Windmere WTO4030C User Manual
Please Read and Save this Use and Care Book
Veuillez lire et conserver ce guide d’entretien et d’utilisation
4-Slice Toaster Oven Broiler
Four/Rôtissoire/Grille-pain à 4 tranches
Model
Modèle
☐
WTO4030C
Accesorios/Partes (EE.UU/
Canadá)
Accessories/Parts (USA/Canada)
1-800-738-0245
USA/Canada 1-800-231-9786
www.prodprotect.com/applica
21
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
☐ Read all instructions.
☐ Do not touch hot surfaces. Use handles or knobs.
☐ To protect against electrical shock do not immerse cord, plugs or appliance in
water or other liquid.
☐ Close supervision is necessary when any appliance is used by or near
children.
☐ Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts.
☐ Do not operate any appliance with a damaged cord or plug, or after the
appliance malfunctions or has been damaged in any manner. Return
appliance to the nearest authorized service facility for examination, repair
or adjustment. Or, call the appropriate toll-free number on the cover of this
manual.
☐ The use of accessory attachments not recommended by the appliance
manufacturer may cause injuries.
☐ Do not use outdoors.
☐ Do not let cord hang over edge of table or counter, or touch hot surfaces.
☐ Do not place on or near a hot gas or electric burner, or in a heated oven.
☐ Extreme caution must be used when moving an appliance containing hot oil
or other hot liquids.
☐ To disconnect, turn any control to OFF, then remove plug from wall outlet.
☐ Do not use appliance for other than intended use.
☐ Use extreme caution when removing tray or disposing of hot grease.
☐ Do not clean with metal scouring pads. Pieces can break off the pad and
touch electrical parts, creating a risk of electric shock.
☐ Oversized foods or metal utensils must not be inserted in this
appliance, as they may create a re or risk of electric shock.
☐
A re may occur if the toaster oven is covered or touching ammable
material including curtains, draperies, walls and the like, when in
operation. Do not store any item on top of unit when in operation.
☐
Extreme caution should be exercised when using containers
constructed of other than metal or glass.
☐
Do not store any materials, other than manufacturer's recommended
accessories, in this oven when not in use.
☐
Do not place any of the following materials in the oven: paper,
cardboard and plastic.
☐
Do not cover crumb tray or any part of the oven with metal foil. This will
cause overheating of the oven.
SAVE THESE INSTRUCTIONS.
This product is for household use only.
POLARIZED PLUG (120V Models Only)
This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug is intended to fit into a polarized outlet
only one way. If the plug does not fit fully into the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician. Do not attempt to modify the plug
in any way.
TAMPER-RESISTANT SCREW
Warning: This appliance is equipped with a tamper-resistant screw to
prevent removal of the outer cover. To reduce the risk of fire or electric
shock, do not attempt to remove the outer cover. There are no userserviceable parts inside. Repair should be done only by authorized service
personnel.
ELECTRICAL CORD
a) A short power-supply cord (or detachable power-supply cord) is to be
provided to reduce the risk resulting from becoming entangled in or tripping
over a longer cord.
b) Longer detachable power-supply cords or extension cords are available and
may be used if care is exercised in their use.
c) If a long detachable power-supply cord or extension cord is used,
1) The marked electrical rating of the detachable power-supply cord or
extension cord should be at least as great as the electrical rating of the
appliance,
2) If the appliance is of the grounded type, the extension cord should be
a grounding-type 3-wire cord, and
3) The longer cord should be arranged so that it will not drape over the
countertop or tabletop where it can be pulled on by children or tripped over.
Note: If the power supply cord is damaged, it should be replaced by qualified
personnel. In Latin America by, an authorized service center.
4
3
Product may vary slightly from what is illustrated.
1. Control panel
2. Power light
† 3. Temperature/function control
(Part # WTO4030C-01)
† 4. Timer control (with 30-minute timer)
(Part # WTO4030C-02)
5. Bottom heating element
6. Drop down crumb tray
† 7. Wire rack (Part # WTO4030C-03)
† 8. Bake pan (Part # WTO4030C-04)
9. Glass door
10. Top heating element
11. Handle
† Consumer replaceable/removable parts
1
A
2
3
4
7
8
9
10
11
5
6
B
1
1. Dropdown crumb tray
CONTROL PANEL
1. Power light
2. Temperature/function control
3. Timer control (with 30-minute timer)
Important:
When making toast or using
the TIMER function, always
turn the dial past 10 and
then turn back or forward to
desired setting.
1
2
3
D
B
1
2
† 1. Wire rack (Part # WTO4030C-03)
† 2. Bake pan (Part # WTO4030C-04)
† Consumer replaceable/removable
parts
6
5
• Do not use oven roasting bags in this toaster oven broiler, as they may come in contact with
the heating elements.
Caution: Allow at least 1" air space between the top of the container and the upper
heating elements. Never use glass lids on glass or metal bake ware. If a lid is necessary,
cover tightly with heavy-duty aluminum foil.
INSTRUCTIONS FOR TOAST
1. Make sure the drop down crumb tray is firmly in place in the bottom of the toaster oven
broiler.
2. Plug into 120V~ AC outlet.
3. Open the glass door. Place the wire rack in shelf position #1 and center bread on the wire
rack. Close the glass door.
4. Turn the temperature/function control to TOAST
.
5. Turn the timer control to 10 then back to the desired light to dark setting. The power light will
come on.
Important: To set the timer control for less than 10 minutes, turn to 10 and then turn back
to the appropriate amount of time.
Caution: As soon as the timer control is engaged, the toaster oven broiler will turn
on. Both the top and the bottom heating elements may cycle on and off to maintain
temperature for the entire toasting time.
Caution: As soon as the timer control is engaged both heating elements will become hot
immediately. Use care not to place anything on top of the toaster oven broiler. Do not
touch the toaster oven broiler or any part of the toaster oven broiler without wearing oven
mitts.
6. With the timer control set, the toaster oven broiler will shut off automatically when the toast
cycle is complete. If toasting is completed before the timer control shuts the toaster oven
broiler off, you may shut the toaster oven broiler off manually by turning the timer control to
the off (0) position. The power light will go out. Turn the temperature/function control to the off
(0) position.
7. Do not set timer control past time indicated on toast graphics. When time set has passed, a
signal will sound, and the timer control will finish in the off (0) position. The power light will go
out.
Note: Watch toast until desired color is achieved.
8. Turn the temperature/function control to the off position.
9. Open the glass door. Wear protective oven mitts to remove toast from toaster oven broiler.
Be careful when removing toast from the back of the wire rack. The inside of the toaster oven
broiler is very hot. Close glass door.
10. Unplug unit and allow to cool before cleaning.
Caution: Do not leave toaster oven broiler unattended during toasting.
HINTS FOR TOAST
• Remove all protective wrappings from food before placing in toaster oven broiler. Follow
toaster food directions.
• Frozen, thick and heavy bread may require a longer time setting (e.g. bagels and English
muffins).
Important: Use extra caution when using this Toaster Oven broiler for toasting pastry
items with runny-type frosting or fillings.
• When toasting more than one slice of bread, use slices of similar size, thickness and
freshness.
How to Use
This unit is for household use only.
GETTING STARTED
• Read all instructions in this guide carefully.
• Carefully unpack your toaster oven broiler and remove all packaging materials.
• Place your toaster oven broiler on a level surface such as a countertop or table. Be sure the
sides, back, and top of the oven are at least four inches away from any walls, cabinets, or
objects on the counter or table.
• Remove all stickers from the toaster oven broiler except the rating label located on the back.
• Remove wire rack and bake pan and wash in warm, soapy water. Rinse and dry thoroughly
before placing in the toaster oven broiler.
• Remove any dust that may have accumulated during packaging, simply wipe the toaster oven
broiler exterior with a clean, damp cloth.
• Do not use abrasive cleansers.
• Do not put the toaster oven broiler, cord or plug in water.
• When you are ready to use the toaster oven broiler, plug the cord into a120 V~ AC outlet.
• To eliminate any protective substance or oil that may have been used for packing and
shipping, set the unit to TOAST
and set the timer for it to toast for about 15 minutes. A
small amount of smoke and odor may be detected. This is normal.
• To avoid scratching, marring, or discoloration, do not store anything on top of the toaster oven
broiler during operation.
Caution: Appliance surfaces are hot during and after use.
Caution: Always wear protective, insulated oven mitts on hands when touching hot oven
or hot dishes and food or when inserting or removing wire rack, baking dish and food.
COOKING CONTAINERS
• The bake pan included with the toaster oven broiler is suitable for items such as cookies,
rolls, biscuits, nachos and pork chops.
• Choose bake ware made of metal, or glass/ceramic without lids.
• Dark or dull pans absorb heat faster; foods will bake more rapidly and crust will brown more
easily than in shiny bake pans.
• Check package directions and/or with the ovenware manufacturer to determine if the
container is suitable for use in a toaster oven broiler.
$ " 65 *0 /
THIS OVEN GETS HOT. WHEN
IN USE, ALWAYS USE OVEN
MITTS OR POT HOLDERS
WHEN TOUCHING ANY OUTER
OR INNER SURFACE OF THE
OVEN
THIS OVEN GETS HOT.
WHEN IN USE, ALWAYS USE OVEN
MITTS OR POT HOLDERS WHEN
TOUCHING ANY OUTER OR INNER
SURFACE OF THE OVEN.
CAUTION
8
7
INSTRUCTIONS FOR BROILING
Note: Only the top heating element will heat when the BROIL
function is used.
1. Make sure the drop down crumb tray is firmly in place in the bottom of the toaster oven
broiler.
2. Plug into 120 V~ AC outlet. Close the glass door.
3. Remove all protective wrappings from food before placing in toaster oven broiler.
4. Place food directly onto the bake pan. Brush food with sauces or oil as desired.
5. Open the glass door. Place the wire rack into Shelf Position #1 or #2. Place the bake pan
with food into the toaster oven broiler and close the glass door.
6. Turn the temperature/function control to BROIL
.
7. Turn the timer control to the desired time.
8. To set the timer control for less than 10 minutes, turn to 10 and then turn back to the
appropriate amount of time.
Note: As soon as the timer control is engaged, the toaster oven broiler will turn on.
Note: As soon as the timer control is engaged the top heating element will become hot
immediately. Use care not to place anything on top of the toaster oven broiler. Do not touch the
toaster oven broiler or any part of the toaster oven broiler without wearing oven mitts.
9. Broil according to package or recipe time. When broiling food that needs to be cooked on
both sides, set the timer control to the time necessary for one side.
10. With the timer control set, the toaster oven broiler will shut off automatically when the
broiling is complete. If broiling is completed before the timer control shuts the toaster oven
broiler off, you may shut the toaster oven broiler off manually by turning the timer control
to the off position. The power light will go out. Turn the temperature/function control to the
off position.
11. When the broiling time is complete, a signal will sound, and the timer control will finish in
the off position. The power light will go out.
12. Open the glass door. Wear protective oven mitts to carefully slide the bake pan part way
out of the toaster oven broiler. Turn the food, slide the bake pan back into the toaster oven
broiler and close the toaster oven broiler glass door. Turn the timer control to the desired
time.
13. When the broiling time is complete, a signal will sound, and the timer control will finish in
the off position. The power light will go out.
14. Turn the temperature/function control to the off position.
15. Open the glass door. Wear protective oven mitts to remove food from toaster oven broiler.
Be careful when removing food. The inside of the toaster oven broiler is very hot. Close the
glass door.
16. Unplug unit and allow to cool completely before cleaning.
Caution: Do not leave toaster oven broiler unattended during broiling.
INSTRUCTIONS FOR TOP BROWNING
Note: To top brown foods, follow the Toast instructions but place the food in the bake pan on the
wire rack.
Important: Do not leave toaster oven broiler unattended during top browning.
• One slice of bread requires a lighter setting than several slices of bread.
• Stale bread, thin bread or sweet bread products, such as tea cakes and fruit loafs, brown
much more quickly than ordinary bread so they should be toasted for less time.
• Different breads require different toasting times. Turn timer control dial to the off position and
open the glass door to check toast color. Close glass door and reset timer control if more
toasting time is needed.
• For best results, clean drop down crumb tray frequently.
INSTRUCTIONS FOR BAKING
1. Make sure the drop down crumb tray is firmly in place in the bottom of the toaster oven
broiler.
2. Plug into 120 V~ AC outlet. Close the glass door.
3. Set the temperature/function control to the desired temperature.
4. Set the timer for 10 minutes and preheat the toaster oven broiler. After 10 minutes, a
signal will sound and the toaster oven broiler will automatically shut off.
5. Remove all protective wrappings from food before placing in toaster oven broiler.
6. Open the glass door. Place the wire rack into Shelf Position #1 or #2. Use the baking
tray or an appropriate baking container and center it on the wire rack. If you would like
your food browned top and bottom, place food directly on wire rack and close glass door.
Bake according to package or recipe time.
7. Turn the timer control to the desired time. The power light will come on.
8. To set the timer control for less than 10 minutes, turn to 10 and then turn back to the
appropriate amount of time.
Note: As soon as the timer control is engaged, the toaster oven broiler will turn on. Both the
top and the bottom heating elements will cycle on and off to maintain temperature for the entire
cooking time.
Note: As soon as the timer control is engaged both heating elements will become hot
immediately. Use care not to place anything on top of the toaster oven broiler. Do not touch the
toaster oven broiler or any part of the toaster oven broiler without wearing oven mitts.
9. If the timer control has been set, the toaster oven broiler will shut off automatically when
bake is complete. If cooking is completed before the timer control shuts the toaster oven
broiler off, you may shut the toaster oven broiler off manually by turning the timer control
to the off (0) position. The power light will go out. Turn the temperature/function control
to the off (0) position.
10. When the bake time is complete, a signal will sound, and the timer control will finish in
the off (0) position. The power light will go out.
11. Turn the temperature/function control to the off (0) position.
12. Open the glass door. Wear protective oven mitts to remove food from toaster oven
broiler. The inside of the toaster oven is very hot. Close the glass door.
13. Unplug the unit and allow to cool completely before cleaning.
Important: Do not use glass covers on baking pans. If using a glass or glass-ceramic
baking container, make sure it is at least 1 inch away from the top heating element.
Caution: Do not leave toaster oven broiler unattended during baking.
HINTS FOR BAKING
• Heavy-duty aluminum foil may be used to cover top of baking container to reduce over
browning. Tuck ends of foil closely against edge of pan.
• Place food toward the back of the toaster oven broiler for better browning.
• Food may cook faster than recipe or package time. Check for doneness prior to end of cook
time.
• Rotate and turn food over for more even browning halfway through the cooking process.
• To prevent heat loss, avoid opening the glass door excessively.
Loading...
