Uni-Directional Headset Microphone
MIC 100
USER MANUAL
This lightweight Headset Microphone is a highly sensitive, electret
condenser microphone with wide frequency response for crisp, clear
sound. It’s aesthetic, hands-free design is ideal for anyone who uses a
microphone while speaking or performing, such as a vocalist, coach or
teacher.
The microphone is a great companion to many of the Williams AV wireless
transmitters. You can also use the microphone with most PC sound cards
that have a 3.5mm diameter electret microphone input jack.
Your microphone's features include:
• Hands-Free Headset - keeps your hands free for other tasks while you
speak or perform.
• Gooseneck Microphone Stem - lets you easily adjust the microphone's
position as you wear the headset.
Specifications:
• Polar Pattern: Uni-directional
• Frequency Response: 70 Hz to 15,000 Hz
• Impedance: 600Ω ± 30% (at 1 KHz)
• Sensitivity: -70dB ± 3dB (0dB=1V/microbar)
• Operating Voltage: 1V~10V DC (RL:680Ω)
• Cable: Ø 2.6mm dia x 1.2 m long
• Connector: Ø 3.5mm mono right-angle plug
• Foam windscreen
Frequency Response Curve
25
20
10
0
-10
Relative Response In db
-20
-25
20 50 200100
500
Frequency In Hertz
5K
2K1K 20K10K 30K
Recycling Instructions
Help Williams AV product the environment! Please take the time to
dispose of your equipment properly.
Product Recycling:
Please do NOT dispose of your Williams AV equipment in the household
trash. Please take the equipment to a electronics recycling center OR
return the product to the factory for proper disposal.
WilliamsAV.com
MIC 100A
U.S. | 800.843.3544 [email protected] INTL | +1.952.943.2252 [email protected]
© 2022, Williams AV, LLC
