Win-Holt 7116 User Manual
TRANSPORT & MOBILE STORAGE
PAGE
26
800.444.3595 I 516.921.0538 fax I www.winholt.com
Freight Class: 250
BETTER
HEAVY DUTY USE
LIFE WARRANTY
AGAINST RUST
Equipment Guide
Multipurpose cart designed for storage and
transportation of pots, pans, wire baskets, cups, and
dishes.
The frame is constructed of all welded 1½" x 1½" x
3/16" all welded reinforced aluminum. The shelves are
constructed of heavy duty reinforced aluminum sheet.
Standard configuration is 3 lips flanged up and front lip
down. Other configurations are available upon request.
A wrap around bumper protects walls, associates and
equipment. Welded handle for easy maneuverability.
Maneuvers on two 8" x 2" rigid and two 8" x 2" swivel
polyurethane wheels with double race casters.
Queen Mary Banquet Carts
Aluminum
Multipurpose cart designed for storage and transportation
of pots, pans, wire baskets, cups, and dishes.
304 Stainless Steel
A wrap around bumper protects walls, associates and
equipment. Welded handle for easy maneuverability.
Maneuvers on two 8" x 2" rigid and two 8" x 2" swivel
polyurethane wheels with double race casters.
Model
Number
Order#
Overall Dimensions
# of
Shelves
Shelf
Spacing
Approx.
Ship
Weight
Width Length Height
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (lb) (kg)
BNQT-3 154325
28 711 60 1,524
65
7
/16
1,662
3 27 686 140 64
BNQT-4 127546 4
17
19
/32
447 160 73
BNQT-5 112598 5 13½ 343 180 82
Caster Information
73161 123035 Swivel Plate Caster with 8" Mold-on Polyurethane Wheel
⎯
7471 123537 Rigid Plate Caster with 8" Mold-on Polyurethane Wheel
⎯
7116 122294 8" Mold-on Polyurethane Wheel
⎯
Queen Mary Banquet Carts
Stainless Steel
Model
Number
Order#
Overall Dimensions
# of
Shelves
Space
Between
Shelves
Approx.
Ship Wt
Width Length Height
(in) (mm) (in) (mm) (in) (mm) (in) (mm) (lb) (kg)
BNQT-3SS 232012
28 711 60 1,524
65
7
/16
1,662
3 27 686 295 134
BNQT-4SS 168997 4
17
19
/32
447 340 154
BNQT-5SS 232021 5 13½ 343 385 174
Caster Information
73161 123035 Swivel Plate Caster with 8" Mold-on Polyurethane Wheel
⎯
7471 123537 Rigid Plate Caster with 8" Mold-on Polyurethane Wheel
⎯
7116 122294 8" Mold-on Polyurethane Wheel
⎯
BEST
HEAVY DUTY USE
LIFE WARRANTY
AGAINST RUST
Equipment Guide
Ideal for
Food Service
& Industrial
Environments!
In line with our policy to continually improve our
products, Win-Holt reserves the right to change materials and specifications without notice.
Freight Class: 250
