G
HIGH SPEED BURNISHER
Operating Instructions (ENG)
MODEL: MB1500
MB1500 98804 10/19/02
Read these instructions before using the machine.
THIS PAGE LEFT BLANK INTENTIONALLY
1
MB1500 98804 05/19/00
MACHINE DATA LOG/OVERVIEW
YOUR DEALER
Address: _______________________________________________________________________________________________
MODEL______________________________
DATE OF PURCHASE ________________
SERIAL NUMBER____________________
Name: __________________________________________________________________________________________________
For the name and address of your dealer contact: Windsor Industries
Phone Number: _________________________________________________________________________________________
MB1500 98804 05/19/00
2
TABLE OF CONTENTS
3
Machine Data Log/Overview..........................2
Table of Contents...........................................3
HOW TO USE THIS MANUAL
How to use this Manual.................................1-1
SAFETY
Important Safety Instructions ........................2-1
Hazard Intensity Level...................................2-2
Grounding Instructions..................................2-3
OPERATION
Technical Specifications................................3-1
Handle Installation.........................................3-2
Operation.......................................................3-3
Pad Driver Installation....................................3-4
MAINTENANCE
Machine Troubleshooting..............................4-1
Wiring Diagram/Notes...................................4-2
GROUP PARTS LIST
Motor Group...................................................5-1
Frame Group.................................................5-3
Drive/Pad Lock Group...................................5-5
Handle Group.................................................5-7
Wiring Group..................................................5-9
Suggested Spare Parts ...............................5-11
Warranty......................................................5-12
MB1500 98804 01/29/02
HOW TO USE THIS MANUAL
This manual contains the following sections:
- HOW TO USE THIS MANUAL
- SAFETY
- OPERATIONS
- MAINTENANCE
- PARTS LIST
The HOW TO USE THIS MANUAL section will tell
you how to find important information for ordering
correct repair parts.
Parts may be ordered from authorized Windsor
dealers. When placing an order for parts, the
machine model and machine serial number are
important. Refer to the MACHINE DATA box which
is filled out during the installation of your machine.
The MACHINE DATA box is located on the inside of
the front cover of this manual.
MODEL _____________________________________
DATE OF PURCHASE ________________________
SERIAL NUMBER ____________________________
SALES REPRESENTATIVE # ___________________
DEALER NAME ______________________________
OPERATIONS GUIDE NUMBER __________________
The PARTS LIST section contains assembled parts
illustrations and corresponding parts list. The parts
lists include a number of columns of information:
- REF – column refers to the reference
number on the parts illustration.
- PART NO. – column lists the part
number for the part.
- QTY – column lists the quantity of the
part used in that area of the machine.
- DESCRIPTION – column is a brief
description of the part.
- SERIAL NO. FROM – column indicates
the first machine the part number is
applicable to. When the machine design
has changed, this column will indicate
serial number of applicable machine.
The main illustration shows the most
current design of the machine. The
boxed illustrations show older designs.
- NOTES – column for information not
noted by the other columns.
NOTE: If a service or option kit is installed on your
machine, be sure to keep the KIT INSTRUCTIONS
which came with the kit. It contains replacement
parts numbers needed for ordering future parts.
PUBLISHED ________________________________
The SAFETY section contains important information
regarding hazard or unsafe practices of the
machine. Levels of hazards is identified that could
result in product or personal injury, or severe injury
resulting in death.
The OPERATIONS section is to familiarize the
operator with the operation and function of the
machine.
The MAINTENANCE section contains preventive
maintenance to keep the machine and its
components in good working condition.
MB1500 98804 05/19/00
IMPORTANT SAFETY INSTRUCTIONS
!
WARNING:
When using an electrical appliance, basic precaution
must always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.
To reduce the risk of fire, electric shock, or injury:
Use only indoors. Do not use outdoors or expose to rain.
Use only as described in this manual. Use only manufacturer’s recommended components and attachments.
If the machine is not working properly, has been dropped, damaged, left outdoors, or dropped into water, return
it to an authorized service center.
Do not operate the machine with any openings blocked. Keep openings free of debris that may reduce airflow.
Machine can cause a fire when operating near flammable vapors or materials. Do not operate this machine near
flammable fluids, dust or vapors.
This machine is suitable for commercial use, for example in hotels, schools, hospitals, factories, shops
and offices for more than normal housekeeping purposes.
Maintenance and repairs must be done by qualified personnel.
During operation, attention shall be paid to other persons, especially children.
The machine shall only be operated by instructed and authorized persons.
When leaving unattended, unplug the machine.
Do not handle the plug or machine with wet hands.
Do not unplug machine by pulling on cord. To unplug, grasp the plug, not the cord.
Do not use with damaged cord or plug. Follow all instructions in this manual concerning grounding the machine.
Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or
corners.
Do not pull/run machine over cord. Keep cord away from heated surfaces.
Connect to a properly grounded outlet. See Grounding Instructions.
SAVE THESE INSTRUCTIONS
2-1
MB1500 98804 05/19/00
HAZARD INTENSITY LEVEL
2-2
!
WARNING
The following symbols are used throughout this guide as indicated in their descriptions:
HAZARD INTENSITY LEVEL
There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR
SAFETY. The level of hazard intensity is determined by the following definitions:
WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death.
! CAUTION
CAUTION - Hazards or unsafe practices which could result in minor personal injury or product or property
damage.
FOR SAFETY: To Identify actions which must be followed for safe operation of equipment.
Report machine damage or faulty operation immediately. Do not use the machine if it is not in proper
operating condition. Following is information that signals some potentially dangerous conditions to the
operator or the equipment. Read this information carefully. Know when these conditions can exist. Locate
all safety devices on the machine. Please take the necessary steps to train the machine operating
personnel.
FOR SAFETY:
DO NOT OPERATE MACHINE:
Unless Trained and Authorized.
Unless Operation Guide is Read and understood.
In Flammable or Explosive areas.
In areas with possible falling objects.
WHEN SERVICING MACHINE:
Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the
machine. Use Windsor approved replacement parts.
MB1500 98804 05/19/00
GROUNDING INSTRUCTIONS
!
WARNING
THIS PRODUCT IS FOR COMMERCIAL USE
ONLY.
ELECTRICAL:
In the USA this machine operates on a 15 amp
nominal 120V, 60 hz, A.C. power circuit. The
amp, hertz, and voltage are listed on the data
label found on each machine. Using voltages
above or below those indicated on the data label
will cause serious damage to the motors.
GROUNDING INSTRUCTIONS:
This appliance must be grounded. If it should
malfunction or break down, grounding provides a
path of least resistance for electric current to
reduce the risk of electric shock. This appliance
is equipped with a cord having an equipmentgrounding conductor and grounding plug. The
plug must be inserted into an appropriate outlet
that is properly installed and grounded in
accordance with all local codes and ordinances.
This appliance is for use on a nominal 120-volt
circuit, and has a grounded plug that looks like the
plug in “Fig. A”. A temporary adaptor that looks
like the adaptor in “Fig . C” may be used to
connect this plug to a 2-pole receptacle as shown
in “Fig. B”, if a properly grounded outlet is not
available. The temporary adaptor should be used
only until a properly grounded outlet (Fig. A) can
be installed by a qualified electrician. The green
colored rigid ear, lug, or the like extending from
the adaptor must be connected to a permanent
ground such as a properly grounded outlet box
cover. Whenever the adaptor is used, it must be
held in place by a metal screw.
Improper connection of the equipmentgrounding conductor can result in a risk of
electric shock. Check with a qualified
electrician or service person if you are in
doubt as to whether the outlet is properly
grounded. Do not modify the plug provided
with the appliance - if it will not fit the outlet,
have a proper outlet installed by a qualified
electrician.
2-3
MB1500 98804 10/02/00
TECHNICAL SPECIFICATIONS
3-1
ITEM DIMENSION/CAPACITY
Construction Heavy-duty die cast aluminum deck
with heavy-duty rubber bumper,
tubular steel adjustable handle with
die cast aluminum handle housing
and belt driven pad.
Motor 1.75 hp
Pad speed 1500 rpm
Electrical system 115 volts, 60 Hz
Cable 50’ (23 m), 14/3, built in cord wrap
Switches Dual levers with safety lock
Wheels Four 5” (12.7 cm) dia., 1.25” (3 cm)
wide, non-marking tread
Handle 1.5” (4 cm) tubular steel,
adjustable, easy to use thumb
activated safety lock
Dimensions (L x W x H) 31.5” (80 cm) X 21.5” (54 cm) X
43.5” (111 cm)
MB1500 98804 12/07/00
HANDLE INSTALLATION
HANDLE
RECEPTACLE
HANDLE
ASSEMBLY
4
DECK
ASSEMBLY
5
MOTOR
PLUG
6
PIVOT
HOLE
3
1
SEE NOTE
2
The machine is shipped with handle unassembled.
Follow these steps for installation:
1. Remove handle (38293) and deck assembly
(29230) from carton.
2. Attach handle assembly to base using hardware
kit (47331) (attached to handle in a plastic bag)
items 1, 2, and 3.
NOTE: The spacers (items 1) are required for the
correct operation of the handle. The spacers are
positioned completely inside the pivot holes in the
casting, and are held in place by tightening the bolts
and washers (items 2 and 3) against the spacer.
3-2
3. Remove bolt, nut and washers (items 4, 5 and
6) from lower block on handle assembly. Attach
links as shown. Tighten bolt and nut securely,
then back off 1/4 to 1/2 turn.
4. Check handle for movement up and down.
5. Plug motor cord into handle cord receptacle.
MB1500 98804 09/25/02
CONTROLS
2
66334
L
L
1. Safety Lock – Prevents unintended operation of
the machine.
2. Switch Levers – Turns machine on/off.
3. Adjustment Handle – Allows the handle to be
adjusted to a comfortable operating position.
1
OPERATION
1. To adjust handle lock, tighten nut on handle
while in the locked position. Optimum locking
force and ease of locking is accomplished when
the locking lever nut is set to a torque of 30 to 50
inch pounds in the locked position.
2. Gap between clamp halves at the front should
be to the gap in rear when the handle adjust bar
is adjusted properly and in the locked position
(gap approximately 1/16").
2 2
LOCK
UNLOCK
3
The handle adjust bar (14344) for the Merit
polishers are individually preset at the factory for
optimum locking efficiency and minimum effort
of engaging. It should not be necessary to adjust
the handle adjust bar unless the relationship of
the handle adjust bar nut (57275) or fixed clamp
bolt (70692) and their corresponding nuts
(57275) and washer (87086) have been
disturbed. The handle can be positioned to be
locked with the handle adjust bar pointing either
up or down. In order to change the position the
handle and bolt must be removed and rotated
180 degrees. It is incorrect to make it lock
opposite from the way it was assembled by
applying more force to the nut. From the factory
the locking is in the up position when the
machine handle is locked. The pivot pin (66334)
on the handle adjust bar is off center, in
relationship of the screw to the axis of the (see
drawing). To adjust handle adjust bar, tighten
nut on handle while in the locked position. The
handle is locked when the screw is to the
outside of the machine and the flat on the
opposite side of the handle is flush to the
bracket.
14344
87202
67430
70692
57275 (2)
2
87086
1
SHOWN HANDLE IS
IN LOCK POSITION
PIVOT PIN C
HANDLE C
MB1500 98804 01/24/02
LOCKING SIDE FLAT
3-3
OPERATION
3-4
!
CAUTION
!
WARNING
Ensure pad is centered on pad driver. Pull
OPERATION
For indoor use only.
When using the pad, always keep the machine
moving when in contact with the floor.
! WARNING
High starting torque. Hold machine firmly with
both hands.
1. Ensure that the pad driver is in good shape.
Install or change pad if necessary.
2. Plug the machine into a wall outlet as described
in the grounding instructions.
3. Lower the handle by unlocking the adjustment
handle and moving the handle into position.
Relock the handle when it is in a comfortable
position.
Insure that handle is locked in position before
starting machine.
4. Push the safety lock forward, unlocking the
switch levers.
DAILY MAINTENANCE
1. Inspect power cord for wear. To prevent
electrical shock replace cords with frayed or
cracked insulation immediately.
2. Place machine in the storage position.
3. Check pad condition. Change if soiled or torn.
PAD INSTALLATION
1. Lay machine back, exposing the under side.
pad to edge of pad driver in several
directions to check for proper engagement.
NOTE: Use care when replacing center lock
to prevent cross threading.
5. With the safety lock forward, squeeze one or
both of the switch levers, turning the machine
on. (These levers can be operated
independently of each other). The safety lock
will not re-engage until both levers are released.
6. To stop the machine, release the switch levers.
7. Do not let machine rest on pad. When finished
with the machine, return handle to the storage
position.
NOTE: The machine is equipped with a circuit
breaker to protect the motor in the event an overload
condition occurs. The circuit breaker is located on
the rear of the motor. Push the reset button to restart
the machine. If the breaker trips again, correct the
cause of overloading before proceeding.
MB1500 98804 01/24/02
3-5
THIS PAGE LEFT BLANK INTENTIONALLY
MB1500 98804 01/24/02
MACHINE TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
Machine will not run Circuit breaker tripped in
building.
Power switch failure Test switch for continuity
Tripped circuit breaker Reset
Faulty power cord Replace
Fuse in motor is blown Replace
Electrical shock Equipment not grounded Follow grounding
Receptacle not grounded Have an electrician inspect
Internal wiring problem Ensure that the machine
Repeated cuicuit breaker tripping Mechanical problem Higher amp draws indicate
Faulty circuit breaker Test circuit for continuity.
Excessive vibration Pad not centered Re-center pad.
Check and reset
and replace if necessary.
CAUTION: To reduce the
risk of electrical shock,
unplug the machine before
opening fuse holder.
Fuse will only open under
extreme conditions.
Investigate cause before
replacing.
instructions exactly.
building’s wiring.
wiring matches the
appropriate wiring
diagram. Replace any
wires or components which
are short circuiting.
a mechanical problem, find
the problem before using
the machine.
Replace circuit breaker if
necessary.
Pad does not turn but motor is
running
4-1
Damaged or unevenly worn
pad.
Damaged pad driver. Replace.
Belt is loose or broken Adjust or replace belt
MB1500 98804 10/02/00
Replace pad. Do not rest
machine on pad when not
in use.
WIRING DIAGRAM/SERVICE SCHEDULE
4-2
SERVICE SCHEDULE
MAINTENANCE
Check pad wear to prevent buildup of chemicals
Check pad driver system for damage
Check handles, switches, and knobs for damage
Store with pad off the floor
Check all bearings for noise
Check skirt/bumpers for damage and replace as
necessary
Check overall performance of machine
NOTES:
DAILY MONTHLY
*
*
*
*
*
*
*
MB1500 98804 10/19/02
MOTOR GROUP
1
2
4
3
5-1
MB1500 98804 09/28/00
MOTOR GROUP
REF PART NO. QTY DESCRIPTION
1 500290 1 LABEL, MB1500 MAIN
2 27892 1 COVER ASM, MOTOR 1.75HP
3 70700 8 SCR, M5 X .8 X 10MM PHMS BLK
4 53249 1 MOTOR, 115V 1.75 HP
MOTOR COMPONENTS (NOT SHOWN)
REF PART NO. QTY DESCRIPTION
140411 1 CIRCUIT BREAKER, 20 AMP
67029 1 RECTIFIER
14404 1 BRUSH SET MP MOTOR (PKG OF 4)
34378 1 FUSE
34379 1 FUSE HOLDER
09135 2 BEARING, MOTOR
SERIAL NO.
FROM
SERIAL NO.
FROM
NOTES:
NOTES:
MB1500 98804 09/28/00
5-2
FRAME GROUP
1
14
13
15
2
8
3
12
11
16
10
5
4
5-3
7
8
9
MB1500 98804 09/28/00
6
FRAME GROUP
REF PART NO. QTY DESCRIPTION
1 500290 1 LABEL, MAIN
2 53249 1 MOTOR, 115VOLT 1.75HP 3000RPM
3 140397 2 BRACKET, HANDLE LINK
4 29229BLU 1 DECK, 20 IN BURNISHER, BLUE
5 03111 1 AXLE, MAIN POLISHER
6 89206 4 WHEEL, 5D X 1.25 X 13MM ID GRY
7 87203 8 WASHER, 14MM ID X 36MM OD
8 87054 8 WASHER, M8
9 70262 4 SCR, M8 X 20 HHMS
10 03116 1 AXLE, MAIN BURNISHER
11 70691 2 SCR, M6 X 25 HHCS
12 87211 2 WASHER, M6 FLAT
13 27871 2 CAP, EXTRUSION
14 14423 1 BUMPER, EXTRUSION 44.30 IN
15 70184 4 SCR, M8 X 25HHCS
16 57276 2 NUT, PUSH FLAT RD .51 ID
SERIAL NO.
FROM
NOTES:
MB1500 98804 09/28/00
5-4
DRIVE/PAD LOCK GROUP
18
17
10
16
13
15
12
20
2 1
3
4
5
6
8
9
14
19
7
11
11
5-5
MB1500 98804 09/25/00
DRIVE/PAD LOCK GROUP
REF PART NO. QTY DESCRIPTION
1 70709 2 SCR, SET M8 X 1.25 X 8MM CUP POINT
2 87086 4 WASHER, M10
3 70507 4 SCR, 3/8-16 X ¾ HHCS GR5
4 48041 1 KEY, 3/16 X 7/8
5 64106 1 PULLEY, .625 X 3.45
6 87218 1 WASHER, M6 (20.5OD X 1.67) PLT
7 70505 1 SCR, ¼-20 X 1.00 HHCS GR5
8 64107 1 PULLEY, BURNISHER
9 67449 1 RING, 20M EXTERNAL SNAP
10 66337 1 PAD DRIVER, 20 IN BURNISHER
11 51353 1 LOCK, PAD DRIVER BLUE
12 70720 3 SCR, #10 X 3/8 PPHST TYPE B
13 70201 8 SCR, ¼-20 X ¾ FHCS
14 09133 1 BEARING, 20MM X 52MM
15 67450 2 RING, 52MM INTERNAL SNAP
16 14424 1 BELT, DRIVE 38 IN
17 09134 1 BEARING, 25MM X 52MM
18 03115 1 AXLE, PAD DRIVER (MM)
19 27913 1 COVER, BEARING
20 70719 3 SCR, M4 X 8MM PPHMS
SERIAL NO.
FROM
NOTES:
MB1500 98804 09/25/00
5-6
HANDLE GROUP
22
1
21
2
3
17
16
15
14
11
13
18
12
9
11
10
19
20
4
5
6
7
8
27, 11, 12
26
25
{
5-7
23
24
MB1500 98804 01/24/02
HANDLE GROUP
REF PART NO. QTY DESCRIPTION
1 70686 2 SCR, M6 X 45 SHCS BLK
2 51326 1 LOCK, SAFETY HANDLE
3 73990 2 SPRING, EXT. .5OD X 3.5L
4 78437 1 TUBE, GRIP HANDLE
5 36196 2 GRIP, POLISHER HANDLE
6 51327 2 LEVER, SWITCH
7 57274 4 NUT, M6 X 1
8 500194 1 LABEL, WARNING
9 41363 1 HOUSING, POLISHER HANDLE FRONT
10 70689 2 SCR, M4.8 X 10 HHTF TYPE B
11 57275 3 NUT, M10 X 1.5 HEX NYLOCK PLTD
12 87086 3 WASHER, M10 X 30 PLTD
13 730020 1 TUBE ASSY, HANDLE
14 67430 1 ROD, HANDLE ADJUSTMENT
15 87202 1 WASHER, BEARING (HANDLE ADJ)
16 66334 1 PIN, PIVOT HANDLE ADJUSTMENT
17 14344 1 BAR, HANDLE ADJUSTMENT
18 140393 1 BLOCK, HANDLE MOUNT
19 14434 2 BUMPER, BURNISHER HANDLE
20 70692 1 SCR, MID X 75 HHCS PLTD
21 41366 1 HOUSING, POLISHER HANDLE FRONT
22 70687 2 SCR, M6 X 50 SHCS BLK
23 38292 1 HANDLE, BURNISHER
24 730021 1 SPACER, POLISHER HANDLE
25 23207 1 CORDSET, 14/3 X 48 IN, SJT, BLACK
26 730012 1 STRAIN RELIEF, 14/3 STRAIGHT
27 70701 1 SCR, M10 X 1.5 X 90 HHCS PLTD
SERIAL NO.
FROM
NOTES:
MB1500 98804 09/28/00
5-8
WIRING GROUP
1
2
9
8
11
3
4
10
9
7
5
8
5-9
6
MB1500 98804 09/25/00
WIRING GROUP
5-10
REF PART NO. QTY DESCRIPTION
1 70688 2 SCR, M3.5 X 30 HHTF TYPE B
2 87057 2 WASHER, M4 SHAKEPROOF
3 73993 1 SPRING, COMP, .48OD X .875L
4 72123 1 SWITCH, 25A SPST 125-250V SNAP
5 73989 1 SPACER, SWITCH POLISHER
6 23167 1 CORD SET, 14/3 STO X 50' YLW
7 57069 1 NUT, ORG WIRE (2-5 18G/2-14G)
8 87208 2 WASHER, M5 SHAKEPROOF PLTD
9 70689 2 SCR, M4.8 X 10 HHTF TYPE B
10 23207 1 CORDSET, 14/3 X 48", SJT, BLK
11 20005 1 CLAMP, 5/16 NYLON
SERIAL NO.
FROM
NOTES:
MB1500 98804 09/25/00
SUGGESTED SPARE PARTS
PART NO. DESCRIPTION
87202 WASHER / BEARING
73990 SPRING
73993 SPRING
72123 SWITCH
14344 HANDLE, ADJ BAR
66334 PIN, HANDLE ADJ
67430 ROD, HANDLE ADJ
140411 CIRCUIT BREAKER, 20 AMP
67488 RECTIFIER
14404 BRUSH SET MP MOTOR (PKG OF 4)
34378 FUSE
34379 FUSE HOLDER
09135 BEARING, MOTOR
140397 BRACKET, HANDLE LINK
89206 WHEEL, 5D X 1.25 X 13MM ID GRY
87203 WASHER, 14MM ID X 36MM OD
27871 CAP, EXTRUSION
14423 BUMPER, EXTURSION 44.30 IN
57276 NUT, PUSH FLAT RD .51 RD
67449 RING, 20M EXTERNAL SNAP
66337 PAD DRIVER, 20IN BURNISHER
51353 LOCK, PAD DRIVER BLUE
09133 BEARING, 20MM X 52MM
14424 BELT, DRIVE 38 IN
09134 BEARING, 25MM X 52MM
27913 COVER, BEARING
SERIAL NO.
FROM
NOTES:
5-11
MB1500 98804 05/07/02
WINDSOR INDUSTRIES
New Machine Warranty
Limited Warranty
Windsor Industries, Inc. warrants new machines against defects in material and workmanship under normal use and service to the
original purchaser. Any statutory implied warranties, including any warranty of merchantability or fitness for a particular purpose, are
expressly limited to the duration of this written warranty. Windsor will not be liable for any other damages, including but not limited
to indirect or special consequential damages arising out of or in connection with the furnishing, performance, use or inability to use
the machine. This remedy shall be the exclusive remedy of the buyer. The warranty period is subject to the conditions stated below.
6 / 3 / 1 Warranty: 6 Years Polyethylene (PE) Housings, 3 Years Parts, and 1 Year Service Labor
Subject to conditions outlined below, Windsor Industries warrants rotationally molded PE housings and parts on all of its machines to
be free from defects in material and workmanship, under normal use and service for six (6) years to the original owner.
Under this warranty we guarantee the performance of non-polyethylene parts and components to be free from defects and for up to
three (3) years to the original end user. Parts replaced or repaired under this warranty are guaranteed for the remainder of the original
warranty period. (See table below)
Service labor charges are covered for up to one (1) year from the date of purchase through authorized Windsor service provider. No
travel coverage is extended for cord-electric models. See table below for each general product model warranty coverage.
Product PE Housing & Parts Non- PE Parts Service Labor Travel
Rider Scrubbers 6 years 3 years 1 years 6 Months
Rider Sweepers 6 years 1 year 1 years 6 Months
Walk Behind Scrubbers 6 years 3 years 1 years 6 Months
Walk Behind Sweepers 6 years 1 year 1 years 6 Months
Extractors 6 years 3 years 1 years Polishers / Elec. Burnishers / GH 6 years 3 years 1 years Wide Areas Vacuums 6 years 3 years 1 years VacPak Vacuums 6 years 1 year 1 year Air Movers / Dri-matic / TITANä
Propane Burnishers / Strippers - 2 year 1 year Tracer/Flex Sweepers/Scrubbers 6 years 2 year 6 months 90 days
1 year 1 year 1 year -
VERSAMATICÒ
SENSORÒ
Product exceptions and Exclusions:
· Extractor brush motors, pump motors, ALL PC boards and electronics, ALL Vacuum motors (other than VERSAMATICÒ and
SENSORÒ), ALL pumps, and FLEXSOLä diaphragms carry a one (1) year parts and service labor warranty.
· The OnanÒ engines have three (3) year manufacturer’s warranty. The HondaÒ and KawasakiÒ engines have two (2) year
manufacturer’s warranty. NOTE: The engine warranty is administered through the engine manufacturer and must be repaired at
an authorized service center.
Normal wear items and accessories including, but not limited to, belts, brushes, capacitors, carbon brushes, casters, clutches, cords,
filters, finishes, gaskets, hoses, light bulbs, rectifiers, switches, squeegees, bearings, pulleys, relays, actuating cables, wheels, tires,
propane tanks, and batteries will be warranted for manufacturing defects for 90-days from the purchase date.
The warranty commences on the purchase date by the original end user from an authorized Windsor agent, subject to proof of
purchase. The Machine Registration Card must be completed and returned immediately at the time of purchase. If proof of purchase
cannot be identified, the warranty start date is 90 days after the date of sale to an authorized Windsor distributor. Parts replaced or
repaired under warranty are guaranteed for the remainder of the original warranty period.
Windsor Industries reserves the right to change its warranty policy without notice – Rev2 10/16/02 1
Windsor Industries, Inc. ● a Castle Rock Industries company ● 1351 W. Stanford Ave. ● (303) 762-1800 ● 800-444-7654 ● FAX (303) 865-2800
Brush motor, Vacuum motor, Belts – 3 years All other parts – 1 year
Vacuum motor, Belts – 2 years All other parts – 1 year
WINDSOR INDUSTRIES
New Machine Warranty
90 Day Warranty Extension Available
Upon receipt of the Machine Registration Card, Windsor will extend by 90 days, from the date of purchase, all items included under
the one-year provision. This applies only to one-year items and does not include 90-day wear items.
This Warranty Shall Not Apply To:
1. Any product that has been subject to abuse, misuse, neglect or unauthorized alteration (including the use of incompatible or
corrosive chemicals or overloading of capacity).
2. Products that have experienced shipping or freight damage.
3. Repairs necessary to correct any failure due to improper pre-delivery service and inspection by the selling dealer.
4. Excessive time for cleaning units in preparation for repair.
5. Any repairs resulting from poor initial service work or improper diagnosis.
6. Tune-up parts such as plugs, plug wires and condensers.
7. Any design alterations performed by an organization not authorized or specified by Windsor.
8. Battery and charger warranties are handled directly with the manufacturer (TrojanÒ batteries and LesterÒ chargers).
9. High-pressure washing.
10. Electrical components exposed to moisture.
If difficulty develops during the warranty period, contact the authorized Windsor agent from whom the product was purchased.
Windsor Industries, Inc. may elect to require the return of components to validate a claim. Any defective part to be returned must be
shipped freight prepaid to an authorized Windsor Distributor/Service Center or to the Windsor factory.
Use Of Parts Not Approved By Windsor Industries, Inc. Will Void All Warranties
This warranty is valid only for all products sold after July 1, 1995. A product sold before that date shall be covered by the limited
warranty in effect at the date of sale to the original purchaser.
Windsor Industries reserves the right to change its warranty policy without notice – Rev2 10/16/02 2
Windsor Industries, Inc. ● a Castle Rock Industries company ● 1351 W. Stanford Ave. ● (303) 762-1800 ● 800-444-7654 ● FAX (303) 865-2800
Loading...
