Winlite BK200 User Manual

BT-200

User Guide

Includes:

BT-200, charge cable, 2 removable ear clips, 2 sets of silicone tips (S/L), removable cable management clip, and user guide

Please read and follow this user guide thoroughly before using the BT-200.

1. Microphone 4. Power/Phone

2. Volume Down/Track Back 5. Volume Up/Track Forward

3. Charge Port 6. LED Power Indicator

Specifications

Frequency response: 20 Hz – 20 kHz
Driver size: 10mm
Impedance: 16 omega
Sensitivity: 110±5dB

Battery capacity: 70mAh
Play time: Up to 2.0 hours based on usage
Charge time: 2 hours

Button functions

Power/phone button

• Press and hold for at least 5 seconds to power on the BT-200; press and hold for at least 5 seconds
to power off the BT-200.

• When playing music, press and release to pause music; press and release again to play mus ic.

• When receiving an incoming call, press and release to answer; press and release again to

end the call; press and hold for 3 seconds then release to reject the call.

• Press twice quickly to call last number dialed.

• When a user is connected and the BT-200 is off, press and hold for at least 5 seconds to

unpair from Bluetooth (allow another user to connect).

NOTES:

• During the first time set-up, you must hold the power/phone button down until you hear a voice say
“Power on”, then followed by “Ready for pairing” in order to sync your device to Bluetooth. After the initial pairing, you can let go of the power/phone button after you hear a
voice say “Power on”.

• When playing music and a call comes in, the music will pause and you will hear a ringtone.
The music will resume when the call is ended. Device’s ringtone may vary.??

• If you reject a phone call, you will hear a voice say “Phone call rejected” and your music will

resume playing. If the music does not begin, press and release the power/phone button agai n to
resume the current track.

• The power/phone button functions may vary per device.

Volume up/track forward button

• Press and release to raise the volume.

• Press and hold to go to the next track.

NOTE: The volume up/down buttons may control the volume on your device. Device’s result s may vary.

Volume down/track back button

• Press and release to lower the volume.

• Press and hold to go the previous song.

NOTE: The volume up/down buttons may control the volume on your device. Device’s result s may vary.

Charging your BT-200

NOTE: Make sure your BT-200 is fully charged before using it the first time.

1. Gently plug the Micro-USB end of the included charge cable into the charge port of the control box.

2. Plug the USB A end of the cable into a powered USB port, such as a computer, laptop, or USB AC adapter (not included).

3. The LED power indicator located next to the volume up/track forward button will light up s olid red. Once the headset is fully charged, the LED power indicator will turn off.

NOTES:

• When the battery level is below 10%, you will hear a voice say “Battery level low”.
Charge your BT-200 with the included charge cable. This feature only works while the BT-200 is on.

• The LED power indicator will light up red while charging even if the BT-200 is off.

• You can charge your BT-200 while listening to music, however, this extends the charging time.

Connecting via Bluetooth® (first time set-up)

1. Press and hold the power/phone button for at least 5 seconds to turn the headset on.

You will hear a voice say “Power on”, then continue to hold the button until you hear “Ready for pairing” and the LED power indicator will rapidly flash blue and red.

NOTE: During the first time set-up, you must hold the power/phone button down until you hear a voice say “Power on” then followed by “Ready for pairing” in order t o sync
your device to Bluetooth. After the initial pairing, you can let go of the power/phone button after you hear “Power on”.

2. Open the settings on your Bluetooth device. (Bluetooth must be enabled)

3. Select “BT-200” from the list of Bluetooth devices.

4. Once paired, you will hear a voice say “Device connected”. The LED power indicator light will flash blue slowly.

5. To turn off the BT-200, press and hold the power/- phone button for at least 5 seconds. You will hear a voice say “Power off ” before the headset turns off.

NOTES:

4Bluetooth v .1 + EDR, up to a 30 foot transmission range

• Upon use of your BT-200 the volume must be adjusted to your desired level, as the volume level has been pre-set to the maximum. ( 30% initial volume setting)

• Your device will automatically find and pair with the BT-200 after the initial pairing. If your device does not automatically pair within 5 minutes, the BT-200 switches off. You

can switch on the headset and repeat steps 1-4.

• The BT-200 will automatically pair to the last device connected.

• The volume up/down buttons on the BT-200 may control the volume on your device.
Device’s results may vary.

Cable management

To loosen the removable cable management clip.

Troubleshooting

Issue: My BT-200 doesn’t turn on.
Solution: Try the following:

• Make sure the BT-200 is charged.

• Make sure the volume is turned up on your device and the BT-200.

• Make sure you press and hold the power/phone button for at least 5 seconds.

Issue: My BT-200 is not charging.
Solution: Try the following:

• Make sure the charge cable is fully inserted in the BT-200.

• Make sure that the charge port on the headset is free from dust and debris.

• Make sure that you are using the charge cable that came with your BT-200.

• Make sure there is power coming from the power source.

Issue: My BT-200 isn’t syncing to Bluetooth.
Solution: Try the following:

• Make sure you hold the power/phone button down until you hear a voice say “Ready for pairing”
after it says “Power on”.

• Make sure that the Bluetooth setting is turned “on” on your device.

• Check to see if another user is connected to the BT-200.

• Refer to the user guide of your device for Bluetooth syncing instructions.

Issue: My BT-200 volume is turned all the way up, but the volume is still very low.
Solution: Try the following:

• Make sure your BT-200 and audio device are charged.

• Make sure the volume is turned up on your device and the BT-200.

Issue: The person on the other line cannot hear me very well.
Solution: Try the following:

• Make sure your BT-200 and phone are charged.

• Make sure there is nothing covering the microphone on the control box.

• Make sure you have service with your phone provider.

Safety warning

• Do not listen at a high volume level. Extended high volume levels can lead to permanent hearing loss.

• Start with setting the volume level at the lowest volume and adjust until you reach

a comfortable volume level.

• Tampering or removing the battery can result in damage to your product, void of warranty,
and could cause injuries.

• Do not use when a failure to hear your surroundings could be dangerous, such as while driving, or when biking, walking or jogging where traffic is present and ac cidents may
occur.

• Do not use while sleeping, as accidents may occur.

• If you experience any ringing in your ears, try lowering the volume. If the ringing persists,

visit your physician.

Important safety precautions

• Incorrect use or incompatibility with your device may result in reduced battery performance or damage to your device.

• Do not attempt to disassemble product.

• Tampering or removing the battery can result in damage to your product, void of warranty, and could cause injuries.

• Do not allow this product to have contact with liquids.

• Store and operate between 32°F – 113°F.

• Do not place this product near a heat source or flame.

• Do not throw or shake.

• Do not operate if it has been subjected to shock or damage.

• Do not crush or puncture the battery.

• Recharge the battery every 3 months when not in use to keep battery in best condition.
