Page 1
WMP-226(V)/227(V)
Medical Panel PC
USER’S MANUAL
P/N: 205G000WMP2260, V1.5
Copyright© ,2016. All rights reserved
All other brand names are registered trademarks of their respective owners.
The information contained in this document is subject to change without notice
Page 2
WMP-226(V)/227(V) User’s manual
ii
Version Change History
Date
Version
Description
Remark
2012/7/6
1.0
First release
Cosa Huang
2012/8/20
1.1
Update battery spec
James.Chiu
2013/3/6
1.2
1. Add in WMP-226V/227V
models support Ivy bridge
CPU
2. Correct some error
James.Chiu
2013/9/3
1.3
1. Add microphone on I/O
cover as option in feature
James.Chiu
2013/12/20
1.4
1. Add P.cap touch function
2. Add WLAN+BT module as
option
3. Revise BIOS section
James.Chiu
2016/4/18
1.5
Add Cautions with
Continuous displaying fixed
pattern
James
Page 3
WMP-226(V)/227(V) User’s manual
iii
Acknowledgments
Intel® 2nd/3rd generation Core i and Celeron are registered
trademarks of Intel® Corporation.
IBM, PC/AT, PS/2 are trademarks of International Business
Machines Corporation.
Microsoft
®
Windows is a registered trademark of Microsoft
®
Corporation.
RTL is a trademark of Realtek Semi-Conductor Co., Ltd.
C&T is a trademark of Chips and Technologies, Inc.
UMC is a trademark of United Microelectronics Corporation.
ITE is a trademark of Integrated Technology Express, Inc.
VIA is a trademark of VIA Technology, Inc.
Award is a registered trademark of Award Software
International, Inc.
PS/2 is a trademark of International Business Machines
Corporation.
Intel is a trademark or registered trademark of Intel
Corporation.
Microsoft Windows is a registered trademark of Microsoft
Corporation.
Winbond is a registered trademark of Winbond Electronics
Corporation.
All other product names or trademarks are properties of
their respective owners.
Page 4
WMP-226(V)/227(V) User’s manual
iv
FCC Class B
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a residential environment.
This equipment generates, uses and can radiate radio frequency energy. If
not installed and used in accordance with this user manual, it may cause
harmful interference to radio communications.
Note that even when this equipment is installed and used in accordance
with this user manual, there is still no guarantee that interference will not
occur. If this equipment is believed to be causing harmful interference to
radio or television reception, this can be determined by turning the
equipment on and off. If interference is occurring, the user is encouraged
to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and the receiver
Connect the equipment to a power outlet on a circuit different from
that to which the receiver is connected
Consult the dealer or an experienced radio/TV technician for help
Warning:
Any changes or modifications made to the equipment which are
not expressly approved by the relevant standards authority could
void your authority to operate the equipment.
To avoid risk of electric shock, this equipment must only be
connected to a supply mains with protective earth.
Do not modify this equipment without authorization of the
manufacturer.
Page 5
WMP-226(V)/227(V) User’s manual
v
Safety Instructions
Intended use
The WMP-226(V)/227(V) is intended to serve as a medical
monitor which is designed for general purpose for hospital
environment and for diagnosis. It could be used for Surgical,
Radiology, PACS (Picture Archiving Communication Systems),
LIS (Lab Information Systems) and Electronic Medical Record
purpose. It shall not be used for life-supporting system.
WARNING: Critical diagnostic decision must not be based solely
on images displayed by this device
Greeting & Setup
Thank you for purchasing the WMP-226(V)/227(V) unit. We wish
that this unit will be durable and reliable in providing your
medical application needs. Please follow the instructions below to
ensure the unit continues to have high performance.
Unpacking
After opening the carton, there will be a medical panel PC unit
with an accessory box. Examine the contents to see if there are
damages to the unit and if all accessories are present.
Setting up
Please read this manual carefully and remember to keep this
manual for future reference.
Safety Instructions & Cleaning
The unit has undergone various tests in order to comply with
safety standards. Inappropriate use of the open frame unit may
be dangerous. Please remember to follow the instructions below
to insure your safety during the installation and operating
process.
Transporting & Placement of unit
1. When moving the unit on a cart; be very cautious. Quick
stops, excessive forces and uneven surfaces may cause
the cart to overturn thus risking the unit to fall to the
ground.
Page 6
WMP-226(V)/227(V) User’s manual
vi
2. If the medical panel PC unit does fall to the ground,
immediately turn the power off and disconnect cords. Then
contact a service technician for repairs. Continual use of
the unit may result cause a fire or electric shock. Also, do
not repair the unit on your own.
3. Having two or more people transporting the display unit is
recommended. In addition, when installing the unit by
suspending it also requires two or more people.
4. Before suspending the unit, make sure the material used
for suspension is sturdy and stable. If not properly
suspended, the display unit may fall and cause serious
injury to people standing nearby as well as to the unit
itself.
5. If you wish to mount the display unit, remember to use
only the mounting hardware recommended by the
manufacturer.
Electrical and Power Source Related
1. This medical panel PC unit must operate on a power source
as shown on the specification label. If you are not sure
what type of power supply used in the area, consult your
dealer or local power supplier.
2. The power cords must not be damaged. Applied pressure,
added heat, and tugging may damage the power cord.
3. The power cord must be routed properly when setup takes
place. We advise that this aspect measure is to prevent
people from stepping on the cords or while the unit is
suspended to prevent flying objects from getting tangled
with the unit.
4. Do not overload the AC outlets or extension cords.
Electrical shocks or fires may occur from overloading.
5. Do not touch the power source during a thunderstorm.
6. If your hands are wet, do not touch the plug.
7. Use your thumb and index finger, grip firmly on the power
cord to disconnect from the electrical socket. By pulling the
power cord, may result in damaging it.
Page 7
WMP-226(V)/227(V) User’s manual
vii
8. If the unit is not going to be in use for an extended period
of time, remember to disconnect the unit.
9. The medical panel PC unit uses voltage between
100-240VAC. Connect the unit to a power source with the
same numerical value as shown. Please use only the power
cord provided by the dealer to ensure safety and EMC
compliance.
Various Factors of Environment
1. Do not insert objects into the openings.
2. Do not have liquids seep into the internal areas of the
medical panel PC unit.
3. Having liquids seep in or inserting objects into the unit
may result in electric shocks from taking and/or short
circuiting the internal parts.
4. Do not place the medical panel PC unit in the presence of
high moisture areas.
5. Do not install the medical panel PC unit in a wet
environment.
6. Do not place near unit near heat generating sources.
7. Do not place the unit in a location where it will come in
contact with fumes or steam.
8. Remember to keep the medical panel PC unit away from
the presence of dust.
9. If water has flow in or seep in, immediately disconnect the
open frame unit. Then contact a service technician for
repairs.
Ventilation Spacing
1. Do not cover or block the openings on the top and back
sides of the display unit. Inadequate ventilation may cause
overheating thus reducing the lifespan of the unit.
2. Unless proper ventilation is present, do not place unit in an
enclosed area; such as a built-in shelf. Keep a minimum
distance of 10 cm between the display unit and wall.
Page 8
WMP-226(V)/227(V) User’s manual
viii
Cleaning the unit
1. Remember to turn off the power source and to unplug the
cord from the outlet before cleaning the unit.
2. Carefully dismount the unit or bring the unit down from
suspension to clean.
3. Please use a dry soft cloth to clean the unit.
4. Take a dry cloth and wipe the unit dry. Remember to avoid
having liquids seep into the internal components and areas
of the medical panel PC unit.
Servicing, Repairing, Maintenance & Safety Checks
1. If the unit is not functioning properly, observe the
performance level of the display closely to determine what
type of servicing is needed.
2. Do not attempt to repair the medical panel PC unit on your
own. Disassembling the cover exposes users’ to high
voltages and other dangerous conditions. Notify and
request a qualified service technician for servicing the unit.
3. To avoid risk of electric shock, this equipment must only be
connected to a supply mains with protective earth.
4. If any of the following situations occur turn the power
source off and unplug the unit. Then contact a qualified
service technician.
(a) A liquid was spilled on the unit or objects have fallen
into the unit.
(b) The unit is soaked with liquids.
(c) The unit is dropped or damaged.
(d) If smoke or strange odor is flowing out of the operating
unit.
(e) If the power cord or plug is damaged.
(f) When the functions of the unit are dysfunctional.
5. When replacement parts are needed for the medical panel
PC unit, make sure service technicians use replacement
parts specified by the manufacturer, or those with the
same characteristics and performance as the original
Page 9
WMP-226(V)/227(V) User’s manual
ix
parts. If unauthorized parts are used it may result in
starting a fire, electrical shock and/or other dangers.
ISO 7000-0434 : Caution, consult ACCOMPANYING
DOCUMENTS.
ISO 7000-1641 : Follow operating instructions or
Consult instructions for use.
IEC 60417 -5009 : STAND-BY.
IEC 60417-5031 : Direct current.
EU-wide legislation, as implemented in each
Member State, requires that waste electrical and
electronic products carrying the mark (left) must be
disposed of separately from normal household
waste. This includes monitors and electrical
accessories, such as signal cables or power cords.
When you need to dispose of your display products,
please follow the guidance of your local authority, or
ask the shop where you purchased the product, or if
applicable, follow any agreements made between
yourself.
The mark on electrical and electronic products only
applies to the current European Union Member
States.
Page 10
WMP-226(V)/227(V) User’s manual
x
When networking with electrical devices, the operator is
responsible for ensuring that the resulting system meets the
requirements set forth by the following standards:
– EN 60601-1 (IEC 60601-1)
Medical electrical equipment
Part 1: General requirements for safety
– EN 60601-1-1 (IEC 60601-1-1)
Medical electrical equipment
Part 1-1: General requirements for safety
Collateral standard: Safety requirements for
Medical electrical systems
– EN 60601-1-2 (IEC 60601-1-2)
Medical electrical equipment
Part 1-2: General requirements for safety
Collateral standard: Electromagnetic compatibility;
Requirements and tests
Accessory equipment connected to
the analog and digital interfaces
must be in compliance with the
respective nationally harmonized
IEC standards (i.e. IEC 60950 for
data processing equipment, IEC
60065 for video equipment, IEC
61010-1 for laboratory equipment,
and IEC 60601-1 for medical
equipment.) Furthermore all configurations shall comply with the
system standard IEC 60601-1-1. Everybody who connects
additional equipment to the signal input part or signal output part
configures a medical system, and is therefore, responsible that
the system complies with the requirements of the system
standard IEC 60601-1-1. The unit is for exclusive interconnection
with IEC 60601-1 certified equipment in the patient environment
and IEC 60XXX certified equipment outside of the patient
environment. If in doubt, consult the technical services
department or your local representative.
Page 11
WMP-226(V)/227(V) User’s manual
xi
Caution:
DO NOT LEAVE THIS EQUIPMENT IN AN UNCONTROLLED
ENVIRONMENT WHERE THE STORAGE TEMPERATURE IS BELOW
-20° C (-4° F) OR ABOVE 60° C (140° F). THIS MAY DAMAGE THE
EQUIPMENT.
This equipment shall not be used in life support systems.
The user is not to touch SIP/SOPs and the patient at the same
time.
Caution – Use suitable mounting apparatus to avoid risk of injury.
The sound pressure level at the operator’s position according to
IEC 704-1:1982 is no more than 70dB (A).
A) Grounding reliability can only be achieved when the equipment
is connected to an equivalent receptacle marked “Hospital
Only” or “Hospital Grade”.
B) Use a power cord that matches the voltage of the power outlet,
which has been approved and complies with the safety
standard of your particular country.
C) Caution: This adapter Sinpro MPU101-105 is a forming part of
the medical device
Contact information:
3F, No.14, Prosperity Road II, Science-Based Industrial Park,
Hsinchu, Taiwan 300, R.O.C
TEL: (886) 3 5780000
E-Mail: [email protected]
Page 12
WMP-226(V)/227(V) User’s manual
xii
Table of Contents
Acknowledgments ...................................... iii
FCC Class B ............................................... iv
Safety Instructions ...................................... v
Introduction ............................................ 1
Product Description ..................................... 1
Package list ................................................ 2
Features .................................................... 3
Specifications ............................................. 4
Guidance and manufacturer’s declaration –
electromagnetic emissions ........................... 6
Guidance and manufacturer’s declaration –
electromagnetic immunity ............................ 8
Guidance and manufacturer’s declaration –
electromagnetic immunity ............................ 9
Immunity ................................................... 9
Cleaning/Disinfecting ................................. 11
Getting Started ...................................... 12
System Set Up .......................................... 12
Dimension ................................................ 13
System View ............................................ 15
Disconnect Device ..................................... 17
BIOS Setup ............................................ 18
Appendix ................................................ 28
A. Jumper settings and Connectors ............. 28
B. L type Stand (optional kit) ...................... 50
C. Battery Pack Specifications ..................... 51
D. Change Win Xp resolution to 1920*1080 .. 52
E. How to disable battery when system hang up
-WMP-226(V)/227(V) ................................ 53
F. Scrap Computer Recycling ...................... 54
Page 13
WMP-226(V)/227(V) User’s manual
1
Introduction
Product Description
The WMP-226(V)/227(V) Medical Panel PC are based on Intel
2nd/3rd generation Core i processor which can deliver faster
graphic with higher CPU performance. It accommodates one 2.5”
SATA III hard disk drive and up to 8GB DDR3 SODIMM.
The high brightness LCD, Low noise (WMP-226(V)) / Fanless
(WMP-227(V)) solution, integrated multimedia functions and
extensive expansion options make them the perfect platform
upon which to build comprehensive lifestyle computing
applications.
The WMP-226(V)/227(V) includes all the features of a powerful
computer into a slim and attractive chassis. The
WMP-226(V)/227(V) has a 21.5” high brightness TFT display with
1920 x 1080 resolutions.
The WMP-226(V)/227(V) is compact, Giga LAN and selectable
WLAN network compatible PC with full safety and medical
approval and features to control a dedicated system with a wide
variety of applications. Combining the WMP-226(V)/227(V) into
your system can achieve both cost-saving and efficient
improvements.
Common applications include Surgical, Radiology, PACS (Picture
Archiving Communication Systems), LIS (Lab Information
Systems) and Electronic Medical Record. The
WMP-226(V)/227(V) are definitely your perfect choices.
Page 14
WMP-226(V)/227(V) User’s manual
2
Package list
Before you begin installing your Medical Station, please make
sure that the following items have been shipped:
The WMP-226(V) or WMP-227(V) Medical Panel PC unit
One DVD containing user manual, chipset drivers
Power Adapter x 1 (Mf:Sinpro, type/model: MPU101-105)
Power cord – Hospital grade used(US type), or other type in
UK, EU…etc.
Stylus pen x 1 (By configuration)
Screw x 8 (VESA 75/100 use)
Page 15
WMP-226(V)/227(V) User’s manual
3
Features
Seamless on the front side
Easy wipe surfaces with no internal corners
21.5" (1920X1080) Diagnostic Panel
High performance Intel 2nd/3rd generation Core i series
mobile CPU
Two mini PCI-e expansion
HDD Anti-vibration mechanism
Low noise Smart fan solution(WMP-226(V))
Fanless Solution (WMP-227(V))
Anti-bacteria (MRSA) plastic housing
Built-in Battery backup function (option)
optional Video Graphic card (WMP-226(V) only)
Microphone on I/O cover (option)
Support isolated module by different configuration (optional
order configuration)
Support P.cap touch(4 fingers) by different configuration
(optional order configuration)
Page 16
WMP-226(V)/227(V) User’s manual
4
Specifications
[
Hardware Specifications
Display
21,5” 250 nits Full HD TFT LCD
CPU Support
WMP-226
rPGA988B 2nd Generation Intel® Core
i7/i5/i3/Celeron® processor (35W max.)
WMP-226V
rPGA988B 3rd Generation Intel® Core
i7/i5/i3/Celeron® processor (35W max.)
WMP-227
FCBGA1023 2nd Generation Intel® Core
i7/i5/i3/Celeron® processor (17W max.)
WMP-227V
FCBGA1023 3rd Generation Intel® Core
i7/i5/i3/Celeron® processor (17W max.)
Disk Drive Space
2.5” Hard Disk Drive (SATA III)
Expansion
Two Mini PCIe slot;
One PCI-E expansion slot
Button
Power Button// Audio adjustment (+)(-) //
brightness (+)(-) // LCD on/off // Clean me(auto
release after 1 minute)
I/O
Standard version
1 RS-232 port + 1 RS-232/422/485 port
4 USB 2.0 ports
1 DC-in w/ lock function
2 Gigabit LAN RJ-45 Connectors
Sound:
1 x Line-in
1 x line-out
2 x 1.5W Speakers on back side
LCD Specifications
Model Name
AUO M215HTN01.1
Display Type
21.5” LED backlight LCD
Max. Resolution
1920 x 1080 (Full HD)
Contrast Ratio
1000 : 1 (Typ)
Pixel Pitch (um)
248.25 (per one triad) × 248.25
Luminance (cd/m2)
250 (TYP)
Page 17
WMP-226(V)/227(V) User’s manual
5
Viewing Angle
170°(H)
160°(V)
Operating
Temperature
0°C~ 40°C (32°F~104°F)
Brightness Control
Yes
Cautions:
Continuous displaying fixed pattern may induce image sticking.
It’s recommended to use screen saver or moving content
periodically if fixed pattern is displayed on the screen.
Power Adapter Specifications
Power
Close-frame
MFR
Sinpro
Type
MPU101-105
Input Voltage
AC 100 ~ 240 V, 1.25 – 0.5A @ 47 ~ 63 Hz
Output Voltage
DC 12V @ 8.33 A
MTBF
100,000 hrs operation at 25°C
Mechanical Specifications
Architecture
Close-frame
Front Bezel
PET bezel with resistive touch screen
Color
Medical-white
Mounting / Holder
VESA 75/100mm
Construction
3mm ABS + PC TYPE Plastic housing
Dimension (WxHxD)
540 x 375 x 78 mm
Net Weight
WMP-226(V): 6.5kg (w/o power adapter)
WMP-227(V): 7.0kg (w/o power adapter)
Packing Filler
PE
Environmental Specifications
Temperature
Operating: 0°C to 40°C (32°F ~104°F)
Storage, Transportation: -20°C to 60°C (-4°F
~140°F)
Humidity
Operating:
10% to 90%@ 40°C, non-condensing
Storage, Transportation:
10% to 90%, non-condensing
Page 18
WMP-226(V)/227(V) User’s manual
6
Vibration
Operating: 15g/0.53 oz, 11 ms, half sine wave
Non-operating: 50g/1.76 oz, 11 ms, half sine
wave
Shock
Operating: 5 ~ 17 Hz ,
Amplitude：0.117 ~ 500Hz ,
Acceleration：1.0G
Non-operating:10~55Hz/0.15g, 55~500Hz/2.0g
Altitudes
Operational: up to 3000 m (9842 feet)
Shipping: up to 12192 m (40000 feet)
Pressure
700 – 1060 hPa (Operation)
186 – 1060 hPa (Storage)
186 – 1060 hPa (Transportation)
Input Power Rating
For Adaptor:
AC100~240 V, 1.25 – 0.5A, @47 ~ 63 Hz.
For Unit:
DC 12V, 8.33A
Power Consumption
WMP-226(V): 98W Max (Typical: 79.50W)
WMP-227(V): 98W Max (Typical: 46.50W)
Touch Screen
Configuration 1 - 5 wire Resistive touch
Type
Full flat 5-wire, Analog Resistive
Interface
USB interface, 5V
Resolution
4096 x 4096
Light Transmission
>78% at 550 nm wavelength
Life Time
35M times, 250g at same place
Configuration 2 - P.cap touch (4 fingers)
Type
Full flat projective capacitive touch panel
Interface
Controller with USB interface, 5V
Resolution
100ppi to 25ppi Based WIN7 definition ppi
(Pixel per inch)
Light Transmission
90% ± 3%
Life Time
100M times
Guidance and manufacturer’s declaration – electromagnetic
emissions
The model WMP-226(V)/227(V) is intended for use in the
electromagnetic environment specified below. The customer or the user
of the model WMP-226(V)/227(V) should assure that it is used in such an
environment.
Page 19
WMP-226(V)/227(V) User’s manual
7
Emissions test
Compliance
Electromagnetic environment –
guidance
RF emissions
CISPR 11
The model WMP-226(V)/227(V) uses
RF energy only for its internal
function. Therefore, its RF emissions
are very low and are not likely to
cause any interference in nearby
electronic equipment.
RF emissions
CISPR 11
The model WMP-226(V)/227(V) is
suitable for use in all establishments,
including domestic establishments
and those directly connected to the
public low-voltage power supply
network that supplies buildings used
for domestic purposes.
Harmonic
emissions
IEC 61000-3-2
Voltage
fluctuations/
flicker emissions
IEC 61000-3-3
Recommended separation distances between
portable and mobile RF communications equipment and the model
WMP-226(V)/227(V)
The model WMP-226(V)/227(V) is intended for use in an electromagnetic
environment in which radiated RF disturbances are controlled. The
customer or the user of the model WMP-226(V)/227(V) can help prevent
electromagnetic interference by maintaining a minimum distance
between portable and mobile RF communications equipment
(transmitters) and the model WMP-226(V)/227(V) as recommended
below, according to the maximum output power of the communications
equipment.
Rated maximum
output power of
transmitter
W
Separation distance according to
frequency of transmitter
m
150 kHz to
80 MHz
d = 1,2
80 MHz to
800 MHz
d = 1,2
800 MHz to
2,5 GHz
d = 2,3
0,01
0,12
0,12
0,23
0,1
0,38
0,38
0,73
1
1,2
1,2
2,3
10
3,8
3,8
7,3
100
12
12
23
Page 20
WMP-226(V)/227(V) User’s manual
8
For transmitters rated at a maximum output power not listed above, the
recommended separation distanced in meters (m) can be estimated
using the equation applicable to the frequency of the transmitter, where P
is the maximum output power rating of the transmitter in watts (W)
according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher
frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic
propagation is affected by absorption and reflection from structures,
objects and people.
Guidance and manufacturer’s declaration – electromagnetic
immunity
The model WMP-226(V)/227(V) is intended for use in the
electromagnetic environment specified below. The customer or the user
of the model WMP-226(V)/227(V) should assure that it is used in such
an environment.
Immunity test
IEC 60601
test level
Compliance
level
Electromagnetic
environment –
guidance
Electrostatic
discharge
(ESD)
IEC 61000-4-2
6 kV contact
8 kV air
6 kV contact
8 kV air
Floors should be
wood, concrete or
ceramic tile. If floors
are covered with
synthetic material, the
relative humidity
should be at least 30
%.
Electrical fast
transient/burst
IEC 61000-4-4
2 kV for
power
supply lines
1 kV for
input/output
lines
2 kV for
power
supply lines
1 kV for
input/output
lines
Mains power quality
should be that of a
typical commercial or
hospital environment.
Surge
IEC 61000-4-5
1 kV line(s)
to line(s)
2 kV line(s)
to earth
1 kV line(s)
to line(s)
2 kV line(s)
to earth
Mains power quality
should be that of a
typical commercial or
hospital environment.
Page 21
WMP-226(V)/227(V) User’s manual
9
interruptions
and
voltage
variations
on power
supply
input lines
IEC
61000-4-11
<5 % UT
(>95 % dip in
UT)
for 0,5 cycle
40 % UT
(60 % dip in
UT)
for 5 cycles
70 % UT
(30 % dip in
UT)
for 25 cycles
<5 % UT
(>95 % dip in
UT)
for 5 sec
<5 % UT
(>95 % dip in
UT)
for 0,5 cycle
40 % UT
(60 % dip in
UT)
for 5 cycles
70 % UT
(30 % dip in
UT)
for 25 cycles
<5 % UT
(>95 % dip in
UT)
for 5 sec
Mains power quality
should be that of a
typical commercial or
hospital environment.
If the user of the
model
WMP-226(V)/227(V)
requires continued
operation during
power
mains interruptions, it
is recommended that
the model
WMP-226(V)/227(V)
be powered from an
uninterruptible power
supply or a battery.
Power
frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m
3 A/m
Power frequency
magnetic fields
should be at levels
characteristic of a
typical location in a
typical commercial or
hospital environment.
NOTE UT is the a.c. mains voltage prior to application of the test level.
Guidance and manufacturer’s declaration – electromagnetic immunity
The model WMP-226(V)/227(V) is intended for use in the electromagnetic environment specified below.
The customer or the user of the model WMP-226(V)/227(V) should assure that it is used in such an
environment.
Immunity
IEC
60601
test level
Compliance
level
Electromagnetic environment – guidance
Page 22
WMP-226(V)/227(V) User’s manual
10
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 61000-4-3
3 Vrms
150 kHz
to 80
MHz
3 V/m
80 MHz
to 2,5
GHz
Vrms
V/m
Portable and mobile RF communications
equipment should be used no closer to any part
of the model WMP-226(V)/227(V), including
cables, than the recommended separation
distance calculated from the equation
applicable to the frequency of the transmitter.
Recommended separation distance
d = 1,2
d = 1,2 80 MHz to 800 MHz
d = 2,3 800 MHz to 2,5 GHz
where P is the maximum output power rating of
the transmitter in watts (W) according to the
transmitter manufacturer and d is the
recommended separation distance in meters
(m).
Field strengths from fixed RF transmitters, as
determined by an electromagnetic site survey, a
should be less than the compliance level in
each frequency range. b
Interference may occur in the vicinity of
equipment marked with the following symbol:
NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption
and reflection from structures, objects and people.
a
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones
and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be
predicted theoretically with accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in
the location in which the model WMP-226(V)/227(V) is used exceeds the applicable RF compliance
level above, the model WMP-226(V)/227(V) should be observed to verify normal operation. If
abnormal performance is observed, additional measures may be necessary, such as reorienting or
relocating the model WMP-226(V)/227(V).
b
Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
Page 23
WMP-226(V)/227(V) User’s manual
11
Cleaning/Disinfecting
Steps:
1. Wipe the WMP-226(V)/227(V) with a dry clean cloth.
2. Prepare agent per manufacturer’s instructions or hospital
protocol.
Cautions:
Do not immerse or rinse the WMP-226(V)/227(V) and its
peripherals. If you accidentally spill liquid on the device,
disconnect the unit from the power source. Contact your
Biomed regarding the continued safety of the unit before
placing it back in operation.
Do not spray cleaning agent on the chassis.
Do not use disinfectants that contain phenol.
Do not autoclave or clean the WMP-226(V)/227(V) or its
peripherals with strong aromatic, chlorinated, ketone, ether,
or Esther solvents, sharp tools or abrasives. Never immerse
electrical connectors in water or other liquids.
Page 24
WMP-226(V)/227(V) User’s manual
12
Getting Started
System Set Up
The following is a summary of the steps in setting up the system
for use.
(1). You can fix the system to a mounting fixture using the screw
holes on the sides of the system.
(2). Make any required external connections such as the display,
keyboard, and LAN.
(3). Plug the appropriate end of the power cord into the power
connector on the rear of the system and the plug to an
electrical outlet.
(4). Waiting for 3 seconds then press the power switch on the
front panel of the system once to turn on the system power.
(5). If necessary, run the BIOS SETUP programs to configure the
system.
Caution:
In order to boot up system from USB-CD/DVD drive,
please connect USB-CD/DVD drive, turn on computer
power, keep on pressing “F11” key, go into BIOS quick
boot menu, select “USB-CD ROM”, WAIT FOR 20
SECONDS, then press enter, system OS will boot up
from USB-CD/DVD drive directly.
Page 25
WMP-226(V)/227(V) User’s manual
13
Dimension
WMP-226(V)
(VESA Mount Screw type: M4)
Page 26
WMP-226(V)/227(V) User’s manual
14
WMP-227(V)
(VESA Mount Screw type: M4)
Page 27
WMP-226(V)/227(V) User’s manual
15
System View
Front View
Hotkey and LED definition at front panel
Located on Touch screen bottom side, from left to right, front view
1-1. Up. HDD: Yellow
1-2 Down. Battery:
AC mode: Dark
Battery mode: Yellow
Battery low: Yellow blinking
2. Power (with LED status indicator: ON: Green, OFF: dark)
3. Volume adjustment (-)
4. Volume adjustment (+)
5. Brightness (-)
6. Brightness (+)
7. LCD on/off (with LED status indicator: LCD ON: dark, LCD OFF:
Yellow)
Webcam (optional)
Page 28
WMP-226(V)/227(V) User’s manual
16
8. Clean me (with LED status indicator: ON: Yellow, OFF: dark)
a. Keep on contacting 5 seconds to active
b. keep contacting 5 seconds to release
c. auto release after 60 seconds
I/O parts (WMP-226(V)/227(V))
Page 29
WMP-226(V)/227(V) User’s manual
17
Disconnect Device
Unplug the power cord from the power
adapter jack to disconnect the device.
Page 30
WMP-226(V)/227(V) User’s manual
18
BIOS Setup
BIOS Introduction
The AMI BIOS (Basic Input / Output System) installed in your
computer system’s ROM supports Intel processors. The BIOS
provides critical low-level support for a standard device such as
disk drives, serial ports and parallel ports. It also adds virus and
password protection as well as special support for detailed
fine-tuning of the chipset controlling the entire system.
BIOS Setup
The AMI BIOS provides a Setup utility program for specifying the
system configurations and settings. The BIOS ROM of the system
stores the Setup utility. When you turn on the computer, the AMI
BIOS is immediately activated. Pressing the <Del> key
immediately allows you to enter the Setup utility. If you are a
little bit late pressing the <Del> key, POST (Power On Self Test)
will continue with its test routines, thus preventing you from
invoking the Setup. If you still wish to enter Setup, restart the
system by pressing the ”Reset” button or simultaneously pressing
the <Ctrl>, <Alt> and <Delete> keys. You can also restart by
turning the system Off and back On again. The following message
will appear on the screen:
Press <DEL> to Enter Setup
In general, you press the arrow keys to highlight items, <Enter>
to select, the <PgUp> and <PgDn> keys to change entries, <F1>
for help and <Esc> to quit.
When you enter the Setup utility, the Main Menu screen will
appear on the screen. The Main Menu allows you to select from
various setup functions and exit choices.
Page 31
WMP-226(V)/227(V) User’s manual
19
Main
This section provides information on the BIOS information, and Battery information
System Date
Set the system date. Use the <Tab> key to switch between data
elements.
System Time
Set the system time. Use the <Tab> key to switch between time
elements.
Page 32
WMP-226(V)/227(V) User’s manual
20
Advanced
ACPI Settings
Enable ACPI Auto Configuration
Enables or Disables BIOS ACPI Auto Configuration.
Enable Hibernation
Enables or Disables System ability to Hibernate (OS/S4
Sleep State). This option may be not effective with some OS.
ACPI Sleep State
Select the highest ACPI sleep state the system will enter,
when the SUSPEND button is pressed.
Lock Legacy Resources
Enables or Disables Lock of Legacy Resources.
S3 Video Repost
Enables or Disables S3 Video Repost.
S5 RTC Wake Settings
Wake System with Fixed Time
Enables or disables system wake on alarm event. When
enabled, the system will wake on the time specified.
Wake system with Dynamic Time
Enables or disables system wake on alarm event. When
enabled, the system will wake on the current time+Increase
minute(s).
CPU Configuration
Hyper-Threading
Page 33
WMP-226(V)/227(V) User’s manual
21
Enabled for Windows XP and Linux (OS optimized for
Hyper-Threading Technology) and Disabled for other OS (OS
optimized for Hyper-Threading Technology)
Active Processor Cores
Number of cores to enable in each processor package.
Limit CPUID Maximum
When CPUID instruction is executed, newer CPU may return
a value greater than 3 which causes certain problem with
specific operating systems. Enabling "CPUID Maximum
Value Limit" in the CPU configuration of BIOS setup menu
will limit the returned value to 3 and less to get rid of the
problem. The problem is not seen with newer Windows series
operating systems so the default is set to disabled for it.
Execute Disable Bit
XD can prevent certain classes of malicious buffer overflow
attacks when combined with a supporting OS (Windows
Server 2003 SP1, Windows XP SP2, SuSE Linux 9.2, RedHat
Enterprise 3 Update 3.)
Intel Virtualization Technology
When enabled, a VMM can utilize the additional hardware
capabilities provided by Vanderpool Technology
Hardware Prefetcher
To turn on/off the Mid Level Cache (L2) streamer prefetcher.
Adjacent Cache Line Prefetch
To turn on/off prefetching of adjacent cache lines.
TCC Activation offset
Offset from the factory TCC activation temperature.
Primary Plane Current value
The Maximum instantaneous current allow for Primary
Plane.
Secondary Plane Current value
The Maximum instantaneous current allow for Secondary
Plane.
SATA Configuration
SATA Controller(s)
Enable or disable SATA device.
SATA Mode Selection
Select a configuration for SATA controller.
SATA Test Mode
Page 34
WMP-226(V)/227(V) User’s manual
22
This is typically required when the user wants to examine the
physical parameters of the host adapters transmit PHY (eg
examine the ‘eye’ on a scope or similar).
IDE Legacy / Native Mode Selection.
IDE Legacy / Native Mode Selection.
Info Report Configuration
System configration information report. It includes Post
report/Error message report/Summary report
USB Configuration
Legacy USB Support
Enables Legacy USB support. AUTO option disables legacy
support if no USB devices are connected. DISABLE option will
keep USB devices available only for EFI applications
EHCI Hand-off
This is a workaround for 0Ses without EHCI hand-off
support. The EHCI ownership change should be claimed by
EHCI driver.
USB Mass Storage Driver Support
Enable/Disable USB Mass Storage Driver Support.
USB transfer time-out
The time-out value for Control, Bulk, and Interrupt transfers.
Device reset time-out
USB mass storage device Start Unit command time-out.
Device power-up delay
Maximum time the device will take before it properly reports
itself to the HOST Controller.
‘Auto’ uses default value: for a Root port it is 100 ms, for a
Hub port the delay is taken from Hub descriptor.
Serial Port 1~4 Configuration
Serial Port 1 Configuration
Set Parameters of Serial Port 1.
Serial Port 2 Configuration
Set Parameters of Serial Port 2.
Serial Port 3 Configuration
Set Parameters of Serial Port 3.
Serial Port 4 Configuration
Set Parameters of Serial Port 4.
Serial Port 5~6 Configuration(Optional)
Page 35
WMP-226(V)/227(V) User’s manual
23
Serial Port 5 Configuration
Set Parameters of Serial Port 5.
Serial Port 6 Configuration
Set Parameters of Serial Port 6.
Page 36
WMP-226(V)/227(V) User’s manual
24
Chipset
System Agent (SA)/PCH-IO Configuration
This screen provides information on System Agent and PCH
parameters.
Page 37
WMP-226(V)/227(V) User’s manual
25
Boot
Setup Prompt Timeout
Number of seconds to wait for setup activation key.
65535(0xFFFF) means indefinite waiting.
Bootup Numlock State
Selects the keyboard NumLock state.
Boot Beep
Enables or disables boot status beep
Quiet Boot
Allows you to determine whether to display the Logo at system
startup. Disabled displays normal POST message.
Fast Boot
Enables or disables the quick boot function to speed up the
system boot-up process to shorten the waiting time for
entering the operating system and to deliver greater efficiency
for daily use.
CSM16 Parameters
Enable/Disable option ROM execution settings, etc.
CSM parameters
Option ROM execution, boot options filter, etc.
Page 38
WMP-226(V)/227(V) User’s manual
26
Security
Enables or disables the security chip. It is recommended that you
use this function with the Administrator/User password.
Page 39
WMP-226(V)/227(V) User’s manual
27
Save & Exit
Save Changes and Exit
Exit system setup after saving the changes.
Discard Changes and Exit
Exit system setup without saving any changes.
Save Changes and Reset
Reset the system after saving the changes.
Discard Changes and Reset
Reset system setup without saving the changes.
Save Changes
Save the changes done so far to any of setup options.
Discard Changes
Discard the changes done so far to any of setup options.
Restore Defaults
Restore/load default values for all the setup options.
Save as User Defaults
Save the changes done so far as User Defaults.
Restore User Defaults
Restore the User Defaults to all the setup options.
Launch EFI Shell From filesystem device
Attempts to Launch EFI Shell application (Shellx64.efi) from one
of the available filesystem devices.
Page 40
APPENDIX
WMP-226(V)/227(V) User’s manual
28
Appendix
A. Jumper settings and Connectors
This appendix gives the definitions and shows the positions of
jumpers, headers and connectors. All of the configuration
jumpers on WMP-226(V)/227(V) are in the proper position.
Note: Some of jumpers or connectors will be removed
base on system configuration.
Jumper and Connector Definition Block
Page 41
APPENDIX
WMP-226(V)/227(V) User’s manual
29
JP5 –Backlight Adjust
Description
Jumper Setting
analog Inverter
1-2 (default)
PWM Inverter
2-3
JP6 – Touch Panel Wire Selection
Description
Jumper Setting
4 wire
1-2, 3-4, 5-6, 7-8, 9-10
5 wire
3-4, 5-6, 7-8, 9-10 (default)
8 wire
1-2
JP7 – Touch Panel Type Selection
Description
Jumper Setting
3M type
1-2, 3-4 (default)
ELO type
5-6,7-8
JP8– Panel Power Selection
Description
Jumper Setting
+5VS (for 17"/19"/21.5”)
1-2,3-4 (default)
+3.3VS (for 10"/12"/15")
5-6,7-8
JP9 –TPM Settings
Description
Jumper Setting
Clear ME RTC registers
1-2
Keep ME RTC registers
OPEN (default)
Page 42
APPENDIX
WMP-226(V)/227(V) User’s manual
30
JP10 – CMOS Clear
Description
Jumper Setting
Normal Open
1-2 (default)
CMOS Clear
2-3
JP11 – Thermal sensor
Description
Jumper Setting
Auto detect
1-2(default)
always 25 ℃
2-3
always -40 ℃
NC
JP12 – SATA or SATA DOM Selection
Description
Jumper Setting
SATA DOM
1-2 ---power +5V
SATA
2-3(default)--- GND
JP13 – COM1 Function Selection
Description
Jumper Setting
RS-232
5-6, 9-11, 10-12, 15-17, 16-18(default)
RS-422
3-4, 7-9, 8-10, 13-15, 14-16, 21-22
RS-485
1-2, 7-9, 8-10, 19-20
Page 43
APPENDIX
WMP-226(V)/227(V) User’s manual
31
Connector Definition
PJ5 – HDD Power Connector
1
4
Pin #
Signal Description
1
+12V
2
Ground
3
Ground
4
+5V
PJ6 – HDD Power Connector
1
4
Pin #
Signal Description
1
+12V
2
Ground
3
Ground
4
+5V
PJ7 – Battery Connector
Pin1
Pin #
Signal Description
1
BATT+
2
BATT+
Page 44
APPENDIX
WMP-226(V)/227(V) User’s manual
32
3
BATT+
4
BAT_T
5
BAT_C
6
BAT_D
7
BATT_EN#
8
BATT-
9
BATT-
10
BATT-
PJ8 – Power Jack Connector
1 5
Pin #
Signal Description
1
DC In
2
DC In
3
Ground
4
Ground
5
Ground
J5,J6,J7 – Internal USB +3.3V Interface
Pin #
Signal Description
1
+3.3VS
2
Data -
3
Data +
4
Ground
5
Ground
Page 45
APPENDIX
WMP-226(V)/227(V) User’s manual
33
J8 – LCD Inverter Interface
6 1
Pin #
Signal Description
1
+12V
2
+12V
3
Backlight Adjust
4
Backlight Enable
5
Ground
6
Ground
J9 –Resistor Touch Panel Interface
1
9
Pin #
Signal Description
8-wire
4-wire
5-wire
1
UL(X+)
UL(X+)
UL(X+)
2
UR(Y+)
UR(Y+)
UR(Y+)
3
N/A
N/A
PRCBE
4
LR(X-)
LR(X-)
LR(X-)
5
LL(Y-)
LL(Y-)
LL(Y-)
6
X+_DRIVE
N/A
N/A
7
Y+_DRIVE
N/A
N/A
8
X-_DRIVE
N/A
N/A
9
Y-_DRIVE
N/A
N/A
J10,J11/J12 –PWM CPU FAN, SYSTEM FAN
Page 46
APPENDIX
WMP-226(V)/227(V) User’s manual
34
Pin #
Signal Description
J10(SYSTEM)
J11(CPU) 2.54mm
J12(CPU) 2.0mm
1
AUX PWM
CPU PWM
SYS PWM
2
AUX RPM
CPU RPM
SYS RPM
3
VAUXFAN
VCPUXFAN
VSYSXFAN
4
GND
GND
GND
J13 –F/W IC-EETI control
Pin #
Signal Description
1
+3.3V_TP
2
C2CK
3
C2D
4
Ground
J14, J15 – Internal USB 5V Interface
Pin #
Signal Description
1
+5VSB
2
+5VSB
3
Data -
4
Data +
5
Ground
6
Ground
Page 47
APPENDIX
WMP-226(V)/227(V) User’s manual
35
J16, J17 – Internal USB 5V (QM67 only Support)
Pin #
Signal Description
1
+5VSB
2
+5VSB
3
Data -
4
Data +
5
Ground
6
Ground
J18, J21 – mini PCI Express Socket
Page 48
APPENDIX
WMP-226(V)/227(V) User’s manual
36
J19 – Battery Socket
Pin #
Signal Description
1
RTC +3.3V
2
GND
J20 –Standard PCIE X16 Slot Interface
Pin #
Signal Description
Pin #
Signal Description
1
WAKE#
2
+3.3VSB
3
Reserved
4
GND
5
Reserved
6
+1.5VS
7
CLKREQ#
8
Reserved
9
GND
10
Reserved
11
REFCLK-
12
Reserved
13
REFCLK+
14
Reserved
15
GND
16
Reserved
17
Reserved
18
GND
19
Reserved
20
Reserved
21
GND
22
PERST#
23
PERn0
24
+3.3VSB
25
PERp0
26
GND
27
GND
28
+1.5VS
29
GND
30
SMB_CLK
31
PETn0
32
SMB_DATA
33
PETp0
34
GND
35
GND
36
USB_D-
37
GND
38
USB_D+
39
+3.3VSB
40
GND
41
+3.3VSB
42
Reserved
43
GND
44
Reserved
45
CL_CLK
46
Reserved
47
CL_ DATA
48
+1.5VS
49
Controller Link RST#
50
GND
51
Reserved
52
+3.3VSB
Page 49
APPENDIX
WMP-226(V)/227(V) User’s manual
37
Pin
#
Side B
Side A
Pin
#
Side B
Side A
1
+12V
PRSNT1#
42
PETn6
GND
2
+12V
+12V
43
GND
PERp6
3
+12V
+12V
44
GND
PERn6
4
GND
GND
45
PETp7
GND
5
SMCLK
PCIE_TXN6
46
PETn7
GND
6
SMDAT
PCIE_TXP6
47
GND
PERp7
7
GND
PCIE_RXN6
48
Reserved
PERn7
8
+3.3V
PCIE_RXP6
49
GND
GND
9
Reserved
+3.3V
50
PETp8
Reserved
10
+3.3V
+3.3V
51
PETn8
GND
11
WAKE#
PERST#
52
GND
PERp8
12
Reserved
GND
53
GND
PERn8
13
GND
PCIEx16_CLK+
54
PETp9
GND
14
PETp0
PCIEx16_CLK-
55
PETn9
GND
15
PETn0
GND
56
GND
PERp9
16
GND
PERp0
57
GND
PERn9
17
Reserved
PERn0
58
PETp10
GND
18
GND
GND
59
PETn10
GND
19
PETp1
Reserved
60
GND
PERp10
20
PETn1
GND
61
GND
PERn10
21
GND
PERp1
62
PETp11
GND
22
GND
PERn1
63
PETn11
GND
23
PETp2
GND
64
GND
PERp11
24
PETn2
GND
65
GND
PERn11
25
GND
PERp2
66
PETp12
GND
26
GND
PERn2
67
PETn12
GND
27
PETp3
GND
68
GND
PERp12
28
PETn3
GND
69
GND
PERn12
29
GND
PERp3
70
PETp13
GND
30
PCIEx1_CLK+
PERn3
71
PETn13
GND
31
PCIEx1_CLK-
GND
72
GND
PERp13
32
GND
Reserved
73
GND
PERn13
33
PETp4
Reserved
74
PETp14
GND
34
PETn4
GND
75
PETn14
GND
35
GND
PERp4
76
GND
PERp14
36
GND
PERn4
77
GND
PERn14
Page 50
APPENDIX
WMP-226(V)/227(V) User’s manual
38
37
PETp5
GND
78
PETp15
GND
38
PETn5
GND
79
PETn15
GND
39
GND
PERp5
80
GND
PERp15
40
GND
PERn5
81
Reserved
PERn15
41
PETp6
GND
82
PCICLK_33M
GND
J22 – LVDS Interface
Pin #
Signal Description
Pin #
Signal Description
1
+LCD (+5V/ +3.3V)
2
+LCD (+5V/ +3.3V)
3
+LCD (+5V/ +3.3V)
4
+LCD (+5V/ +3.3V)
5
Ground
6
Ground
7
Ground
8
Ground
9
A_RxIn0-
10
B_RxIn0-
11
A_RxIn0+
12
B_RxIn0+
13
Ground
14
Ground
15
A_RxIn1-
16
B_RxIn1-
17
A_RxIn1+
18
B_RxIn1+
19
Ground
20
Ground
21
A_RxIn2-
22
B_RxIn2-
23
A_RxIn2+
24
B_RxIn2+
25
Ground
26
Ground
27
A_CKIN-
28
B_CKIN-
29
A_CKIN+
30
B_CKIN+
31
Ground
32
Ground
33
A_RxIn3-
34
B_RxIn3-
35
A_RxIn3+
36
B_RxIn3+
37
Ground
38
Ground
39
Ground
40
Ground
J23,J24 – DDR3 SO-DIMM Interface
Page 51
APPENDIX
WMP-226(V)/227(V) User’s manual
39
J23 H9.2 Near CPU
J24 H5.2 Near External
Pin
Symbol
Pin
Symbol
Pin
Symbol
Pin
Symbol
Pin
Symbol
Pin
Symbol
1
VREFDQ
69
DQ27
137
DQS4
2
VSS
70
DQ31
138
VSS
3
VSS
71
VSS
139
VSS
4
DQ4
72
VSS
140
DQ38
5
DQ0
73
CKE0
141
DQ34
6
DQ5
74
NC
142
DQ39
7
DQ1
75
VDD
143
DQ35
8
VSS
76
VDD
144
VSS
9
VSS
77
NC
145
VSS
10
DQS0#
78
NC
146
DQ44
11
DM0
79
BA2
147
DQ40
12
DQS0
80
NF/A14
148
DQ45
13
VSS
81
VDD
149
DQ41
14
VSS
82
VDD
150
VSS
15
DQ2
83
A12
151
VSS
16
DQ6
84
A11
152
DQS5#
17
DQ3
85
A9
153
DM5
18
DQ7
86
A7
154
DQS5
19
VSS
87
VDD
155
VSS
20
VSS
88
VDD
156
VSS
21
DQ8
89
A8
157
DQ42
22
DQ12
90
A6
158
DQ46
23
DQ9
91
A5
159
DQ43
24
DQ13
92
A4
160
DQ47
25
VSS
93
VDD
161
VSS
26
VSS
94
VDD
162
VSS
27
DQS1#
95
A3
163
DQ48
28
DM1
96
A2
164
DQ52
29
DQS1
97
A1
165
DQ49
30
RESET#
98
A0
166
DQ53
31
VSS
99
VDD
167
VSS
32
VSS
100
VDD
168
VSS
33
DQ10
101
CK0
169
DQS6#
34
DQ14
102
CK1
170
DM6
35
DQ11
103
CK0#
171
DQS6
36
DQ15
104
CK1#
172
VSS
37
VSS
105
VDD
173
VSS
38
VSS
106
VDD
174
DQ54
39
DQ16
107
A10
175
DQ50
40
DQ20
108
BA1
176
DQ55
41
DQ17
109
BA0
177
DQ51
42
DQ21
110
RAS#
178
VSS
43
VSS
111
VDD
179
VSS
44
VSS
112
VDD
180
DQ60
45
DQS2#
113
WE#
181
DQ56
46
DM2
114
S0#
182
DQ61
47
DQS2
115
CAS#
183
DQ57
48
VSS
116
ODT0
184
VSS
49
VSS
117
VDD
185
VSS
50
DQ22
118
VDD
186
DQS7#
51
DQ18
119
A13
187
DM7
52
DQ23
120
NC
188
DQS7
53
DQ19
121
NC
189
VSS
54
VSS
122
NC
190
VSS
55
VSS
123
VDD
191
DQ58
56
DQ28
124
VDD
192
DQ62
57
DQ24
125
NC
193
DQ59
58
DQ29
126
VREFCA
194
DQ63
59
DQ25
127
VSS
195
VSS
60
VSS
128
VSS
196
VSS
61
VSS
129
DQ32
197
SA0
62
DQ3#
130
DQ36
198
EVENT#
63
DM3
131
DQ33
199
VDDSP
D
64
DQ3
132
DQ37
200
SDA
65
VSS
133
VSS
201
SA1
66
VSS
134
VSS
202
SCL
67
DQ26
135
DQS4#
203
VTT
68
DQ30
136
DM4
204
VTT
Page 52
APPENDIX
WMP-226(V)/227(V) User’s manual
40
J25 – CAP Front Bezel Button Connector
Pin #
Signal Description
1
+3.3V
2
+3.3V
3
KP_SCL
4
KP_SDA
5
HEATER_LED#
6
KP_INT#
7
SATA_LED#
8
Ground
9
Ground
J26 – SDP (EC Simple Debug Port)
Pin #
Signal Description
1
+5V
2
P80_DAT
3
P80_CLK
4
Ground
J27 – EC JTAG
1
9
Page 53
APPENDIX
WMP-226(V)/227(V) User’s manual
41
Pin #
Signal Description
Pin #
Signal Description
1
EC_TRST#
2
+3.3V
3
EC_TMS
4
EC_RDY#
5
EC_TDI
6
GND
7
EC_TCK
8
GND
9
EC_TDO
10
GND
J28 –TPM / ID-394
Pin #
Signal Description
Pin #
Signal Description
1
LPC AD0
2
PCI reset
3
LPC AD1
4
SERIRQ
5
LPC AD2
6
+3.3V
7
LPC AD3
8
+5V
9
LPC Frame
10
PCI CLKRUN
11
Debug CLK
12
SMB CLK
13
GND
14
SMB DATA
15
SUS_STAT#
16
+3.3V
J29 – Front Bezel Button Connector
Pin #
Signal Description
1
Power Button
1
9
Page 54
APPENDIX
WMP-226(V)/227(V) User’s manual
42
2
+3.3V
3
Sound Volume Up
4
Sound Volume Down
5
Ground
6
LCD BackLight Up
7
LCD BackLight Down
8
Touch Screen Forbid
9
LCD BackLight ON/OFF
J30 – PS2 KB/MS connector
Pin #
Signal Description
1
Keyboard data
2
Mouse data
3
GND
4
5V 5 Keyboard clock
6
Mouse clock
J31 – Light Sensor Connector (For Outdoor)
Pin #
Signal Description
1
Light Sensor
2
NC
3
+3.3V
Page 55
APPENDIX
WMP-226(V)/227(V) User’s manual
43
J32 – EC Reset
Pin #
Signal Description
1
VCC_POR#
2
GND
J33 – HEATER, CLEAR ME LED INDICATE
Pin #
Signal Description
1
+3.3V_UC
2
HEATER_LED#
3
KEYLOCK_LED#
J34, J36 – Standard SATA Interface
Pin #
Signal Description
1
Ground
2
Tx+
3
Tx-
4
Ground
5
Rx-
6
Rx+
7
Ground
Page 56
APPENDIX
WMP-226(V)/227(V) User’s manual
44
J35 – RS-232 TTL Connector
Pin #
Signal Description
Pin #
Signal Description
1
DCD#
2
DSR#
3
SIN
4
RTS#
5
SOUT
6
CTS#
7
DTR#
8
RI#
9
GND
10
+5VS
J46,J37 – COM3, COM4 Serial Port
Pin #
Signal Description
Pin #
Signal Description
1
232_DCD
2
232_DSR
3
232_SIN
4
232_RTS
5
232_SOUT
6
232_CTS
7
232_DTR
8
232_RI
9
GND
10
+5VS
J40 – BIOS SOCKET
Pin1
Pin #
Signal Description
Pin #
Signal Description
1
CS#
5
VDD
2
SO 6 HOLD#
3
WP#
7
SCK
4
VSS
8
SI
Page 57
APPENDIX
WMP-226(V)/227(V) User’s manual
45
J41 – POWER & HDD LED (For WMP-176/196 )
Pin #
Signal Description
1
SATA LED
2
+3.3V
3
+3.3V
4
Power LED
J42 – ATX 12V Connect (For Heater Power)
Pin #
Signal Description
1
+12V
2
+12V
3
Ground
4
Ground
J43 , J45 – Passive Speaker Connect
J43(Right Channel)
J45(Left Channel)
Pin #
Signal Description
Pin #
Signal Description
1
AMP. Out +
1
AMP. Out +
2
AMP. Out -
2
AMP Out -
Page 58
APPENDIX
WMP-226(V)/227(V) User’s manual
46
J44 – Handset Connect
Pin #
Signal Description
1
HOOK_ON#
2
Handset speaker
3
Handset MIC
4
GND
J47 – Power Switch connect
Pin #
Signal Description
1
Power ON
2
GND
J48, J49 – Ethernet Port
Pin #
Signal Description
1
Data0+
2
Data0-
3
Data1+
4
Data2+
5
Data2-
6
Data1-
7
Data3+
8
Data3-
Page 59
APPENDIX
WMP-226(V)/227(V) User’s manual
47
J50, J51 – USB1/2,3/4 Port
Pin #
Signal Description
1
+5V
2
Data-
3
Data+
4
GND
J52 – DVI-I Interface
Pin #
Signal Description
Pin #
Signal Description
1
TMDS Data2-
2
TMDS Data2+
3
TMDS Data2 shield
4
NC
5
NC
6
DDC Clock
7
DDC Data
8
Analog VSYNC
9
TMDS Data1-
10
TMDS Data1+
11
TMDS Data1 Shield
12
NC
13
NC
14
+5V
15
GND
16
Hot Plug Detect
17
TMDS Data0-
18
TMDS Data0+
19
TMDS Data0 Shield
20
NC
21
NC
22
TMDS Clock Shield
23
TMDS Clock+
24
TMDS Clock-
C1
Analog Red
C2
Analog Green
C3
Analog Blue
C4
Analog HSYNC
C5
GND
C6
GND
Page 60
APPENDIX
WMP-226(V)/227(V) User’s manual
48
J53,J54 – Audio Connector
Pin #
Signal Description
J53
Microphone (stereo) Pink
J54
Line Out (stereo) Green
J55 – Reset connector
Pin #
Signal Description
1
SYS_RESET#
2
GND
J56 – Reset Button
Pin #
Signal Description
1
SYS_RESET#
2
GND
J57 – COM1 Connector
Page 61
APPENDIX
WMP-226(V)/227(V) User’s manual
49
Pin #
Signal Description
RS-232
RS-422
RS-485
1
Carrier Detect
Transmit Data -
Transmit Data -
2
Receive Data
Transmit Data +
Transmit Data +
3
Transmit Data
Receive Data +
NC
4
Data Terminal
Ready
Receive Data -
NC
5
Ground
NC
NC
6
Data Set Ready
NC
NC
7
Request to Send
NC
NC
8
Clear to Send
NC
NC
9
Ring Indicator
NC
NC
J58 – COM2 Connector
Pin #
Signal Description
Pin #
Signal Description
1
232_DCD
2
232_SIN
3
232_SOUT
4
232_DTR
5
GND
6
232_DSR
7
232_RTS
8
232_CTS
9
232_RI
10
Not Used
Page 62
APPENDIX
WMP-226(V)/227(V) User’s manual
50
B. L type Stand (optional kit)
Key Features and Benefits
Similar color as WMP series
10 degree tilt down and 30 degree tilt up solution
5,000 times hinge life cycle
Specifications:
Weight Capacity:
Max 10kgs
Monitor Mounting Holes
VESA 75*75mm or 100*100mm
Application using
Desktop stand
Page 63
APPENDIX
WMP-226(V)/227(V) User’s manual
51
C. Battery Pack Specifications (optional kit)
Battery Model133
BP-WMP001-22/1900A
Battery Type
Li-ion 2S2P
Minimum Capacity
3800 mAh
Nominal Voltage
7.3 V
Max. Charge Voltage
8.4V
Cut Off Voltage
6.0v
Suggested Charge
Current (Max.)
2A
System Continuous
Discharging Current
(Max.)
16.6 A
The End of Charge
Condition
150 mA/min
Discharge Protection
UVP/OCP
Charge Protection
OVP/OTP
Self-discharge Rate
10uA ~800 uA
Dimensions
133 x 47 x 21mm
Weight
220g+/-20g
Ambient Temperature
0°C ~ +45°C
Storage Temperature
-20°C ~ +60°C
Energy
27.74Wh
Backup
100 W/ 10 min
Page 64
APPENDIX
WMP-226(V)/227(V) User’s manual
52
D. Change Win Xp resolution to 1920*1080
1. Please help to follow below step to change setting
2. In display properties settings advanced monitor
disable hide mode …screen resolution will have 1920*1080
resolution can use.
Page 65
APPENDIX
WMP-226(V)/227(V) User’s manual
53
E. How to disable battery when system hang up
-WMP-226(V)/227(V)
1. When system hang up ,press power button 10 seconds to turn
off system . If you can’t power on system by power button.
Please follow below step to reset system.
2. Remove AC power cord, then the battery LED will on.
3. Press volume up key 10 seconds, then all LED will turn on and
turn off
4. Plug in AC power cord again, press power button then you can
power on system.
Page 66
APPENDIX
WMP-226(V)/227(V) User’s manual
54
F. Scrap Computer Recycling
If the computer equipments need the maintenance or are beyond
repair, we strongly recommended that you should inform us as
soon as possible for the suitable solution. For the computers that
are no longer useful or work well, please contact with worldwide
distributors for recycling.
The worldwide distributors show on the following website:
http://www.wincomm.com.tw/contact.aspx
Note:
Follow the national requirement to dispose unit
Loading...
