPM

and other units without special accessories

• Large memory capacity

• Wide speed range with automatic floating decimal point

• C-MOS single chip microprocessor for high reliability and

low maintenance

• Rugged construction - die-cast aluminum housing

Specifications

HHSSLEDOM

Display Ran ge 0.10 to 25,000 rpm with fl oating decimal

Accuracy ±0.06 rpm: 0.10 t o 999.99 rpm

± 0.6 rpm: 1,000. 0 to 9,9 99.9 rpm

±0.006% of reading ±1 digit (or ±2rpm max.): 10,000 to 25,000 rpm

Display 5 digit 0.47" (12mm) high LCD

Measurin g Units Revolutions: RPH, RPM Feet: FP H, FPM Miles : MPH

Yards: YPH, YP M Inche s: IPM Meters: m PH, mPM

Length: m, cm, inches, feet, yards Total re volutions: REV

Memory System 13 read ings are stored in me mory and retain ed for

5 minute s (last, max., min. an d 10 e xtra mea surements)

Detection Optical coupler , 60 pulses/re v

System Con trol Single c hip C-MO S microp rocessor

Over Range Indica tor Flashing numer als

Update Time 1 seco nd (ty pical)

Batter ies Incl uded Size: 2 AA 1.5V

Life: Ap prox. 65 hrs

Low Voltage Indic ator Flashi ng “LO BAT” display

Operating Temperat ure 32° to 113°F (0° to 45°C)

Construction Die-cast aluminum housing

Weight 0.9 lbs (400g )

Dimensions 7.3"L x 2.4 "W x 1.8" H (185mm x 60mm x 45 .7mm)

Warranty 1 year

STANDARD ACCESSORIES 2 cone a dapters, 1 funnel adapter, 3-1/2" extensi on sha ft,

carrying case and 1 master wheel ( 6" cir. )

Contact RPH (rev./hour) 6 - 99,999 ±0.006% of reading ±1digit 1

REV (total revolution) 0.1 - 9,999.9 ± 0.1 0.1

F: FEET SINGLE RANGE ACCURACY RESOLUTION

F/M (feet/min) 0.05 - 999.99 ± 0.06 0.01

F/H (feet/hour) 3 - 99,999 ±0.006% of reading ±1digit 1

FT (length) 10.099.999 - 10.0

Y: YARDS SINGLE RANGE ACCURACY RESOLUTION

Y/M (yards/min.) 0.02 - 999.99 ± 0.06 0.01

Y/H (yards/hour) 1.0 - 9,999.9 ±0.6 0 .1

YRd (length) 500.0599.99 - 500.0

I: INCHES SINGLE RANGE ACCURACY RESOLUTION

I/M (inches/min.) 0.6 - 9,999.9 ±0.6 0 .1

IN (length) 1.09.999,9 - 1.0

m: METERS SINGLE RANGE ACCURACY RESOLUTION

m/M (meters/min.) 0.02 - 999.99 ± 0.06 0.01

m/H (meters/hour) 0.9 - 9,999.9 ± 0.6 0.1

m (length) 500.0599.99 - 500.0

cm (length) 5.05.999,9 - 5.0

M: MILES SIN GLE RANGE ACCURACY RESOLUTION

M/H (miles/hour) 0.0006 - 9.9999 ± 0.0006 0.00 01

NOTE: When using master wheel, accuracy can be affected

as much as 0.3% of reading

CAUTION: Although tachometer alone is able to achieve
above ranges, the master wheel has a maximum speed limitation
of 5,000 FPM (for safety reasons).

Instruction Manual

HHSSLEDOM

1,000.0 - 9,999.9 ± 0.6 0.1

10,000 - 25,000 ±0.006% of reading ±1digit 1

(or ±2 rpm max.)

(or ±6 rpm max.)

10,000 - 99,999 ± 1 1

1,000.0 - 9,999.9 ± 0.6 0.1

10,000 - 12,500 ± 1 1

(or ±6 FPH max.)

1.09.999,9 - 0.000,1

1999,99 - 000,01

1,000.0 - 4,167.0 ± 0.3 0.1

10,000 - 99,999 ±0.006% of reading ±1digit 1

(or ±6 YPH max.)

10.099.999 - 00.001

1.09.999,9 - 0.000,1

1999,99 - 000,01

10,000 - 99,999 ±0.006% of reading ±1digit 1

(or ±6 IPM max.)

1999,99 - 000,01

1,000.0 - 3,810.0 ± 0.3 0.1

10,000 - 99,999 ±0.006% of reading ±1digit 1

(or ±6 mPH max.)

10.099.999 - 00.001

1.09.999,9 - 0.000,1

1999,99 - 000,01

1999,99 - 000,01

10.000 - 99.999 ± 0.006 0.001

100.00 - 142.05 ± 0.01 0.01

Surface Speed Metric Conversion

Memory Recall

Conversions such as YPM to mPM or mPM to YPM may be
obtained from the memory only by switching from one mode
to another.

Operating Procedure

1. Run wire through the two
wheels at the top of the
unit (as shown).

Wire Feed >

The HHSS may be attached to
a male disconnect on the side
with the pull pin.

2. Turn selector switch to desired unit.

Top View

Tension Knob >

Pin for
male QD
attachment

A. AUTOMATIC MEMORY

The following are automatically stored in memory for 5 minutes
following release of the power switch:

• Last reading

• Maximum reading

• Minimum reading

These readings will be displayed in the following order when
the memory switch is pressed:

• Last reading

• Maximum reading

• Minimum reading

To fill all three memory spaces, unit must operate for about 5
seconds. If any of the above memory readings are missing,
unit must operate a few seconds longer.

B. MEMORY SELECTION

The HHSS has the capability of storing 10 extra readings in
its memory. These readings can be obtained from the same
machine or many machines (up to 10) by pressing the memory
switch momentarily as the reading you wish stored appears on
the display. An "M" with an integer will appear on the top of
the display momentarily, and will be stored in memory. Up to
10 readings can be stored.

3. Begin feeding wire through the unit. Ensure the wheels
are turning as the wire is moving. If there is slippage,
tighten the front tension knob to increase tension.

4. Press and hold the on-off switch.
Display will update approximately
every second.

On/Off Switch

5. Observe speed for as long as it is desired.

6. On-off switch must be released prior to removal of tachometer
from rotating object if last reading must be captured.

7. After release of power switch, the last reading will be displayed
for approximately 5 minutes. Readings will be retained in
memory for 5 minutes and can be extended any number of
additional 5 minute periods by re-pressing the memory switch.

On/Off

NOTE: All memory data will be erased if automatic shut-off
has occurred. To recall a specific reading, press the memory
switch until the desired reading shows up on the display along
with its memory position. To erase all data from the memory,
press the memory switch for at least 5 seconds until display
shows CCCCC. If you hold the memory switch, the display
will continue to show CCCCC until the switch is released, then
will default to 0.00.

Battery Replacement

Low battery voltage is
indicated by LO BAT on
the display. Remove end
cover by using a coin or
appropriate screwdriver
and replace both batteries.
Please note polarity.
