LIGHT
SPY BOT 70082
CLAWS
MESSAGE PLAYBACK
BUTTON
FIG 1
Important: Please save t h is instruction sheet.
It contains valuable product information.
BATTERY SAFETY INFORMATION
• Only adults should install and replace batteries.
• We recommend you use al ka line batteries.
• Do not recharge non-rechargeable batte ries .
• Remove dead or exhausted batteries.
• Insert batteries correctly. Match + an d - sig ns.
• Only use the batteries specified.
• Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.
• Do not mix old and new batteries.
• Do not dispose of batteries in a fire; th ey may explode.
• Dispose of ba tt e r ie s safely.
• Only the same or equivalent type batterie s are recommended to be used.
• The supply terminals are not to be short- circuited.
ADULTS: TO REPLACE BATTERIES
Requires five (5) AA (LR6) batteries (not included) for the vehicle and one (1) 9V (6F22) for
the transmitter.
Rechargeable AA batteries may be used in the vehicle but vehicle’ s performance will be
reduced slightly. Expect only 20 minutes of use from this type of battery.
NOTE: Screw will not detach from either battery compartment door when loosened.
1. Use a small Phillips head screwdriver to loosen the screw(s) in the battery compartment
door on the bottom of the vehicle a nd/or transmitter. (FIG 2 – FIG 3)
2. Remove all exhausted batteries and dispose of properly.
3. Insert 5 new batteries as shown by ba ttery markings into the vehicle an d 1 in to the
transmitter.
4. Replace the battery door(s) and tighten screws.
FIG 2 FIG 3
TO DRIVE SPY BOT
1. Move transmitter’s ON/OFF switch to OFF position (FIG 4).
2. Move Spy Bot’s ON/OFF switch to ON position (FIG 6).
3. Move transmitter’s ON/OFF switch to ON position (FIG 4).
ACCELERATOR TOGGLE
ON/OFF SWITCH
STEERING TOGGLE
FIG 4
SPY BOT ON/OFF SWITCH
FIG 5
4. Push forward on the accelerator toggle to move Spy Bot forward (FIG 4).
5. Pull back on the accelerator toggle to move Spy Bot backwards.
6. To turn right, move steering toggle to the right.
7. To turn left, move steering toggle to the left.
8. To go straight, do not touch steering toggle.
TO OPERATE SPY BOT’S CLAW
1. Maneuver Spy Bot so object you want to pick up is between claws (FIG 1).
2. Press front of button to close claws on object. Continue holding button in until claws pick
object up. Spy Bot can’t move while claws are in operation.
3. Drive Spy Bot to were you want to take object. Claws will not operate while Spy Bot is
moving.
4. Press back of button to set objec t do wn and open claws. Back Spy Bot up and drive awa y.
CLAW
OPEN
CLOSE
RECORD
LIGHT
FIG 6
TO OPERATE SPY BOT’S LIGHT
1. Press once on back of button to turn light ON (FIG 6).
2. Press again to turn light OFF.
3. Light may be turned ON and OFF while Spy Bot is moving.
TO RECORD A MESSAGE
1. Maneuver Spy Bot into position and stop.
2. Press RECORD button to start recording (FIG 6). Recording time is 6 seconds. Spy Bot
will not operate while recording.
3. You may record over the previous message by pressing the RECORD button aga in.
4. When recording is finished, bring S p y Bot ba ck to home base and press MESSAGE
PLAYBACK BUTTON to hear what Spy Bot heard.
WHEEL ALIGNMENT
1. When Spy Bot will not go in a straight line, adjust wheel alignment with the control
lever (FIG 7).
2. Move lever to the left if Spy Bot is turning right
3. Move lever to the right if Spy Bot is turning left.
FIG 7
Turn off Spy Bot and it transmitter afte r use to conserve batteries.
Don’t drive Spy Bot through puddles or mud, on a wet floor, or in sand, rain or snow. These
conditions can cause damage.
Don’t expose Spy Bot or it’s transmitter to temperature extreme s .
Don’t store Spy Bot or it’s transmitter in direct sunlight or near a heat source.
Dead batteries can leak chemicals that cause damage. Never leave dead or weak batteries in
Spy Bot or it’s transmitter for long period of time.
FCC ID: N3ESPYROBOT70082T & N3ESPYROBOT70082R
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO
CONDITIONS: 1. THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND 2. THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
