Wile 200 Operator's Manual

Moisture meter

EN Operators manual

Thank you for choosing Wile grain moisture meter. Wile 200 ensures quick and
easy measurement of moisture, temperature and hectoliter weight of the sample.
Automatic temperature and hectoliter weight compensation guarantees accurate
results. The meter is equipped with a patented integrated grain leveling system.
Excess grain goes into the compartment around test cell keeping working area
neat during whole measuring process.

Read this manual carefully to learn how to operate this unit correctly.

1 METER
2 CARRYING CASE
3 USB CABLE
4 BATTERIES
5 MANUAL

Box Contents

2

1

4

5

3

Kosteusmittari
Fukthaltsmätare

FI
Käyttöohje
SE
Bruksanvisning

2

Use

Important: The scales of Wile moisture meters are developed to measure
average quality grain. Exceptional growth conditions and new varieties of grain
can considerably affect grain properties. Therefore, in the beginning of new
harvest season we recommend to check the readings of your meter against an
oven dried sample.

FUNCTIONS

SYMBOL Denition

Replace batteries

<4.0 Moisture is below the lower limit for this grain

>28.0 Moisture is above the upper limit for this grain

Error code

MEASURING PROCESS

Wile 200 guides user step by step directly on the screen during the whole
measuring process.

1. Place hopper on tester. Press and release ON/OFF button to turn on tester.
After power up the display shows the results of the last grain tested.

2. Select grain using the UP/DOWN buttons. Once the desired grain is se­lected then press the ENTER button. Place tester on a stable and mostly level
surface. Press ENTER to initiate test.

!
