Devon Chandelier
Assembly Instructions
Important Safety Instructions:
• These instructions are provided for your safety. It is important that they are read carefully and completely before
installing fixture.
• We strongly recommend that a professional electrician install all direct-wired fixtures.
• This fixture has been rated for up to (6) 40-watt max. Type B candelabra bulbs (not included). To avoid the risk of fire,
do not exceed the recommended wattage.
WARNING: This lighting f ixture contains lead , a chemical known to th e State of California to c ause cancer, birth d efects
and other reproductive harm. Wash hands after installing, handling, cleaning or otherwise touching this light fixture.
Pre-assembly:
• For your safety and convenience, assembly by two people is recommended.
• Remove all parts and hardware from box along with any plastic protective packaging.
• Do not discard any contents until after assembly is complete to avoid accidentally discarding small parts or hardware.
Parts Enclosed:
• (1) Crossbar
• (1) Ceiling loop
• (1) Canopy
• (1) Lock collar
• (1) Chain
• (1) T op loop
• (1) Top cap with upper hanging rings
• (6) Extension Rods
• (1) Fixture body with lower hanging rings
• (6) Lamp Shades
To Install:
1. SHUT OFF THE MAIN ELECTRICAL SUPPLY FROM THE MAIN FUSE BOX/CIRCUIT BREAKER!
2. Attach chain top loop on top cap by opening and re-closing one link with pliers. Note: us e a soft cloth bet ween the
pliers and chain to prevent damage to chain finish.
3. Feed lantern wire through alternating links in chain and through lock collar and ceiling loop.
4. Slide canopy onto chain.
5. Determine the desired hanging lengt h of lanter n. Adju st chain leng th by using p liers to ope n and re-close links. Note:
use a soft cloth between the pliers and chain to prevent damage to chain finish.
6. Fasten chain to ce il ing lo op.
7. Attach the extension rods to the top cap and fixture body as shown in the diagram.
8. Gently pull wiring from ceiling outlet box and allow the wires to hang.
9. IT IS IMPERA TIVE THAT THE OUTLET BOX IN YOUR HOME BE PROPERLY GROUNDED. If your outlet box DOES
NOT have a GROUND WIRE, be sure to inser t the green ground screw into the crossbar facing DOWN, and wrap the
fixture’s bare copper gr ound wire around the gro und s crew on the crossbar. If your outlet box has a G ROUND W IRE
(green or bare wire) attach this wire t o the bare c opper GRO UND W IRE of the fixtur e. Fasten with a plas tic wire nut
and wrap with electrical tape.
10. Carefully inspect the lant ern’s two f ixture wires. O ne has ver y fine ridges m olded into t he plas tic cov ering – this is th e
NEUTRAL WIRE. The second wire’s covering is smooth – this is the HOT WIRE.
11. Connect the NEUTRAL W IRE from the fixture to the NEUTRAL JUNCT ION BOX WIRE f rom the outlet box (usually
white). Fasten each to geth er with a plastic wire nut and wrap th e connec tion with elec trica l tape. Be sure t hat no wire
strands are exposed.
12. Connect the HOT WIRE from the fixture to the HOT JUNCTION BOX WIRE from the outlet box (usually black). Fasten
each together with a plastic wire nut and wrap the connecti on with electrical tap e. Be sure that no wire strands are
exposed.
13. DO NOT REVERSE THE HOT AND NEUTRAL CONNECTIONS OR SAFETY WILL BE COMPROMISED!
14. Tuck the wire connections neatly into the ceiling outlet box.
15. Attach the crossbar to the ceiling outlet box with the mounting screws. Tighten with screwdriver.
16. Attach the ceiling loop to the crossbar as shown.
Hardware included:
• (2) Mounting screws
• (1) Green ground screw
• (3) Wire nuts
To Install Y ou Will Need:
• Screwdriver
• Pliers
• Electrical tape
Page 2
17. Slide canopy over the chain and ceiling loop until it is flush with the ceiling.
Canopy
Ceiling loop
Lock collar
Mounting screw
Ground screw
Hanging ring
Fixture Body
Hanging ring
Chain
Top loop
Extension Rod
Top cap
Shade
Bulb
Crossbar
Wirenut
Outlet box
18. Tighten the canopy by screwing the lock collar to the base of the canopy until snug.
19. Insert bulbs (not included) into sockets.
20. Restore power to outlet box and test fixture.
21. Assembly is complete
thank you for your purchase
Williams Sonoma, Inc. | Customer Service 1.877.812.6235 | www.williams-sonoma.com
