WINIADAEWOO DLA32C7, DLA37C7 User Manual

Proper use guarantees

product life.

Before using the product, be advised
that you read this owner’s manual well
and try to operate it.

INSTRUCTION MANUAL

LCD TELEVISION

C32HDGB
C37HDGB
C42HDGB

WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE

THIS APPLIANCE TO RAIN OR MOISTURE.

CAUTION :

TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulat­ed “dangerous voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk electric shock.

The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and servic­ing instructions in the literature accompanying the appliance.

Caution

Caution

2

NOTE :

This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reason­able protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause interference to radio
communications. However, there is no guarantee that interference will not occur in a partic­ular installation.

If this equipment does cause interference to radio or television reception which can be
determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures.

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.

- Consult authorized service centers for help.

- Only shielded interface cable should be used.

Finally, any changes or modifications to the equipment by the user not
expressly approved by the grantee or manufacturer could void the users
authority to operate such equipment,

FCC RF IINTERFERENCE STATEMENT

Important

Safeguards

Please read the following safeguards for your TV and retain for future reference.
Always follow all warnings and instructions marked on the television.

1. Read, Retain and Follow All Instructions

Read all safety and operating instructions before operating the TV. Retain them safely
for future reference. Follow all operations and instructions accordingly.

2. Heed Warnings

Adhere to all warnings on the appliance and in the operating instructions.

3. Cleaning

Unplug the TV from the wall outlet before cleaning. Do not use liquid, abrasive, or aerosol cleaners.
Cleaners can permanently damage the cabinet and screen. Use a lightly dampened cloth for
cleaning.

4. Attachments and Equipment

Never add any attachment and/or equipment without approval of the manufacturer as such additions
may result in the risk of fire, electric shock or other personal injury.

5. Water and Moisture

The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids,
such as vases, shall be placed on the apparatus.

6. Setting

Do not place this TV on an unstable cart, stand or table. Placing the TV on an unstable base can
cause the TV to fall, resulting in serious personal injuries as well as damage to the TV. Use only a
cart, stand, bracket or table recommended by the manufacturer or salesperson.

7. Ventilation

Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the TV and to
protect it from overheating. Do not cover the ventilations openings in the cabinet and never place the set in a confined
space such as built-in cabinet unless proper ventilation is provided. Leave a minimum 10 cm gap all around the unit.

8. Power Source

This TV should be operated only from the type of power source indicated on the marking label. If you are not
sure of the type of power supplied to your home, consult your appliance dealer or local power company.

9. Grounding or Polarization

This TV is equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This
plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into
the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the polarized plug. A warning that an apparatus with CLASS I construction
shall be connected to a MAINS socket outlet with a protective earthing connection.

10. Power-Cord Protection

Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords at plugs, wall outlets, and the point
where they exit from the TV.

MAINS plug is used as the disconnect device, the disconnect device shall remain readily operable.

11. Lightning

For added protection for this TV during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent
damage to the TV due to lightning and power-line surges.

3

Important
Safeguards

4

13. Power Lines

An outside antenna system should not be located in the vicinity of overhead power lines or other electric light
or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from touching such power lines or circuits as contact with
them might be fatal.

14. Overloading

Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock.

15. Object and Liquid Entry

Never push objects of any kind into this TV through openings as they may touch dangerous voltage points or
short-out parts that could result in fire or electric shock. Never spill liquid of any kind on or into the TV.

16. Outdoor Antenna Grounding

If an outside antenna or cable system is connected to the TV, be
sure the antenna or cable system is grounded so as to provide
some protection against voltage surges and built-up static charges.
Section 810 of the National Electric Code, ANSI /NFPA No. 70-1984,
provides information with respect to proper grounding of the mast
and supporting structure, grounding of the lead in wire to an antenna
discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.

17. Servicing

Do not attempt to service this TV yourself as opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service personnel.

18. Damage Requiring Service

Unplug the TV from the wall outlet and refer servicing to qualified service personnel under the following
conditions:
(a) When the power-supply cord or plug is damaged.
(b) If liquid has been spilled, or objects have fallen into the TV.
(c) If the TV has been exposed to rain or water.
(d) If the TV does not operate normally by following the operating instructions. Adjust only those controls

that are covered by the operating instructions as an improper adjustment of other controls may result in

damage and will often require extensive work by a qualified technician to restore the TV to its normal operation.
(e) If the TV has been dropped or the cabinet has been damaged.
(f) When the TV exhibits a distinct change in performance - this indicates a need for service.

19. Replacement Parts

When replacement parts are required, be sure the service technician has used replacement parts specified
by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may
result in fire, electric shock or other hazards.

20. Safety Check

Upon completion of any service or repair to the TV, ask the service technician to perform safety checks to
determine that the TV is in safe operating condition.

21. Heat

The product should be situated away from heat sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.

Warning

5

This section must be read carefully and followed by the user prior to the operation of the product.

The manual states important instructions for the user's own safety, and the proper operation of the product.

In case of an accident, please unplug the unit from the outlet immediately.

Hold the plug when unplugging the unit
from the outlet. The cord may cause fire or
electric shock if damaged.

Do not cause the product to lean or put it in an
unstable place since it may cause a serious
injury to a person, as well as damage to the
product if it falls.

Do not put any object that contains water ­such as flowerpot - near to the unit.
The water may penetrate into the unit, and be
a cause of fire or hazardous electric shock.

To reduce the risk of electric shock, do not
remove cover or back. No user -serviceable
parts inside. Refer to qualified service
personnel for repair.

Do not put on or use the product near water and
moisture-such as in a bathroom, washbowl, etc.
It may be a cause of fire and electric shock
hazards.

To prevent fire and damages to the product,
unplug the unit from the outlet during lightning
storm, or when it is left unattended and unused
for a long period of time.

Do not let children hang on or climb on the
product since it may be a cause of serious
injury.

Slots and openings in the case are provided for
ventilation to ensure reliable operation of the
product. Never put in any item-such as a coin,
paper, match- through these openings since it
may touch dangerous voltage points that could
result in fire or shock hazard.

Warning

6

Do not put volatile substance-such as
benzene, naphtha- near the product since it
may cause a change in the product's colour.

Do not view the TV too closely since it may
cause damage in your eyesight.

Refer servicing to qualified service
personnel for cleaning at least once a year
since dust inside the TV set may be a result
or fire and malfunctioning of the product.

The product should be situated away from
any heat source-such as radiators, heat
registers, stoves, or other products that
produce heat.

Do not put on any heavy item on the power
cord since it may result in fire or hazardous
electric shock if the cord is damaged.

Do not cover the top of the television set.
Ventilation will be prevented, and it may be
a cause of fire if the product is internally
overheated.

Unplug the power from the outlet and all the related
connections from the unit to prevent electric shock. At least
two people must work together to move the TV set when
transporting to prevent the TV from falling, and
consequently, any serious injury or damage.

Do not touch the power cord with
moisturized or wet hands when plugging to
or unplugging from the outlet since it may be
a cause of electric shock.

Please be advised of electric wires and cables when installing
the antenna. It may be a cause of hazardous electric shock and
fire if the antenna touches or falls on the electric wire; thus, it
must be installed firmly, and far away from the cables.

Do not spill water or drop the remote
controller since it may be a cause of
malfunctioning.

This section must be read carefully and followed by the user prior to the operation of the product.

The manual states important instructions for the user's own safety, and the proper operation of the product.

Please keep the user's manual in a safe place for future reference.

Do not expose the product to a dusty or
moisturized place since it may be a cause of
malfunctioning.

Table of

Contents

7

Installation and Maintenance

Antenna Connection 9
Video Connection 12
Camcorder & Video Game Connection 13
DVD Player Connection 14
STB(Set Top Box) Connection 15
PC Connection 16
Cable TV Broadcasting Connection 18
Connect with the Dolby Digital AMP 19
Name of Each Part 20

Basic Guide

Parts of the Remote Controller 22
Method To Use Basic Menu 24
To Watch TV 25
Setting Up TV Stations 27
Selection of TV/VIDEO Input Signal 30
Selection Multimedia Input Signal 31

Application Guide

Picture Adjustment 33
Sound Adjustment 37
Features - Closed Caption 42
Features - PIP/POP 44
Features - Parental Control 46
Features - ETC 49
Time Setting 51
Channel Banner 54
Troubleshooting 56
Standard of Product 58

Supplied
Accessories

Make sure that the following accessories are provided with the product.

AC cord

P

S
I
D

Y
A
L

E

D
I
U

G

R
E
W

O

P

M
I
T

L
U
M

O
E
D

I
V

/
V
T

123

456

78

H
C

.
V
E

R
P

A

I
D
E

9

R
E
T

N
E

V
A
F

0

H

C

L
O
V

U

N
E
M

L
L

I
T
S

L

VO

EP
E
L

S

E

D/

UT

D

H

M

A

SE

C

A
R
E

H
C

N

P

IO

I
P

PT

CA

EEN

R

SC

E

P
I

IZ

P

S

N
O
I

T
I
S

O

H

P

C
P
I

P

E
C

R
U
O

S

P

A
W
S

D
N
U

T

O

C

S

E
F
F

S

E
T
M

D

N
U
O

E

S

D

E

R

MO

U

T

C

E

I

D

P

MO

AC cord Instruction manual

Batteries

Cable holder

The method of wire arrangement

1. Assemble the cable holder enclosed on the back
of TV. (PICTURE 1)
(ASSEMBLY METHOD: After you push the
"A"(prominence part of cable holder) in the
hole, rotate the cable holder clockwise as an
angle of 90°. You can separate in reverse order
of assembly.)

2. Open the cable holder. (PICTURE 2)
( you can open the cable holder then press and
push "B" part.)

3. After arranging cables with the cable holder,
lock "B" again. (PICTURE 3)

Remote controller

1

23

8

Antenna

Connection

9

Indoor Antenna Connection

1. Connect the feeder cable of the antenna to the combining adapter.

WHEN THE IMAGE IS NOT CLEAR : Unclear screen image and bad reception may be a cause of wrong

antenna connection. Be sure to check its direction and place when
installing.

2. Connect the combining adapter to the antenna input at the left side of the TV set.

WHEN USING THE COMBINING ADAPTER : You may obtain the combining adapter at your closest

Service Center.

Combining adapter

S-VIDEO

AV 1 INPUT COMPONENT INPUT

L-AUDIO-R

VIDEO L-AUDIO-R

MONITOR OUT

OPTICAL
OUTPUT

PC AUDIOHDMI

INPUT

SERVICE

Pb/Cb Pr/Cr

DIGITAL AUDIO

Antenna Input

REAR OF THE TV SET
