PARTS
®
86037810 CHARIOT® VACUUM 12/16/06
BRUSH DECK
10
8
9
29
30
11
33
20
14
15
19
13
1
12
21
16
17
14
26
19
31
18
8
6
25
9
9
24
10
8
14
9
32
6
27
23
10
8
14
22
7
6
5
4
28
2
28
3
5-1
86037810 CHARIOT® VACUUM 07/31/08
BRUSH DECK
REF PART NO. PRV NO. QTY DESCRIPTION
1 86272350 66194 2 PIN, DOWEL GROOVE 3/16” X 3/4”L
2 86230700 12536 2 BRUSH, 27.75 X 4.0 OD
3 86227730 03130 2 AXLE, BRUSH DRIVE RECIEVER STUB
4 86227720 03129 2 AXLE, BRUSH BEARING STUB
5 86008710 80623 4 RING, 3/4” EXT SNAP H-D
6 86079420 620113 9 PLATE, LOCK W/STUDS
7 86200500 140-11 3 KNOB, RT/TANK *(12) WAS 70893
8 86271900 57294 18 NUT, 10-24 HEX NYLOCK THIN SS
9 86319050 - 9 BEARING, SHIELDED 1.125 OD X .500 ID ** WAS 09019
10 86000920 09055 9 BEARING FLANGE
11 86079430 620114 1 PLATE, BRUSH DOOR
12 86229010 09162 2 BEARING, 22 X 10 X 6 SS
13 86250740 64118 1 PULLEY, TIMING 5MM HTD 22T 15W
14 86272810 67132 7 RING, 1/2 EXT. SNAP H-D
15 86068460 78943 1 BRACKET, BELT TENSIONER
16 86279630 87212 2 WASHER, .344 ID X .13 OD X .09 T PLT
17 86270830 57023 2 NUT, 5/16-18 HEX NYLOCK SS
18 86277130 70795 2 SCR, 5/16-18 X 1.0 CARRIAGE SS
19 86279350 87140 8 WASHER, WAVE 1/2ID X 3/4D X .125
20 86092260 29278 1 DECK, BRUSH VACUUM
21 86227710 03128 2 AXLE, BRUSH DRIVER STUB
22 86254330 730401 5 SPACER. .504 ID X .690 OD X .25 L
23 86250750 64119 3 PULLEY, TIMING 5MM HTD 30T, 15W
24 86229450 11050 1 BELT, TIMING, 5MM X 12MM 2-SIDED
25 86278330 70641 1 SHOULDER BOLT, 3/8OD X 3/8L SS
26 86227700 03127 1 AXLE, .50DIA X 14 W/FLATS, JACK
27 86278100 70894 3 SET SCR, 10-32 X .5 SOC CUP PT SS
28 86277650 70895 4 SCR, ¼-20 X 1.25 PFHMS SS
29 86010780 87162 3 WASHER, 1/4 SPLIT LOCK PLTD
30 86010630 87013 3 WASHER, 1/4 ID X 5/8 OD SS
31 86272830 67138 2 RING, 3/8 EXT SNAP
32 86296990 - 1 LABEL, BELT ROUTING, IVAC *(1)
33 86244500 501107 1 LABEL, BRUSH ORIENTATION *(1)
* SEE SERIAL NUMBER PAGE
**CALL MANUFACTURER FOR SERIAL NUMBER
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 01/12/09
5-2
BRUSH DECK LINKAGE
19
13
23
24
6
30
31
25
27
28
26
27
28
1
16
17
2
15
29
5
18
12
6
10
9
6
12
12
21
6
14
13
34
6
20
8
11
32
5
4
8
6
5
4
8
6
5
4
8
8
5
6
32
32
13
7
5-3
18
22
4
3
33
86037810 CHARIOT® VACUUM 09/23/08
BRUSH DECK LINKAGE
REF PART NO. PRV NO. QTY DESCRIPTION
1 86273920 70049 4 SCR, 1/4-20 X 1.75 PPHMS SS
2 86063340 270141 1 COVER, DE CK SIDE, RIGHT
3 86063350 270142 1 COVER, DE CK SIDE, LEFT
4 86228840 09124 6 BEARING, FLANGED .314ID X .502 OD
5 86010670 87029 16 WASHER, 5/16 FLAT SS
6 86270830 57023 28 NUT, 5/16-18 HEX NYLOCK SS
7 86073550 51420 2 BRKT, HEAD ATTACH
8 86259420 87232 10 WASHER, THRUST .51 ID X 1 OD BRO
9 86068410 14838 1 BRACE, ANGLE
10 86088730 14819 1 BAR, TIE, DECK
11 86073560 51421 2 BRKT, HEAD ATTACH
12 86277030 70780 8 SCR, 5/16-18 X 1.25 CARRIAGE SS
13 86276070 70593 8 SCR, 5/16-18 X 3/4 CARRIAGE SS
14 86255000 730385 4 SPRING, EXT. .75 OD X 3.5L
15 86068420 29279 1 BRACKET, SCRUB DECK MOUNTING
16 86010780 87162 4 WASHER, 1/4 SPLIT LOCK PLTD
17 86010810 87191 4 WASHER, 1/4 ID X 1.0 OD FLAT SS
18 86226830 73268 2 SPRING, EXT .68D X 3.00L X .098W
19 86235410 78946 1 EDGING, 3/16” GRIP X 2.0 LG
20 86189050 790464 4 NUT, WELL 1/4-20 HD
21 86236560 43002 1 FOAM, SOUND INSUL, LFT CVR *(2)
22 86236550 43001 1 FOAM, SOUND INSUL, RT CVR *(2)
23 86236570 43003 1 FOAM, SOUND INSUL, UNDR CARR *(2)
24 86068360 141900 1 BRACKET, SCRUB DECK MOUNTING *(3)
25 86072210 141901 1 BRACKET, SPRING TENSIONER *(3)
26 86068370 141903 1 BRACKET, SPRING ANCHOR *(3)
27 86279510 87171 2 WASHER, 3/8 FLAT
28 86271930 57297 2 NUT, 3/8-16 HEX NYLOCK SS
29 86279130 87083 2 WASHER, 5/16 SPLIT LOCK PLTD
30 86006560 70083 4 SCR, 5/16-18 X 1 HHCS SS NP
31 86276870 70748 1 SCR, 3/8-16 X 2.50 CARRIAGE SS
32 86276710 70717 6 SCR, 5/16-18 X 2.0 CARRIAGE SS
33 86270900 57037 2 NUT, 1/4-20 WING SS *(12)
34 86276610 70697 2 SCR, 1/4-20 X 1.25 PPHMS SS **
* SEE SERIAL NUMBER PAGE
** CALL MANUFACTURER FOR SERIAL NUMBER
SERIAL NO.
FROM
NOTES:
WAS
70049
86037810 CHARIOT® VACUUM 09/23/08
5-4
BRUSH DECK MOTOR & NOZZLE
6
11
10
12
1
7
8
9
2
13
4
2
3
14
5
5-5
15
86037810 CHARIOT® VACUUM 11/14/07
BRUSH DECK MOTOR & NOZZLE
REF PART NO. PRV NO. QTY DESCRIPTION
1 86222130 53275 1 MOTOR, 36VDC, 20A, .5HP *(4) WAS 53638
2 86234610 22112 2 COUPLER, .501 ID, 1/2 JAW “D” *(4) WAS 22108
3 86234600 22109 1 COUPLER, SPIDER, SHL070, HYTREL
4 86088100 730403 1 STRAP, BRUSH MOTOR
5 86078040 58006 1 NOZZLE, VACUUM *(5)
6 86276780 70728 2 SCR, 5/16-18 X 3/4 HHCS SS
7 86010630 87013 3 WASHER, 1/4 ID X 5/8 OD SS
8 86010780 87162 3 WASHER, 1/4 SPLIT LOCK PLTD
9 86273780 70015 3 SCR, 1/4-20 X 3/4 HHCS SS NP
10 86010670 87029 2 WASHER, 5/16 FLAT SS
11 86279130 87083 2 WASHER, 5/16 SPLIT LOCK PLTD
12 86264940 27051 2 CABLE TIE, 11.38” UL/CSA
13 86277930 70119 2 SET SCR, 1/4-20 X 3/8 KCP DL
14 86271720 57246 4 NUT, 1/4-20 WING NYLOCK ZINC *(5)
15 86238060 36247 1 GASKET, 3.50 W X 25.75L X .19T *(5)
16 OPEN
* SEE SERIAL NUMBER PAGE
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 11/14/07
5-6
BRUSH DECK LIFT
13
12
1
28
5
7
8
10
11
21
2
31
3
4
6
9
14
13
30
26
25
17
9
23
24
15
14
9
11
13
16
13
11
32
14
9
29
18
14
9
14
10
14
17
22
5-7
20
9
86037810 CHARIOT® VACUUM 08/14/07
BRUSH DECK LIFT
REF PART NO. PRV NO. QTY DESCRIPTION
1 86238350 36214 1 GRIP, 3/16 X 1.00 BLUE
2 86076610 38319 1 HANDLE, SQUEEGEE LIFT
3 86257170 72200 1 SWITCH, DPDT, SNAP ACTION
4 86250240 72201 1 PLUNGER, SWITCH, OVERTRAVEL
5 86009560 82053 1 PIN, CLEVIS 1/4 X .63 PLTD
6 86271660 57233 2 NUT, 4-40 HEX NYLOCK
7 86007020 70673 1 SCR, 5/16-18 X 1.25 HHCS SS NP
8 86231570 270105 1 CABLE, SQG LIFT SCRUBPLUS
9 86270830 57023 8 NUT, 5/16-18 HEX NYLOCK SS
10 86276070 70593 2 SCR, 5/16-18 X 3/4 CARRI AGE SS DELUXE ONLY
11 86223370 66464 4 PULLEY, PLASTIC 3.0 DIA.
12 86073600 66833 1 BRKT, PULLEY RETAINER, SINGLE
13 86231150 09151 5 BUSHING FLANGE, .314 ID X.502 OD
14 86010670 87029 8 WASHER, 5/16 FLAT SS
15 86083500 66832 1 PLATE, PULLEY RETAINER, CORNER
16 86083490 66831 1 PLATE, PULLEY MOUNT, CORNER
17 86276760 70724 4 SCR, 5/16-18 X 1.25 BSHCS SS
18 86066130 89501 1 ASM, HANDLE RETAINER *(6)
19 OPEN - - - - 20 86091820 140807 1 BRKT, SIDE CHANNEL R
21 86271840 57285 2 NUT, 5/16-18 HEX NYLO CK THIN SS DELUXE ONLY
22 86068400 14623 1 BRKT, CABLE MOUNT DELUXE ONLY
23 86083440 66824 1 PLATE, PULLEY MOUNTING, CENTER
24 86277460 70847 1 SCR, 5/16-18 X 5/8 BSHCS SS
25 86259420 87232 2 WASHER, THRUST .51 ID X 1 OD BRO
26 86276010 70580 2 SCR, 4-40 X 1.0 PPHMS
27 86279450 87161 2 WASHER, #6 FLAT SAE PLTD
28 86008650 80604 1 COTTER, 1/4” RING
29 86254280 730331 1 SPACER, 1.00 OD X .32 ID X .375
30 86277130 70795 1 SCR, 5/16-18 X 1.00 CARRIAGE SS DELUXE ONLY
31 86231760 27725 1 CABLE ASM, SQUEEGEE TC DELUXE ONLY
* SEE SERIAL NUMBER PAGE
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 12/16/06
5-8
BUMPER
1
2
6
10
7
10
9
11
8
7
6
5
4
3
1
5-9
86037810 CHARIOT® VACUUM 12/16/06
BUMPER
REF PART NO. PRV NO. QTY DESCRIPTION
1 86276890 70752 6 SCR, 5/16-18X3/4 PTHMS SS
2 86007070 70849 2 SCR, 5/16-18 X 1.00 PPHMS SS
3 86063230 140813 1 BUMPER, LEFT
4 86063240 140814 1 BUMPER, RIGHT
5 86071020 140783 1 BRKT, FRONT BUMPER
6 86270830 57023 4 NUT, 5/16-18 HEX NYLOCK SS
7 86010670 87029 4 WASHER, 5/16 FLAT SS
8 86070730 140729 2 BRKT, BUMPER MOUNT, SIDE
9 86197040 57264 4 NUT, 5/16-18 HEX ACORN PLTD
10 86279130 87083 4 WASHER, 5/16 SPLIT LOCK PLTD
11 86251750 67602 2 RISER, BUMPER
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 12/16/06
5-10
CONTROL PANEL
1
14A
14B
19
4
5
6
20
30
21
3
2
7
16
16
8
26
18
15
17
13
9
6
10
11
13
12
34
30
24
23
29
33
31
31
27
28
2
25
22
23
24
5-11
86037810 CHARIOT® VACUUM 10/23/07
CONTROL PANEL
REF PART NO. PRV NO. QTY DESCRIPTION
1 86273980 70066 2 SCR, 10-32 X 3/4 PPHMS SS
2 86223740 70872 6 SCR, 1/4-20 X .59 PPHMS SSC
3 86273820 70019 2 SCR, 1/4-20 X 1.25 HHCS SS
4 86277480 70850 3 SCR, 5/16-18 X 1/2 PTHMS SS
5 86008760 80682 1 CONN, 175 DCA GRY W/O TERMS
6 86005810 57245 8 NUT, 1/4-20 HEX NYLOCK SS
7 86070720 140728 1 BRKT, BATT CONN BASIC
8 86271840 57285 3 NUT, 5/16-18 HEX NYLOCK THIN SS
9 86006370 67315 3 RELAY, 36VDC 100 AMP HVY DUTY
10 86010670 87029 6 WASHER, 5/16 FLAT SS
11 86279130 87083 6 WASHER, 5/16 SPLIT LOCK PLTD
12 86271120 57125 6 NUT, 5/16-18 BRASS
13 86005700 57104 5 NUT, 10-32 W/STAR WASHER PLTD
14A 86002760 270092 1 CONTROLLER, CHAIN DRIVE BASIC
14B 86027740 27911 1 CONTROLLER, GEAR BASIC
15 86008900 80845 1 BOOT, SEAL-PUSH BUTTON 7/16-28
16 86002010 14942 4 BOOT, 3/8 CIRCUIT BREAKER
17 86005560 54199 1 METER, 36V LED BATTERY
18 86007180 72160 1 SWITCH, EMERGENCY STOP
19 86007190 72161 1 SWITCH KEY DPST
20 86007130 72128 1 SWITCH, DPDT 2-POSITION ROCKER
21 86257280 81371 1 SWITCH, PUSH BUTTON
22 86078180 61481 1 PANEL, VACUUM
23 86251410 67506 3 RELAY, 15A 36V MINI
24 86255900 73538 10 STANDOFF, 6-32 X 5/8 HEX NYL
25 86005530 54154 1 METER, 12-48 VDC LED HOUR
26 86257110 72189 1 SWITCH, 4P3T FIXED POS ROCKER
27 86279300 87134 2 WASHER, #6 LOCK
28 86001910 14606 1 BREAKER, 30A 50VDC CIRCUIT
29 86229770 140805 1 BLOCK, SHUNT MOUNT
30 86257140 72196 1 SWITCH ASM, SEALED PB RND GRN
31 86002000 14717 2 BREAKER, 3 AMP 1681-090-300
32 86250210 66873 1 PLUG, DOME .375
33 86230080 141044 2 BREAKER, 22A 250VAC, 50VDC *(4)
34 86246630 82996 1 LIGHT, INDICATOR, RED
* SEE SERIAL NUMBER PAGE
** CALL MANUFACTURER FOR SERIAL NUMBER
SERIAL NO.
FROM
CHAIN
* *
BASIC (3)
BASIC (1)
BASIC (NOT
NOTES:
DRIVE ONLY
GEAR
DRIVE ONLY
DELUXE (4)
DELUXE (2)
SHOWN)
86037810 CHARIOT® VACUUM 10/23/07
5-12
CONTROL PANEL HOUSING
1
11
10
7
9
2
3
3
6
5
4
8
5-13
86037810 CHARIOT® VACUUM 12/16/06
CONTROL PANEL HOUSING
REF PART NO. PRV NO. QTY DESCRIPTION
1 86005810 57245 4 NUT, 1/4-20 HEX NYLOCK SS
2 86290540 - 6 SCR, 10-32 X 1/2 TORX SS BLK NP
3 86277480 70850 6 SCR, 5/16-18 X1/2 PTHMS SS
4 86070710 140726 1 BRKT, LEFT CONSOLE MOUNT
5 86237900 35278 3 GASKET, .125T X .25W X 23L
6 86062220 270117 1 CONSOLE, BURNISHER
7 86070700 140725 1 BRKT, RIGHT CONSOLE MOUNT
8 86279750 87252 4 WASHER, RET, PUSHNUT, 5/16 BOLT
9 86089650 78524 4 TUBE, 5/8 OD X .357 ID X 1.57
10 86277420 70841 4 SCR, 5/16-18 X 2.5 PTHMS SS
11 86010630 87013 4 WASHER, 1/4 ID X 5/8 OD SS
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 02/20/07
5-14
DECAL
4
5
3
2
6
1
5-15
86037810 CHARIOT® VACUUM 01/06/09
DECAL
REF PART NO. PRV NO. QTY DESCRIPTION
1 86004970 50990 1 LABEL, WINDSOR LOGO DOMED
2 86244800 501228 1 LABEL, CHARIOT IVACUUM RT WAS 500884
3 86244360 501071 1 LABEL, PANEL R VAC
4 86244190 500882 1 LABEL, PANEL BASIC LEFT
5 86243990 500780 1 LABEL, COVER PANEL
6 86244810 501229 1 LABEL, CHARIOT IVACUUM LT WAS 500885
NOTE: See “SAFETY LABEL LOCATION” page for safety label information.
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 01/06/09
5-16
FRAME-LOWER
14
16
17
21
15
13
11
3
3
10
2
3
3
12
1
4
8
5
3
6
9
9
9
5-17
18
19
20
3
86037810 CHARIOT® VACUUM 12/16/06
7
12
FRAME-LOWER
REF PART NO. PRV NO. QTY DESCRIPTION
1 86092510 34440 1 FRAME, MAIN ASM
2 86088760 75458 1 TRAY, SLIDE, LEFT
3 86270830 57023 18 NUT, 5/16-18 HEX NYLOCK SS
4 86071430 140863 1 BRKT, BRACE, RGT FRONT
5 86071120 140811 1 BRKT, TIP BRACE, RIGHT, REAR
6 86010670 87029 4 WASHER, 5/16 FLAT SS
7 86064300 140790 2 PAD, TIPPING BAR
8 86070740 140730 1 BRKT, LINKAGE, RIGHT
9 86276070 70593 16 SCR, 5/16-18 X 3/4 CARRIAGE SS
10 86091420 05251 1 AXLE, REAR WELDMENT
11 86088750 75457 1 TRAY, SLIDE, RIGHT
12 86079320 620101 2 PLATE, PAD RETAINER
13 86071130 140812 1 BRKT, TIP BRACE, LEFT, REAR
14 86070750 140731 1 BRKT, LINKAGE, LEFT
15 86070760 140733 1 BRKT, BRACE, LEFT FRONT
16 86279130 87083 4 WASHER, 5/16 SPLIT LOCK PLTD
17 86197040 57264 4 NUT, 5/16-18 HEX ACORN PLTD
18 86079290 620097 2 PLATE, REAR COVER ADJ.
19 86010630 87013 4 WASHER, 1/4 ID X 5/8 OD SS
20 86271870 57290 4 NUT, 1/4-20 HEX NYLOCK THIN SS
21 86276950 70772 4 SCR, 1/4-20 X 3/4 CARRIAGE SS
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 12/16/06
5-18
FRAME-UPPER
1
2
3
2
3
4
7
2
2
4
3
8
4
2
4
5
2
3
6
4
5-19
2
3
86037810 CHARIOT® VACUUM 12/16/06
FRAME-UPPER
REF PART NO. PRV NO. QTY DESCRIPTION
1 86071360 140855 1 BRKT, HORIZ ELECT, BURNISHER
2 86270830 57023 13 NUT, 5/16-18 HEX NYLOCK SS
3 86010670 87029 12 WASHER, 5/16 FLAT SS
4 86276070 70593 12 SCR, 5/16 X 3/4 CARRIAGE SS
5 86078620 14023 1 BRKT, VERTICAL SUPPORT
6 86091820 140807 1 BRKT, SIDE CHANNEL R
7 86073500 270090 1 BRKT, SIDE CHANNEL L
8 86277460 70847 1 SCR, 5/16-18 X 5/8 BSHCS SS
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 12/16/06
5-20
HOOD
1
3
2
4
5
8
16
6
7
5
13
12
7
11
10
9
14
5-21
15
11
86037810 CHARIOT® VACUUM 11/16/06
HOOD
REF PART NO. PRV NO. QTY DESCRIPTION
1 86293630 - 1 LID, VACUUM
2 86076720 41534 1 HINGE, LID
3 86273830 70020 3 SCR, 1/4-20 X 1/2 HHCS SS NP
4 86226370 14493 2 BUSH, BRZ FLG .25 X .38 X .38
5 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS
6 86076710 41533 1 HINGE, TANK
7 86010630 87013 5 WASHER, 1/4 ID X 5/8 OD SS
8 86006840 70390 3 SCR, 1/4-20 X 1 FHCS PLTD
9 86032920 75482 1 TANK, VACUUM BODY COVER
10 86279630 87212 4 WASHER, .344 ID X 1.13 OD X .09 T PLT
11 86006760 70305 6 SCR, 5/16-18 X 3/4 HHCS GR5 PLTDL
12 86273820 70019 2 SCR, 1/4-20 X 1.25 HHCS SS
13 86250250 66286 2 PLUSNUT, 1/4-20 FLATHEAD
14 86254280 730331 2 SPACER, 1.00 OD X .32 ID X .375
15 86279630 87212 2 WASHER, .344 ID X 1.13 OD X .09 T PLT
16 86273780 70015 2 SCR, 1/4-20 X 3/4 HHCS SS NP
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 05/02/07
5-22
PEDAL PLATFORM
28
30
10
11
12
1
2
9
3
4
5
6
31
22
23
26
20
17
8
27
32
24
25
9
10
11
12
29
14
17
13
18
7
15
16
19
5-23
21
20
17
86037810 CHARIOT® VACUUM 10/04/07
PEDAL PLATFORM
REF PART NO. PRV NO. QTY DESCRIPTION
1 86217650 34432 1 DIVIDER
2 86222700 34429 1 PLATFORM
3 86216380 140713 2 BUSHING, 8MM X 10LG CLY
4 86007110 72123 2 SWITCH, 25A SPST 125-250V SNAP
5 86279720 87248 4 WASHER, M4 INT STAR
6 86272040 57503 4 NUT, M3.5 X 2.8 HEX
7 86223580 67502 2 ROD, PIVOT, 8.5MM X 77
8 86222520 34431 1 PEDAL, BRAKE
9 86277390 70836 4 SCR, M3.5 X 38 PHMS
10 86233170 20054 3 CLAMP, 3/8 NYLON UL/CSA
11 86279730 87249 4 WASHER, M5 INT STAR
12 86277380 70835 4 SCR, M4.8 X 16 PHTF
13 86222510 34430 1 PEDAL, THROTTLE
14 86254970 730304 2 SPRING, COMP 18MM OD X 83 X 2
15 86222780 620047 2 PLATE, PIVOT
16 86277360 70833 2 SCR, M6 X 10 PH
17 86274340 70179 11 SCR, M6 X 16 PH
18 86224360 730325 2 SPACER 12.7MM ID X 2.78W X 6L
19 86222810 620050 1 PLATE, COVER
20 86279140 87085 9 WASHER, M6 SPLIT LOCK DIN127B
21 86288720 57277 2 NUT, M6 NYLOCK PLATED
22 86250280 66135 1 POTENTIOMETER, 5K OHMS
23 86222790 620048 1 PLATE, THROTTLE
24 86278060 70759 2 SET SCR, M4 X 4MM NP
25 86224350 730305 1 SPACER, 8MM 16L
26 86277370 70834 1 SCR, M5 X 30 SHCS
27 86221850 34433 1 LINK, THROTTLE
28 86218810 23717 1 HARNESS, TWISTER PEDAL
29 86136310 57086 1 NUT, M5 HEX
30 86264920 27049 1 CABLE TIE, 7” UL/CSA
31 86224750 73993 1 SPRING, COMP, .480D X .91 *(7)
32 86223260 66085 1 PLUNGER, PLATFORM SWITCH *(7)
NOTE: Complete platform assembly is available, Part No. 86028310
* SEE SERIAL NUMBER PAGE
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 12/16/06
5-24
PEDAL PLATFORM
18
14
2
3
17
16
6
6
1
15
11
14
13
19
20
12
5
22
7
5
8
8
4
9
21
5
8
23
5-25
12
11
10
86037810 CHARIOT® VACUUM 12/16/06
PEDAL PLATFORM
REF PART NO. PRV NO. QTY DESCRIPTION
1 86277430 70843 1 SCR, 1/4-20 X 3.00 SHCS
2 86274690 70258 2 SCR, 5/16-18 X 1.5 HHCS GR5PLT
3 86264920 27049 3 CABLE TIE, 7” UL/CSA
4 86231070 730328 2 BUMPER, 1 X 1.375 RUBBER
5 86010670 87029 5 WASHER, 5/16 FLAT SS
6 86259430 87485 4 M12 FLAT WASHER
7 86010770 87143 2 WASHER, 7/16ID X1D.08 FLT SS
8 86270830 57023 5 NUT, 5/16-18 HEX NYLO CK SS
9 86256470 70852 2 STUB AXLE, M12-1.75 X 45MM
10 86005810 57245 1 NUT, 1/4-20 HEX NYLOCK SS
11 86010810 87191 2 WASHER, 1/4” IDX1.0O D FLAT SS
12 86064480 629993 1 PLATE, SWITCH BASE
13 86286580 47479 1 SPACER, ACTUATOR SWITCH
14 86007780 73576 1 SPRING, COMP .60D X2.0L X .045W
15 86279760 87256 2 WASHER, 1/4 LOCK HICOLLAR PLT
16 86259440 87486 2 WASHER, M12 SPRING L OCK
17 86271190 57142 2 NUT, M12 X 1.75 HEX DIN934 PLT
18 86248920 66487 1 PIN, CLEVIS 1/2 X 2.25 *(7)
19 86278850 80613 2 WASHER, .506 ID X .94D X .064 NYL *(7)
20 86008680 80607 1 COTTER, 1/2” RING *(7)
21 86256130 730402 1 STRAP, STATIC, .2T X 1W X 3L
22 86276980 70775 1 SCR, 5/16 X 2 HHCS SS
23 86279630 87212 1 WASHER, .344ID X 1.13 OD X .09T PLT
* SEE SERIAL NUMBER PAGE
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 12/16/06
5-26
REAR COVER
12
11
9
10
9
8
7
6
5
13
14
3
2
3
4
1
2
15
16
5-27
86037810 CHARIOT® VACUUM 12/16/06
REAR COVER
REF PART NO. PRV NO. QTY DESCRIPTION
1 86276780 70728 3 SCR, 5/16-18 X 3/4 HHCS SS
2 86279130 87083 5 WASHER, 5/16 SPLIT LOCK PLTD
3 86010670 87029 5 WASHER, 5/16 FLAT SS
4 86031780 270082 1 COVER, REAR DELUXE
5 86005860 57273 2 NUT, 1/4-20 X 12MM HEX BARREL
6 86228980 09152 2
7 86275870 70556 2 SCR, 1/4-20 X 1.5” PPHMS SS WAS 70697
8 86242140 72193 1 KNOB, 3/8-16 X 1.5
9 86010770 87143 2 WASHER, 7/16ID X 1D X .08FLT SS
10 86248380 66433 1 PAD, FLAT LEANING
11 86005630 57022 1 NUT, 3/8-16 HEX NYLOCK THIN SS
12 86071030 140786 1 BRKT, ASSEMBLY, REAR COVER
13 86010780 87162 2 WASHER, 1/4 SPLIT LOCK PLTD
14 86271940 57299 2 NUT, 1/4-20 ACORN SS
15 86006560 70083 2 SCR, 5/16-18 X 1 HHCS SS NP
16 86066940 140891 1 BAR, COVER
BEARING FLANGED .377ID X
.505OD
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 10/13/08
5-28
SIDE BROOM – DELUXE
20
22
21
1
2
10
11
4
2
SIDE BROOM ASM.
5
9
1
1
8
6
7
8
13
8
2
14
15
19
18
16
3
2
12
5-29
17
14
86037810 CHARIOT® VACUUM 12/16/06
SIDE BROOM – DELUXE
REF PART NO. PRV NO. QTY DESCRIPTION
1 86006560 70083 7 SCR, 5/16-18 X 1 HHCS SS
2 86271840 57285 9 NUT, 5/16 –18 HEX NYLOCK THIN SS
3 86062570 27954 1 COVER, SIDE BROOM
4 86274350 70187 4 SCR, 10-24 X 1/2 PHTC –F-
5 86068350 14119 1 BRACKET, MOUNT, SIDE BRUSH
6 86259410 87206 1 WASHER, THRUST .51 ID X 1 OD X .063
7 86277130 70795 2 SCR, 5/16-18 X 1.00 CARRIAGE SS
8 86228840 09124 3 BEARING, FLANGED .314 ID X .502 OD
9 86088500 14118 1 BRACKET, SWIVEL, SIDE BRUSH
10 86065790 14104 1 ARM - MO UNTING, SIDE BRUSH
11 86006590 70088 4 SCR, 10-32 X 1/2 PPHMS SS NP
12 86226830 73268 1 SPRING, EXT .68D X 3.00 L X .098W
13 86247390 53276 1 MOTOR, 36VDC, 90 DEG./16HP
14 86271870 57290 4 NUT, 1/4-20 HEX NYLOCK THIN SS
15 86094090 89282 1 SHAFT, COLLAR ASSEMBLY PLATE
16 86010630 87013 3 WASHER, 1/4 ID X 5/8 OD SS
17 86230600 12040 1 BRUSH, 13”, NYLON BLACK, SIDE
18 86273740 70010 1 SCR, 1/4-20 X 1.5 HHCS SS
19 86273810 70018 3 SCR, 1/4-20 X 1 HHCS SS
20 86073530 29280 1 BRKT, SIDE BROOM, CABLE MNT *(8)
21 86270830 57023 2 NUT, 5/16-18 HEX NYLOCK SS
22 86276070 70593 2 SCR, 5/16-18 X ¾ CARRIAGE SS
* SEE SERIAL NUMBER PAGE
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 12/16/06
5-30
STEERING
6
8
28
9
10
1
2
3
4
5
7
22
24
21
23
18
26
25
27
29
17
20
19
15
11
12
13
14
14
19
16
5-31
7
86037810 CHARIOT® VACUUM 12/16/06
STEERING
REF PART NO. PRV NO. QTY DESCRIPTION
1 86271610 57228 1 NUT, 5/8-16 HEX NYLOCK THN
2 86234810 27945 1 COVER, STEERING WHEEL
3 86259610 730117 1 WHEEL, STEERING 40 SPLINE HUB
4 86224050 730318 1 SHAFT, UPPER STEERING
5 86228790 09111 1 BEARING, FLANGE .88ODX.75IDX.75
6 86091740 140720 1 BRKT, UPPER STEERING
7 86270830 57023 4 NUT, 5/16-18 HEX NYLOCK SS
8 86005610 57016 1 NUT, 7/8 DIA PUSHLOCK
9 86219600 45012 1 JOINT, UNIVERSAL FEMALE
10 86272900 67416 1 RING, 3/4” KLIP
11 86224060 730319 1 SHAFT, LOWER STEERING
12 86219650 48110 1 KEY, 5MM SQ X 39MM L
13 86228670 09072 1 BEARING, 3/4” BORE FLANGED
14 86276070 70593 4 SCR, 5/16-18 X 3/4 CARRIAGE SS
15 86224800 730315 2 SPROCKET, STEERING SHAFT
16 86010670 87029 2 WASHER, 5/16 FLAT SS
17 86135970 48045 1 KEY, 3/16 SQ X 5/8 LONG
18 86275190 70377 1 SCR, 3/8-16 X 1.25 HHCS SS
19 86008610 80595 2 FLANGE, BEARING PRESS STEEL
20 86001030 09148 1 BEARING, BALL 3/4 BORE SPHERED
21 86224320 730221 1 SPACER, .63 OD X .385ID X .64L
22 86224810 730316 1 SPROCKET, DRIVE WHEEL STEERING
23 86005630 57022 1 NUT, 3/8-16 HEX NYLOCK THIN SS
24 86002750 270088 1 CHAIN, ISO 08B, 12.7MM PITCH
25 86278940 87008 2 WASHER, 1/4 ID X 1-1/4OD PLT
26 86010780 87162 1 WASHER, 1/4 SPLIT LOCK PLTD
27 86274330 70175 1 SCR, M6 X 20HHMS PLTD
28 86279130 87083 2 WASHER, 5/16 SPLIT LOCK PLTD
29 86253200 70806 1 SET SCR, M6 X 25 NP SERVICE ONLY
- 86232780 279001 - CHAIN, MASTERLINK 12.7MM SERVICE ONLY
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 12/16/06
5-32
VACUUM
3
2
39 (BASIC)
22
24
28
29
25
DELUXE
36
27
26
29
44
3
4
10
11
18
19
1
3
10
14
13A,B
38
15
13A,B
16
13B
1
2
33
1
3
0
3
4
12
7
40
41
42
43
1
20
35
17
5
6
9
8
5-33
37
TO VAC NOZZLE
86037810 CHARIOT® VACUUM 07/08/08
26
29
23
22
21
VACUUM
REF PART NO. PRV NO. QTY DESCRIPTION
1 86273780 70015 8 SCR, 1/4-20 X 3/4 HHCS SS NP
2 86197220 87193 2 WASHER, 1/4 X 1.5 FENDER PLTD
3 86086740 730397 1 SCREEN, VAC INTAKE
4 86237960 35362 2 GASKET, VACUUM BOX LID
5 86075570 51460 1 COVER, VAC BOX
6 86272020 57313 5 NUT, 3-32 HEX THIN NYLOCK SS
7 86240300 39718 1 HOSE, GRY VAC, 2.5 X 36
8 86200030 41394 1 HINGE, ACCESS PLATE SENSEI
9 86087370 730398 1 SPACER, VAC BOX LID
10 86005810 57245 4 NUT, 1/4-20 HEX NYLOCK SS
11 86229990 140927 1 BOX, WAV VACUUM
12 86277620 70891 2 SCR, 8-32 X 1/2 HHCS SS
13A 86233120 20019 3 CLAMP, 2.75” WORM GEAR BASIC ONLY
13B 86233120 20019 4 CLAMP, 2.75” WORM GEAR DELUXE ONLY
14 86088130 73950 1 STRAP, CHUTE
15 86247520 53818 1 VAC MOTOR, 36V 1ST TD
- 86290210 - - BRUSH SET MOTOR 53818
16 86068440 54208 1 BRACKET, VAC MOTOR MOUNT
17 86236190 34456 1 FITTING, 2 OD MALE X MALE PVC DELUXE ONLY
18 86247660 54209 1 MUFFLER, SOUND TUBE PLASTIC DELUXE ONLY
19 86002830 27196 2 CABLE, TIE, .375 X 24.7 DELUXE ONLY
20 86240760 81399 1 HOSE, 2” VAC X 32” DELUXE ONLY
21 86068110 14028 1 BRACKET, VAC BOX MOUNT
22 86276780 70728 6 SCR, 5/16-18 X 3/4 HHCS SS
23 86270830 57023 2 NUT, 5/16-18 HEX NYLO CK SS
24 86010780 87162 6 WASHER, 1/4 SPLIT LOCK PLTD
25 86235400 78600 2 EDGING, 16” GRIP X 5.50” LG
26 86010670 87029 6 WASHER, 5/16 FLAT SS
27 86006730 70259 2 SCR, 5/16-18 X 1.75 HHCS PLTD
28 86075530 27923 1 COVER, VAC MOTOR DELUXE ONLY
29 86279130 87083 8 WASHER, 5/16 SPLIT LOCK PLTD
30 86062710 29274 1 DEBRIS CHUTE, WAV
31 86227870 140915 1 BAG, CLOTH VACUUM
32 86215090 140949 1 BAG, PAPER WIDE AREA VAC
33 86224380 730336 2 SPACER, 1 OD X .391 ID X 1.063
34 86238050 36246 1 GASKET, 4.25OD X 3.63ID X .25
35 86240310 39719 1 HOSE, GRAY VAC, 2.25 X 10.0 WAS 39419
36 86238450 36245 1 GROMMET, 3.0 ID X 3.25 GROOVE
37 86234890 270148 1 CUFF, 2.5 SLIP X 2.5 HOSE
38 86009380 81866 1 CUFF, 2” ID VAC-U-FLEX HOSE
39 86081230 62708 1 PLATE, VAC COVER BASIC ONLY
40 86198000 40067 1 HOSEBARB, 1/8MPT X 3/8 PLASTIC
41 86281680 39486 1 HOSE, 3/8ID NYLOBRAID X 2”
42 86233090 20016 2 CLAMP, 1/4 ID HOSE
43 86257160 72199 1 SWITCH, VACUUM 15” H20 NC/NO
44 86251750 67602 1 RISER, BUMPER
- 86316200 - - VACUUM LINT BRUSH NOT SHOWN
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 10/11/08
5-34
WHEEL-FRONT DRIVE-CHAIN
1
2
3
18
17
33
35
32
31
20
27
26
4
18
5
17
8
9
10
23
15
24
11
12
19
13
14
15
16
17
18
6
7
25
1
21
22
14
9
9
30
29
28
5-35
86037810 CHARIOT® VACUUM 05/19/08
WHEEL-FRONT DRIVE-CHAIN
REF PART NO. PRV NO. QTY DESCRIPTION
1 86223980 09134 4 SEALED BALL BRNG, 25MM X 52MM
2 86223480 67450 2 RING, 52MM INTERNAL SNAP
3 86219420 41510 1 STEERING, HUB
4 86224040 730306 1 SHAFT, ASM, DRIVE PIVOT
5 86005510 53810 1 MOTOR, 36V 180RPM GEAR
- 86216210 53820 - BRUSH SET MOTOR 53810
- 86227440 05261 - ARMATURE 53810 MOTOR
6 86136360 57275 1 NUT, M10X1.5 HEX NYLOCK PLTD
7 86010720 87086 1 WASHER, M10 X 30 PLTD
8 86222730 620038 1 PLATE, DRIVE WHEEL YOKE LH
9 86277320 70828 11 SCR, M10 X 30 HHCS
10 86275640 70515 4 SCR, 3/8-24 X 3/4 HHCS GR5 PLTD
11 86279700 87244 5 WASHER, M10 X 18 FLAT
12 86219620 48106 1 KEY, 1/4 SQ. X .63
13 86007620 730310 1 SPROCKET, MOTOR SHAFT
14 86279710 87245 3 WASHER, M8 (2 THK X 26 OD) FLAT
15 86136640 70262 2 SCR, M8-1.25 X 20HHMS PLTD
16 86222710 620036 1 PLATE, CHAIN COVER
17 86279690 87243 12 WASHER, M6 SPLIT LOCK BLK
18 86277340 70830 12 SCR, M6 X 15 HHCS BLK
19 86002730 270085 1 CHAIN, ISO 08B 12.7MM PITCH/LINK
- 86232770 279000 - CHAIN, OFF-SET LINK 12.7MM SERVICE ONLY
- 86232780 279001 - CHAIN, MASTERLINK 12.7MM SERVICE ONLY
20 86222760 620041 1 PLATE, DRIVE YOKE RH
21 86007630 730311 1 SPROCKET, DRIVE WHEEL
22 86002710 270076 1 CHAIN TENSIONER
23 86224270 730293 1 SLEEVE, CHAIN TENSIONER
24 86277330 70829 1 SCR, M10 X 45 HHCS
25 86222720 620037 1 PLATE, BEARING RETAINER
26 86224330 730294 1 SPACER, 25.5ID X 45OD X 65L
27 86219630 48107 1 KEY, 3/16 SQ X .67
28 86000850 05231 1 AXLE, DRIVE
29 86219640 48108 1 KEY, 1/4 SQ X 1.5
30 86259940 89275 1 WHEEL, 10X2.5 W/KEYWY GRY, NT
31 86222750 620040 1 PLATE, DRIVE YOKE FRONT
32 86224340 730295 1 SPACER, 25.5ID X 45OD X 43L
33 86222770 620042 1 PLATE, BEARING COVER
34 86217720 29269 - DRIVE ASM, MOTOR COMPLETE
35 86311040 - 1 SPACER, CHAIN DRIVE AXLE
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 05/19/08
5-36
WHEEL-FRONT DRIVE, GEAR
1
2
5
18
17
16
20
15
19
14
21
13
12
4
11
6
7
3
10A
10B
8
9
22
5-37
86037810 CHARIOT® VACUUM 02/21/09
WHEEL-FRONT DRIVE, GEAR
SERIAL NO.
REF PART NO. PRV NO. QTY DESCRIPTION
1 86275190 70377 4 SCR, 3/8-16 X 1.25 HHCS SS
2 86010790 87163 4 WASHER, 3/8 SPLIT LOCK PLTD
3 86002830 27196 1 CABLE TIE, .375 X 24.7
4 86006170 66031 1 PIN, ROLL 1/8” X 3/4”L
5 86223980 09134 3 SEALED BALL BRNG, 25MM X 52MM
6 86219420 41510 1 HUB STEERING
7 86223480 67450 2 RING, 52MM INTERNAL SNAP
8 86224020 730233 1 SHAFT ASM, DRIVE PIVOT
9 86215440 140920 1 BOX, DRIVE UNIT
10A 86011120 89262 1 WHEEL, 10 X 2, 5 X 1.06 W/KEYWAY
10B 86259920 89273 1 WHEEL, 10 X 2. 5 W/KEYWAY, GRY
11 86224440 730387 1 SPACER, 25.51 ID X 45 OD X 39.1 L
12 86222720 620037 1 PLATE, BEARING RETAINERX
13 86225810 87506 1 WASHER, ANTI-ROTATION
14 86279710 87245 1 WASHER, M8 (2THK X 26 OD)
15 86136640 70262 1 SCR, M8-1.25 X 20 HHMS PLTD
16 86222770 620042 1 PLATE, BEARING COVER
17 86279690 87243 4 WASHER, M6 SPLIT LOCK BLK
18 86277340 70830 4 SCR, M6 X 15 HHCS BLK
19 86223980 09134 3 SEALED BALL BRNG, .25MM X 52MM
20 86277320 70828 10 SCR, M10 X 30 HHCS
21 86222760 620041 1 PLATE, DRIVE YOKE RH
22 86217730 29276 1 DRIVE MOTOR ASSEMBLY
- 86216210 53820 - BRUSH SET MOTOR, 53810 86005510
* SEE SERIAL NUMBER PAGE
FROM
NOTES:
OPTION
COMPLETE
86037810 CHARIOT® VACUUM 02/21/09
5-38
WHEEL-FRONT BRAKE
14
18
16
19
20
17
1
2
3
21
13
15
12
10
11
4
7
8
6
9
5
5-39
86037810 CHARIOT® VACUUM 02/21/09
WHEEL-FRONT BRAKE
SERIAL NO.
REF PART NO. PRV NO. QTY DESCRIPTION
1 86010790 87163 4 WASHER, 3/8 SPLIT LOCK PLTD
2 86275190 70377 4 SCR, 3/8-16 X 1.25 HHCS SS
3 86006170 66031 1 PIN, ROLL 1/8” X 3/4”L SS
4 86005810 57245 2 NUT, 1/4-20 HEX NYLOCK SS
5 86277320 70828 1 SCR, M10 X 30 HHCS
6 86233410 81270 1
7 86005710 57105 4
8 86273740 70010 2 SCR, 1/4-20 X 1.50 HHCS
9 86008920 80889 2
10 86257490 76155 2 TERMINAL MOUNT
11 86006840 70390 2 SCR, 1/4-20 X 1 FHCS PLTD
12 86010630 87013 2 WASHER, 1/4 ID X 5/8 OD SS
13 86273340 00-000289 4 SCR, 8-32 X 3/8 SHCS SS
14 86001740 140816 1 BRAKE, 36VDC W/CONNECTOR
15 86270990 57090 3 NUT, 10-32 HEX NYLOCK SS *(9)
16 86301950 - 1 PLATE, BRAKE SPACER *(9)
17 86264930 27050 1 CABLE TIE, 3.5” UL/CSA
18 86301960 - 1 SKIRT, BRAKE *(9)
19 86010650 87018 3 WASHER, #10 X 9/16 OD *(9)
20 86274290 70162 3 SCR, 10-32 X 3/8 PPHMS SS *(9)
21 86320870 - 1 SWITCH, 36V BRAKE
* SEE SERIAL NUMBER PAGE
CLAMP, 3/4 DIA CUSHION
.406DIA
NUT, 1/4-20 HEX W/STAR
WASHER
BOOT, RUBBER TERM.
ISOLATOR
FROM NOTES:
86037810 CHARIOT® VACUUM 02/21/09
5-40
WHEEL-REAR
5-41
1
2
3
86037810 CHARIOT® VACUUM 10/23/07
WHEEL-REAR
REF PART NO. PRV NO. QTY DESCRIPTION
1 86259950 89276 2 WHEEL, 10X2.5 W/BRNGS, GRAY, NT
2 86008710 80623 2 RING, ¾” EXT SNAP H-D
3 86232130 17309 2 CAP, 2.75 ID X 1.0 L BLK VINYL
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 10/23/07
5-42
WIRING-BATTERIES
2
1
7
6
3
4
20A
20B
5
9
26
25
23
24
8
10
11
22
12
13
14
15
16
5-43
19
17
18
86037810 CHARIOT® VACUUM 10/23/07
WIRING-BATTERIES
REF PART NO. PRV NO. QTY DESCRIPTION
1A 86260200 80872 2 WIRE, 4X14.5BK 3/8 RING X 3/8 RING
1B 86002510 23125 2 CABLE ASM, BAT. JUMPER X 15”
2 86008920 80889 6 BOOT, RUBBER TERM. ISOLATOR
3 86271910 57295 6 NUT, 5/16-18 FLEXLOCK
4 86010670 87029 6 WASHER, 5/16 FLAT SS
5 86264960 27915 2 CABLE TIE, .375 X 43”
6A 86260610 880836 1 WIRE, 4X25RD CTERM X 3/8RING *(10)
6B 86002570 23190 1 WIRE, 4X27 RD BCLAMP X CTERM
7A 86260230 80876 1 WIRE, 4X30 BK CTERM X 3/8RING
7B 86002580 23191 1 WIRE, 4X27 BK BCLAMP X CTERM
8 86008760 80682 1 CONN, 175 DCA GRY W/O TERMS
9 86229700 08071 3 BLOCK, 3.0 X 1.5 X 1.5
10 86008300 78242 1 TRAY, BATTERY LINER
11 86008410 78568 1 TRAY, BATTERY
12 86272810 67132 1 RING, ½ EXT. SNAP H-D
13 86092910 51396 1 LATCH ROD, BATTERY TRAY
14 86254990 730313 1 SPRING, COMP, 63ODX3.5LX.047
15 86278150 70117 8 SHOULDER BOLT, 5/16 OD X 1.0 L
16 86259910 89265 8 WHEEL, BATTERY TRAY
17 86088790 78571 2 TRAY, STANDARD STOP
18 86276070 70593 4 SCR, 5/16-18 X ¾ CARRIAGE SS
19 86270830 57023 4 NUT, 5/16-18 HEX NYLOCK SS
20A 86228410 10023 3 BATTERY, 12V, 205AH
20B 86283410 10030 3 BATTERY, 12V, 225AH
21 86284090 02456 1 CHARGE R, 36V, 20A, 115V, C175 NOT SHOWN
22 86005810 57245 8 NUT, ¼-20 HEX NYLOCK SS
23 86233360 28038 1 CLAMP, CABLE KIT SY945
24 86270890 57034 1 NUT, ACORN 10-32
25 86010650 87018 1 WASHER, #10 X 9/16 OD
26 86273980 70066 1 SCREW, 10-32 X ¾ PPHMS SS
* SEE SERIAL NUMBER PAGE
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 10/20/08
5-44
WIRING-COMPONENTS
2
1
3
4
6
4
5
7
8
9
10
5-45
11
13
12
86037810 CHARIOT® VACUUM 02/03/09
WIRING-COMPONENTS
REF PART NO. PRV NO. QTY DESCRIPTION
1 86010780 87162 2 WASHER, 1/4 SPLIT LOCK PLTD
2 86273830 70020 2 SCR, 1/4-20 X 1/2 HHCS SS NP
3 86255910 73659 2 STANDOFF, 1/4-20 X 1.0 HEX INS
4 86005710 57105 4 NUT, 1/4-20 HEX W/STAR WASHER
5 86010630 87013 2 WASHER, 1/4 ID X 5/8 OD SS
6 86006850 70393 2 SET SCR, 1/4-20 1.25L
7 86008920 80889 2 BOOT, RUBBER TERM. ISOLATOR
8 86238500 81427 2 GROMMET, 1.703IDX2.5ODX.125GRV
9 86276070 70593 1 SCR, 5/16-18 X 3/4 CARRIAGE SS
10 86239720 41520 1 HORN, 108DB MINIATURE PIEZO
11 86233410 81270 1 CLAMP, 3/4 DIA CUSHION .406DIA
12 86270830 57023 1 NUT, 5/16-18 HEX NYLOCK SS
13 86010670 87029 1 WASHER, 5/16 FLAT SS
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 10/23/07
5-46
WIRING-CONTROL PANEL
68/RED
67/WHT-GRN
59/WHT-GRN
68/RED
7
38/BLK
25A/WHT-RED
57/WHT-RED
37/BLK
A
BAG FULL
30/WHT-GRN
58/WHT-ORG
25/WHT-RED
39/RED
BAG FULL RELAYINTERRUPT RELAY
1/WHT
2/BLK
STATUS LED
28/RED
17/RED
13/RED
12/RED
39/RED
85/GRN
57/WHT-RED
55/WHT-RED
36/BLK
37 BLK
75/BLK
74/RED
62/BLK
63/BLK
61/RED
71/ORG
69/BLK
47/DK GRN
73/RED
30A
74/RED
3/LT BLU
64/RED
32/WHT
65/WHT
66/WHT
56/RED
50/RED
4
J
42/GRN
40/YLW
44/GRN
26/WHT-RED
51/RED
8/BRN
9/BRN
63/BLK
84/BLK
GFEDCB
2 BLK
1 WHT
16/RED
25A
35A
3A
15/RED
11 BLK
70/LT BLU
83/BLK
62/BLK
69/BLK
60/BLK
24/BLK
76/BLK
29/BLK
81/BLK
75/BLK
87/BLK
19/BLK
54/RED
3A
53/RED
49/RED
55/WHT-RED
41/YLW
43/GRN
79/BLK
46/DK BLU
33
33/BLK
4/RED
64/RED
65/WHT
66/WHT
45/GRY
22/ORG
23/ORG
K
6
1
14/RED
71/ORG
31/WHT-BLK
BRUSH
RELAY
18/RED
35/LT BLU
70/LT BLU
18/RED
85/GRN
12/RED
86/WHT-YLW
VAC
RELAY
3
I
76/BLK
WHTBLK
4
52/RED
H
5
6/RED
73/RED
72/RED
18/RED
60/BLK
MAIN
RELAY
53/RED
4
L
I
4
2
5-47
DIAGRAM A
DIAGRAM G
40/YLW
45/GRY
78/RED
47/DK GRN
30/WHT-ORG
10/GRN
46/DK BLU
33/BLK
84/BLK 7/BRN
13/RED
11/BLK
DIAGRAM J
DIAGRAM D
67/WHT-GRN
87/BLK
31/WHT-BLK
16/RED
24/BLK
3
4
3/LT BLU
59/WHT-GRN
6
7
86/WHT-YLW
56/WHT-ORG
27/WHT-RED
21/BLK
12
1
23/ORG
DIAGRAM K
79/BLK
29204
46/DK BLU
33
67619
45/GRY
33/BLK
4/RED
DIAGRAM L
6
1
MAIN
RELAY
29204
DIAGRAM CDIAGRAM B
28/RED
MAIN
RELAY
A
B
20/BLK
DIAGRAM I
35/LT BLU
48/RED
7/BRN
5/ORG
DIAGRAM H
8/BRN32/WHT
29273
B
A
29204
6/ORG
9/BRN
10/GRN
DIAGRAM FDIAGRAM E
82/RED
80/RED
79/BLK
83/BLK
3
4
81/BLK
78/RED
6
1
86037810 CHARIOT® VACUUM 07/22/08
WIRING-CONTROL PANEL
REF PART NO. PRV NO. QTY DESCRIPTION
1 86239230 41550 1 HARNESS, CONTROL PANEL
2 86260540 880426 1 WIRE, 4X13 RD C.TERM X 5/16RING
3 86010860 880353 1 WIRE, 4X20 BL CTERM X5/16RING
4 86261210 29204 3 DIODE ASM, 76008, 79008
5 86261250 29273 1 DIODE ASM, FAST RECOVERY
6 86251490 67619 1 RESISTOR ASM, 1/2 WATT 33 OHM *(11)
7 86311210 - 1 LIGHT ASM, INDICATOR, CODE
* SEE SERIAL NUMBER PAGE
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 05/27/08
5-48
WIRING-DRIVE MOTOR
1 WHT
RED
2 BLK
BLK
1
WHT
CONTROL PANEL
BLK
HARNESS
1 WHT
2 BLK
2 BLK
5-49
86037810 CHARIOT® VACUUM 10/23/07
WIRING-DRIVE MOTOR
REF PART NO. PRV NO. QTY DESCRIPTION
1 86239120 41522 1 HARNESS, CHARIOT PROPEL
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 10/23/07
5-50
WIRING-MAIN HARNESS
HEADLIGHT
HORN
BRAKE
DRIVE
MOTOR
VAC
MOTOR
BRUSH
MOTOR
SIDE
BROOM
1
DIAGRAM A
DIAGRAM B
DIAGRAM D
24/BLK
12
1
7
7/BRN
2
8/BRN
23/ORG
21/BLK
27/WHT-RED
58/WHT-ORG
86/WHT-YLW
60/WHT-GRN
6
DIAGRAM C
A
B
13/RED
11/BLK
16/RED
31/WHT-BLK
87/BLK
67/WHT-GRN
A
B
28/RED
20/BLK
84/BLK
1
43
32/WHT
3
BACKUP
ALARM
DIAGRAM E
83/BLK
78/RED
81/BLK
1
3
4
6
80/RED
79/BLK
82/RED
FLASHING
LIGHT
A
B
C
D
E
DIAGRAM F
F
31A/WHT-BLK
6
1
58A/WHT-ORG
87A/BLK
67A/WHT-GRN
4
3
60A/WHT-GRN
86A/WHT-YLW
2
60/WHT-GRN
86/WHT-YLW
LEVER
SWITCH
67/WHT-GRN
31/WHT-BLK
58/WHT-ORG
87/WHT-YLW
FLASHING
LIGHT
LEVER
SWITCH
DIAGRAM G
G
5-51
DENOTES OPTIONAL EQUIPMENT
86037810 CHARIOT® VACUUM 10/23/07
WIRING-MAIN HARNESS
REF PART NO. PRV NO. QTY DESCRIPTION
1 86239170 41528 1 HARNESS, BRAKE
2 86239240 41552 1 HARNESS, LEVER SWITCH
3 86239220 41549 1 HARNESS, I VAC, MAIN
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 10/23/07
5-52
WIRING-PEDAL PLATFORM
B
A
1
BRN
BLU
DIAGRAM A
5 ORG
6 BRN
4 RED
7 GRN
3 LT BLU
DIAGRAM B
BRN
RED
5 GRN
10 BRN
6 ORG
5-53
86037810 CHARIOT® VACUUM 10/23/07
WIRING-PEDAL PLATFORM
REF PART NO. PRV NO. QTY DESCRIPTION
1 86218810 23717 1 HARNESS, TWISTER PEDAL
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 10/23/07
5-54
WIRING DIAGRAM
LIFT
LEVER
SIDE
BROOM
62/BLK
81/BLK
69/BLK
14/RED
29204
35A/LT-BLU
25A/RED
16/RED
83/BLK
21A/BLK
12 PIN DEUTSCH
21A/BLK
70A/LT-BLU
71/ORG
18/RED
60A/BLK
67/WHT-GRN
67/WHT-GRN
1
31/WHT-BLK
72/RED
6/RED
SWITCH
6 PIN
DEUTSCH
87/BLK
58/WHT-ORG
87A/BLK
58A/WHT-ORG
74/RED
BRUSH
RELAY
73/RED
MAIN
RELAY
31/WHT-BLK
31A/WHT-BLK
69A/BLK
FULL BAG
SWITCH
4 PIN
DEUTSCH
4 PIN
DEUTSCH
86/WHT-YLW
60/WHT-GRN
27/WHT-RED
24/BLK
24A/BLK
59/WHT-GRN
27A/WHT-RED
86A/WHT-YLW
B
-
T
L
/
3
73A/RED
2
3
71A/ORG
70/LT-BLU
29215
53/RED
23/ORG
23A/ORG
E
U
L
VACUUM
29204
WHT
RELAY
29204
54/RED
53A/RED
18A/RED
52A/RED
55/WHT-RED
32/WHT
12/RED
32/WHT
84/BLK
7/BRN
6 PIN
DEUTSCH
84/BLK
7A/BRN
32A/WHT
27/RED
26A/RED
85A/GRN
86/WHT-ORG
30/WHT-ORG
10/GRN
5/ORG
7/BRN
46/BLU
48/RED
BRUSH
MOTOR
28/RED
20/BLK
2 PIN
PACKARD
20A/BLK
28A/RED
28/RED
BROOM
BRUSH
18A
15A/RED
15/RED
1/WHT
1
33/BLK
33K
86310910
CURTIS 1228 MOTOR CONTROLLER
SIDE
3A
2/BLK
TRACTION
2A/BLK
1A/WHT
29A/BLK
57A/WHT
37A/BLK
57A/WHT
76/WHT-RED
38/BLK
36/BLK
55A/WHT-RED
58/WHT-ORG
85/GRN
57/WHT
39/RED
30A/WHT-ORG
40/YLW
78/RED
47/GRN
9
2
1
45/GRY
BLK
35/LT BLU
R
39A/RED
68A/RED
59/WHT-GRN
67/WHT-GRN
68/RED
16/RED17/RED
17A/RED
14A/RED
13/RED
VACUUM
12A/RED
75A/BLK
VACUUM
MOTOR
11/BLK
13/RED
2 PIN
PACKARD
11A/BLK
13A/RED
20/BLK
21/BLK
19A/BLK
30A
8
7
/
29/BLK
74A/RED
B+B-M2M1
24/BLK
11/BLK
19/BLK
B
L
K
LK
B
/
5
7
60/BLK
FRONT
REAR
40A/YLW
9/BRN
79/BLK
58A/BLK
26/RED
50/RED
51A/RED
22/ORG
WARNING
73/RED
72/BLK
40/RED
BATTERY
METER
SPEED
SWITCH
FORWARD/REV
67619
33
33A/BLK
SWITCH
RESET
SWITCH
BACK UP
ALARM
42/GRN
43/GRN
44/GRN
40/BLK
30/GRN
79/BLK
46/BLU
45A/GRY
DEUTSCH
4A/RED
3A/LT-BLUE
32/RED
41/BLK
100K
200K
6 PIN
9A/BRN
6A/ORG
10A/GRN
87/BLK
4/RED
HEAD
WARNING
LIGHT
LIGHT
FLASHER
UNIT
8/BRN
81/RED
83/RED
82/BLK
78/RED
81/BLK
6 PIN
DEUTSCH
8/BRN
83A/BLK
81A/BLK
80A/RED
82A/RED
78A/RED
84/BLK
63A/BLK
8A/BRN
RUN/RESET
66A/WHT
65A/WHT
64A/RED
RELAY
KEY
82/RED
SWITCH
56/RED
49/RED
65/WHT
64/RED
66/WHT
56A/RED
82/RED
77/RED
48A/RED
PLATFORM
SWITCH
OPERATION
PRESENT
SWITCH
THROTTLE
POT
HEADLIGHT
SWITCH
59/RED
77A/RED
220K
E-STOP
HORN
SWITCH
32/RED
22/ORG
5-55
BLK
STATUS
WHT
LED
INDICATES OPTIONAL
EQUIPMENT
36V
86037810 CHARIOT® VACUUM 07/22/08
SUGGESTED SPARE PARTS
REF PART NO. PRV NO. DESCRIPTION
1 86001910 14606 BREAKER, 30A 50VDC CIRCUIT
2 86002000 14717 BREAKER, 3 AMP 1681-090-300
3 86002010 14942 BOOT, 3/8 CIRCUIT BREAKER
4 86232130 17309 CAP, 2.75 ID X 1.0 L BLACK VINYL
5 86004860 48073 KEY, SWITCH
6 86251410 67506 RELAY, 15A 36V MINI
7 86007140 72130 SWITCH, SPST 2-POSITION ROCKER
8 86007190 72161 SWITCH, DPST KEY
9 86001740 140816 BRAKE, 36 VDC W/CONNECTOR
10 86002730 270085 CHAIN, ISO 08B 12.7 MM PITCH
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 10/23/07
5-56
BACK-UP ALARM - OPTION
3
1
2
4
5-57
86037810 CHARIOT® VACUUM 10/23/07
BACK-UP ALARM - OPTION
REF PART NO. PRV NO. QTY DESCRIPTION
1 86071140 140817 1 BRKT, BACK UP ALARM
2 86231500 80882 1 BUZZER, PIEZO 6-28VCD
3 86276780 70728 1 SCR, 5/16-18 X 3/4 HHCS SS
4 86271840 57285 1 NUT, 5/16-18 HEX NYLOCK THIN SS
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 10/23/07
5-58
BATTERY CART - OPTION
27
23
22
28
3
30
5
24
3
9
15
5
3
26
2
6
25
29
8
1
2
3
3
3
10
8
9
3
5
5
6
7
3
11
4
12
13
14
5-59
21
16
20
8
19
18
17
86037810 CHARIOT® VACUUM 02/12/08
16
3
15
3
BATTERY CART - OPTION
REF PART NO. PRV NO. QTY DESCRIPTION
1 86006930 70514 2 SCR, 5/16-18 X 1.00 BSHCS SS
2 86254290 730338 4 SPACER, 10D X .343ID, .5 LG
3 86270830 57023 33 NUT, 5/16-18 HEX NYLOCK SS
4 86077010 41517 1 HOUSING, BATTERY CART
5 86010670 87029 7 WASHER, 5/16 FLAT SS
6 86228840 09124 3 BEARING, FLANGED .314D X .502OD
7 86259410 87206 1 WASHER, THRUST, .51 ID X 1 OD X .063
8 86259400 87205 6 WASHER, THRUST .51 ID X 1 ODBRO
9 86254890 730018 3 SPRING, EXT, .50D X 4.0L
10 86068490 140019 1 BRKT, TRAY CATCH
11 86254280 730331 2 SPACER, 1.00 OD X .32 ID X .375
12 86083120 66442 1 PLATE, BATTERY CART BACK
13 86076600 38318 2 HANDLE, BATTERY CART
14 86004070 36196 2 GRIP, POLISHER HANDEL
15 86276790 70732 4 SCR, 5/16-18 X 1.75 HHCS SS
16 86276690 70715 8 SCR, 5/16-18 X 1.75 CARR SS
17 86199430 040-03 2 CASTER SWIVEL 4” 250# CPCTY
18 86078890 620020 8 PLATE, CASTER SPACER
19 86277130 70795 16 SCR, 5/16-18 X 1.00 CARRIAGE SS
20 86007020 70673 1 SP SCR, 5/16-18 X 1.25 HHCS SS NP
21 86232590 18032 2 CASTER, 4” HARD RUBBER RIGID
22 86001350 140390 2 BUSHING, SPANNER .435 X 1.10
23 86011020 89202 2 WHEEL, 3” DIA CUSHION RUBBER
24 86271840 57285 2 NUT, 5/16-18 HEX NYLOCK THIN SS
25 86008130 73958 2 SPACER, 3/8OD X .62W X .312L, AL
26 86274730 70265 2 SCR, 1/4-20 X 3/4 SHCS PLTD
27 86070790 140737 2 BRKT, BATTERY LOCK MOUNT
28 86087340 730339 2 SPACER, LATCH GUIDE
29 86070800 140738 2 BRKT, BATTERY TRAY LOCK
30 86271870 57290 2 NUT, 1/4-20 HEX NYLO CK THIN SS
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 02/12/08
5-60
BATTERY CART - OPTION
1
2
4
3
5
11
7
6
10
3
17
3
6
10
7
5
8
9
12
5-61
13
14
15
6
10
3
3
10
16
86037810 CHARIOT® VACUUM 10/23/07
BATTERY CART - OPTION
REF PART NO. PRV NO. QTY DESCRIPTION
1 86078330 66478 1 PEDAL, BATTERY CART
2 86276070 70593 2 SCR, 5/16-18 X 3/4 CARRIAGE SS
3 86270830 57023 12 NUT, 5/16-18 HEX NYLOCK SS
4 86087800 730307 2 STIFFENER, PEDAL, BATTERY CART
5 86228840 09124 4 BEARING, FLANGED .314ID X .502OD
6 86259410 87206 6 WASHER, THRUST .51 ID X 1 OD X .063
7 86006560 70083 4 SCR, 5/16-18 X 1 HHCS SS NP
8 86077140 51404 2 LATCH, BATTERY CART
9 86226830 73268 2 SPRING, EXT .68D X 3.00L X .098W
10 86010670 87029 10 WASHER, 5/16 FLAT SS
11 86244280 500934 1 LABEL, BATTERY CAR OPERATION
12 86276060 70590 4 SCR, 5/16-18 X 2.5 CARR GR5
13 86254280 730331 12 SPACER, 1.00 ODX .32ID X .375
14 86231150 09151 4 BUSHING FLANGE, .314 X .502 OD
15 86259400 87205 8 WASHER, THRUST .51 ID X 1 OD BRO
16 86276690 70715 16 SCR, 5/16-18 X 1.75 CARR SS
17 86077530 51403 2 LINKAGE, LATCH, BATT CART
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 10/23/07
5-62
SEAT - OPTION
2
16
14
1
3
4
5
6
8
7
17
18
19
9
13
12
11
10
15
5-63
23
24
20
22
21
86037810 CHARIOT® VACUUM 10/23/07
SEAT - OPTION
REF PART NO. PRV NO. QTY DESCRIPTION
1 86248390 730324 1 PAD, REAR REST
2 86082640 629995 1 PLATE, SEAT COVER
3 86276890 70752 4 SCR, 5/16-18 X 3/4 PTHMS SS
4 86279460 87164 2 WASHER, 1/2 SPLIT LOCK PLTD
5 86270710 01-000277 1 NUT, WING 3/8-16
6 86271930 57297 1 NUT, 3/8-16 HEX NYLOCK SS
7 86278910 87003 3 WASHER, 3/8 ID X 7/8 OD SS
8 86070830 140742 1 BRKT, LEFT REAR SEAT
9 86070840 140743 1 BRKT, RIGHT REAR SEAT
10 86277710 730347 1 SCR, 3/8-16 X 2.75 HHCS SS
11 86008650 80604 1 COTTER, 1/4” RING
12 86246320 51142 1 LEVER, HANDLE LOCK
13 86272300 66133 1 PIN, CLEVIS 3/16 X .88 PLTD
14 86251860 66481 1 ROD, ARM HANDLE LOCK 4” LG
15 86279620 87200 2 WASHER, .41D X 1.3OD NYLON
16 86276070 70593 2 SCR, 5/16-18 X 3/4 CARRIAGE SS
17 86277510 70857 1 SCR, 3/8-16 X 5.0 HHCS SS FT
18 86009200 81535 1 KNOB, 3/8-16 4 PRONG ALUM
19 86254300 730350 1 SPACER, SEAT LOCK
20 86094000 05246 1 SEAT MOUNT POST
21 86276710 70717 2 SCR, 5/16-18 X 2.0 CARRIAGE SS
22 86093790 05247 1 RECEIVER ASSY, SEAT MOUNT
23 86010670 87029 4 WASHER, 5/16 FLAT SS
24 86270830 57023 4 NUT, 5/16-18 HEX NYLOCK SS
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 10/23/07
5-64
WARNING LIGHTS - OPTION
6
FRONT
1
2
3
3
4
5
7
3
1
5-65
2
6
REAR
86037810 CHARIOT® VACUUM 10/23/07
WARNING LIGHTS - OPTION
REF PART NO. PRV NO. QTY DESCRIPTION
1 86270990 57090 4 NUT, 10-32 HEX NYLOCK SS
2 86010650 87018 4 WASHER, #10 X 9/16 OD
3 86276820 70740 4 SCR, 10-32 X 1/2 PTHMS BLK NP
4 86071490 140871 1 BRKT, UPPER WARNING LIGHT
5 86270990 57090 2 NUT, 10-32 HEX NYLOCK SS
6 86246200 51454 2 LED AMBER LIGHT, 12V
7 86071500 140872 1 BRKT, LOWER WARNING LIGHT
SERIAL NO.
FROM
NOTES:
86037810 CHARIOT® VACUUM 10/23/07
5-66
SERIAL NUMBERS
REF.
NO.
MODEL: SERIAL #
1
CV28, CVE28, CVX28, CVXE28, CVXCD28: 10125210000022
2
CV28, CVE28, CVX28, CVXE28, CVXCD28: 1000160104
3
CV28, CVE28, CVX28, CVXE28, CVXCD28: 1000166771
4
CV28, CVE28, CVX28, CVXE28, CVXCD28: 1000168552
5
CV28, CVE28, CVX28, CVXE28, CVXCD28: 1000165165
6
CV28, CVE28, CVX28, CVXE28, CVXCD28: 1000157499
7
CV28, CVE28, CVX28, CVXE28, CVXCD28: 1000157501
8
CV28, CVE28, CVX28, CVXE28, CVXCD28: 1000160235
9
CV28, CVE28, CVX28, CVXE28, CVXCD28: 10060210000104
10
CV28, CVE28, CVX28, CVXE28, CVXCD28: 1000160355
11
CV28, CVE28, CVX28, CVXE28, CVXCD28: 1000158030
CV28: 1062526000009, CVE28: 10125136000009, CVXE28: 1012518000015, CVX28: 1012519000329,
12
CVX28X: 1012521000082, CV28X: 10125280000007, CVXCD28: 1012551000001
5-67
86037810 CHARIOT® VACUUM 04/20/08
Loading...
