Model ANT 034
Remote rubber duckie antenna for RPK-005 mounting
Manual and User Guide
MAN 174A
Model ANT 034 Remote Rubber Duckie Antenna
Overview
The ANT 034 is a 75 Ohm rack mountable remote antenna designed for 72-76 MHz
operation. It is intended for use with Williams Sound FM transmitters (i.e. PPA T35,
PPA T27).
Contents
1 - ANT 021 Rubber Duckie Antenna with Swivel F-Connector
1 - CNR 004 RF Connector with nut
1 - WCA 086 Coax Cable, 3’, F-Connector
2 - Nylon Washers
1 - Manual
Recycling Instructions
Help Williams Sound protect the environment! Please take the time to dispose of
your equipment properly.
Product Recycling
Please do NOT dispose of your Williams Sound equipment in the household
trash. Please take the equipment to an electronics recycling center; OR return
the product to the factory for proper disposal.
Figure 1: ANT 034 Assembly
ANT 021 RUBBER
DUCKIE ANTENNA
ANT 035 RIGHT ANGLE
F CONNECTOR
CNR 004
(RF CONNECTOR)
RPK 005
RACK-MOUNT BRACKET
(NOT INCLUDED)
FSW 500
WASHER
FSW 500
WASHER
NUT (FNW001)
WCA 086
3 FT.COAX CABLE
WITH F CONNECTORS
MAN 174A
A308
Model ANT 034 Remote Rubber Duckie Antenna
ANT 034 Assembly & Installation Procedure
1. The ANT 034 can be mounted to an audio rack with the RPK 005 (a 1/2-width,
single-space rack bracket, ordered separately). This solution is most commonly
used when the transmitter will also be mounted in the rack.
2. Thread the ANT 021 rubber duckie on to the ANT 035 (see gure 1). Turn the
F-connector on the ANT 021 clockwise by hand until connection is tight.
3. Install the washers with the smaller side facing the RPK 005 rack bracket as
shown. Correct orientation of the washers is crucial to maintaining antenna
isolation. Tighten the nut with moderate pressure using the proper size wrench.
4. Thread one end of the WCA 086 3’ coax cable on to the back of the assembled
bracket-antenna unit. Use ngers only to tighten.
5. Attach other end of WCA 086 3’ coax cable to the F-Connector “Antenna” jack on
the Williams Sound 72-76 MHz transmitter (i.e. PPA T35, T27). Use ngers only to
tighten.
NOTE: Do not bend coax cable sharply at any point. The ANT 034 rubber duckie
antenna should be vertical for best performance, and to comply with
FCC rules.
Warranty
The ANT 034 rack mountable remote antenna is covered by a 90 day warranty. If you
experience difculty with your antenna, call toll-free for customer assistance:
1-800-843-3544 (U.S.A.) or 1-952-943-2252 (Outside the U.S.A.)
If it is necessary to return the system for service, your customer service representative
will give you a Return Authorization Number (RA) and shipping instructions.
MAN 174A
Model ANT 034 Remote Rubber Duckie Antenna
10300 Valley View Rd • Eden Prairie, MN 55344
800-328-6190 / 952-943-2252 • FAX: 952-943-2174
www.williamssound.com
©2012 Williams Sound • All Rights Reserved
