SoundPlus®
Infrared Listening System
Installation Guide and User Manual
TX9 EMITTER
MOD 232 MODULATOR
MAN 132I
Page 2
SoundPlus® Infrared Listening System
Contents
System Overview ......................................................................................................................................................................... 3
MOD 232 Modulator Setup ....................................................................................................................................................... 4
Determine Location .......................................................................................................................................................................... 4
Wiring and Connections ................................................................................................................................................................... 4
Power Connection for U.S. Application ....................................................................................................................................... 4
For Applications Outside The U.S. Requiring 240 VAC Mains Supply: ............................................................................. 4
Baseband Cable Connection .........................................................................................................................................................5
Audio Connection ...............................................................................................................................................................................6
Features and Controls ......................................................................................................................................................................6
Configuration Settings ...................................................................................................................................................................... 7
TX9 Emitter Setup ....................................................................................................................................................................... 8
TX9 Location and Placement .........................................................................................................................................................8
Coverage Area .............................................................................................................................................................................9
Multiple Emitters Installed to Maximize Coverage ..................................................................................................................10
Compressor Gain ................................................................................................................................................................................ 11
TX9 Features and Controls ..................................................................................................................................................... 12
Mounting the TX9 ..............................................................................................................................................................................12
Receiver Safety Information .................................................................................................................................................... 13
Recycling Instructions ............................................................................................................................................................... 13
Infrared Receivers ..................................................................................................................................................................... 14
Trouble Shooting ....................................................................................................................................................................... 15
TX9 Indicator Light Is Not On. .......................................................................................................................................................15
Only TX9’s Power Indicator LED Comes On. ...........................................................................................................................15
No Sound Through Receivers. ......................................................................................................................................................15
Sound Through The Receivers Is Weak And Noisy. ..............................................................................................................15
Buzzing Or Humming Noise In Sound System. .......................................................................................................................15
SoundPlus® Infrared Listening System Specifications ....................................................................................................... 16
Two-Channel Modulator, Model MOD 232 ...............................................................................................................................16
SoundPlus® Infrared Listening System Specifications ........................................................................................................17
Multi–Channel Infrared Emitter, Model TX9 .............................................................................................................................. 17
Limited Warranty ........................................................................................................................................................................ 18
2
Page 3
SoundPlus® Infrared Listening System
System Overview
The Williams Sound SoundPlus® Infrared Listening System consists of a MOD 232 Modulator(s) and one or more TX9
Emitters which use invisible infrared (IR) light to broadcast speech or music to wireless infrared receivers.
The system is designed to transmit high quality audio for hearing assistance and language translation applications.
Because the system uses infrared light for transmission, it is not aected by interference from radio equipment and
does not interfere with radio equipment. No FCC license or radio approval is required.
The system can be used with microphones as a stand-alone system, or can be connected to other sound equipment.
Infrared systems generally cannot be used in direct sunlight because of sunlight’s large amount of interfering infrared
light.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct the interference at his own
expense.
NOTICE: A plasma monitor can degrade the audio quality of the SoundPlus® Infrared Listening System.
3
Page 4
SoundPlus® Infrared Listening System
A255
BASEBAND OUTPUT
ANOTHER SOUND SYSTEM.
CONFIGURATION SWITCHES
CONTROLS CHANNEL SELECTION,
COMPRESSOR GAIN, MIC/LINE
INPUT, CHANNEL ON/OFF, AND
OTHER CONTROLS.
BASEBAND INPUT
POWER
SUPPLY
MOD 232 Modulator Setup
Determine Location
The modulator is usually located with the sound system amplifier or mixer for easy access to an audio input signal.
For portable systems, the modulator can be placed near the emitter or in another convenient location. Infrared Stand
Kit SS-6 is available for portable systems.
Wiring and Connections
Figure 1: MOD 232 (Rear View)
A SECOND MODULATOR
MAY BE CONNECTED
HERE FOR 4 (FOUR)
CHANNEL OPERATION.
INPUT CH A CH B
ACCEPTS ANY LOW
IMPEDANCE MICROPHONE
OR LINE LEVEL SIGNAL.
AUDIO LINE OUTPUT
RCA JACK FOR MONITORING,
RECORDING, OR ROUTING
PROCESSED AUDIO TO
WARNING: POWERLINE VOLTAGE MUST NOT FALL BELOW 94V, OR SYSTEM
PERFORMANCE WILL BE GREATLY REDUCED!
Power Connection for U.S. Application
1. Connect the TFP 016 power supply to the 3-pin Molex connector located on the
rear of the MOD 232. (See Figure 2, right.)
SENDS INDIVIDUAL
AND/OR COMBINED
CARRIER FREQUENCIES
OF 2.3, 2.8, 3.3, 3.8 MHz
TO A TX9 EMITTER.
POWER IN
24 VAC, 50-60Hz
120 VAC (US); TFP 016 POWER SUPPLY
230 VAC (CE); TFP 027 POWER SUPPLY
Figure 2: Power Connection
For Applications Outside The U.S. Requiring 240 VAC Mains Supply:
Use the transformer power supply, model TFP 027.
Secondary specifications: 24 VAC, 35 VA, 50/60 Hz.
2. Plug the power supply into the AC outlet.
4
Page 5
SoundPlus® Infrared Listening System
SECOND WIR TX9 EMITTER (OPTIONAL)
A248
WIR TX9 EMITTER (REAR)
MOD 232 MODULATOR #2 (REAR)MOD 232 MODULATOR #1 (REAR)
A249
Baseband Cable Connection
The MOD 232 can directly drive one or two emitters. TX9 emitters repeat the baseband signal, so any number of
emitters can be used. The modulator outputs CANNOT be split with CATV splitters.
Determine the length of RG-58 cable needed to reach from the TX9 Emitter to the Modulator unit. Install BNC
connectors to each end of the cable.
For two-channel operation, only one MOD 232 is required: Connect the coaxial cable to one of the Baseband Output
jacks on the rear of the MOD 232. The other end of the coaxial cable connects to the Baseband Input jack of the TX9
Emitter. See Figure 3 below.
Figure 3: Baseband Connection, Two Channel Operation
Multi-Channel Infrared Transmitter
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF FIRE OR
Class 1
ELECTRIC SHOCK DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
LED Product
Note: It is normal for this unit to feel warm while it is in operation.
Power Supply Wiring:
Use NEC, Class 2 Wiring, 18 ga. minimum,
200 ft. (70m) maximum length (18 ga.)
Baseband Signal Wiring:
Use RG58 Coax,1000 ft. (350m) max. length
Williams Sound, Minneapolis, Minnesota, USA
Patent Pending
24 VACNC
Power In:
24VAC
~
Plug
50-60Hz
35VA
RoHS
Mounting
Bracket
Made in U.S.A.
Power On Baseband On
www.williamssound.com
Baseband Signal Wiring:
Use 50 Ohm Coaxial Cable (RG58)
Baseband
(Modulation)
InOut Out
MOD 232 MODULATOR (REAR)
50 Ohms
BASEBAND
OUTPUT
BASEBAND
OUTPUT
Multi-Channel Infrared Transmitter
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF FIRE OR
Class 1
ELECTRIC SHOCK DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
LED Product
Note: It is normal for this unit to feel warm while it is in operation.
Power Supply Wiring:
Use NEC, Class 2 Wiring, 18 ga. minimum,
200 ft. (70m) maximum length (18 ga.)
Baseband Signal Wiring:
Use RG58 Coax,1000 ft. (350m) max. length
Williams Sound, Minneapolis, Minnesota, USA
Patent Pending
24 VACNC
Power In:
24VAC
~
Plug
50-60Hz
35VA
RoHS
Mounting
Bracket
Made in U.S.A.
Power On Baseband On
www.williamssound.com
Baseband Signal Wiring:
Use 50 Ohm Coaxial Cable (RG58)
TX9 BASEBAND INPUT TX9 BASEBAND INPUT
Connect to the TX9 using RG-58 cable and BNC connectors. The MOD 232 has two baseband output jacks to
simplify connections when multiple emitters are used.
To setup a system for four-channel operation, two MOD 232 Modulators are required. Link the two Modulator units
together as shown in Figure 4. Connect the baseband output from the second modulator in the chain to the TX9
emitter(s) baseband input connector.
Figure 4: Baseband Connection, Four Channel Operation
Baseband
(Modulation)
InOut Out
50 Ohms
BASEBAND
OUTPUT
COAXIAL CABLE (WCA 068) TX9 BASEBAND INPUT
IMPORTANT: Each channel must be set to a dierent frequency!
BASEBAND
INPUT
BASEBAND
OUTPUT
5
Page 6
SoundPlus® Infrared Listening System
BALANCED LINE USING 3–PIN CONNECTOR
IN PHASE
UNBALANCED LINE USING 3–PIN CONNECTOR
BALANCED LINE USING 1/4" CONNECTOR
IN PHASE
UNBALANCED LINE USING 1/4" CONNECTOR
A254
COMPRESS CONTROL
INPUTS MIXED
STEREO LED
AUDIO LEVEL
CONTROLS
A OR B STEREO AUDIO
CARRIER (CXR) LEDs
Audio Connection
Microphone Input:
With the modulator DIP switches set for microphone input, the 3-pin XLR jack accepts balanced microphones. Power
for condenser microphones can be selected by DIP switch. The minimum input level is 100uV and the maximum level
is 90 mV.
XLR Line-Level Input:
With the modulator DIP switches set for line-level input, the 3-pin XLR jack accepts balanced line-level audio inputs.
The minimum input level is 21mV and the maximum level is 10V.
1/4" TRS Line-Level Input:
The 1/4" Tip/Ring/Sleeve (TRS) jack can accept only a balanced or unbalanced line-level input. A 25 V, 70 V, or 100V
speaker line can be connected to the balanced line input using an appropriate attenuator. “T” pads made with
resistors yield better fidelity than speaker matching transformers.
Figure 5: Audio Connection
Features and Controls
Figure 6: Features and Controls (MOD 232 Rear)
3 PIN CONNECTOR
INDICATES SELECTED
FREQUENCY, FLASHES
TO INDICATE A FAULT.
1 2
3
2:1 SETTING WILL
INCREASE TRANSMITTED
AUDIO UP TO 30 dB
DURING PERIODS OF
LOW LEVEL SOUND.
3 PIN CONNECTOR
INDICATES CHANNEL
A AND CHANNEL B
ARE MIXED AND
TRANSMITTED
BY CHANNEL A.
CHANNEL B IS OFF.
1 2
3
INDICATES
STEREO MODE.
POWER SWITCH
TURNS THE MODULATOR
ON AND OFF. THE WALL
MOUNTED POWER SUPPLY
STAYS ON AT ALL TIMES.
POWER ON
INDICATOR
6
LEVEL INDICATORS
INDICATOR SHOWS
AUDIO LEVEL IN 3dB
INCREMENTS.
IR LED
FOR TESTING
RECEIVERS.
PHONE SWITCH
SELECTS CHANNEL
A OR B AUDIO
WHEN NOT IN
STEREO MODE.
PHONE JACK
1/4” PHONE JACK.
MONITORS CHANNEL
DEPENDING ON
POSITION OF PHONE
JACK SWITCH, AND
MODE OF OPERATION.
Page 7
SoundPlus® Infrared Listening System
CHANNEL A AND B
A252
A250
Configuration Settings
Figure 8 illustrates how to configure your system using the DIP switches (Figure 7) located on the back of the MOD
232 Modulator. This diagram is also printed on top of the MOD 232 Modulator unit for quick reference.
Figure 7: Configuration Switches
CONFIGURATION
SWITCHES
Figure 8: DIP Switch Configuration Chart
IMPORTANT: Channel A and Channel B must be set to dierent frequencies!
Compressor Gain
The MOD 232’s Compressor Gain is set in “Moderate” mode from the factory. Use this setting for simultaneous
interpretation. Be sure that the compress control, located on the front of the MOD 232 (Figure 6, page 6), is turned
fully counter-clockwise. Compression can be added if desired by turning the compress control clockwise.
For hearing assistance applications, the MOD 232’s Compressor Gain can be set to “Maximum” mode. For additional
compression, use a tuning wand (PLT 005) or small screw driver and gently turn the compress control (Figure 6, page
6) on the front of the MOD 232 clockwise.
7
Page 8
SoundPlus® Infrared Listening System
A237
TX9 Emitter Setup
TX9 Location and Placement
To determine the best location for the TX9 Emitter, it helps to think of the IR emitter as an invisible floodlight. You’ll want
to aim it so the listeners are “flooded” with the infrared light. Mount the emitter at least 2 ft (.61 m) above the audience.
Position the emitter to face in a slightly downward angle - that will increase the “throw” of the infrared beam. Infrared
light reflects o most surfaces and scatters, increasing the coverage area. Rough surfaces tend to absorb infrared light,
minimizing reflections, and limiting coverage to the direct illumination. Remember: opaque objects block infrared light.
Thus, emitters cannot be concealed behind opaque walls, curtains, etc.
The emitter front red plastic lens must NOT be painted. Neither should emitters be used in areas of extreme high or low
temperature, humidity, or chemical environments.
The TX9 Infrared Emitter should not be installed where there is a lot of direct sunlight, which can create infrared
interference.
Figure 9: 3 Dimension Foot Pattern
Figure 10: NOTE: When pointing the emitter, be sure to keep the long dimension horizontal.
CORRECT
INCORRECT
8
Page 9
Coverage Area
0
90
10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160
FEET
FEET
A136
Figure 11: Maximum Range when using the RX22-4, RX15-2, or RX18 receiver
SoundPlus® Infrared Listening System
80
70
60
50
40
30
20
10
-10
-20
-30
-40
-50
-60
-70
-80
-90
RECEIVER COVERAGE AREA WITH
TX9 OR TX90 TRANSMITTER IN
SINGLE CHANNEL MODE
RX22-4 RECEIVER
RX15-2 RECEIVER
RX18 RECEIVER
0
These patterns are the direct radiation pattern. The infrared radiation does not drop to zero outside the illustrated
patterns; it decreases. It still may be usable at a greater distance, depending on the receiver sensitivity and the
reflective characteristics of the room. Reflections of the infrared light from walls, ceilings, and floors may change
these patterns.
9
Page 10
SoundPlus® Infrared Listening System
A262
COVERAGE AREA
TER
A263
WIR TX9 EMITTER #3 (REAR)
WIR TX9 EMITTER #2 (REAR) WIR TX9 EMITTER #1 (REAR)
A256
Multiple Emitters Installed to Maximize Coverage
Figure 12A
WIR TX9 WIR TX9
WIR TX9 WIR TX9
Figure 12B
Figure 12A and 12B: Overlapping Illumination
Patterns to Cover Larger Listening Areas
WIR TX9
WIR TX9
Figure 13: Connecting Multiple TX9 Emitters
Multi-Channel Infrared Transmitter
Class 1
LED Product
Note: It is normal for this unit to feel warm while it is in operation.
Power Supply Wiring:
Use NEC, Class 2 Wiring, 18 ga. minimum,
200 ft. (70m) maximum length (18 ga.)
Baseband Signal Wiring:
Use RG58 Coax,1000 ft. (350m) max. length
Williams Sound, Minneapolis, Minnesota, USA
Patent Pending
Power In:
24VAC
~
50-60Hz
35VA
RoHS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
Made in U.S.A.
24 VACNC
Plug
Power On Baseband On
Mounting
Bracket
BASEBAND
OUTPUT
www.williamssound.com
Baseband Signal Wiring:
Use 50 Ohm Coaxial Cable (RG58)
Baseband
(Modulation)
InOut Out
50 Ohms
Multi-Channel Infrared Transmitter
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF FIRE OR
Class 1
ELECTRIC SHOCK DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
LED Product
Note: It is normal for this unit to feel warm while it is in operation.
Power Supply Wiring:
Use NEC, Class 2 Wiring, 18 ga. minimum,
200 ft. (70m) maximum length (18 ga.)
Baseband Signal Wiring:
Use RG58 Coax,1000 ft. (350m) max. length
Williams Sound, Minneapolis, Minnesota, USA
Patent Pending
24 VACNC
Power In:
24VAC
~
Plug
50-60Hz
35VA
BASEBAND
INPUT
RoHS
Mounting
Bracket
Made in U.S.A.
Power On Baseband On
BASEBAND
OUTPUT
www.williamssound.com
Baseband Signal Wiring:
Use 50 Ohm Coaxial Cable (RG58)
Baseband
(Modulation)
InOut Out
50 Ohms
BASEBAND
INPUT
WITH SINGLE EMITTER
COVERAGE AREA
WITH SECOND EMIT
ADDED TO SAME
EMISSION POINT
(50% INCREASE)
BASEBAND
OUTPUT
BASEBAND
INPUT
MOD 232 MODULATOR (REAR)
BASEBAND
OUTPUT
BASEBAND
OUTPUT
TO ADDITIONAL EMITTERS
TO SECOND TX9 EMITTERTO THIRD TX9 EMITTER TO TX9 EMITTER
TO ADDITIONAL
EMITTERS
An unlimited number of WIR TX9 emitters can be daisy-chained together to maximize the coverage area.
Remember that each emitter needs its own power supply and cannot share a power supply with a modulator or
another emitter.
10
Page 11
SoundPlus® Infrared Listening System
A251
2
:
1
COMPRESSION RATIO, MAX GAIN
2:1 COMPRESSION RATIO, MODERATE GAIN
1
:
1
C
O
M
P
R
E
S
S
I
O
N
R
A
T
I
O
,
M
A
X
O
R
M
O
D
E
R
A
T
E
G
A
I
N
Compressor Gain
The MOD 232’s Compressor Gain is set in “Moderate” mode from the factory. Use this setting for simultaneous
interpretation. Be sure that the compress pot control, located on the front of the MOD 232 (Figure 6, page 6), is
turned fully counter-clockwise. Compression can be added if desired by turning the compress pot control clockwise.
For hearing assistance applications, the MOD 232’s Compressor Gain can be set to “Maximum” mode. For additional
compression, use a tuning wand (PLT 005) or small screw driver and gently turn the compress pot (Figure 6, page 6)
on the front of the MOD 232 clockwise.
The dierence between “Moderate” and “Maximum” Compressor Gain is illustrated below:
Figure 14
To setup the MOD 232 for “Moderate” Compressor Gain: Place switch 1 in the £ “on” position.
To setup the MOD 232 for “Maximum” Compressor Gain: Place switch 1 in the ¤ “o” position.
11
Page 12
SoundPlus® Infrared Listening System
Power On Baseband On
Multi-Channel Infrared Transmitter
Made in U.S.A.
24 VACNC
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE.
Power In:
24VAC
50-60Hz
35VA
Power Supply Wiring:
Baseband Signal Wiring:
Baseband Signal Wiring:
Note: It is normal for this unit to feel warm while it is in operation.
Plug
Use NEC, Class 2 Wiring, 18 ga. minimum,
200 ft. (70m) maximum length (18 ga.)
Use 50 Ohm Coaxial Cable (RG58)
Use RG58 Coax,1000 ft. (350m) max. length
www.williamssound.com
InOut Out
50 Ohms
Baseband
(Modulation)
~
Mounting
Bracket
RoHS
Class 1
LED Product
Williams Sound, Minneapolis, Minnesota, USA
Patent Pending
A257
WALL / CEILING MOUNTING BRACKET
FOR USE WITH BKT 024 MOUNTING BRACKET
POWER ON LED
VISIBLE ON BOTTOM
BASEBAND ON LED
VISIBLE ON BOTTOM
BASEBAND OUT
BNC CONNECTOR, 50Ω
50 kHz-8 MHz BASEBAND
BASEBAND IN
BNC CONNECTOR, 50Ω
50 kHz-8 MHz BASEBAND
POWER IN
120 VAC (US); TFP 010 POWER SUPPLY
230 VAC (CE); TFP 027 POWER SUPPLY
A258
WIR TX9
EMITTER
TX9 Features and Controls
Figure 15: TX9 Emitter Rear View
Mounting the TX9
Figure 16: Mounting the TX9 to a wall, ceiling, or suspended ceiling with the BKT 024 using a Mounting Plate or a T-Bar Clip
BKT 024
CEILING MOUNT WALL MOUNT
WIR TX9
EMITTER
T-BAR CLIP
OPTIONAL MOUNTING
FOR SUSPENDED CEILING
WITH CROSS TEE
BKT 024
BKT 024
12
Page 13
SoundPlus® Infrared Listening System
Receiver Safety Information
HEARING SAFETY
CAUTION!
This product is designed to amplify sounds to a high volume level which could potentially cause hearing damage if
used improperly. To protect your hearing and the hearing of others:
1. Turn the volume down before putting on the earphone or headphone, and then adjust the volume to a
comfortable level.
2. Set the volume level at the minimum setting that you need to hear.
3. If you experience feedback (a squealing or howling sound), reduce the volume setting and move the
microphone away from the earphone or headphone.
4. Do not allow children or other unauthorized persons to have access to this product.
BATTERY SAFETY
CAUTION!
This product is supplied with disposable Alkaline batteries. Do not attempt to recharge disposable batteries, which
may explode, release dangerous chemicals, cause burns, or other serious harm to the user or product.
MEDICAL DEVICE SAFETY
CAUTION!
1. Before using this product with an implantable or other medical device, consult your physician or the
manufacturer of your implantable or other medical device.
2. If you have a pacemaker or other medical device, make sure that you are using this product in accordance with
safety guidelines established by your physician or the implantable device manufacturer.
Recycling Instructions
Battery Safety and Disposal
Help Williams Sound protect the environment! Please take time to dispose of your equipment properly.
Please do NOT dispose of batteries in the household trash. Please take the batteries to a retail or
community collection point for recycling.
Product Recycling:
Please do NOT dispose of your Williams Sound equipment in the household trash. Please take the
equipment to an electronics recycling center or return the product to the factory for proper disposal.
13
Page 14
SoundPlus® Infrared Listening System
A162
EARPHONE
JACK
BATTERY
POWER/
CHANNEL
INDICATOR
A169
RIGHTLEFT
Infrared Receivers
Figure 13: Four Channel Receiver, Model WIR RX22-4
CHANNEL
SELECTOR
OFF
Channel Frequency
1 2.3 MHz
2 2.8 MHz
3 3.3 MHz
4 3.8 MHz
"ON"
INDICATOR
ON/OFF
VOLUME SWITCH
Figure 14: WIR RX15-2 Headset Receiver
COVER
Figure 15: WIR RX18 Under-the-chin Receiver
INFRARED
SENSOR
POWER/CHANNEL
SWITCH
VOLUME
KNOB
MONITOR/MUTE
BUTTON
AUDIO INPUT JACK
MUTE
14
VOLUME
CONTROL
BATTERY
(BAT AP11A)
Page 15
SoundPlus® Infrared Listening System
Trouble Shooting
TX9 Indicator Light Is Not On.
• Make sure the transformer is plugged into the emitter and any remote power switch is on.
• Make sure the electrical outlet is on.
• Make sure the 24 VAC power supply is working.
Only TX9’s Power Indicator LED Comes On.
• Make sure the MOD 232 is on.
• Make sure the baseband cable is connected properly. See page 5, Figures 3 & 4.
• Check to see if the carrier light on the MOD 232 is on.
• Make sure an audio signal is being sent to the MOD 232.
No Sound Through Receivers.
• If some of the receivers work but others don’t, check for bad batteries or earphones on the receivers that aren’t
working.
• If none of the receivers work, check to see if the power and baseband cable are connected to the emitter and that
the TX9 Power and Baseband Present Indicator lights are ON.
• Check to see if the modulator is connected properly to the sound system. The Frequency Indicator should be lit and
there should be activity on the MOD 232 Level Indicators.
• Make sure the “eye” is not covered up on the receiver. There must be clear line of sight between the receiver eye
and the emitter panel.
Sound Through The Receivers Is Weak And Noisy.
• Make sure each channel is set to a dierent frequency on the MOD 232 modulator. Listen to the audio signal through
the Phones jack of the MOD 232 modulator. You can also hold a receiver in front of the Infrared Test LED on the front
of the MOD 232 modulator and listen to the audio signal. If the signal is weak and noisy here, check the Input Level
switch and Input Level Control settings. Increase the input signal level from the sound system by turning up the mixer
control. If the signal sounds okay, you may need to re-position the emitter panels or add additional panels.
NOTE: Make sure the powerline voltage does not fall below 94V, or system performance will be greatly reduced!
Buzzing Or Humming Noise In Sound System.
• Check for ground loops or noise on the input signal. Call your Authorized Williams Sound dealer or representative.
15
Page 16
SoundPlus® Infrared Listening System
SoundPlus® Infrared Listening System Specifications
Two-Channel Modulator, Model MOD 232
Size, Weight: 8.5” W x 8.2” D x 1.7” H (21.5 cm x 20.8 cm x 4.4 cm), 3.1lbs. (1.5 kg)
Color: Black epoxy paint with white legends
Rack Mount: 1/2 rack space wide, 1 rack space high, one or two modulators may be mounted in a single IEC rack space with RPK 005
(single) or RPK 006 (double) Rack Mount Kits
Power Supply: Wall Transformer, 24VAC, 50-60 Hz, 15VA
North America: TFP 016, UL/CSA
Europe: TFP 027-01, 2-pin Schuko plug, CE
UK: TFP 027-02, 3-pin UK plug, CE
Modulation: FM Wideband, +50kHz deviation, 50uS pre-emphasis
Carrier Frequency: Channel A: Selectable, 2.3/2.8/3.3/3.8MHz,
Channel B: Selectable, 2.3/2.8/3.3/3.8MHz
Signal to Noise Ratio: More than 60dB
Frequency Response: 30 to 16,000Hz, +1 dB, -3dB, electrical response
Total Harmonic Distortion: Less than 2%, electrical response
Audio Processing: Compression (slope) adjustable from 1:1 to 2:1
Switchable compression gain: Moderate: 16dB. Max: 33dB
Auto Carrier Shut-O: 15 minute timer shuts o carrier when no audio is present (can be disabled)
Power Switch: Two-position push button, ON/OFF
Power Indicator: Green LED
Audio Level Controls: CHA and CHB Input Level, rotary knobs
Audio Indicators: CHA and CHB Audio Level, 10-segment LED’s
Carrier LEDs: 4 green LED carrier “on” indicators per channel (indicates frequency, malfunctions)
Compress Control: 1:1 or 2.0:1
Input Mix LED: Indicates inputs A and B audio are mixed and transmitted by CHA. CHB o
Stereo LED: Indicates stereo mode
Phones Switch: Selects CH1 or CH2 for phones when not in stereo mode
Phones Output: 1/4” TRS headphone jack. Accepts stereo, mono, and any impedance phones.
Infrared Test LED: IR LED for receiver testing, monitoring, and audio signal testing.
Power Input: 3-Pin Molex, 24VAC, 50-60Hz, 15 VA
Audio Input Jack: CHA and CHB combination XLR/TRS jack
Mic Level: Balanced, Lo-Z, 100µV min. to 90 mV max., 1mV nominal, 3kΩ input impedance, supplies switchable simplex power
per DIN 45596 for condenser mics
Line Level: Balanced or unbalanced, 21mV min. to 10V max., 212mV nominal, 100kΩ
Audio Line Output Jacks: RCA Jack, CHA and CHB, 500mV, unbalanced, 100Ω source impedance, load impedance must be greater than1kΩ
Configuration Switches: CHA and CHB 8-position DIP switch, selects Mic/Line input, compressor gain, simplex power, discrete or mixed inputs, carrier
frequency, channel disable, auto shut-o timer.
Baseband Input Jack: BNC, allows mixing with additional MOD 232 Modulator (4CH operation), 100mV, 50Ω input impedance, use with MOD 232,
BNC, RG-58 Cable
Baseband Output Jack: Two BNC jacks carry baseband signal, 100mV/channel, 50Ω source impedance, for use with WIR TX9 or MOD 232 only
Approvals: CE, FCC, RoHS, WEEE
Operating requirements: 0-50º C ambient temperature, non-condensing, non-corrosive atmosphere
Warranty: 5 years on Modulator, 90 days on accessories
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
16
Page 17
SoundPlus® Infrared Listening System Specifications
Multi–Channel Infrared Emitter, Model TX9
NOTE: SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
Dimensions, Weight: 11.25” W x 6.25” H x 2.125” D (28.6 cm x 15.9 cm x 5.4 cm), 1.9 lbs (0.9 kg)
Color: Black with white legends, red acrylic lens (also available in white)
Power Supply: Wall Transformer, 24 VAC, 50-60Hz, 35 VA, 3-pin MOLEX Connector
North America: TFP 010, UL/CSA
Europe: TFP 027-01, 2-pin Schuko plug, CE
UK: TFP 027-02, 3-pin UK plug, CE
Note: Each WIR TX9 requires its own power supply
Power Cable: NEC Class 2 wiring, two-conductor, 18 ga, 200’ (61m) max. length
Indicators: Green LED power indicator, red LED baseband indicator
Carrier Frequency: 50 kHz to 8 MHz
Emitter IR Power: 3.5 watts
Coverage Area: 28,000 sq. ft. (2600 sq. m) in single channel mode when using the RX22-4 Receiver
18,000 sq. ft (1700 sq. m) in two channel mode when using the RX22-4 Receiver
11,000 sq. ft (1000 sq. m) in four channel mode when using the RX22-4 Receiver
3,500 sq. ft (325 sq. m) in single channel mode when using the RX15-2 Receiver
3,063 sq. ft (285 sq. m) in single channel mode when using the RX18 Receiver
(See coverage area diagrams)
Baseband Input: BNC, 100 mV per carrier, 50 Ω, for use with WIR TX9 or MOD 232 only
Baseband Output: BNC, 50 Ω, for use with TX9 only
Baseband Cable: RG 58 Coax, BNC connectors, maximum 1000’ (300m) length
Operating Requirements: 0-50º C ambient temperature, non-condensing, non-corrosive atmosphere
Mounting Kits: Wall or Ceiling Mount: BKT 024 Omnidirectional mount, Mic Stand Kit: SS-11 or SS-6
Warranty: 5 years on emitter, 90 days on accessories
Approvals: CE, FCC, RoHS, WEEE
Compatible Receivers: WIR RX22-4 Four-Channel Receiver, RX18 Two-Channel Receiver, RX15-2 Two-Channel Receiver
SoundPlus® Infrared Listening System
Visit our website for the latest specifications and publications: www.williamsav.com
17
Page 18
SoundPlus® Infrared Listening System
Limited Warranty
Williams Sound (a division of Williams AV) products are engineered, designed, and manufactured under carefully
controlled conditions to provide you with many years of reliable service. Williams Sound warrants the SoundPlus™
Infrared Listening System against defects in materials and workmanship for FIVE (5) years. During the first five years
from the purchase date, we will promptly repair or replace the SoundPlus® Infrared Listening System.
Microphones, earphones, headphones, batteries, cables, carry cases, and all other accessory products carry a 90day warranty. Chargers carry a one year warranty.
WILLIAMS SOUND HAS NO CONTROL OVER THE CONDITIONS UNDER WHICH THIS PRODUCT IS USED. WILLIAMS
SOUND, THEREFORE, DISCLAIMS ALL WARRANTIES NOT SET FORTH ABOVE, BOTH EXPRESS AND IMPLIED,
WITH RESPECT TO THE SOUNDPLUS™ INFRARED LISTENING SYSTEM, INCLUDING BUT NOT LIMITED TO, ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. WILLIAMS SOUND SHALL
NOT BE LIABLE TO ANY PERSON OR ENTITY FOR ANY MEDICAL EXPENSES OR ANY DIRECT, INCIDENTAL OR
CONSEQUENTIAL DAMAGES CAUSED BY ANY USE, DEFECT, FAILURE OR MALFUNCTIONING OF THE PRODUCT,
WHETHER A CLAIM FOR SUCH DAMAGES IS BASED UPON WARRANTY, CONTRACT, TORT OR OTHERWISE.
THE SOLE REMEDY FOR ANY DEFECT, FAILURE OR MALFUNCTION OF THE PRODUCT IS REPLACEMENT OF
THE PRODUCT. NO PERSON HAS ANY AUTHORITY TO BIND WILLIAMS SOUND TO ANY REPRESENTATION OR
WARRANTY WITH RESPECT TO THE SOUNDPLUS™ INFRARED LISTENING SYSTEM. UNAUTHORIZED REPAIRS OR
MODIFICATIONS WILL VOID THE WARRANTY.
The exclusions and limitations set out above are not intended to, and should not be construed so as to contravene
mandatory provisions of applicable law. If any part or term of this Disclaimer of Warranty is held to be illegal,
unenforceable, or in conflict with applicable law by a court of competent jurisdiction, the validity of the remaining
portions of this Disclaimer of Warranty shall not be aected, and all rights and obligations shall be construed and
enforced as if this Limited Warranty did not contain the particular part or term held to be invalid.
If you experience diculty with your system, call Toll-Free for customer Assistance:
1-800-843-3544 (U.S.A.) or +1 952 943 2252 (Outside the U.S.A.)
If it is necessary to return the system for service, your Customer Service Representative will give you a Return
Authorization Number (RA) and shipping instruction.
Pack the system carefully and send it to:
Williams AV LLC.
Attn: Repair Dept.
10300 Valley View Road
Eden Prairie, MN 55344 USA
Your warranty becomes eective the date you purchase your system. Your returned warranty card is our way of
knowing when you warranty begins. Please take a moment to fill it out and mail the enclosed card. You may also
register your product online at www.williamsav.com. This information will help us serve you better in the future. Thank
you!
18
Page 19
This page has been left blank.
SoundPlus® Infrared Listening System
19
Page 20
SoundPlus® Infrared Listening System
20
info@williamsav.com / www.williamsav.com
800-843-3544 / INTL: +1-952-943-2252
© 2019, Williams AV, LLC MAN 132I
Loading...
