HEATER PROOFER & CABINETS
PAGE
44
800.444.3595 I 516.921.0538 fax I www.winholt.com
EC-1840-C
Enclosed Mobile Transport Cabinets
Enclosed Mobile Transport Cabinets
Heavy Duty
Freight Class:150
Stores and transport goods–retards dehydration! All
welded, reinforced, non-insulated aluminum. Sanitary and
rustproof.
Double pan construction with reinforced braces,
1½"spacing between runners.
Easily maneuverable on four 5" Polyurethane, swivel plate,
double ball race casters. Locking casters are available.
Model
Number
Order#
Overall Dimensions
Pan
Cap.
Approx.
Ship Wt
Width Length Height
(in) (mm) (in) (mm) (in) (mm) 18” x 26” (lb) (kg)
EC1816-C 110795
21 533 27 686
32 813 16 57 26
EC1824-C 110824 44 1,118 24 70 32
EC1832-C 110832 56 1,422 32 84 38
EC1840-C
E XPRESS
S HIP
110841 68 1,727 40 94 43
With Clear Acrylic Door
EC1840-C / LD 150375 21 533 27 686 68 1,727 40 11 5 52
Replacement Caster Information
738A 128784 Swivel Plate Caster with 5" Polyurethane Wheel
7112 122180 5" Polyurethane Wheel
B
ETTER
MEDIUM DUTY USE
HACCP HELPERS
LIFE WARRANTY
AGAINST RUST
Equipment Guide
B
EST
MEDIUM DUTY USE
HACCP H
ELPERS
LIFE WARRANTY
AGAINST RUST
Equipment Guide
Option: Specify options by adding suffix to Model Number
CORR Correctional Package
EC-1816-C
Stores and transport goods–retards dehydration!
Constructed of all welded, reinforced, non-insulated
aluminum. Sanitary and rustproof.
Double pan top construction with reinforced brace, 1½"
spacing between runners.
Heavy duty, reinforced hinges and latch assure easy
closing with a secure fit.
Maneuvers easily on 5" polyurethane, swivel plate, double
ball race casters.
Heavy Duty,
reinforced,
galvanized steel
undercarriage,
provides
extra strength
support.
Option: Specify options by adding suffix to Model Number
CORR Correctional Package /6PU 6” Polyurethane Casters
Freight Class:150
Model
Number
Order#
Overall Dimensions
Pan
Cap
Approx.
Ship Wt
Width Length Height
(in) (mm) (in) (mm) (in) (mm) 18”x26” (lb) (kg)
Heavy Duty Enclosed Cabinet with Reinforced Undercarriage
EC1840-CTL 110859 21 533 27 686 68 1,727 40 115 52
Extra Heavy Duty Enclosed Cabinet with Reinforced Undercarriage and Frame
EC1832-CTLPURC 150383
21 533 27 686
56 1,422 32 115 52
EC1840-CTLPURC 110904 68 1,727 40 120 54
Replacement Caster Information
7318 123051 Swivel Plate Caster with 5" Polyurethane Wheel
7128 122438 5" Polyurethane Wheel
EC-1840-CTLPURC
