Need help? www.WilsonElectronics.com
Tech Support 866-294-1660
Mon.- Fri. Hours: 7 am to 6 pm MST
MobilePro
®
Cellular Signal Booster
46 0113
2
Need help? www.WilsonElectronics.com
Tech Support 866-294-1660
Mon.- Fri. Hours: 7 am to 6 pm MST
Contents
Package Contents ....................................................3
Optional Accessories .................................................3
Installation Options ...................................................3
Vehicle Installation Option ..........................................3
In-Building Installation Option ........................................5
Understanding the MobilePro Light ......................................6
Recommended Additional FAQ .........................................6
Safety and Recommendations ..........................................7
Signal Booster Specifications ................................. Back Cover
Guarantee and Warranty ...................................... Back Cover
IT IS VERY IMPORTANT
TO POWER YOUR SIGNAL
BOOSTER USING A SURGE
PROTECTED AC POWER
STRIP WITH AT LEAST A 1000
JOULE RATING.
FAILURE TO DO THIS WILL VOID YOUR WARRANTY
IN THE EVENT OF A POWER SURGE OR LIGHTNING
STRIKE.
! !
THE SIGNAL BOOSTER UNIT IS DESIGNED
FOR USE IN AN INDOOR, TEMPERATURECONTROLLED ENVIRONMENT (LESS
THAN 150 DEGREES FAHRENHEIT). IT IS
NOT INTENDED FOR USE IN ATTICS OR SIMILAR
LOCATIONS SUBJECT TO TEMPERATURES IN
EXCESS OF 150°F.
Installation Instructions for the Following Wilson Electronics Signal Booster:
MobilePro® Dual-Band Wireless Smart Technology ™ Signal Booster
Model # 460013 FCC ID: PWO460013
3
Need help? www.WilsonElectronics.com
Tech Support 866-294-1660
Mon.- Fri. Hours: 7 am to 6 pm MST
To purchase call 800-204-4104 or go to www.WilsonElectronics.com
Refer to page 7 for additional Antenna Kit Options
12” Antenna
(311103)
Marine
Antenna
(311130-5810)
Trucker
Antenna
(311133)
Mobile Power
Supply
(859984)
Optional Antennas Kits
Gooseneck
Suction Cup
Cradle Mount
(901120)
Cup Holder
Cradle Mount
(901130)
Adjustable
Desk Mount
(901137)
Mounting Options
Installation Options
Before you start your installation, read through
each step of the instructions. Also, watch the
installation video at wilsonelectronics.com/
MobileProvideo. You can install MobilePro in
your vehicle, in your home, ofce, or in a hotel
room or other building using the following steps.
Vehicle Installation Option
1. Install the Outside Antenna. Select a
location on top of the car that is:
• On a magnetic surface, preferably near
the center of the vehicle’s roof.
• At least 12 inches from any other
antennas.
• Free of obstructions.
• At least 6 inches from any windows
(including sunroofs).
• At least 8 inches from any people.
The Outside Antenna must be installed
vertically.
2. Run the Outside Antenna cable into the
car. The cable is strong enough that it
may be shut in most vehicle doors without
damaging the cable. For a cleaner look,
carefully pull down the door seal, run the
cable under the seal, and push the seal
back into place. This method reduces
wear on the cable as the door opens and
closes.
Optional Accessories
Wireless
Signal Booster
Mini-Magnet
Mount Antenna
(301126)
AC DC
Power Supply
(859969)
USB power cable with
power power adapter
(859963)
Antenna
Window Mount
(901128)
Package Contents
Carrying case included
Appearance of device and accessories may vary.
Mobile
Power Supply
Vehicle Dash
Mounting Kit
-Rugged/Screw Mount
-Adhesive Mount
-Vent Clip Mount
-Alcohol Prep Pad
