Wiha pliers.

Quality and ergonomics for professionals.

230

EN_s230-281_Zangen_2012 15.02.12 17:40 Seite 231

Pliers assortment

www.wiha.com

Wiha pliers.

Quality and ergonomics for professionals.

Wiha pliers matrix.

Discover real pliers quality.

Wiha SB pliers assortment.

Full assortment in convincing quality.

...............................................................................................

Wiha Inomic®.

Pliers – reinvented.

.............................................................................................................................................

Wiha Inomic®VDE.

Completely relaxed.

............................................................................................................................................

Wiha Professional.

Quality down to the last detail.

– Revolving punch pliers. – Pliers sets.

....................................................................................................................................................

................................................................................................................

....................................................................................................................

Wiha Professional electric.

Completely reliable.

– Cable shears. – Crimp tools. – Crimping and stripping tool. – Pliers sets.

............................................................................................................................................

.............................................................................................................................................

.................................................................................................................................................

.......................................................................................................

....................................................................................................................................................

...................................................................................

232 – 233

234 – 235

236 – 237

238 – 239

240 – 241

242 – 244 245 246

247 – 250 251 252 – 253 253 – 254 250

Wiha Industrial.

Comfortable in your hand, versatile in application.

..............................................................

Wiha Classic.

The complete workshop range.

– Circlip pliers.

..............................................................................................................................................

– Pipe wrenches swedish style. – Grip pliers. – Pliers sets.

....................................................................................................................................................

................................................................................................................

....................................................................................................

Wiha Electronic.

Precision for made-to-measure work.

................................................................................................

Wiha Professional ESD.

Precise in every detail.

.....................................................................................................................................

Wiha Professional ESD.

For high standards when it comes to precision and safety.

..........................................

255 – 258

259 – 269 264 – 265 266 267 268 – 269

270 – 273

274 – 277

278 – 281

231

EN_s230-281_Zangen_2012 15.02.12 17:40 Seite 232

Wiha pliers.

Quality and ergonomics for professionals.

Quality in all aspects from stripping to gripping

Maximum quality for all products – in this way Wiha meets the high demands of the user. This also holds true for the pliers assortment.

First class material, tried-and-true processes

Selected, premium grade steel, pleasant plastic application on the handle and a manufacturing process for all aspects according to state-of-the-art quality management directives – this forms the basis for the tried-and-trusted Wiha quality. A special heat treatment and inductive hardening of highly stressed parts ensure a long service life.

Even more precise? Yes!

"Functionality": this somewhat sober yet important phrase represents a host of clever ideas. As such Wiha pays attention to a precise interplay of joints and an exact processing of cutting edges and gripping surfaces.

Ergonomics: "grippy" in the best sense of the word!

Wiha pliers are consistently designed according to the requirements of users. Proof of this is the innovative and angled form of the Wiha Inomic pliers series. And the multi-component pliers handles have also been designed according to the latest findings from the field of ergonomics. With extra wide handle backs and a well thought-out distribution of soft and hard zones they are both comfortable and easy on the hands.

Not only new, but innovative as well

Current examples in the further development of the Wiha pliers series clearly demonstrate what the power of innovation can achieve for users: – Wiha has perfected the interplay

of technology and natural movement with the Inomic generation.

– More "bite", meaning greater

cutting performance with less expenditure of effort: that's what Wiha DynamicJoint represents. The optimised joint construction reduces the force needed for cutting by up to 40 % !

pliers

– MagicTips,the precision tips

made from high performance steel create an added plus in terms of stability and safety with the Basic series circlip pliers. The special latching function that prevents a jumping away of the safety rings is as unique as it is useful!

Because that is and has always been the aim of Wiha innovations making work with pliers safer, more energysaving and with greater comfort. For absolutely professional results.

232

EN_s230-281_Zangen_2012 15.02.12 17:40 Seite 233

Force of power with cutting

hard wire ø 1.6 mm [2,000 N/mm²] after 1,200 cuts

TÜV-Süd test, October 2009

Comparison of Wiha to next best competitor:

9.6 kg less force of power

with 180 mm combination pliers

82% 94% 99% 97%

2.8 kg less force of power

with 180 mm heavy-duty diagonal cutters

53% 77% 69% 72%

www.wiha.com

100% corresponds to 80 kg hand strength 10% corresponds to 8 kg hand strength

Competitors

Wiha quality management

The Wiha quality assurance system in accordance with ISO 9001:2008 ensures with pliers as well that only first-class products leave our factory. Continuously monitored production processes and documented organisational procedures form the basis for the excellent quality for which Wiha products are renowned.

For its outstanding design quality, the new Wiha pliers generation has received the "iF - prduct design award". In 2011, there was a focus on the brand image. A strong and striking product appearance is the result of consistent brand management.

Distinction of the new Wiha pliers generation:

Convincing design quality, design and product appearance.

For ergonomic and qualitative design, the Wiha Inomic not only the "iF – product design award" but the "red dot design award" as well. In addition to the red dot award, organised as part of the world's largest show for contemporary design, the iF product design award is one of the oldest and most renowned design accolades.

Inomic The levels of innovation, functionality, ergonomics and service life speak for themselves.

distinctions:

pliers were awarded

Wiha Professional pliers have won the

"Focus in Silver" award for outstanding design. The Stuttgart Design Center awarded the 2006 international design prize in a special energy category. Energy also determines the reference level – the key to success.

"Focus in Silver" award: Convincing ergonomics, surface feel and clean design lines.

233

EN_s230-281_Zangen_2012 15.02.12 17:40 Seite 234

Wiha pliers matrix.

Discover real pliers quality.

Combination pliers

High leverage combination pliers

Needle nose pliers

Needle nose pliers, angled

Long-flat nose pliers Long-round nose pliers Precision mechanic’s needle nose pliers Diagonal cutters

Heavy duty diagonal cutters

Electrician's diagonal cutters Precision mechanic’s diagonal cutters Cable cutters

Wiha Inomic

180 239 180 241 160 243 160 248 160 256 160 260

160 239 160 241 160 244 160 248 160 256 160 261

160

Wiha

Inomic

239 160 241 140 244 140 249 140 257 140 261

Wiha

VDE

Professional

180 243 180 248 180 256 180 260 200 243 200 248 200 256 200 260 200 243 200 248 200 256 200 260 225 243 225 248 225 256 225 260

200 244 200 248 200 256 200 261 160 244 160 248 160 256 160 261 200 244 200 248 200 256 200 261 160 243 160 248 160 256 160 260 160 243 160 249 160 256 160 260

160 244 160 249 160 257 160 261 180 244 180 249 180 257 180 261 160 244 160 249 160 257 160 261 180 244 180 249 180 257 180 261 200 244 200 249 200 257 200 261

Wiha Professional electric

160 249

160 249 160 262 200 249 200 262

Wiha Industrial

Wiha Classic

160 261

125 261

tripping pliers

S Crimping pliers for end sleeves

Revolving punch and loop pliers Revolving punch pliers Water pump pliers

Water pump pliers with push button setting

QuickFix water pump pliers End cutting nippers

Pincers (carpenter's pincers)

Concretors pincers with handle coating

Concretors pincers

Pipe wrenches swedish style, S-jaw

Pipe wrenches swedish style, 45°

Pipe wrenches swedish style, 90°

1 1 ½ 2 1 1 ½ 2 1 1 ½ 2

160 243 160 250 160 257 160 262

225 245 225 245

180 258 180 262

250 245 250 258 250 262

300 258 300 262 180 258 180 262

250 245 250 258 250 262

300

250 245 250 262

160 257 160 263 180 257 180 263 200 257 200 263

" " "

" "

145 262 180 262

258 300 262

180 263 200 263 220 263 250 263 280 263 300 263 220 263 250 263 280 263 300 263 320 266 420 266 535 266 315 266 420 266 570 266 320 266 415 266 555 266

Grip pliers with wire cutter Welding grip pliers Cable shears Crimp tools

Automatic stripping pliers Crimping and stripping tool

234

267

•

267

251

•

252

•

253

•

253

•

254

•

EN_s230-281_Zangen_2012 15.02.12 17:40 Seite 235

www.wiha.com

for boreholes for shafts for boreholes for shafts

Circlip pliers for bores

– Straight shape

Circlip pliers for shafts

– Shape D: 90° angled shape

Diagonal cutter

– Narrow, pointed head

Diagonal cutter

– Wide, pointed head

J 0 8 - 13 265 A 0 3 - 8 265 J 0 8 - 13 264 A 0 3 - 10 264 J 1 12 - 25 265 A 1 10 - 25 265 J 1 12 - 25 264 A 1 10 - 25 264 J 2 • 19 - 60 265 A 2 • 19 - 60 265 J 2 19 - 60 264 A 2 19 - 60 264 J 3 • 40 -100 265 A 3 • 40 -100 265 J 3 40 -100 264 A 3 40 -100 264 J 4 • 85 -140 265 A 4 • 85 -140 265 J 4 85 -140 264 A 4 85 -140 264 J 01 8 - 13 265 A 01 3 - 8 265 J 01 8 - 13 264 A 01 3 - 10 264 J 11 12 - 25 265 A 11 10 - 25 265 J 11 12 - 25 264 A 11 10 - 25 264 J 21• 19 - 60 265 A 21 • 19 - 60 265 J 21 19 - 60 264 A 21 19 - 60 264 J 31• 40 -100 265 A 31 • 40 -100 265 J 31 40 -100 264 A 31 40 -100 264 J 41• 85 -140 265 A 41 • 85 -140 265 J 41 85 -140 264 A 41 85 -140 264

• with safety latching function

Wiha Professional ESD

•

••

•

with wire trapping spring

115 275 115 275 115 275

Wiha Electronic

with wire trapping spring

•

••

•

••

•

118 272 128 272

138 271 138 271 138 271

Diagonal cutter

– Narrow, semi-circular head

Diagonal cutter

– Wide, semi-circular head

Oblique cutting nippers

– Wide, pointed head

Oblique end cutting nippers

– Narrow head – Extra narrow head, cutting edges angled at 40° – Wide head, angled at 29°

End cutting nippers

– Extra narrow, slim shape – Wide head

Needle nose pliers

– Straight head

Needle nose pliers

– Angled

Round nose pliers

Flat nose pliers

Pointed pliers

Stripping pliers

– 20 18 16 14 12 10 AWG, – 26 24 22 20 18 16 AWG,

0.81 - 2.59 mm

0.4 - 1.3 mm

•

115 276

115 276 115 276

110 276 110 276

110 276 115 277

120 277

145 277

120 277

•

138 272

118 272

135 273

180 273 180 273

235

EN_s230-281_Zangen_2012 15.02.12 17:40 Seite 236

Wiha SB pliers assortment.

Full assortment in convincing quality.

Combination pliers

High leverage combination pliers

Needle nose pliers

Needle nose pliers, angled

Long-flat nose pliers

Long-round nose pliers

Diagonal cutters

Heavy duty diagonal cutters

Wiha Professional

Order-No. Ty p Order-No. Ty p Order-No. Ty p Order-No. Ty p

27327 160 243 27399 180 243 27400 200 243

27401 200 243 27402 225 243

27403 160 244 27404 200 244

27405 160 244 27406 200 244

27407 160 243

27408 160 243

27409 140 244 27507 160 244 27410 180 244

7411160 244

2 27412 180 244 27413 200 244

Wiha Professional electric

27328 160 248 27418 180 248 27419 200 248

27420 200 248 27421 225 248

27422 160 248 27423 200 248

27424 160 248 27425 200 248

27426 160 248

27427 160 249

27428 140 249 27429 160 249 27430 180 249

7432160 249

2 27434 180 249 27435 200 249

Wiha Industrial

34565 160 256 34307 180 256 34308 200 256

34566 200 256 34567 225 256

34309 160 256 34515 200 256

34569 160 256 34570 200 256

34310 160 256

34568 160 256

34311 140 257 34516 160 257 34571 180 257

4572160 257

3 34517 180 257 34573 200 257

Wiha Classic

27325 160 260 27336 180 260 27337 200 260

27338 200 260 27339 225 260

27340 160 261 27341 200 261

27342 160 261 27343 200 261

27344 160 260

27345 160 260

27346 140 261 27347 160 261 27348 180 261

7349160 261

2 27370 180 261 27371 200 261

Electrician's diagonal cutters

Cable cutters

Stripping pliers

Water pump pliers

Water pump pliers with push button setting

QuickFix water pump pliers

End cutting nippers

Pincers (carpenter's pincers)

Concretors pincers with handle coating

Concretors pincers

27417 160 243

27414 250 245

27415 250 245

27416 250 245

27431 160 249

35704 160 249 35705 200 249

27437 160 250

34313 160 257

36985 180 258 34312 250 258 36986 300 258

36987 180 258 34518 250 258 36988 300 258

36982 160 257 36983 180 257 36984 200 257

36217 160 262 36981 200 262

27368 160 262

27350 180 262 27381 250 262 27382 300 262

27351 180 262 27383 250 262 27384 300 262

27385 250 262

27372 160 263 27373 180 263 27374 200 263

27375 180 263 27376 200 263

27377 220 263 27378 250 263 27379 280 263 27380 300 263

27501 220 263 27502 250 263 27503 280 263 27504 300 263

236

EN_s230-281_Zangen_2012 15.02.12 17:41 Seite 237

for boreholes for shafts for boreholes for shafts

www.wiha.com

Order-No. Ty pOrder-No. Ty pOrder-No. Ty pOrder-No. Ty p

Circlip pliers for bores

– Straight shape

Circlip pliers for shafts

– Shape D: 90° angled shape

Diagonal cutter

– Narrow, pointed head

Diagonal cutter

– Wide, pointed head

6975 J 0 8 - 13 265

3 36225 J 1 12 - 25 265 36222 J 2 • 19 - 60 265 36272 J 3 • 40 -100 265

36976 J 01 8 - 13 265 36223 J 11 12 - 25 265 36224 J 21• 19 - 60 265 36225 J 31• 40 -100 265

• with safety latching function

36977 A 0 3 - 8 265 36978 A 1 10 - 25 265 36220 A 2 • 19 - 60 265 36219 A 3 • 40 -100 265

36979 A 01 3 - 8 265 36980 A 11 10 - 25 265

6218 A 21• 19 - 60 265

3 36221 A 31• 40 -100 265

Wiha Professional ESD

Order-No. Typ Order-No. Ty p

27443 27442

27445

•

27446 27444

with wire trapping spring

•

••

•

27352 J 0 8 - 13 264 27353 J 1 12 - 25 264 27354 J 2 19 - 60 264 27355 J 3 40 -100 264

27356 J 01 8 - 13 264 27357 J 11 12 - 25 264 27358 J 21 19 - 60 264 27359 J 31 40 -100 264

Wiha Electronic

27388

115 275 115 275

115 275 115 275 115 275

27390

27391 27395 27393

27360 A 0 3 - 10 264 27361 A 1 10 - 25 264 27362 A 2 19 - 60 264 27363 A 3 40 -100 264

27364 A 01 3 - 10 264 27365 A 11 10 - 25 264 27366 A 21 19 - 60 264 27367 A 31 40 -100 264

with wire trapping spring

•

••

•

••

•

118 272 128 272

138 271 138 271 138 271

Diagonal cutter

– Narrow, semi-circular head

Diagonal cutter

– Wide, semi-circular head

Oblique cutting nippers

– Wide, pointed head

Oblique end cutting nippers

– Narrow head – Extra narrow head, cutting edges angled at 40° – Wide head, angled at 29°

End cutting nippers

– Extra narrow, slim shape – Wide head

Needle nose pliers

– Straight head

Needle nose pliers

– Angled

Round nose pliers

Flat nose pliers

Pointed pliers

27447

27448 27449

27451 27450

27452 27453

27329 120 277

27439 120 277

27440 120 277

27441 120 277

•

115 276

115 276 115 276

110 276 110 276

110 276 115 277

27398

27397

27326

•

138 272

118 272

135 273

237

EN_s230-281_Zangen_2012 15.02.12 17:41 Seite 238

Wiha Inomic®.

Pliers – reinvented.

Head of pliers made of high quality tool steel, cutting edges additionally induction hardened

Metal parts with all-round, corrosion resistant surface

The areas in the arm of the pliers that move and press against each other feature hard plastic: low abrasion

Locking mechanism: Pliers should be transported and stored in closed position

Handle with ergonomic soft-grip zone made of thermoplastic elastomer (TPE) in the pressure area around the ball of the thumb

Innovative technology and as ergonomic as nature: descriptions that ﬁt Wiha Inomic

pliers perfectly.

Firstly as an extension of the hand: ﬁrm and secure when gripping, and with a natural movement that is easy on the joints. And then progressive know-how: with high quality materials that feel soft but are relentless with components being worked upon.

Pliers have been around for ages. But never with so many ideas and intelligent details as the Wiha

Inomic

pliers.

The relaxed hold when using Inomic ensures fatigue-free work.

In collaboration with the IAO Stuttgart (Institute for Industrial Engineering), a wide variety of shapes and variants for this new generation of pliers was investigated during the course of extensive studies and user tests. Gripping system, hand closure forces, jaw shapes and geometries are just a few of the points examined.

Impact-resistant tool body made of ﬁbre-glass reinforced plastic: Low weight

Gentle

•

Wiha Inomic

The angled form is easy on muscles, tendons and joints

Powerful

•

All ﬁngers grip at the same time.

Robust and durable

•

Strong pliers jaws, complete zinc-nickel coating, impact resistant construction

Sensitive

•

Greater control with grasping via opening spring with ﬁne resistance

Ergonomic

•

Like the extension of a hand: grasping is simple, ﬁrm and safe

Attractive

•

An appealing design

238

EN_s230-281_Zangen_2012 15.02.12 17:41 Seite 239

Safety note:

When working with cutting pliers – beware of wire ends ﬂying away. Please wear safety glasses.

www.wiha.com

Combination pliers.

Z 01 0 15

Head shape: Extra long cutting edge for ﬂat and round cables. Design: Serrated gripping jaws.

Material: Pliers head of high-quality tool steel.

Application: For gripping, holding and cutting.

Order-No. 33260 180 3.3 2.2 155 5

Combination pliers Inomic®.

Cutting edges additionally induction hardened to approx. 64 HRC. Arms of the pliers move in parallel: +25% force transfer. Angled shape (23°) for fatigue-free work. With opening spring and locking mechanism.

Handles made of tough ﬁbre-glass reinforced plastic,

rgonomic soft grip zone in the handle.

With improved access to the objects to be processed.

Needle nose pliers and diagonal cutters.

Z 05 0 15

Head shape: Straight form with extra-long cutting edge. Design: Ridged gripping surfaces.

Material: Pliers head of high-quality tool steel.

Application: For gripping, holding and cutting.

Order-No. 33256 160 2.5 1.6 150 5

Needle nose pliers Inomic®.

Handles made of tough ﬁbre-glass reinforced plastic,

rgonomic soft grip zone in the handle.

With improved access to the objects to be processed.

Radial abduction

Ulnar abduction

The Inomic®pliers are angled at 23° to support the physiological movement of the wrist when working and thus prevent an unhealthy wrist position, which often leads to problems such as carpal tunnel syndrome.

Details of cutting results of cutting pliers.

Symbol Types of wire Example Tensile strength ca. N/mm Soft wire Copper, aluminium 220 - 250 Medium hard wire Iron nail 750 - 800 Hard wire Spring wire, steel nails 1.600 - 1.800 Piano wire Hardened spring steel 2.200 - 2.300

Test wires standardised in DIN ISO 5744

Z 12 0 15

Diagonal cutters Inomic®.

Head shape: Semi-circular, swedish style. Design: Arms of the pliers move in parallel: +25% force transfer.

Angled shape (23°) for fatigue-free work. With opening spring and locking mechanism.

Material: Pliers head of high-quality tool steel.

Handles made of tough ﬁbre-glass reinforced plastic, ergonomic soft grip zone in the handle.

Application: For soft and hard wires.

With improved access to the objects to be processed.

Order-No. 33254 160 2.8 2.0 140 5

239

EN_s230-281_Zangen_2012 15.02.12 17:41 Seite 240

Wiha Inomic®VDE.

Completely relaxed.

Head of pliers made of high quality tool steel, cutting edges additionally induction hardened

Metal parts with all-round, corrosion resistant surface

The areas in the arm of the pliers that move and press against

ach other feature hard plastic:

e low abrasion

Locking mechanism: Pliers should be transported and stored in closed position

Handle with ergonomic soft-grip zone made of thermoplastic elastomer (TPE) in the pressure area around the ball of the thumb

How can maximum safety and eﬀective working be combined with live parts? It's possible, with the Wiha

Inomic

VDE.

A principle of nature has inspired Wiha for the design of this pliers range: the angled form of the pliers means the user can work without tiring limbs, sinews and muscles, and he can apply a powerful grip when cutting. That means: tiredness and aching limbs are not an issue even after hours of work.

240

And just to be on the safe side: Wiha Inomic

VDE pliers are regularly subjected to a wide range of stringent quality inspections, thus repeatedly conﬁrming their high normative quality.

Safety and functionality at the highest level - and with unashamedly good looks!

The relaxed position of the hand when using Inomic fatigue-free work. Guaranteed with highest electrical safety level.

Approved for work in the area of live parts up to 1,000 V AC or 1,500 V DC.

When working with VDE tools, observe the national safety and accident prevention regulations!

VDE ensures

Impact-resistant tool body made of ﬁbre-glass reinforced plastic: Low weight

Wiha Inomic

Uncompromisingly safe

•

VDE.

Manufactured and inspected according to IEC 60900:2004, one-oﬀ testing at 10,000 V, GS mark for inspected safety, VDE tested

Gentle

•

The angled form is easy on muscles, tendons and joints

Powerful

•

All ﬁngers grip at the same time.

Robust and durable

•

Strong pliers jaws, complete zinc-nickel coating, impact resistant construction

Sensitive

•

Greater control with grasping via opening spring with ﬁne resistance

Ergonomic

•

Like the extension of a hand: grasping is simple, ﬁrm and safe

Attractive

•

An appealing design

EN_s230-281_Zangen_2012 15.02.12 17:41 Seite 241

Safety note:

When working with cutting pliers – beware of wire ends ﬂying away. Please wear safety glasses.

www.wiha.com

Combination pliers.

Z 01 9 16

Standards: Manufactured acc. to IEC 60900:2004. Head shape: With cutting edge for ﬂat and round cable. Design: Serrated gripping jaws.

aterial: Pliers head of high-quality tool steel.

Application: For gripping, holding and cutting.

Combination pliers Inomic®VDE. Insulation up to 1000 V AC, GS-mark.

Cutting edges additionally induction hardened to approx. 62 HRC. Arms of the pliers move in parallel: +25% force transfer. Angled shape (23°) for fatigue-free work. With opening spring and locking mechanism.

Handles made of tough ﬁbre-glass reinforced plastic, ergonomic soft grip zone in the handle.

With improved access to the objects to be processed.

Needle nose pliers and diagonal cutters.

Z 06 9 16

Standards: Manufactured acc. to IEC 60900:2004. Head shape: Straight shape with blade and three stripping points 2.5 mm²,

Design:

Material: Pliers head of high-quality tool steel.

Application: For gripping, holding, cutting and stripping.

Needle nose pliers Inomic®VDE. Insulation up to 1000 V AC, GS-mark.

1.5 mm², 0.75 mm².

Ridged gripping surfaces. Cutting edges additionally induction hardened to approx. 62 HRC. Arms of the pliers move in parallel: +25% force transfer. Angled shape (23°) for fatigue-free work.

ith opening spring and locking mechanism.

Handles made of tough ﬁbre-glass reinforced plastic, ergonomic soft grip zone in the handle.

With improved access to the objects to be processed.

Order-No. 30658 180 3.5 2.5 1.6 160 5

Radial abduction

Ulnar abduction

Details of cutting results of cutting pliers.

Test wires standardised in DIN ISO 5744

Order-No. 30661 160 2.5 1.6 155 5

Z 12 9 16

Diagonal cutters Inomic®VDE. Insulation up to 1000 V AC, GS-mark.

Standards: Manufactured acc. to IEC 60900:2004. Head shape: Innovative head with dual cutting function.

Cutting edge with bevel near the joint, cutting edge without bevel in the front cutting area.

Design: Cutting edges additionally induction hardened to approx. 62 HRC.

Arms of the pliers move in parallel: +25% force transfer. Angled shape (23°) for fatigue-free work. With opening spring and locking mechanism.

Material: Head of pliers made of ball-bearing steel, hardened to approx. 60 HRC.

Handles made of tough ﬁbre-glass reinforced plastic, ergonomic soft grip zone in the handle.

Application: For cutting hard wires in the joint area.

Flush, burr-free cutting of soft wires, cables and plastics in the front cutting area. With improved access to the objects to be processed.

Order-No. 30666 160 3.5 2.5 1.6 145 5

241

EN_s230-281_Zangen_2012 15.02.12 17:41 Seite 242

Wiha Professional.

Quality down to the last detail.

For its outstanding design quality,

the new Wiha pliers generation has received the "iF - prduct design award". In 2011, there was a focus on the brand image.

Valuable chrome plating for long lasting corrosion protection

Wiha received the "Focus in Silber" award for outstanding design.

Hard, comfortable elastomer zones ensure low friction in the movement range of the ﬁngers

The stops on the ends of the arms prevent the hands from slipping

The robust, ergonomic handle is carefully ﬁxed to the pliers

Functionality, quality and comfort: only three of the many features that professionals fundamentally demand of their tools. Wiha Professional implements these in a consistent manner.

With a new dimension in terms of functionality: DynamicJoint, the progressive development of the joint construction, ensures precise cuts with simultaneously up to 40% less force of power. Cutting performance is still as high even after thousands of applications!

And in addition Wiha Professional pliers are characterised by manufacture from selected, multi-hardened steel with quality chrome plating. The elastic, shock absorbing plastic handles guarantee comfortable, fatigue-free work.

Wiha Professional carries on where average tools give up the ghost. For thoroughly professional results every time.

Less force of power:

- 9,6 kg

- 12,6 kg

TÜV Süd test, October 2009

Competitors

Harmonious design of the front part of the handle for an optimum ﬁnger hold when applying force

Up to 40% less force for cutting. The low expenditure of energy thanks to DynamicJoint is especially advantageous when cutting a large number of hard objects.

Extra broad arms made of soft, non-slip elastomer are gentle on the parts of the hand that are sensitive to pressure

Wiha Professional.

Powerful

•

With DynamicJoint, the high quality joint construction for simple, long-term cutting eﬃciency

As hard as steel

•

Pliers head drop forged from high quality steels

Robust and durable

•

Cutting edges are individually tempered and additionally induction hardened to approx. 64 HRC; joints are extremely wear resistant and withstand high stresses, with high-quality riveting

Ergonomic

•

Extra wide handle backs, with soft and hard zones perfectly distributed across the handle

Attractive

•

Award-winning design with high quality chrome-plated head

242

EN_s230-281_Zangen_2012 15.02.12 17:41 Seite 243

Safety note:

When working with cutting pliers – beware of wire ends ﬂying away. Please wear safety glasses.

www.wiha.com

Combination and high leverage combination pliers.

Z 01 0 05

Standards: DIN ISO 5746. Head shape: Extra long cutting edge for ﬂat and round cables.

esign: OptiGrip - the newly designed gripping surface with 'triple-point support'

Material: High-quality tool steel, tempered. Application: General purpose pliers for gripping and holding as well as cutting

Order-No. 26704 160 6 ½ 3.0 2.0 195 5 26707 180 7 3.4 2.2 245 5 26710 200 8 3.6 2.5 325 5

Combination pliers Professional.

ensures optimal hold of the workpiece while working. Cutting edges additionally induction hardened to approx. 62 HRC. The Wiha DynamicJoint ensures optimal transmission of hand strength to the cutting edges.

soft and hard wires and cables.

Stripping, long-ﬂat and round nose pliers.

Z 55 0 05

Standards: DIN ISO 5743. Head shape: Precision cutting edge prism for even cutting of cable insulation. Design: An easy to use adjusting screw allows the stripping diameter to be set.

Material: High-quality tool steel, tempered. Application: Simple stripping of cables and strands of up to ø 5 mm/ 10 mm²

Order-No. 26846 160 6 ½ 155 5

Stripping pliers Professional.

Opening spring for effortless and sensitive handling of pliers.

conductor cross-section.

Z 02 0 05

Standards: DIN ISO 5746. Head shape: Extra long cutting edge for ﬂat and round cables. Design: OptiGrip - the newly designed gripping surface with 'triple-point support'

Material: High-quality tool steel, specially tempered. Application: Power assisted general purpose pliers for gripping and holding as well as

Order-No. 26713 200 8 3.8 2.8 2.3 315 5 26716 225 9 4.4 3.0 2.5 370 5

High leverage combination pliers Professional.

ensures optimal hold of the workpiece while working. Particularly powerful leverage results in 40% less effort being required for cutting tasks compared with standard combination pliers. Cutting edges additionally inductively hardened to approx. 64 HRC, therefore also appropriate for cutting piano wire. The Wiha DynamicJoint ensures optimal transmission of hand strength to the cutting edges.

cutting wires and cables ranging in hardness from soft to extremely hard.

Wiha Info

Opti-Grip – optimal grip

NEW

due to newly designed gripping surfaces

•

A firm hold:

The 'triple-point support' protects the workpiece from twisting or slipping.

•

Highly effective:

Optimum grip even with a large jaw opening – and at the same time significantly less force needed

•

A wide selection:

Now in standard Wiha combination pliers and high leverage combination pliers

Z 07 0 05

Standards: DIN ISO 5745. Head shape: Extra long head. Design: Ridged gripping surfaces. Material: High-quality tool steel, tempered. Application: Gripping and right-angled bending of wires and sheet metal parts.

Order-No. 26731 160 6 ½ 160 5

Z 09 0 05

Standards: DIN ISO 5745. Head shape: Extra long head. Design: Ridged gripping surfaces. Material: High-quality tool steel, tempered. Application: Gripping and bending of wires and sheet metal parts.

Order-No. 26734 160 6 ½ 140 5

Details of cutting results of cutting pliers.

Test wires standardised in DIN ISO 5744

Long-ﬂat nose pliers Professional.

Long-round nose pliers Professional.

243

EN_s230-281_Zangen_2012 15.02.12 17:42 Seite 244

Wiha Professional.

Quality down to the last detail.

Needle nose pliers with cutting edge (snipe nose pliers).

Z 05 0 05

Standards: DIN ISO 5745.

ead shape: Straight shape.

H Design: Extra long cutting edge for ﬂat and round cables.

Material: High-quality tool steel, tempered. Application: Gripping and holding as well as cutting soft and hard wires and cables.

Order-No. 26719 160 6 ½ 2.5 1.8 155 5 26722 200 8 2.8 2.0 200 5

Needle nose pliers Professional with cutting edge.

Gripping surfaces partially serrated in parts. Cutting edges additionally induction hardened to approx. 62 HRC.

Preferred choice in the mechanical sector.

Diagonal cutters and heavy duty diagonal cutters.

Z 12 0 05

Standards: DIN ISO 5749. Head shape: Semi-circular, swedish style. Design: Low wear lap joint, riveted and able to withstand high loads.

Material: High-quality tool steel, tempered. Application: For soft and hard wires.

Order-No. 26736 140 5 ½ 4.0 2.5 1.8 160 5 26740 160 6 ½ 4.0 2.8 2.0 200 5 26743 180 7 4.0 3.0 2.5 250 5

iagonal cutters Professional.

The Wiha DynamicJoint ensures optimal transmission of hand strength to the cutting edges. Lightweight action, clean cutting achieved by specially milled precision cutting edges. Durable cutting edges due to additional induction hardening to approx. 62 HRC.

Z 05 1 05

Standards: DIN ISO 5745. Head shape: Angled, approx. 40°. Design: Extra long cutting edge for ﬂat and round cables.

Material: High-quality tool steel, tempered. Application: Gripping and holding as well as cutting soft and hard wires and cables.

Order-No. 26724 160 6 ½ 2.5 1.8 155 5 26726 200 8 2.8 2.0 200 5

Needle nose pliers Professional with cutting edge.

Gripping surfaces partially serrated in parts. Cutting edges additionally induction hardened to approx. 62 HRC.

Preferred choice in the mechanical sector.

Wiha Info

TÜV Süd test,

Wiha DynamicJoint – Top of their class

•

Innovative:

Unique joint construction, patent applied for

•

Effective:

Low loss of force means less force needed for cutting – up to 40%

•

Permanent:

Optimal performance even after thousands of cuts

Less force of power:

- 9,6 kg

- 12,6 kg

Up to 40% less force for cutting

October 2009

Competitors

Z 16 0 05

Standards: DIN ISO 5749. Head shape: Semi-circular. Design: Low wear lap joint, riveted and able to withstand high levels of load.

Material: High-quality tool steel, specially tempered. Application: Power assisted, all round diagonal cutter for soft wire as well as the most

Order-No. 26747 160 6 ½ 3.5 2.5 2.0 190 5 26750 180 7 3.8 2.7 2.3 260 5 26753 200 8 4.2 3.0 2.5 315 5

Details of cutting results of cutting pliers.

Test wires standardised in DIN ISO 5744

Heavy duty diagonal cutters Professional.

The Wiha DynamicJoint ensures optimal transmission of hand strength to the cutting edges. Lightweight action, clean cutting achieved by specially milled precision cutting edges. Long term cutting is achieved through additional inductive hardening to approx. 64 HRC.

stringent of demands made by piano wires.

244

EN_s230-281_Zangen_2012 15.02.12 17:42 Seite 245

Safety note:

When working with cutting pliers – beware of wire ends ﬂying away. Please wear safety glasses.

www.wiha.com

Water pump pliers.

Z 21 0 05

Standards: DIN ISO 8976. Head shape: Narrow head, therefore also appropriate for work in small spaces.

esign: Precision adjustment joint, box type, providing optimum adaptation

Material: Chrome vanadium tool steel, tempered. Application: For gripping and holding pipes and angular proﬁles such as hex nuts

Order-No. 26762 250 10 2 50 380 5

Water pump pliers Professional, box type.

to object to be gripped. Long durability achieved by additional inductive hardening of gripper jaws.

in the installation area.

Revolving punch pliers.

5,0 mm

4,5 mm

A B C

4,5 mm 5,0 mm 5,5 mm

4,0 mm

Z 65 2 05

Professional revolving punch and loop pliers.

Head shape: Alternate equipping of perforating tubes and loop punches. Design: Locking lever and rotatable magazine with hole sizes

4.0 / 4.5 and 5.0 mm and corresponding loop punches.

Ergonomic plastic handle. Material: Body of pliers made of high-resistance special steel, nickel-plated. Application: For perforating and pressing of loops in three sizes with only one tool.

Order-No. 29550 225 9 4.0-5.0 325 5

Z 22 0 05

Water pump pliers Professional with push button setting.

Standards: DIN ISO 8976. Head shape: Extra narrow head, therefore also appropriate for work in difﬁcult

to access areas.

Design: Precision adjustment joint, box type, providing optimum adaptation

to object to be gripped. Rapid and simple push button setting and locking.

Long durability achieved by additional inductive hardening of gripper jaws. Material: Chrome vanadium tool steel, tempered. Application: For gripping and holding pipes and angular proﬁles such as hex nuts

in the installation area.

Order-No. 26766 250 10 2 50 400 5

Z 23 0 05

QuickFix water pump pliers Professional, box type.

Standards: DIN ISO 8976. Head shape: Narrow head, therefore also appropriate for work in small spaces. Design: Fast and easy-to-adjust water pump pliers, with automatic adjustment

of the box type, precision-stepped joint.

Optimum adjustment to the object to be gripped.

Long durability achieved by additional inductive hardening of gripper jaws. Material: Chrome vanadium tool steel, tempered. Application: For rapid and optimum gripping and holding of pipes and angular proﬁles

such as hex nuts in the installation area.

Z 65 0 05

Professional revolving punch pliers.

Head shape: Size designation of perforating tubes in viewing window. Design: Locking mechanism and 6 exchangeable punching tools,

diameter: 2.0 / 2.5 / 3.0 / 3.5 / 4.0 / 4.5 mm. With opening spring and locking mechanism

for real single-handed operation. Material: Body of pliers made of high-resistance special steel, nickel-plated. Application: Perforation of a wide variety of different materials in trade,

industry and DIY.

Order-No. 28402 225 9 2.0-4.5 325 5

Opening width of water pump pliers.

Maximum gripper width across flats [mm]

]

Maximum gripper pipe diameter

[

Order-No. 26769 250 10 1 ½ 40 380 5

245

EN_s230-281_Zangen_2012 15.02.12 17:42 Seite 246

Wiha Professional.

Quality down to the last detail.

Pliers set and tool set.

Z 99 0 002 05

Design: All pliers made of high quality tool steel, hardened,

Content: High leverage combination pliers, series Z 02 0 05, 200 mm

Application: Power assisted pliers for providing craftsmen or industrial mechanics

Order-No. Series 26854 Z 99 0 002 05 1

Pliers set Professional Plus, 3 pcs.

polished and chrome-plated. Multi-component handles with slip guard for safe and comfortable operation. Cutting pliers are also suited for extremely hard wires. QuickFix water pump pliers with "automatic" rapid adjustment. Weight 1120 g.

- with Wiha DynamicJoint and OptiGrip High leverage diagonal cutters, series Z 16 0 05, 180 mm

- with Wiha DynamicJoint QuickFix water pump pliers, 250 mm (Z 23 0 05 series)

with a basic set of pliers.

Display.

NEW

Z 99 0 005 05VH

Design: Pliers made of high quality tool steel, hardened,

Content:

Application: The pliers selection for demanding users in trade and industry.

Professional pliers display. Card display with 10 pieces.

polished and chrome plated. Multi-component handles with slip guard for safe and comfortable operation.

2x combination pliers, 180 mm (Z 01 0 05 series)

- with Wiha DynamicJoint and OptiGrip 2x high-leverage combination pliers, 200 mm (Z 02 0 05 series)

– with Wiha DynamicJoint and OptiGrip

2x needle nose pliers, 160 mm (Z 05 0 05 series)

2x diagonal cutters, 160 mm (Z 12 0 05 series)

- with Wiha DynamicJoint 2x heavy-duty diagonal cutters, 180 mm (Z 16 0 05 series)

– with Wiha DynamicJoint

Z 99 0 003 05

Design: Pliers made of high quality tool steel, hardened,

Content: Diagonal cutters, series Z 12 0 05, 160 mm - with Wiha DynamicJoint

Application: The compact basic set of pliers and screwdrivers for demanding

Order-No. Series 26856 Z 99 0 003 05 1

Tool set Professional Mix, 5 pcs.

polished and chrome plated. Multi-component handles with slip guard for safe and comfortable operation. Wiha SoftFinish Weight 720 g.

Needle nose pliers series Z 05 0 05, 200 mm Wiha SoftFinish

- slotted screwdriver, series 302: 3.5x100 / 5.5x125

- Phillips screwdriver, series 311: PH2x100

craftsmen and industrial mechanics.

screwdriver with round blade and ChromTop®blade tip.

screwdriver:

Order-No. Series 36066 Z 99 0 005 05VH 1

Wiha Info

NEW

Opti-Grip – optimal grip due to newly designed gripping surfaces

•

A firm hold:

The 'triple-point support' protects the workpiece from twisting or slipping.

•

Highly effective:

Optimum grip even with a large jaw opening – and at the same time significantly less force needed

•

A wide selection:

Now in standard Wiha combination pliers and high leverage combination pliers

Thanks to a unique geometry:

Each workpiece always securely packed.

246

EN_s230-281_Zangen_2012 15.02.12 17:42 Seite 247

Wiha Professional electric.

Completely reliable.

Hard, comfortable elastomer zones ensure low friction in the movement range of the ﬁngers

www.wiha.com

The stops on the ends of the arms prevent the hands from slipping

For its outstanding design quality,

the new Wiha pliers generation

has received the

iF - prduct design award".

" In 2011, there was a focus

n the brand image.

Valuable chrome plating for long lasting corrosion protection

Wiha received the "Focus in Silber" award for outstanding design.

Harmonious design of the front part of the handle for an optimum ﬁnger hold when applying force

he robust, ergonomic handle

T is carefully ﬁxed to the pliers

Extra broad arms made of soft, non-slip elastomer are gentle on the parts of the hand that are sensitive to pressure

For the VDE-tested Wiha Professional electric pliers only one thing counts: to protect the user one hundred percent when working precisely with live parts.

The new DynamicJoint construction proves its worth: it makes cutting signiﬁcantly easier and helps to eliminate the danger of cramping or slipping due to excessive force of power.

In addition the handle insulation and curved handle ends that prevent the ﬁngers slipping away ensure even more safety.

Less force of power:

- 9,6 kg

- 12,6 kg

Up to 40% less force for cutting. The low expenditure of energy thanks to DynamicJoint is especially advantageous when cutting a large number of hard objects.

TÜV Süd test, October 2009

Competitors

Must maintain the highest level of electrical safety! All Wiha Professional electric pliers meet the strict VDE requirements.

Approved for work in the area of live parts up to 1,000 V AC or 1,500 V DC.

When working with VDE tools, observe the national safety and accident prevention regulations!

Wiha Professional electric.

Uncompromisingly safe

•

Manufactured and inspected according to IEC 60900:2004, one-oﬀ testing at 10,000 V, GS mark for inspected safety, VDE tested

Powerful

•

With DynamicJoint, the high quality joint construction for simple, long-term cutting eﬃciency

As hard as steel

•

Pliers head drop forged from high quality steels

Robust and durable

•

Cutting edges are individually tempered and additionally induction hardened, joints are extremely wear resistant and can withstand high stresses, and with high-quality riveting

Ergonomic

•

Extra wide handle backs, with soft and hard zones perfectly distributed across the handle

Attractive

•

Award-winning design

247

EN_s230-281_Zangen_2012 15.02.12 17:42 Seite 248

Wiha Professional electric.

Completely reliable.

Combination and stripping pliers.

Z 01 0 06

Standards: DIN ISO 5746. Manufactured acc. to IEC 60900:2004.

ead shape: Extra long cutting edge for ﬂat and round cables.

H Design: OptiGrip - the newly designed gripping surface with 'triple-point support'

Material: High-quality tool steel, tempered. Application: General purpose pliers for gripping and holding as well as cutting

Order-No. 26705 160 6 ½ 3.2 2.0 195 5 26708 180 7 3.4 2.2 245 5 26711 200 8 3.6 2.5 325 5

Combination pliers Professional electric.

Individually tested protective insulation 1,000 V AC, VDE and GS tested.

soft and hard wires and cables. For all work on or around electrical components up to 1000 V AC.

Long-ﬂat and needle nose pliers.

Z 05 0 06

Standards: DIN ISO 5745. Manufactured acc. to IEC 60900:2004.

ead shape: Straight shape.

H Design: Extra long cutting edge for ﬂat and round cables.

Material: High-quality tool steel, tempered. Application: Gripping and holding as well as cutting soft and hard wires and cables.

Order-No. 26720 160 6 ½ 2.5 1.8 155 5 26727 200 8 2.8 2.0 200 5

Needle nose pliers Professional electric with cutting edge. Individually tested protective insulation 1,000 V AC, VDE and GS tested.

Gripping surfaces partially serrated in parts. Cutting edges additionally induction hardened to approx. 62 HRC.

Preferred choice in the electrical sectors. For all work on or around electrical components up to 1000 V AC.

Z 02 0 06

Standards:

Head shape: Extra long cutting edge for ﬂat and round cables. Design: OptiGrip - the newly designed gripping surface with 'triple-point support'

Material: High-quality tool steel, specially tempered. Application: Power assisted general purpose pliers for gripping and holding as well as

Order-No. 26714 200 8 3.8 2.8 2.3 330 5 26717 225 9 4.4 3.0 2.5 390 5

High leverage combination pliers Professional electric. Individually tested protective insulation 1,000 V AC, VDE and GS tested.

DIN ISO 5746. Manufactured acc. to IEC 60900:2004.

cutting wires and cables ranging in hardness from soft to extremely hard. For all work on or around electrical components up to 1000 V AC.

NEW

Wiha Info

NEW

Opti-Grip – optimal grip due to newly designed gripping surfaces

•

A firm hold: The 'triple-point support'

protects the workpiece from twisting or slipping.

•

Highly effective: Optimum grip even with a large jaw opening –

and at the same time significantly less force needed

•

A wide selection: Now in standard Wiha combination pliers

and high leverage combination pliers

Z 05 1 06

Standards: DIN ISO 5745. Manufactured acc. to IEC 60900:2004. Head shape: Angled, approx. 40°. Design: Extra long cutting edge for ﬂat and round cables.

Material: High-quality tool steel, tempered. Application: Gripping and holding as well as cutting soft and hard wires and cables.

Order-No. 26728 160 6 ½ 2.5 1.8 155 5 26729 200 8 2.8 2.0 200 5

Z 07 0 06

Standards: DIN ISO 5745. Manufactured acc. to IEC 60900:2004. Head shape: Extra long head. Design: Ridged gripping surfaces. Material: High-quality tool steel, tempered. Application: Gripping and right-angled bending of wires and sheet metal parts.

Order-No. 26732 160 6 ½ 160 5

Needle nose pliers Professional electric with cutting edge. Individually tested protective insulation 1,000 V AC, VDE and GS tested.

Gripping surfaces partially serrated in parts. Cutting edges additionally induction hardened to approx. 62 HRC.

Preferred choice in the electrical sectors. For all work on or around electrical components up to 1000 V AC.

Long-ﬂat nose pliers Professional electric. Individually tested protective insulation 1,000 V AC, VDE and GS tested.

For all work on or around electrical components up to 1000 V AC.

248

EN_s230-281_Zangen_2012 15.02.12 17:42 Seite 249

Safety note:

When working with cutting pliers – beware of wire ends ﬂying away. Please wear safety glasses.

www.wiha.com

Round nose pliers and diagonal cutters.

Z 09 0 06

Standards: DIN ISO 5745. Manufactured acc. to IEC 60900:2004.

ead shape: Extra long head.

H Design: Ridged gripping surfaces. Material: High-quality tool steel, tempered. Application: Gripping and bending of wires and sheet metal parts.

Order-No. 26735 160 6 ½ 140 5

Z 12 0 06

Standards: DIN ISO 5749. Manufactured acc. to IEC 60900:2004. Head shape: Semi-circular, swedish style. Design: Low wear lap joint, riveted and able to withstand high loads.

Material: High-quality tool steel, tempered. Application: Universal cutter for cutting soft and hard wires and cables,

Order-No. 26737 140 5 ½ 4.0 2.5 1.8 160 5 26741 160 6 ½ 4.0 2.8 2.0 200 5 26744 180 7 4.0 3.0 2.5 250 5

Z 16 0 06

Standards: DIN ISO 5749. Manufactured acc. to IEC 60900:2004. Head shape: Semi-circular. Design: Low wear lap joint, riveted and able to withstand high levels of load.

Material: High-quality tool steel, specially tempered. Application: Power-assisted all-round diagonal cutter for cutting

Order-No. 26748 160 6 ½ 3.5 2.5 2.0 190 5 26751 180 7 3.8 2.7 2.3 260 5 26754 200 8 4.2 3.0 2.5 315 5

Long-round nose pliers Professional electric. Individually tested protective insulation 1,000 V AC, VDE and GS tested.

For all work on or around electrical components up to 1000 V AC.

Diagonal cutters Professional electric. Individually tested protective insulation 1,000 V AC, VDE and GS tested.

Lightweight action, clean cutting achieved by specially milled precision cutting edges. Durable cutting edges due to additional induction hardening to approx. 62 HRC. The Wiha DynamicJoint ensures optimal transmission of hand strength to the cutting edges.

also suitable for cutting and stripping cables. For all work on or around electrical components up to 1000 V AC.

Heavy duty diagonal cutters Professional electric. Individually tested protective insulation 1,000 V AC, VDE and GS tested.

Lightweight action, clean cutting achieved by specially milled precision cutting edges. Long term cutting is achieved through additional inductive hardening to approx. 64 HRC. The Wiha DynamicJoint ensures optimal transmission of hand strength to the cutting edges.

soft to extremely hard wires and cables. For all work on or around electrical components up to 1000 V AC.

Diagonal and cable cutters.

Z 14 0 06

Standards: DIN ISO 5749. Manufactured acc. to IEC 60900:2004.

ead shape: Semi-circular, swedish style.

H Design: Low wear lap joint, riveted and able to withstand high loads.

Material: Special tool-steel, hardened & tempered.

pplication: Special diagonal cutters with additional function for electrical installation.

Order-No. 26745 160 6 ½ 4.0 2.0 200 5

Z 50 1 06

Standards: Manufactured acc. to IEC 60900:2004. Head shape: Classic cutting form. Design: Light, energy-saving and clean cutting with

Material: Special tool-steel, hardened & tempered. Application: Cable cutter for cutting of copper and aluminium cables without crushing,

Order-No. 34743 160 6 ½ 16 50 190 5 34744 200 8 20 60 305 5

Electrician's diagonal cutters Professional electric.

Individually tested protective insulation 1,000 V AC,

VDE and GS tested.

The Wiha DynamicJoint ensures optimal transmission of hand strength

to the cutting edges.

Lightweight action, clean cutting achieved by

specially milled precision cutting edges.

Durable cutting edges due to additional induction hardening to

approx. 62 HRC.

Rear cutting area near to plier joint also suitable for

medium-hard and hard wire.

Front cutting area for soft wire, with precision stripping stations

for 1.5 mm² and 2.5 mm² single-wire conductor.

For all work on or around electrical components up to 1000 V AC.

Cable cutters Professional electric.

Individually tested protective insulation 1,000 V AC,

VDE and GS tested.

specially ground precision cutting edges.

Durable cutting edges due to additional induction hardening to

approx. 62 HRC. Safety stop prevents ﬁnger injuries after cutting.

also suitable for stripping.

Not for steel cable, wires and copper conductors with hard coatings.

For all work on or around electrical components up to 1000 V AC.

Wiha Info

Wiha DynamicJoint – Top of their class

•

Innovative: Unique joint construction

•

Effective: Low loss of force means

less force needed for cutting – up to 40%

•

Permanent: Optimal performance even after thousands of cuts

249

EN_s230-281_Zangen_2012 15.02.12 17:42 Seite 250

Wiha Professional electric.

Completely reliable.

Stripping pliers and display.

Z 55 0 06

Standards: DIN ISO 5743. Manufactured acc. to IEC 60900:2004. Head shape: Precision cutting edge prism for even cutting of cable insulation. Design: An easy to use adjusting screw allows the stripping diameter to be set.

Material: High-quality tool steel, tempered. Application: Simple stripping of cables and strands of up to ø 5 mm/ 10 mm²

Order-No. 26847 160 6 ½ 155 5

Stripping pliers Professional electric. Individually tested protective insulation 1,000 V AC, VDE and GS tested.

Opening spring for effortless and sensitive handling of pliers.

conductor cross-section. For all work on or around electrical components up to 1000 V AC.

Pliers set and tool set.

Z 99 0 001 06

Design: All pliers made of high quality tool steel, hardened,

Content: VDE combination pliers, series Z 01 0 06, 180 mm

Application: All tools suitable for use with or near live components up to 1000 V AC.

Pliers set Professional electric, 3 pcs. Individually tested protective insulation 1,000 V AC, VDE and GS tested.

polished and chrome-plated. Multi-component handles with slip guard for safe and comfortable operation. Individually tested for electrical safety in accordance with IEC 60900:2004. Weight 820 g.

- with Wiha DynamicJoint VDE diagonal cutters, series Z 12 0 06, 160 mm

- with Wiha DynamicJoint Needle nose pliers series Z 05 0 06, 200 mm

For all work on or around electrical components up to 1000 V AC.

NEW

Z 99 0 005 06VH

Design: Pliers made of high quality tool steel, hardened,

Content: 2x combination pliers, 180 mm (Z 01 0 06 series)

Application: The pliers selection for demanding electricians.

Order-No. Series 36063 Z 99 0 005 06VH 1

Professional electric pliers display. Card display with 10 pieces. Insulation up to 1000 V AC, GS-mark.

polished and chrome plated. Multi-component handles with slip guard for safe and comfortable operation.

2x needle nose pliers, 200 mm (Z 05 0 06 series) 2x diagonal cutters, 160 mm (Z 12 0 06 series) 2x heavy-duty diagonal cutters, 180 mm (Z 16 0 06 series) 2x stripping pliers, 160 mm (Z 55 0 06 series)

For all work on or around electrical components up to 1000 V AC.

Order-No. Series 26852 Z 99 0 001 06 1

Z 99 0 002 06

Design: Pliers made of high quality tool steel, hardened,

Content: Needle nose pliers, series Z 05 0 06, 200 mm

Application: The small, basic set of pliers and screwdrivers for skilled electricians.

Tool set Professional electric Mix, 5 pcs. Individually tested protective insulation 1,000 V AC, VDE and GS tested.

polished and chrome plated. Multi-component handles with slip guard for safe and comfortable operation. Insulated screwdrivers. Tips with black ﬁnish. Individually tested for electrical safety in accordance with IEC 60900:2004. Weight 780 g.

VDE diagonal cutters, series Z 12 0 06, 160 mm

- with Wiha DynamicJoint

Wiha SoftFinish

- slotted screwdriver, series 320N: 3.5x100 / 5.5x125

- Phillips screwdriver, series 321N: PH2x100

For all work on or around electrical components up to 1000 V AC.

electric screwdriver:

250

Order-No. Series 26755 Z 99 0 002 06 1

EN_s230-281_Zangen_2012 15.02.12 17:42 Seite 251

www.wiha.com

Cable shears.

Z 71 1 06

ead shape: Lightweight standard model, straight.

H Design: Standard model with wire stripper, cutting length 37 mm.

Material: C 50 carbon steel, hardened, nickel-plated. Application: Universal cutter for electricians and other trades,

Order-No. 27907 145 5 ¾ 95 5

Cable shears Professional electric.

Screw joint, adjustable cutting blades. Extruded plastic handle for a secure hold when cutting.

also suitable for cutting and cutting back of cables.

Cable shears.

Z 71 4 06

ead shape: Sturdy model, straight, very robust, micro-toothed cutting.

H Design: Precision model with wire stripper; cutting length 50 mm.

Material: High-alloy carbon steel, hardened, black ﬁnish. Application: Highly-developed universal cutter for electricians and other trades,

Order-No. 27910 145 5 ¾ 120 manganese-phosphated 5

Electrician's / craftsman's cutters Professional electric.

Concealed, adjustable screw joint.

Extruded handle made of impact-resistant plastic

for powerful and safe cutting.

also suitable for cutting and stripping copper cables.

Z 71 6 06

Head shape: Strong, powerful design, straight, very robust, micro-ridged blade. Design: Particularly comfortable two-component handle

Material: Blades made of stainless steel, handles made of high-quality plastics. Application: Qualitative, comfortable universal shears for electricians

Order-No. 33910 145 5 ¾ 80 5

Electrician's / craftsman's cutters Professional electric.

with soft zone in area subject to compressive stress. Cutting edge with wire cutter, cutting length 43 mm, cutting edge hardness approx. 56 HRC. Concealed, adjustable screw joint.

and many applications for trade and industry. Also suitable for cutting and cutting back of cables.

Z 71 5 06

Head shape: Standard model, straight, micro-toothed blade. Design: Particularly comfortable two-component handle

Material: Blades made of stainless steel, handles made of high-quality plastics. Application: Comfortable universal cutter for many applications in trade and industry,

Order-No. 29420 145 5 ¾ 60 5

Electrician's / craftsman's cutters Professional electric.

with soft zone in area subject to compressive stress.

Cutting edge with wire cutter, cutting length 34 mm.

Concealed, adjustable screw joint.

also suitable for cutting and stripping cables.

251

EN_s230-281_Zangen_2012 15.02.12 17:42 Seite 252

Wiha crimp tools.

Crimp tools.

Z 62 0 000 06

Head shape: Square crimp, linear pressing. Design: Tool with only one crimp proﬁle.

Material: Of high-tensile special steel.

Application: For processing of wire-end sleeves with and without isolating collar

Order-No. 33845 196 0.08 – 10 28 – 8 300 1

Crimp tools for wire-end sleeves.

Automatic adjustment of cross-section area.

ateral contact feed.

L Low hand force required with optimal transmission. Delockable force lock for ensuring complete crimping process; required crimp pressure is factory set. Ergonomically formed soft handle with slip protection for especially comfortable handling.

Parts subject to extreme loading are specially hardened and tempered.

according to DIN 46228, EN 50027. Especially suitable for processing twin sleeves.

Crimp tools.

Z 62 0 002 06

Head shape: Oval crimp, radial pressing.

Design: Crimp proﬁle:

Material: Of high-tensile special steel.

Application: For processing of red, blue and yellow isolated cable eyes,

Crimping tools for isolated cable eyes and contacts.

Conducting and isolating crimp are carried out in one work step.

Red proﬁle: 0.5 - 1.0 mm² / AWG 20 - 16 Blue proﬁle: 1.5 - 2.5 mm²/ AWG 16 - 14 Yellow proﬁle: 4.0 - 6.0 mm² / AWG 12 - 10

Delockable force lock for ensuring complete crimping process; required crimp pressure is factory set.Ergonomically formed soft handle with slip protection for especially comfortable handling.

Parts subject to extreme loading are specially hardened and tempered.

pin-end cable connectors, contact pins, contact pin sleeves, circular pins, circular pin sleeves, batch connectors and parallel connectors according to DIN 46234. For standardised, solderless electrical connections.

Z 62 0 001 06

Head shape: Trapezoid crimp, radial travel. Design: Crimp proﬁle:

Material: Of high-tensile special steel.

Application: For processing of wire-end sleeves with and without isolating collar

Crimp tools for wire-end sleeves.

Proﬁle 1. 0.14 - 0.75 mm² / AWG 26 - 18 Proﬁle 2. 1.0 - 1.5 mm²/ AWG 18 - 16 Proﬁle 3. 2.5 mm² / AWG 14 Proﬁle 4. 4.0 mm² / AWG 12 Proﬁle 5. 6.0 mm²/ AWG 10 Proﬁle 6. 10.0 mm² / AWG 8

Delockable force lock for ensuring complete crimping process; required crimp pressure is factory set. Ergonomically formed soft handle with slip protection for especially comfortable handling.

Parts subject to extreme loading are specially hardened and tempered.

according to DIN 46228, EN 50027.

Order-No. 33841 220 0.5 – 6 20 – 10 510 1

Z 62 0 004 06

Head shape: W injection, radial pressing. Design: Crimp proﬁle:

Material: Of high-tensile special steel.

Application: For processing of non-isolated cable eyes, pin-end cable connectors,

Crimping tools for non-isolated cable eyes with closed sleeve.

Proﬁle 1. 0.1 - 0.5 mm² / AWG 26 - 20 Proﬁle 2. 0.5 - 2.5 mm² / AWG 20 - 14 Proﬁle 3. 4.0 - 6.0 mm² / AWG 12 - 10 Proﬁle 4. 10.0 - 16.0 mm² / AWG 8 - 6

Delockable force lock for ensuring complete crimping process; required crimp pressure is factory set. Ergonomically formed soft handle with slip protection for especially comfortable handling.

Parts subject to extreme loading are specially hardened and tempered.

batch connectors and mini cable eyes according to DIN 46234/ DIN 46230/ DIN 46341. For solderless electrical connections according to standards.

Order-No. 33844 220 0.14 – 10 26 – 8 510 1

252

Order-No. 33843 220 0.1 – 16 26 – 6 510 1

EN_s230-281_Zangen_2012 15.02.12 17:42 Seite 253

Wiha crimp tools and stripping pliers.

www.wiha.com

Crimping tools and stripping pliers.

Z 62 0 003 06

Head shape: B-crimp, radial pressing.

Design: Crimp proﬁle: Contact width 6.3 / 9.5 mm

Material: Of high-tensile special steel.

Application: For processing of non-isolated contact pins and contact pin sleeves

Order-No. 33842 220 0.25 – 6 22 – 10 510 1

Crimping tools for non-isolated contact pins.

Conducting and isolating crimp are carried out in one work step.

Proﬁle 1. 0.25 - 0.5 mm² / AWG 22 - 20 / F 6.3 + 9.5 Proﬁle 2. 0.5 - 1.0 mm² / AWG 20 - 16 / F 6.3 + 9.5 Proﬁle 3. 1.5 - 2.5 mm²/ AWG 16 - 14 / F 6.3 + 9.5 Proﬁle 4. 4.0 - 6.0 mm² / AWG 12 - 10 / F 6.3 + 9.5

Delockable force lock for ensuring complete crimping process; required crimp pressure is factory set. Ergonomically formed soft handle with slip protection for especially comfortable handling.

Parts subject to extreme loading are specially hardened and tempered.

according to DIN 46247 for standardised, solderless electrical connections.

Stripping pliers and stripping cassette.

24672SB

Design: Self-adjusting straight cutting edge in exchangeable cassette and

Material: Housing of tough glass-ﬁbre reinforced plastic.

Application: For precise stripping and cutting of single, multi and ﬁne-wired cables

Automatic stripping pliers.

Blister packed.

wire cutter for copper and Al conductors.Optimally positioned wire cutter

enables effortless cutting of multi-wire conductors to 10 mm² / 8 AWG.

Simply replaceable stripping cassette with adjustable stripping length

to 18 mm and adjustable cutting depth for various insulation materials.

Ergonomically sophisticated solution with soft plastic zone in main handle,

secure gripping without play, optimised handle opening width,

an angled head as well as a low weight for working without fatigue.

Soft plastic zone in upper handle section used for gripping.

for many tasks in the electronics industry.

NEW

24675SB

Design: Automatic setting to various conductor diameters.

Material: Housing of glass-ﬁbre reinforced polyamide. Application: Stripping of all commonly used ﬂexible and

Order-No. 36050 190 7½ 0.2 - 6.0 24-10 110 1

Automatic stripping pliers. Blister packed.

Settable length stop from 5 -12 mm, can be removed if required. Integrated, easily accessible wire cutter. Light, ergonomically designed tool body with narrow head for optimal use in hard-to-reach areas. Locking for safe, space-saving transport.

solid conductors from 0.2 – 6.0 mm² (24 - 10 AWG). Wire cutter for cutting of Cu and Al conductors to max. Ø2 mm.

Order-No. 33847 190 7½ 0.02 – 10 34 – 8 135 1

24673SB

Design: Cassette with straight blade.

Order-No. 33846 0.02 – 10 34 – 8 71

Stripping cassette for automatic stripping pliers.

Blister packed.

253

EN_s230-281_Zangen_2012 15.02.12 17:42 Seite 254

Wiha crimping and stripping tool.

Stripping tools.

NEW

246 2202

Design: Comfortable stripping with continuously adjustable cutting depth

Material: Impact resistant plastic housing made of Polyamide

Application: Precise, fast and safe stripping of all common round cable

Order-No. 35969 165 6 ½ 4.0 – 28 80 1

NEW

2462202SB

Order-No. 35538 165 6½ 4.0 – 28 1

Cable stripper.

per adjusting screw and self-turning inner cutter. Damage to the inner conductor is therefore eliminated. Self-tensioning holding lever for safe cable guide. With cutter and hooked blade incl. safety cap for transport and storage. Additional spare blades included in the tool. Ergonomically designed construction.

einforced with glass-ﬁbre.

r Hooked blade and cutter are made of hardened steel.

from ø 4 mm – 28 mm. Self-turning inner cutter for circular and longitudinal cutting.

Cable stripper. Blister packed.

Crimping and stripping tool.

24677SB

Design: Double layered, folding stripping tool with opening spring and

Material: Housing of glass-ﬁbre reinforced polyamide. Application: Flush stripping of round and damp-proof cable from Ø 8 – 13 mm

Order-No. 36052 125 5 8 - 13 45 1

NEW

24678SB

Design: Double layered, folding stripping tool with opening spring and

Material: Housing of glass-ﬁbre reinforced polyamide. Application: Incremental stripping of all commonly used coaxial cables

Stripping tool for round cables. Blister packed.

locking mechanism. Setting of cutting depth not required. Ergonomically designed tool body for non-slip, safe work.

e.g. NYM 3 x 1.5 mm² to 5 x 2.5 mm²), also for hard-to-reach locations

( e.g. ceiling and wall areas, in junction boxes, distribution boxes, switch cabinets etc.

Stripping tool for coaxial cables. Blister packed.

locking mechanism. Setting of cutting depth not required. Extra-long tool body for optimal handling. With 5.0 - 20.0 mm length scale.

(e.g. antenna and transmission cables) from 4.8 – 7.5 mm outer diameter. Also suitable for stripping of round cables (e.g. NYM 3 x 0.75 mm², PVC ﬂex 10 mm² and 16mm²).

NEW

24678SB

Standards: Manufactured acc. to IEC 60900:2004. Design: Robust, ﬁxed, sickle-shaped hooked blade.

Material: Insulating multi-component handle.

Application: For stripping thick cables and cutting open

Order-No. 36053 200 8 120 1

254

Stripping knife for round cables. Blister packed.

Shoe-shaped blade tip limits the cutting depth and prevents damage to conductors. Protective cap for safe transport and protection of cutting edges.

Blade of hardened, non-rusting steel.

the various layers of multi-insulated cables. For all work on or around electrical components up to 1000 V AC.

Order-No. 36051 110 4¼ 4.8 - 7.5 30 1

EN_s230-281_Zangen_2012 15.02.12 17:42 Seite 255

Wiha Industrial.

Comfortable in your hand, versatile in application.

For its outstanding design quality,

the new Wiha pliers generation

has received the

iF - prduct design award".

" In 2011, there was a focus

n the brand image.

Multiple polished heads

Wiha received the "Focus in Silber" award for outstanding design.

www.wiha.com

The interior is made of harder material for less friction

For industrial applications in particular, the diversity of tools and the demands made upon them have increased dramatically. Here the Wiha Industrial pliers series has proven to be ideal. It combines the advantages of the Wiha Professional and Basic series: pleasant handling, a concise shape and a ﬂexible range.

With DynamicJoint, Wiha Industrial implements the new generation of precision joints: cuts are powerful and at the same time more energysaving than ever before. Tests have proven: up to 40% less expenditure of eﬀort is a convincing argument.

Functional gripping surfaces and exact closing, induction hardened cutting edges

Less force of power:

- 9,6 kg

- 12,6 kg

TÜV Süd test, October 2009

Competitors

Wiha Industrial pliers oﬀer a secure hold when gripping, bending and cutting soft and hard wire.

Up to 40% less force for cutting. The low expenditure of energy thanks to DynamicJoint is especially advantageous when cutting a large number of hard objects.

The exterior of the handle is made of soft, non-slip elastomer

Wiha Industrial.

Powerful

•

With DynamicJoint, the high quality joint construction for simple, long-term cutting eﬃciency

As hard as steel

•

Pliers head drop forged from high quality steels

Robust and durable

•

Cutting edges are individually tempered and additionally induction hardened to approx. 64 HRC; joints are extremely wear resistant and withstand high stresses, with high-quality riveting

Ergonomic

•

Extra wide handle backs, with soft and hard zones perfectly distributed across the handle

Attractive

•

An appealing design, with a multi-polished head

255

EN_s230-281_Zangen_2012 15.02.12 17:42 Seite 256

Wiha Industrial.

Comfortable in your hand, versatile in application.

Combination and high leverage combination pliers.

Z 01 0 02

Standards: DIN ISO 5746. Head shape: Extra long cutting edge for ﬂat and round cables. Design: OptiGrip - the newly designed gripping surface with 'triple-point support'

Material: High-quality tool steel, tempered. Application: General purpose pliers for gripping and holding as well as cutting

Order-No. 30979 160 6 ½ 3.0 2.0 195 5 30826 180 7 3.4 2.2 245 5 30978 200 8 3.6 2.5 325 5

Combination pliers Industrial.

nsures optimal hold of the workpiece while working.

e Cutting edges additionally induction hardened to approx. 62 HRC. The Wiha DynamicJoint ensures optimal transmission of hand strength to the cutting edges.

soft and hard wires and cables.

Flat and round-nose pliers.

Z 07 0 02

Standards: DIN ISO 5745. Head shape: Extra long head. Design: Gripping surfaces serrated and inductively hardened. Material: High-quality tool steel, tempered.

pplication: Gripping and right-angled bending of wires and sheet metal parts.

Order-No. 32330 160 6 ½ 160 5

Z 09 0 02

Standards: DIN ISO 5745. Head shape: Extra long head. Design: Gripping surfaces serrated and inductively hardened. Material: High-quality tool steel, tempered. Application: Gripping and bending of wires and sheet metal parts.

Order-No.

32332 160 6 ½ 140 5

Long ﬂat-nose pliers Industrial.

Long round-nose pliers Industrial.

Z 02 0 02

Standards: DIN ISO 5746. Head shape: Extra long cutting edge for ﬂat and round cables. Design: OptiGrip - the newly designed gripping surface with 'triple-point support'

Material: High-quality tool steel, specially tempered. Application: Power assisted general purpose pliers for gripping and holding as well as

Order-No. 32319 200 8 3.8 2.8 2.3 315 5 32320 225 9 4.4 3.0 2.5 370 5

High-leverage combination pliers Industrial.

cutting wires and cables ranging in hardness from soft to extremely hard.

Wiha Info

NEW

Opti-Grip – optimal grip due to newly designed gripping surfaces

•

A firm hold: The 'triple-point support'

protects the workpiece from twisting or slipping.

•

Highly effective: Optimum grip even with a large jaw opening –

and at the same time significantly less force needed

•

A wide selection: Now in standard Wiha combination pliers

and high leverage combination pliers

256

Z 05 0 02

Standards: DIN ISO 5745. Head shape: Straight shape. Design: Extra long cutting edge for ﬂat and round cables.

Material: High-quality tool steel, tempered. Application: Gripping and holding as well as cutting soft and hard wires and cables.

Order-No. 32322 160 6 ½ 2.5 1.8 155 5 32323 200 8 2.8 2.0 200 5

Z 05 1 02

Standards: DIN ISO 5745. Head shape: Angled, approx. 40°. Design: Extra long cutting edge for ﬂat and round cables.

Material: High-quality tool steel, tempered. Application: Gripping and holding as well as cutting soft and hard wires and cables.

Order-No. 32324 160 6 ½ 2.5 1.8 155 5 32328 200 8 2.8 2.0 200 5

Needle nose pliers Industrial with cutting edge.

Gripping surfaces partially serrated in parts. Cutting edges additionally induction hardened to approx. 62 HRC.

Preferred choice in the mechanical sector.

Needle nose pliers Industrial with cutting edge.

Gripping surfaces partially serrated in parts. Cutting edges additionally induction hardened to approx. 62 HRC.

Preferred choice in the mechanical sector.

EN_s230-281_Zangen_2012 15.02.12 17:43 Seite 257

Safety note:

When working with cutting pliers – beware of wire ends ﬂying away. Please wear safety glasses.

www.wiha.com

Diagonal cutters and heavy duty diagonal cutters.

Z 12 0 02

Standards: DIN ISO 5749. Head shape: Semi-circular, swedish style. Design: Low wear lap joint, riveted and able to withstand high loads.

Material: High-quality tool steel, tempered. Application: For soft and hard wires.

Order-No. 30975 140 5 ½ 4.0 2.5 1.8 160 5 30827 160 6 ½ 4.0 2.8 2.0 200 5 30976 180 7 4.0 3.0 2.5 250 5

Diagonal cutters Industrial.

he Wiha DynamicJoint ensures optimal transmission of hand strength

T to the cutting edges. Lightweight action, clean cutting achieved by specially milled precision cutting edges. Durable cutting edges due to additional induction hardening to approx. 62 HRC.

Industrial heavy-duty end cutting nippers and stripping pliers.

Z 17 0 02

Standards: DIN ISO 5748. Head shape: Classic style. Design: Low wear lap joint, riveted and able to withstand high levels of load.

Material: High-quality tool steel, tempered. Application: Power assisted, all round diagonal cutter for soft wires as well as

Order-No. 36035 160 6 ½ 3.5 2.5 180 5 36036 180 7 3.8 2.8 200 5 36037 200 8 4.0 3.0 220 5

Industrial heavy-duty end cutting nippers.

triking high quality cutting edge with high cutting performance and

low application of force due to highly precise processing.

Good durability due to additional induction hardening of cutting edges to

approx. 62 HRC.

demanding piano wires.

Also appropriate for binding (plaiting) and cutting wire netting in reinforced

concrete structures.

Z 16 0 02

Standards: DIN ISO 5749. Head shape: Semi-circular. Design: Low wear lap joint, riveted and able to withstand high levels of load.

Material: High-quality tool steel, tempered. Application: Power assisted, all round diagonal cutter for soft wire as well as the most

Order-No. 32333 160 6 ½ 3.5 2.5 2.0 190 5 32339 180 7 3.8 2.7 2.3 260 5 32341 200 8 4.2 3.0 2.5 315 5

Heavy-duty diagonal cutters Industrial.

The Wiha DynamicJoint ensures optimal transmission of hand strength to the cutting edges. Lightweight action, clean cutting achieved by specially milled precision cutting edges. Long term cutting is achieved through additional inductive hardening to approx. 64 HRC.

stringent of demands made by piano wires.

Wiha Info

Wiha DynamicJoint – Top of their class

•

Innovative: Unique joint construction

•

Effective: Low loss of force means

less force needed for cutting – up to 40%

•

Permanent: Optimal performance even after thousands of cuts

Z 55 0 02

Standards: DIN ISO 5743. Head shape: Precision cutting edge prism for even cutting of cable insulation. Design: An easy to use adjusting screw allows the stripping diameter to be set.

Material: High-quality tool steel, tempered. Application: Simple stripping of cables and strands of up to ø 5 mm/ 10 mm²

Order-No. 32345 160 6 ½ 155 5

Stripping pliers Industrial.

Opening spring for effortless and sensitive handling of pliers.

conductor cross-section.

257

EN_s230-281_Zangen_2012 15.02.12 17:43 Seite 258

Wiha Industrial.

Comfortable in your hand, versatile in application.

Stripping and water pump pliers.

Z 21 0 02

Standards: DIN ISO 8976. Head shape: Narrow head, therefore also appropriate for work in small spaces. Design: Precision adjustment joint, box type, providing optimum adaptation

Material: Chrome vanadium tool steel, tempered. Application: For gripping and holding pipes and angular proﬁles such as hex nuts

Order-No. 36038 180 7 130170 5 32342 250 10 2 50 380 5 36039 300 12 2 ½ 63 640 5

Water pump pliers Industrial.

to object to be gripped. Long durability achieved by additional inductive hardening of gripper jaws.

in the installation area.

NEW

Tool set and display.

Z 99 0 006 02

Design: Pliers of high quality tool steel, hardened and polished.

Content: Diagonal cutters, series Z 12 0 02, 160 mm

Application: The professional set of pliers and screwdrivers for demanding

Tool set Industrial Mix, 5 pcs.

Multi-component handles with slip guard for safe and comfortable operation. Wiha SoftFinish Weight 755 g.

- with Wiha DynamicJoint

ombination pliers, series Z 01 0 02, 180 mm

- with Wiha DynamicJoint

Wiha SoftFinish

- slotted screwdriver, series 302: 3.5x100 / 5.5x125

- Phillips screwdriver, series 311: PH2x100

craftsmen and industrial mechanics.

screwdriver with round blade and ChromTop®blade tip.

screwdriver:

Z 22 0 02

Standards: DIN ISO 8976. Head shape: Extra narrow head, therefore also appropriate for work in difﬁcult

Design: Precision adjustment joint, box type, providing optimum adaptation

Material: Chrome vanadium tool steel, tempered. Application: For gripping and holding pipes and angular proﬁles such as hex nuts

Order-No. 36040 180 7 130175 5 32352 250 10 2 50 400 5 36041 300 12 2 ½ 63 670 5

Opening width of water pump pliers.

Maximum gripper width across flats [mm] Maximum gripper pipe diameter

Water pump pliers Industrial with push button adjustment.

to access areas.

to object to be gripped. Rapid and simple push button setting and locking. Long durability achieved by additional inductive hardening of gripper jaws.

in the installation area.

NEW

[

]

Order-No. Series 30824 Z 99 0 006 02 1

NEW

Z 99 0 005 02VH

Design: Pliers made of high quality tool steel, hardened,

Content: 2x combination pliers, 180 mm (Z 01 0 02 series)

Application: The pliers selection for demanding users in trade and industry.

Industrial pliers display. Card display with 10 pieces.

polished and chrome plated. Multi-component handles with slip guard for safe and comfortable operation.

2x high-leverage combination pliers, 200 mm (Z 02 0 02 series) 2x needle nose pliers, 160 mm (Z 05 0 02 series) 2x diagonal cutters, 160 mm (Z 12 0 02 series) 2x heavy-duty diagonal cutters, 180 mm (Z 16 0 02 series)

258

Order-No. Content 36065 1

EN_s230-281_Zangen_2012 15.02.12 17:43 Seite 259

Wiha Classic.

The complete workshop range.

For its outstanding design quality,

the new Wiha pliers generation

has received the

iF - prduct design award".

" In 2011, there was a focus

n the brand image.

Multiple polished heads

Anti-slip, oil and thinner resistant handle

www.wiha.com

Pipe, wire, sheet metal parts, cable, springs, nails, bolts and screws, safety rings, wire-end sleeves: the tool needs to be as diverse as the materials and tasks it faces in everyday work.

The most suitable prerequisites are supplied by the Wiha Basic range of pliers: over 80 pliers have been

in all possible application

tested scenarios. And Wiha continues to perfect them: DynamicJoint for example, the progressive development of the joint construction, ensures significantly easier cutting. And the precise Wiha MagicTips stabilise and protect the circlip pliers.

Wiha Basic – tried-and-true quality at a competitive price, with an appealing design.

Less force of power:

- 9,6 kg

- 12,6 kg

Body fully hardened

TÜV Süd test, October 2009

Competitors

All-round end cutting nippers for soft wire as well as for tough cutting of hard wire.

Up to 40% less force for cutting. The low expenditure of energy thanks to DynamicJoint is especially advantageous when cutting a large number of hard objects.

Wiha Classic.

Powerful

•

With DynamicJoint, the high quality joint construction for simple, long-term cutting eﬃciency

Extra rugged,

•

right up to the tips

With Wiha MagicTips, the precision tips that ensure a ﬁrm hold with unexcelled stability

As hard as steel

•

Pliers head drop forged from high quality steels

Robust and durable

•

Cutting edges are individually tempered and additionally induction hardened to approx. 64 HRC; joints are extremely wear resistant and withstand high stresses, with high-quality riveting

Ergonomic

•

An ergonomic handle shape for optimal handling

Attractive

•

An appealing design, with a multi-polished head

259

EN_s230-281_Zangen_2012 15.02.12 17:43 Seite 260

Wiha Classic.

The complete workshop range.

Combination pliers and high-leverage combination pliers.

Z 01 0 01

Standards:

Head shape: Extra long cutting edge for ﬂat and round cables. Design: OptiGrip - the newly designed gripping surface with 'triple-point support'

Material: High-quality tool steel, tempered. Application: General purpose pliers for gripping and holding as well as cutting

Order-No. 26703 160 6 ½ 3.0 2.0 160 5 26706 180 7 3.4 2.2 205 5 26709 200 8 3.6 2.5 280 5

Classic combination pliers.

DIN ISO 5746.

oft and hard wires and cables.

Long-ﬂat and needle nose pliers.

Z 07 0 01

Order-No. 26730 160 6 ½ 130 5

Z 09 0 01

Standards: DIN ISO 5745. Head shape: Extra long head. Design: Ridged gripping surfaces. Material: High-quality tool steel, tempered. Application: Gripping and bending of wires and sheet metal parts.

Classic long ﬂat-nose pliers.

Classic long round-nose pliers.

Z 02 0 01

Standards:

Head shape: Extra long cutting edge for ﬂat and round cables. Design: OptiGrip - the newly designed gripping surface with 'triple-point support'

Material: High-quality tool steel, specially tempered. Application:

Order-No. 26712 200 8 3.8 2.8 2.3 275 5 26715 225 9 4.2 3.0 2.5 330 5

Classic high-leverage combination pliers.

DIN ISO 5746.

Power assisted general purpose pliers for gripping and holding as well as cutting wires and cables ranging in hardness from soft to extremely hard.

Order-No. 26733 160 6 ½ 110 5

Wiha Info

Wiha DynamicJoint – Top of their class

•

Innovative: Unique joint construction

•

Effective: Low loss of force means

less force needed for cutting – up to 40%

•

Permanent: Optimal performance even after thousands of cuts

Wiha Info

NEW

Opti-Grip – optimal grip due to newly designed gripping surfaces

•

A firm hold: The 'triple-point support'

protects the workpiece from twisting or slipping.

•

Highly effective: Optimum grip even with a large jaw opening –

and at the same time significantly less force needed

•

A wide selection: Now in standard Wiha combination pliers

and high leverage combination pliers

260

EN_s230-281_Zangen_2012 15.02.12 17:43 Seite 261

Safety note:

When working with cutting pliers – beware of wire ends ﬂying away. Please wear safety glasses.

www.wiha.com

Needle nose and round-nose pliers.

Z 05 0 01

Standards: DIN ISO 5745. Head shape: Straight shape. Design: Extra long cutting edge for ﬂat and round cables.

Material: High-quality tool steel, tempered. Application: Gripping and holding as well as cutting soft and hard wires and cables.

Order-No. 26718 160 6 ½ 2.5 1.8 120 5 26721 200 8 2.8 2.0 165 5

Z 05 1 01

Standards: DIN ISO 5745. Head shape: Angled, approx. 40°. Design: Extra long cutting edge for ﬂat and round cables.

Material: High-quality tool steel, tempered. Application: Gripping and holding as well as cutting soft and hard wires and cables.

Order-No. 26723 160 6 ½ 2.5 1.8 120 5 26725 200 8 2.8 2.0 165 5

Classic needle nose pliers with cutting edge.

Gripping surfaces partially serrated in parts. Cutting edges additionally induction hardened to approx. 62 HRC.

Preferred choice in the mechanical sector.

Classic needle nose pliers with cutting edge.

Gripping surfaces partially serrated in parts. Cutting edges additionally induction hardened to approx. 62 HRC.

Preferred choice in the mechanical sector.

Precision mechanic and diagonal cutters.

Z 44 3 01

Standards: DIN ISO 5749. Head shape: Semi-circular, swedish style. Design: Low wear lap joint, riveted and able to withstand high loads.

Material: High-quality tool steel, tempered. Application: For almost ﬂush cutting of soft and semi-hard wires.

Order-No. 36189 125 6½ 2 0.8 65 5

Z 12 0 01

Standards: DIN ISO 5749. Head shape: Semi-circular, swedish style. Design: Low wear lap joint, riveted and able to withstand high loads.

Material: High-quality tool steel, tempered. Application: For cutting of soft and hard wire.

Order-No. 26738 140 5 ½ 4.0 2.5 1.8 130 5 26739 160 6 ½ 4.0 2.8 2.0 170 5 26742 180 7 4.0 3.0 2.5 220 5

Classic precision mechanic's diagonal cutters with spring.

ightweight action, clean cutting achieved by specially

milled precision cutting edges.

Long term cutting is achieved through additional inductive hardening

to approx. 60 HRC.

With spring and opening limit for effortless, sensitive working.

Classic diagonal cutters.

The Wiha DynamicJoint ensures optimal transmission of hand strength

to the cutting edges. Lightweight action, clean cutting achieved by

specially milled precision cutting edges. Durable cutting edges due to

additional induction hardening

to approx. 62 HRC.

NEW

Z36001

Standards: DIN ISO 5745. Head shape: Straight shape. Design: Gripping surfaces partially serrated in parts.

Material: High-quality tool steel, tempered. Application: Grip and hold as well as cut soft and hard wires and cables,

Order-No. 36483 160 6½ 2 1.2 95 5

Precision mechanic's needle nose pliers with cutting edge and spring.

Cutting edges additionally induction hardened to approx. 62 HRC. With spring and opening limit for effortless, sensitive working.

popular for precision mechanics and model-making applications.

Z 16 0 01

Standards: DIN ISO 5749. Head shape: Semi-circular. Design: Low wear lap joint, riveted and able to withstand high levels of load.

Material: High-quality tool steel, specially tempered. Application: Power-assisted all-round diagonal cutter for cutting

Order-No. 26746 160 6 ½ 3.5 2.5 2.0 160 5 26749 180 7 3.8 2.7 2.3 220 5 26752 200 8 4.2 3.0 2.5 275 5

Classic heavy-duty diagonal cutters.

The Wiha DynamicJoint ensures optimal transmission of hand strength

to the cutting edges. Lightweight action, clean cutting achieved by

specially milled precision cutting edges.

Long term cutting is achieved through additional inductive hardening

to approx. 64 HRC.

soft to extremely hard wires and cables.

261

EN_s230-281_Zangen_2012 15.02.12 17:43 Seite 262

Wiha Classic.

The complete workshop range.

Cable cutter, wire-end sleeve and stripping pliers.

Z 50 1 01

Head shape: Classic cutting form. Design: Light, energy-saving and clean cutting with specially ground precision

Material: High-quality tool steel, tempered. Application: Cable cutter for cutting of copper and aluminium cables without crushing,

Order-No. 34729 160 6 ½ 16 50 150 5 34730 200 8 20 60 270 5

Classic cable cutter pliers.

cutting edges. Durable cutting edges due to additional induction hardening to approx. 62 HRC. Safety stop prevents ﬁnger injuries after cutting.

also suitable for stripping. Not for steel cable, wires and copper conductors with hard coatings.

Standards: DIN ISO 8976. H Design: Precision adjustment joint, box type, providing optimum adaptation

Material: Chrome vanadium tool steel, tempered. Application: For gripping and holding pipes and angular proﬁles such as hex nuts

Water pump pliers.

21 0 01

ead shape: Narrow head, therefore also appropriate for work in small spaces.

Order-No. 26760 180 7 1 30 145 5 26761 250 10 2 50 345 5 26763 300 12 2 ½ 63 555 5

Classic water pump pliers, box type.

to object to be gripped. Long durability achieved by additional inductive hardening of gripper jaws.

in the installation area.

Z 60 0 01

Standards: DIN ISO 5743. Head shape: Fixed proﬁle grooves for the relevant conductor cross-sections. Design: Trapezoidal or semi-circular proﬁles for a secure connection between

Material: High-quality tool steel, tempered. Application: For crimping end sleeves acc. to DIN 46228 parts 1 + 4.

Order-No. 28330 145 5 ¾ 0.25-2.5 130 5 30066 180 7 0.25-16 250 5

Z 55 0 01

Standards: DIN ISO 5743. Head shape: Precision cutting edge prism for even cutting of cable insulation. Design: An easy to use adjusting screw allows the stripping diameter to be set.

Material: High-quality tool steel, tempered. Application: Simple stripping of cables and strands of up to ø 5 mm/ 10 mm²

Order-No. 26845 160 6 ½ 125 5

Classic crimping pliers.

end sleeve and conductor. Sleeve and conductor inserted from the side.

Classic stripping pliers.

Opening spring for effortless and sensitive handling of pliers.

conductor cross-section.

Z 22 0 01

Standards: DIN ISO 8976. Head shape: Extra narrow head, therefore also appropriate for work in difﬁcult

Design: Precision adjustment joint, box type, providing optimum adaptation

Material: Chrome vanadium tool steel, tempered. Application: For gripping and holding pipes and angular proﬁles such as hex nuts

Order-No. 26764 180 7 1 30 150 5 26765 250 10 2 50 365 5 26767 300 12 2 ½ 63 570 5

Z 23 0 01

Standards: DIN ISO 8976. Head shape: Narrow head, therefore also appropriate for work in small spaces. Design: Fast and easy-to-adjust water pump pliers, with automatic adjustment

Material: Chrome vanadium tool steel, tempered. Application: For rapid and optimum gripping and holding of pipes and angular proﬁles

Classic water pump pliers with push button adjustment.

to access areas.

to object to be gripped. Rapid and simple push button setting and locking. Long durability achieved by additional inductive hardening of gripper jaws.

in the installation area.

QuickFix Classic water pump pliers, box type.

of the box type, precision-stepped joint. Optimum adjustment to the object to be gripped. Long durability achieved by additional inductive hardening of gripper jaws.

such as hex nuts in the installation area.

262

Order-No. 26768 250 10 1 ½ 40 360 5

EN_s230-281_Zangen_2012 15.02.12 17:43 Seite 263

Safety note:

When working with cutting pliers – beware of wire ends ﬂying away. Please wear safety glasses.

www.wiha.com

End cutting nippers and pincers.

Z 17 0 01

Standards: DIN ISO 5748. Head shape: Classic style. Design: Low wear lap joint, riveted and able to withstand high levels of load.

Material: High-quality tool steel, tempered. Application: Power assisted, all round diagonal cutter for soft wires as well as

Order-No. 26757 160 6 ½ 3.5 2.5 180 5

6758

2 26759 200 8 4.0 3.0 220 5

lassic heavy-duty end cutting nippers.

Striking high quality cutting edge with high cutting performance and low application of force due to highly precise processing. Good durability due to additional induction hardening of cutting edges to approx. 62 HRC.

demanding piano wires. Also appropriate for binding (plaiting) and cutting wire netting in reinforced concrete structures.

7 3.82.82

Monier pliers (rabitz pliers).

Z 31 0 01

Standards: DIN ISO 9242. Head shape: Classic style. Design: Low wear lap joint, riveted and able to withstand high levels of load.

Material: High-quality tool steel, tempered. Application: For binding (plaiting) and cutting wire netting in reinforced concrete

Order-No. 26774 220 8 ¾ 3.2 2.0 360 5 26776 250 10 3.5 2.2 425 5 26778 280 11 3.8 2.4 460 5

6780

lassic Monier pliers (rabitz pliers).

High quality cutting edge with high cutting performance and

low application of force due to highly precise processing.

Good durability due to additional induction hardening of cutting edges

to approx. 62 HRC.

structures in a single operation.

3.82.44

Z 30 0 01

Standards: DIN ISO 9243. Head shape: Classic style. Design: Low wear lap joint, riveted and able to withstand high levels of load.

Material: High-quality tool steel, tempered. Application: For withdrawing and cutting nails and wire pins.

Order-No. 26771 180 7 265 5 26772 200 8 350 5

Opening width of water pump pliers.

Maximum gripper width across flats [mm] Maximum gripper pipe diameter

Classic pincers (grip, edge pliers).

]

[

Z 31 0 00

Standards: DIN ISO 9242. Head shape: Classic style. Design: High quality cutting edge with high cutting performance and

Material: High-quality tool steel, tempered. Application: For binding (plaiting) and cutting wire netting in reinforced concrete

Order-No. 26773 220 8 ¾ 3.2 2.0 350 5 26775 250 10 3.5 2.2 415 5 26777 280 11 3.8 2.4 450 5 26779 300 12 3.8 2.4 475 5

Classic Monier pliers (rabitz pliers).

low application of force due to highly precise processing.

Good durability due to additional induction hardening of cutting edges

to approx. 62 HRC.

structures in a single operation.

Wiha Info

Since pliers have moving parts and sometimes have bright steel parts, they require a certain amount of care:

Therefore keep the joints of the pliers as clean as possible and occasionally give them and the bright surfaces a drop of low viscosity oil which does not contain acid or resin.

You will then be able to enjoy your Wiha quality pliers for a long time to come.

263

EN_s230-281_Zangen_2012 15.02.12 17:43 Seite 264

Wiha Classic.

The complete workshop range.

Circlip pliers for bores (internal).

Z 33 0 01

Standards: DIN ISO 5256. Head shape: Straight shape. Design: Drop forged, cylindrical precision tips. Material: Chrome-vanadium tool steel. Application: For inserting / removing circlips from inside bores.

Order-No. 26781 J 0 139 58-13 95 5 26782 J 1 140 5 12-25 95 5 26783 J 2 180 7 19-60 155 5 26784 J 3 225 9 40-100 245 5 29425 J 4 310 12 85-140 410 5

Classic circlip pliers for inner rings (bores).

Circlip pliers for shafts (external).

34 0 01

Standards: DIN ISO 5254. Head shape: Straight shape. Design: Drop forged, cylindrical precision tips. Material: Chrome-vanadium tool steel. Application: For ﬁtting / removing circlips externally to / from shafts or axles.

Order-No. 26789 A 0 139 53-10 90 5 26790 A 1 140 5 10-25 90 5 26791 A 2 180 7 19-60 155 5 26792 A 3 225 9 40-100 260 5 29428 A 4 310 12 85-140 455 5

Classic circlip pliers for outer rings (shafts).

Z 33 1 01

Standards: DIN ISO 5256. Head shape: Angled form. Design: Drop forged, cylindrical precision tips. Material: Chrome-vanadium tool steel. Application: For inserting / removing circlips from inside bores.

Order-No. 26785 J 01 139 58-13 95 5 26786 J 11 140 5 12-25 95 5 26787 J 21 180 7 19-60 155 5 26788 J 31 225 9 40-100 245 5 29427 J 41 310 12 85-140 410 5

Classic circlip pliers for inner rings (bores).

Wiha Info

Wiha MagicTips – Top of their class

•

Maximum grip: The special latching function preventing jumping away

of the safety rings makes the Wiha circlip pliers truly unique

•

Hard as steel: Additional hardening of tips means high wear resistance

and therefore excellent durability

•

Surface refined: Protected against rust

•

Precise: Precision tips of special high performance steel

for maximum grip and high stability

Z 34 1 01

Standards: DIN ISO 5254. Head shape: Angled form. Design: Drop forged, cylindrical precision tips. Material: Chrome-vanadium tool steel. Application: For ﬁtting / removing circlips externally to / from shafts or axles.

Order-No. 26794 A 01 139 53-10 90 5 26795 A 11 140 5 10-25 90 5 26796 A 21 180 7 19-60 155 5 26797 A 31 225 9 40-100 260 5 29429 A 41 310 12 85-140 455 5

Special latching function prevents jumping away of the safety rings

Classic circlip pliers for outer rings (shafts).

264

EN_s230-281_Zangen_2012 15.02.12 17:43 Seite 265

www.wiha.com

Circlip pliers for bores (internal).

Z 33 4 01

Standards: DIN ISO 5256. Head shape: Straight shape. Design: Wiha MagicTips – highly resilient precision tips manufactured

Material: Chrome vanadium tool steel, tempered. Application: For inserting / removing circlips from inside bores.

Order-No. 34688 J 0 140 58-13 95 5 34689 J 1 140 5 12-25 95 5 34690 J 2 • 180 7 19-60 155 5 34691 J 3 • 220 9 40-100 245 5 34692 J 4 • 305 12 85-140 410 5

• with safety latching function

Classic circlip pliers for inner rings (bores).

from best ball-bearing steel. With special surface ﬁnish to protect against rust and with a unique latching function (from size 2) that effectively prevents jumping away of the safety rings. High wear resistance with additional hardening of tips. Slim plier head for optimal access and a good view of the workpiece.

Circlip pliers for shafts (external).

Z 34 4 01

Standards: DIN ISO 5254. Head shape: Straight shape. Design: Wiha MagicTips – highly resilient precision tips manufactured

Material: Chrome vanadium tool steel, tempered. Application: For ﬁtting / removing circlips externally to / from shafts or axles.

Order-No. 34698 A 0 140 57-10 90 5 34699 A 1 140 5 10-25 90 5 34700 A 2 • 185 7 19-60 155 5 34701 A 3 • 240 9 40-100 260 5 34702 A 4 • 300 12 85-140 455 5

• with safety latching function

lassic circlip pliers for outer rings (shafts).

from best ball-bearing steel.

With special surface ﬁnish to protect against rust and with a unique

latching function (from size 2) that effectively prevents jumping away

of the safety rings.

High wear resistance with additional hardening of tips.

Slim plier head for optimal access and a good view of the workpiece.

Spring protected in the joint, cannot be lost.

Z 33 5 01

Standards: DIN ISO 5256. Head shape: Angled form. Design: Wiha MagicTips – highly resilient precision tips manufactured

Material: Chrome vanadium tool steel, tempered. Application: For inserting / removing circlips from inside bores.

Order-No. 34693 J 01 140 58-13 95 5 34694 J 11 140 5 12-25 95 5 34695 J 21 • 180 7 19-60 155 5 34696 J 31 • 220 9 40-100 245 5 34697 J 41 • 305 12 85-140 410 5

• with safety latching function

Classic circlip pliers for inner rings (bores).

from best ball-bearing steel. With special surface ﬁnish to protect against rust and with a unique latching function (from size 21) that effectively prevents jumping away of the safety rings. High wear resistance with additional hardening of tips. Slim plier head for optimal access and a good view of the workpiece.

Z 34 5 01

Standards: DIN ISO 5254. Head shape: Angled form. Design: Wiha MagicTips – highly resilient precision tips manufactured

Material: Chrome vanadium tool steel, tempered. Application: For ﬁtting / removing circlips externally to / from shafts or axles.

Order-No. 34703 A 01 140 57-10 90 5 34704 A 11 140 5 10-25 90 5 34705 A 21 • 185 7 19-60 155 5 34706 A 31 • 240 9 40-100 260 5 34707 A 41 • 300 12 85-140 455 5

• with safety latching function

Classic circlip pliers for outer rings (shafts).

from best ball-bearing steel.

With special surface ﬁnish to protect against rust and with a unique

latching function (from size 21) that effectively prevents jumping away

of the safety rings.

High wear resistance with additional hardening of tips.

Slim plier head for optimal access and a good view of the workpiece.

Spring protected in the joint, cannot be lost.

265

EN_s230-281_Zangen_2012 15.02.12 17:43 Seite 266

Wiha Classic.

The complete workshop range.

Pipe wrenches swedish style.

Z 26 0 00

Standards: DIN 5234. Head shape: S-jaw shape angled 45°. Design: Self-clamping gripping of pipes and hex nuts at 3 points.

Material: Chrome-vanadium steel, tempered. Application: Safe and secure grip on pipes and hex nuts.

Order-No. 29435 320 1 0-40 750 1 29436 420 1 ½ 0-55 1350 1 29437 535 2 0-67 2450 1

Classic corner pipe pliers, S-jaw.

orsion-free handle proﬁle.

T Adjusting nut secured to prevent loss. Long durability achieved by additional inductive hardening of gripper jaws.

Pipe wrenches swedish style.

Z 26 2 00

Standards: DIN 5234. Head shape: Swedish shape angled 90°. Design: Safe and secure grip due to teeth that are offset against the direction

Material: Chrome-vanadium steel, tempered. Application: Safe and secure grip on pipes, ﬂat workpieces and nuts.

Order-No. 29441 320 1 0-40 750 1 29442 415 1 ½ 0-55 1250 1 29443 555 2 0-67 2450 1

Classic corner pipe pliers, 90°.

f rotation.

o Torsion-free handle proﬁle. Adjusting nut secured to prevent loss. Long durability achieved by additional inductive hardening of gripper jaws.

Z 26 1 00

Standards: DIN 5234. Head shape: Swedish shape angled 45°. Design: Safe and secure grip due to teeth that are offset against the direction of

Material: Chrome-vanadium steel, tempered. Application: Safe and secure grip on pipes, ﬂat workpieces and nuts.

Order-No. 29438 315 1 0-40 750 1 29439 420 1 ½ 0-55 1240 1 29440 570 2 0-67 2500 1

Classic corner pipe pliers, 45°.

rotation. Torsion-free handle proﬁle. Adjusting nut secured to prevent loss. Long durability achieved by additional inductive hardening of gripper jaws.

Symbols.

Details of cutting results of cutting pliers.

Test wires standardised in DIN ISO 5744

Dimensions.

Maximum gripper width across flats Maximum gripper pipe diameter Opening width, flat Clamping range Retaining ring, external Retaining ring, internal

Jaw style: Cutter style:

Flat jaws

Half round jaws

Round jaws

Cutter without bevel

Cutter with small bevel

Cutter with bevel

Center cutter

Scissors cutter

Anvil cutter

Stripper

266

EN_s230-281_Zangen_2012 15.02.12 17:43 Seite 267

www.wiha.com

Grip pliers.

Z 66 0 00

Head shape: Bent gripper jaws with wire cutter. Design: Single-handed operation with quick-release lever,

Material: Forged jaws made of chrome-vanadium-steel.

Application: Clamping and gripping of round and ﬂat material.

Order-No. 29485 180 7 8-30 0-20 360 5 29486 250 10 8-40 0-20 530 5 29487 300 12 8-65 0-30 1000 5

Classic grip pliers with wire cutter.

adjusting screw and integrated wire cutter.

Body of pliers made of high-resistance special steel, nickel-plated.

Wire cutter for cutting welded wires.

Grip pliers.

Z 67 1 00

Head shape: U-shaped, with two supporting surfaces. Design: Single-handed operation with quick-release lever and adjusting screw. Material: Clamping jaw made of robust and heat-resistant cast iron.

Application: Clamping and gripping of adjacent round materials during welding.

Order-No. 29489 280 11 10-72 912 2

Classic pipe welder grip pliers.

ody of pliers made of high-resistance special steel, nickel-plated.

Z 67 0 00

Head shape: U-shaped, with two supporting surfaces. Design: Single-handed operation with quick-release lever and adjusting screw. Material: Clamping jaw made of robust and heat-resistant cast iron.

Application: Clamping and gripping of adjacent proﬁled or ﬂat materials during welding.

Order-No. 29488 280 11 35-65 0-25 900 2

Opening width of grip pliers.

Maximum gripper width across flats [mm] Maximum opening width at jaw flats [mm]

Classic welder grip pliers.

Body of pliers made of high-resistance special steel, nickel-plated.

Z 67 2 00

Head shape: C-shaped, with rounded supporting surface. Design: Single-handed operation with quick-release lever and adjusting screw. Material: Forged jaws made of chrome-vanadium-steel.

Application: Clamping and gripping of awkward-shaped workpieces or sections

Order-No. 29490 280 11 0-90 660 2

Classic proﬁle welder grip pliers (clamp grip pliers).

Body of pliers made of high-resistance special steel, nickel-plated.

with high ridges.

Proﬁle height up to 40 mm, proﬁle depth up to 50 mm.

267

EN_s230-281_Zangen_2012 15.02.12 17:43 Seite 268

Wiha Classic.

The complete workshop range.

Pliers sets.

Z 99 0 001 01

Design: All pliers made of high-quality tool steel, hardened.

Content: Combination pliers, series Z 01 0 01, 180 mm

Application: Standard set of pliers for the basic set of tools.

Order-No. Series 26850 Z 99 0 001 01 1

Classic pliers set, 3-pcs.

Head of pliers polished several times and non-slip, oil- and solvent-resistant handle coating. Weight 630 g.

- with Wiha DynamicJoint and OptiGrip Diagonal cutters, series Z 12 0 01, 160 mm

- with Wiha DynamicJoint Needle nose pliers, series Z 05 0 01, 160 mm

Tool set.

Z 99 0 003 01

Design: All pliers made of high-quality tool steel, hardened.

Content: Professional combination pliers, 180 mm (Z 01 0 05 series)

Application: The basic set of pliers and screwdrivers for demanding craftsmen and

Classic Mix tool set, 5-pcs.

Head of pliers polished several times and non-slip, oil- and solvent-resistant handle coating. Screwdrivers with round blades, chrome-plated, tips with Wiha ChromTop Multi-component handles with slip guard for safe and comfortable operation. Weight 745 g.

– with Wiha DynamicJoint and OptiGrip Diagonal cutters, series Z 12 0 01, 160 mm

- with Wiha DynamicJoint

Wiha SoftFinish

- slotted screwdriver, series 302: 5,5x125

- Phillips screwdriver, series 311: PH1x80 / PH2x100

industrial mechanics.

ChromTop

screwdriver with round blade and

blade tip.

Z 99 0 002 01

Design: All pliers in proven Classic quality.

Content: High leverage combination pliers, series Z 02 0 01, 200 mm

Application: Power-assisted set of pliers as part of basic set of tools.

Order-No. Series 26853 Z 99 0 002 01 1

268

Classic Plus pliers set, 3-pcs.

Cutting pliers also suitable for piano wire. QuickFix water pump pliers with "automatic" rapid adjustment. Weight 1025 g.

- with Wiha DynamicJoint and OptiGrip High leverage diagonal cutters, series Z 16 0 01, 180 mm

- with Wiha DynamicJoint

QuickFix water pump pliers, series Z 23 0 01, 250 mm

Order-No. Series 26855 Z 99 0 003 01 1

Wiha Info

NEW

Opti-Grip – optimal grip due to newly designed gripping surfaces

•

A firm hold: The 'triple-point support'

protects the workpiece from twisting or slipping.

•

Highly effective: Optimum grip even with a large jaw opening –

and at the same time significantly less force needed

•

A wide selection: Now in standard Wiha combination pliers

and high leverage combination pliers

Wiha Info

Wiha DynamicJoint – Top of their class

•

Innovative: Unique joint construction

•

Effective: Low loss of force means

less force needed for cutting – up to 40%

•

Permanent: Optimal performance even after thousands of cuts

EN_s230-281_Zangen_2012 15.02.12 17:44 Seite 269

www.wiha.com

Pliers sets.

Z 99 0 004 01

Design: All pliers in proven Classic quality.

Content: Circlip pliers for bores, series Z 33 0 01, J10

Application: Set of pliers as basic set of tools for attaching retaining rings to and

Order-No. Series 26793 Z 99 0 004 01 1

Classic Circlip pliers set, 4-pcs.

Particularly precise tips due to high-speed turning, cylindrical with deﬁned ﬂat cone point. Tightened with great dimensional accuracy and not subsequently curved. Weight 680 g.

Circlip pliers for bores, series Z 33 0 01, J20 Circlip pliers for shafts, series Z 34 0 01, A10 Circlip pliers for shafts, series Z 34 0 01, A20

removing them from shafts and boreholes.

Display.

NEW

Z 99 0 005 01VH

Design: Pliers of high quality tool steel, hardened and polished.

Content: 3x circlip pliers for bores (Z 33 4 01, J10, J20, J30 series)

Application: The pliers selection for common demands when applying and

MagicTips pliers display, 30 pcs.

Wiha MagicTips – highly resilient precision tips manufactured

from best ball-bearing steel.

With special surface ﬁnish to protect against rust and with a unique

latching function (from size 2) that effectively prevents jumping away

of the safety rings.

High wear resistance with additional hardening of tips.

3x circlip pliers for bores (Z 33 5 01, J11, J21, J31 series)

3x circlip pliers for shafts (Z 34 4 01, A20, A30 series)

3x circlip pliers for shafts (Z 34 5 01, A21, A31 series)

removing safety rings to shafts and in bores.

Mit Teststation direkt am Display

Z 99 0 007 01

Design: Wiha MagicTips – highly resilient precision tips manufactured

Content: Circlip pliers for bores, series Z 33 4 01, J10

Application: Set of pliers as basic set of tools for attaching retaining rings to and

Order-No. Series 34708 Z 99 0 007 01 1

Classic Circlip pliers set, 4-pcs.

from best ball-bearing steel. High wear resistance with additional hardening of tips. Slim plier head for optimal access and a good view of the workpiece. Weight 650 g.

– with Wiha MagicTips Circlip pliers for bores, series Z 33 4 01, J20 – with Wiha MagicTips Circlip pliers for shafts, series Z 34 4 01, A10 – with Wiha MagicTips Circlip pliers for shafts, series Z 34 4 01, A20 – with Wiha MagicTips

removing them from shafts and boreholes.

Order-No. Series 36064 Z 99 0 005 01VH 1

Wiha Info

Wiha MagicTips – Top of their class

•

Maximum grip: The special latching function preventing jumping away

of the safety rings makes the Wiha circlip pliers truly unique

•

Hard as steel: Additional hardening of tips means high wear resistance and

therefore excellent durability

•

Surface refined: Protected against rust

•

Precise: Precision tips of special high performance steel

for maximum grip and high stability

269

EN_s230-281_Zangen_2012 15.02.12 17:44 Seite 270

Wiha Electronic.

Precision for made-to-measure work.

Glare free gunmetal ﬁnish

Precision ground cutting edges

Arms made of soft, non-slip elastomer are gentle on the parts of the hand that are sensitive to pressure

Hard, comfortable elastomer zones ensure low friction in the movement range of the ﬁngers

Harmonious design of the front part of the handle for an optimum ﬁnger hold

The robust, ergonomic handle is carefully ﬁxed to the pliers

A calm hand is essential for working with electronic components. The Wiha Electronic pliers optimally support the user in this respect.

The sophisticated details are conspicuous: ground, razor-sharp cutting edges for smooth cuts. A handle shape that correctly positions the hand of the user. A glare-free, ﬁnely pressed pliers head for precise, safe grasping and cutting.

And all with an excellent quality and at a competitive price to which both professionals and demanding handymen will not be able to say no to.

The Electronic long-nose pliers from Wiha hold small components and bend wires.

Wiha Electronic.

Specially for ﬁne work

•

Glare-free, phosphate coated head, applied precision joint

Precise

•

Precisely ground cutting edges

As hard as steel

•

Finely pressed from high grade C70 steel

Robust and durable

•

Cutting edges are additionally hardened up to 63 HRC

Sensitive

•

Greater control with grasping via opening spring with ﬁne resistance

Ergonomic

•

An innovative handle shape for optimal handling

270

EN_s230-281_Zangen_2012 15.02.12 17:44 Seite 271

Safety note:

When working with cutting pliers – beware of wire ends ﬂying away. Please wear safety glasses.

www.wiha.com

Diagonal cutters, wide shape.

0,0

13,5

Z 41 1 03

Head shape: Wide, pointed head. Design: Cutting edge with full ﬂush cutter function.

Material: C 70 special tool steel. Application: For an absolutely ﬂush cut of soft wires in the electronics industry.

Order-No. 26818 138 5 ½ 1.3 70 5

Diagonal cutters Electronic.

With opening spring.

5,0

10,0

13,5

Diagonal cutters, wide shape with wire trapping spring.

10,0

13,5

41 6 03

Head shape: Wide, pointed head. Design: Cutting edge with full ﬂush cutter function.

Material: C 70 special tool steel.

Application: For an absolutely ﬂush cut of soft wires in the electronics industry.

Order-No. 26825 138 5 ½ 1.3 80 5

Diagonal cutters Electronic with wire trapping spring.

With opening spring and ﬁxture for collecting ends

of wires that have been cut off.

Cutting edges approx. 56 HRC.

6,0

Z 41 3 03

Standards: DIN ISO 9654. Head shape: Wide, pointed head. Design: Cutting edge with semi-ﬂush cutter function,

Material: C 70 special tool steel.

Application: Universal small diagonal cutter for cutting soft and medium hard wires in

Order-No. 26815 138 5 ½ 2.0 0.8 80 5

Details of cutting results of cutting pliers.

Test wires standardised in DIN ISO 5744

Diagonal cutters Electronic.

thus also appropriate for medium hard wires. Strong design for soft wires up to ø 2.0 mm. With opening spring.

Cutting edges > 60 HRC.

the electronics and precision mechanical engineering industries.

6,0

Wiha Info

Electronics pliers with cutting edges are designed especially for cutting soft to medium hard wires.

The diameters of materials which your electronics pliers are able to cut depend not only on the material selected and the hardness of the cutting edges but also depend greatly on the geometry of the cutting edges:

• Pliers with the full flush cutter function may cut off wires smoothly and flushly but are only appropriate for soft copper wires (99.85% pure copper)

• Pliers with the semi-flush and normal bevelled cutting edges function on the other hand may not cut in a totally flush manner but can cut thin iron wires or even medium hard steel wire

• You will find details of precise cutting results in the individual figures of pliers

271

EN_s230-281_Zangen_2012 15.02.12 17:44 Seite 272

Wiha Electronic.

Precision for made-to-measure work.

Diagonal cutters, narrow shape.

8,0

9,5

Z 40 0 03

Head shape: Extra narrow, short head for working in particularly restricted spaces. Design: Cutting edge with full ﬂush cutter function.

Material: C 70 special tool steel. Application: For absolutely ﬂush cutting of soft wires in places

Order-No. 26812 118 4 ½ 0.8 60 5

Z 40 1 03

Head shape: Narrow, pointed head. Design: Cutting edge with full ﬂush cutter function.

Material: C 70 special tool steel. Application: For absolutely ﬂush cutting of soft wires in places

icro diagonal cutter Electronic.

With opening spring.

which are difﬁcult to access in the electronics industry.

Diagonal cutters Electronic with wire trapping spring.

With opening spring and ﬁxture for collecting ends of wires that have been cut off.

which are difﬁcult to access in the electronics industry.

4,0

8,0

10,0

5,0

Diagonal cutters.

10,0

13, 5

Z 46 0 03

Head shape: Wide, pointed head. Design: Cutting edge with full ﬂush cutter function.

Material: C 70 special tool steel. Application: For absolutely ﬂush cutting of soft wires in places

Order-No. 26833 138 5 ½ 1.3 70 5

Z 46 0 03

Head shape: Extremely narrow, short head for working in particullarly restricted spaces. Design: Cutting edge with full ﬂush cutter function.

Material: C 70 special tool steel. Application: For absolutely ﬂush cutting of soft wires in places

blique cutting nippers Electronic.

With cutting edge at 48° for cutting obliquely from above or from the side.

which are difﬁcult to access in the electronics industry.

3,5

Micro oblique cutting nippers Electronic.

Edge at 30° to face end of pliers for cutting obliquely from above or from the side.

which are difﬁcult to access in the electronics industry.

5,0

10,0

4,0

Order-No. 26813 128 5 1.0 70 5

272

Order-No. 26830 118 4 ½ 0.6 60 5

Details of cutting results of cutting pliers.

Test wires standardised in DIN ISO 5744

EN_s230-281_Zangen_2012 15.02.12 17:44 Seite 273

www.wiha.com

Needle nose pliers

20,0

13,0

Z 36 0 03

Head shape: Narrow, short head. Design: With plain inside jaws.

Material: C 70 special tool steel. Application: For holding small components as well as for holding and angling wires.

Order-No. 26801 135 5 ½ 70 5

ointed pliers Electronic.

Width at tip is only 1.2 mm.

1, 2

6,0

Stripping pliers.

40,0

Z 49 2 03

Head shape: Wide, long head with ridged gripping surface,

Design: Wire stripping stations:

Material: C 70 special tool steel. Application: For gripping, cutting and stripping of wires with diameter.

Order-No. 33471 180 7 0.81 - 2.59 20 - 10 70 5

lectronic stripping pliers.

shears blade and ﬁrm wire stripping stations.

0.8 / 1.0 / 1.3 / 1.6 / 2.0 / 2.6 mm, AWG 20 / 18 / 16 / 14 / 12 / 10. With opening spring and locking mechanism.

40,0

28,9

Wiha Info

A variety of different pliers are required for electronics applications.

Simply contact us if you require different models for other applications.

Z 49 7 03

Head shape: Wide, long head with ridged gripping surface,

Design: Wire stripping stations:

Material: C 70 special tool steel. Application: For gripping, cutting and stripping of wires with diameter.

Order-No. 33472 180 7 0.4 - 1.3 26 - 16 70 5

Electronic stripping pliers.

shears blade and ﬁrm wire stripping stations.

0,4 / 0.5 / 0.6 / 0.8 / 1.0 / 1.3 mm, AWG 26 / 24 / 22 / 20 / 18 / 16. With opening spring and locking mechanism.

28,5

273

EN_s230-281_Zangen_2012 15.02.12 17:44 Seite 274

Wiha Professional ESD.

Precise in every detail.

Hard, comfortable elastomer zones

nsure low friction in the movement

e range of the ﬁngers

Double leaf spring for sensitive working

The anti-static, ergonomic handle is ﬁxed to the pliers

Low glare mirror polished ﬁnish

Wiha Professional ESD is ideal for electronics professionals needing precise, robust pliers.

The formula for success for the pliers series is as simple as it is clever: uncompromising sharpness and hardness for ﬂush cutting, and pleasant comfort with the handle for ﬁrm, fatigue-free grasping, holding and cutting.

274

Precision box joint with long service life

The Professional ESD diagonal cutter with a broad, pointed head cut soft wires ﬂush.

Antistatic arms made of soft, non-slip elastomer are gentle on the parts of the hand that are sensitive to pressure

The Professional ESD needle-nose pliers are predominantly used for ﬁne gripping and bending work.

Suitable for work at ESD workstations in accordance with IEC 61340-5-1.

Safety Notice: Wiha Professional ESD pliers are noninsulated, therefore not suitable for working on live parts.

Wiha Professional ESD.

ESD safe

•

Suitable for work at ESD workstations in accordance with IEC 61340-5-1, surface resistance 10

Anti-static

•

- 109ohms

Unique: all handle components are discharging (dissipative)

Precise

•

Box joint, resistant against twisting

As hard as steel

•

Pliers head drop forged from high quality steels

Robust and durable

•

Cutting edges are individually tempered and additionally induction hardened to approx. 64 HRC; joints are extremely wear resistant and withstand high stresses, with high-quality riveting

Ergonomic

•

Extra wide handle backs, with soft and hard zones perfectly distributed across the handle

Attractive

•

Appealing design with ﬁnely polished head

EN_s230-281_Zangen_2012 15.02.12 17:44 Seite 275

Safety note:

When working with cutting pliers – beware of wire ends ﬂying away. Please wear safety glasses.

www.wiha.com

Diagonal cutter, narrow, pointed shape.

10,5

9,5

6,0

Z 40 1 04

tandards: DIN ISO 9654. IEC 61340-5-1.

S Head shape: Narrow, pointed head. Design: Bevelled cutting edges, individually tested, also appropriate

Material: High alloy carbon steel C 60. Application: For cutting different hardnesses of wires in places

Order-No. 26808 115 4 ½ 1.0 0.6 0.3 60 5

Z 40 4 04

Standards: DIN ISO 9654. IEC 61340-5-1. Head shape: Extra narrow, short head for working

Design: Cutting edge almost without bevel for virtually ﬂush cutting, individually

Material: High alloy carbon steel C 60. Application: For virtually ﬂush cutting copper wire in ﬂat places

Order-No. 26814 115 4 ½ 1.0 60 5

Diagonal cutter Professional ESD.

for thin, hard wires. Maximum service life of cutting edge achieved through additional inductive hardening to approx. 64 HRC. With opening spring. Surface resistance 10

- 109ohms.

which are difﬁcult to access.

10,5

9,5

6,0

Diagonal cutter Professional ESD.

in particularly restricted spaces.

tested. Maximum service life of cutting edge achieved through additional inductive hardening to approx. 64 HRC. With opening spring. Surface resistance 10

- 109ohms.

which are difﬁcult to access.

Diagonal cutter, broad, pointed shape.

Z 41 1 04

Standards: DIN ISO 9654. IEC 61340-5-1. Head shape: Wide, pointed head. Design: Bevelled cutting edges, also appropriate for hard wires.

Material: High alloy carbon steel C 60. Application: All round electronic diagonal cutter for cutting wires

Order-No. 26816 115 4 ½ 1.4 1.0 0.4 60 5

Z 41 3 04

Standards: DIN ISO 9654. IEC 61340-5-1. Head shape: Wide, pointed head. Design: Cutting edge without bevel for absolute ﬂush cutting.

Material: High alloy carbon steel C 60. Application: For absolutely ﬂush cutting of copper wire.

Order-No. 26821 115 4 ½ 1.0 60 5

Diagonal cutter Professional ESD.

aximum service life of cutting edge achieved through additional inductive

M hardening to approx. 64 HRC. With opening spring. Surface resistance 10

- 109ohms.

of different hardnesses.

Diagonal cutter Professional ESD.

Maximum service life of cutting edge achieved through additional inductive hardening to approx. 64 HRC. With opening spring. Surface resistance 10

- 109ohms.

13,5

11, 5

7, 5

13,5

11, 5

7, 5

13,5

10,5

9,5

6,0

Z 40 3 04

Diagonal cutter Professional ESD.

Standards: DIN ISO 9654. IEC 61340-5-1. Head shape: Narrow, pointed head. Design: Blade without facet, individually inspected, suited to thin, tough wire.

Maximum service life of cutting edge achieved through additional inductive hardening to approx. 64 HRC. With opening spring. Surface resistance 10

- 109ohms. Material: High alloy carbon steel C 60. Application: For absolutely ﬂush cutting of copper wire in places

which are difﬁcult to access.

Order-No. 33521 115 4 ½ 1.0 60 5

11, 5

7, 5

Z 41 4 04

Diagonal cutters Professional ESD with wire trapping spring.

Standards: DIN ISO 9654. IEC 61340-5-1. Head shape: Wide, pointed head. Design: With ﬁxture for trapping ends of wires which have been cut off.

Cutting edge with full ﬂush cutter function for virtually ﬂush cutting. Maximum service life of cutting edge achieved through additional inductive hardening to approx. 64 HRC. With opening spring. Surface resistance 10

- 109ohms. Material: High alloy carbon steel C 60. Application: For virtually ﬂush cutting copper wire, function for trapping cut off wire.

Order-No. 26822 115 4 ½ 1.2 60 5

275

EN_s230-281_Zangen_2012 15.02.12 17:44 Seite 276

Wiha Professional ESD.

Precise in every detail.

Diagonal cutter, semi-circular shape.

10,5

9,5

Z 43 1 04

Standards: DIN ISO 9654. IEC 61340-5-1. Head shape: Narrow, semi-circular head. Design: Cutting edge with full ﬂush cutter function for virtually ﬂush cutting.

Material: High alloy carbon steel C 60. Application: For virtually ﬂush cutting of copper wire in places

Order-No. 26826 115 4 ½ 1.2 60 5

Z 44 1 04

Standards: DIN ISO 9654. IEC 61340-5-1. Head shape: Wide, semi-circular head. Design: Bevelled cutting edges, also appropriate for thin, hard wires.

Material: High alloy carbon steel C 60. Application: All round electronic diagonal cutter for cutting wires

Order-No. 26831 115 4 ½ 1.4 1.0 0.4 60 5

Diagonal cutter Professional ESD.

Maximum service life of cutting edge achieved through additional inductive hardening to approx. 64 HRC. With opening spring. Surface resistance 10

which are difﬁcult to access.

Diagonal cutter Professional ESD.

Maximum service life of cutting edge achieved through additional inductive hardening to approx. 64 HRC. With opening spring. Surface resistance 10

of different hardnesses.

- 109ohms.

6,0

13,5

11, 5

7, 5

Oblique end cutters.

10,0

12,0

14,0

7, 5

Z 46 1 04

Standards: DIN ISO 9654. IEC 61340-5-1. Head shape: Wide head, angled at 29°. Design: Cutting edge with full ﬂush cutter function for virtually ﬂush cutting.

Material: High alloy carbon steel C 60. Application: For virtually ﬂush cutting of soft wires.

Order-No. 26835 115 4 ½ 1.2 78 5

Z 46 4 04

Standards: DIN ISO 9654. IEC 61340-5-1. Head shape: Extra narrow head.

Design: Cutting edge with full ﬂush cutter function for virtually ﬂush cutting.

Material: High alloy carbon steel C 60. Application: For virtually ﬂush cutting thin, soft wires in places

Order-No. 26838 110 4 ¼ 0.6 42 5

Oblique end cutting nippers Professional ESD.

Maximum service life of cutting edge achieved through additional inductive hardening to approx. 64 HRC. With opening spring. Surface resistance 10

Can be used horizontally and virtically.

Oblique end cutting nippers Professional ESD.

Cutting edges angled at 40°.

Maximum service life of cutting edge achieved through additional inductive hardening to approx. 64 HRC. With opening spring. Surface resistance 10

which are particularly difﬁcult to access.

- 109ohms.

6,3

20,0

10,0

5,8

13,5

11, 5

7, 5

Z 44 3 04

Standards: DIN ISO 9654. IEC 61340-5-1. Head shape: Wide, semi-circular head. Design: Cutting edge with full ﬂush cutter function for virtually ﬂush cutting.

Material: High alloy carbon steel C 60. Application: For virtually ﬂush cutting of soft wires.

Order-No. 26832 115 4 ½ 1.2 60 5

276

Diagonal cutter Professional ESD.

Maximum service life of cutting edge achieved through additional inductive hardening to approx. 64 HRC. With opening spring. Surface resistance 10

- 109ohms.

19,0

6,5

2,8

Z 47 1 04

Standards: DIN ISO 9654. IEC 61340-5-1. Head shape: Extra narrow, slim shape. Design: Cutting edge with full ﬂush cutter function for virtually ﬂush cutting.

Material: High alloy carbon steel C 60. Application: For virtually ﬂush cutting of soft wires in places

Order-No. 26839 110 4 ¼ 0.6 65 5

End cutting nippers Professional ESD.

Maximum service life of cutting edge achieved through additional inductive hardening to approx. 64 HRC. With opening spring. Surface resistance 10

which are particularly difﬁcult to access.

- 109ohms.

5,8

EN_s230-281_Zangen_2012 15.02.12 17:44 Seite 277

www.wiha.com

End cutters and gripping pliers.

5,5

11, 5

16,5

7, 5

Z 47 2 04

Standards: DIN ISO 9654. IEC 61340-5-1. Head shape: Wide head. Design: Cutting edge with full ﬂush cutter function for virtually ﬂush cutting.

Material: High alloy carbon steel C 60. Application: For frontal, virtually ﬂush cutting of thicker, soft wires.

Order-No.

6840 115 4 ½1.4 65 5

Z 36 0 04

Standards: DIN ISO 9655. IEC 61340-5-1. Head shape: Straight head. Design: Fine, semi-circular tips. Ridged gripping surfaces.

Material: C 45 special tool steel, hardened and tempered. Application: Mainly for precision gripping and bending work.

End cutting nippers Professional ESD.

Maximum service life of cutting edge achieved through additional inductive hardening to approx. 64 HRC. With opening spring. Surface resistance 10

- 109ohms.

Needle nose pliers Professional ESD.

With opening spring. Surface resistance 10

- 109ohms.

Gripping pliers. Set combinations.

20,5

2,0

Z 37 0 04

Standards: DIN ISO 9655. IEC 61340-5-1. Head shape: Round, short jaws. Design: Smooth gripping surfaces. With opening spring.

Material: C 45 special tool steel, hardened and tempered. Application: Mainly for precision gripping and bending work.

Order-No. 26804 120 4 ¾ 60 5

Z 38 0 04

Standards: DIN ISO 9655. IEC 61340-5-1. Head shape: Flat, short jaws. Design: Smooth gripping surfaces. With opening spring.

Material: C 45 special tool steel, hardened and tempered. Application: Mainly for precision gripping and bending work.

Order-No. 26806 120 4 ¾ 60 5

Round nose pliers Professional ESD.

Surface resistance 10

- 109ohms.

Flat nose pliers Professional ESD.

Surface resistance 10

- 109ohms.

22,5

1, 4

9, 5

6,5

9, 5

6,5

Order-No. 26799 120 4 ¾ 9.5 23 6.5 1.4 60 5 27905 145 5 ¾ 12.0 40 7.5 2.0 93 5

22,5

1, 5

Z 36 1 04

Needle nose pliers Professional ESD.

Standards: DIN ISO 9655. IEC 61340-5-1. Head shape: Angled at 45°. Design: Fine, semi-circular tips. Smooth gripping surfaces.

With opening spring. Surface resistance 10

- 109ohms. Material: C 45 special tool steel, hardened and tempered. Application: Mainly for precision gripping and bending work.

Order-No. 26802 120 4 ¾ 60 5

Wiha Info

A variety of different pliers are required for electronics applications.

Simply contact us if you require different models for other applications.

9,5

6,5

Z 99 0 001 04

Professional ESD pliers set, 4 pcs. Dissipative tools, electrostatically discharging.

Design: ESD tools manufactured according to IEC 61340-5-1.

All pliers of high quality tool steel, hardened and ﬁne-polished. Plier handles electrostatically discharge via all components. Surface resistance 10

- 109ohms. Pouch: Light and space-saving storage of tools. Content: Diagonal cutter without facet, 115 mm (Z 41 3 04 series)

Diagonal cutter with facet, 115 mm (Z 44 1 04 series) Angular forward cutters, with minimal facet, 110 mm (Z 46 4 04 series) Electric needle nose pliers, 120 mm (Z 36 0 04 series)

Application: Universal set for all cutting work with electronic applications.

Order-No. Series 33507 Z 99 0 001 04 1

277

EN_s230-281_Zangen_2012 15.02.12 17:44 Seite 278

Wiha Professional ESD.

For high standards when it comes to precision and safety.

ESD coating

Depending on the application situation, the tweezers have extra ﬁne, strong or extremely rugged tips

The new assortment of Wiha electronic tweezers expands the possibilities for exact, and at the same time, careful work with electronic components. These precision, special or universal tweezers are rapidly becoming essential accessories for everyday electronics work due to their high-quality design: ESD safe (anti-static), anti-magnetic, stainless and acid-resistant. Unlike purely metal tweezers, the special coating here ensures a controlled dissipation of static charges, and therefore safe, standard-compliant use.

Anti-magnetic alloy made of chromium-nickel stainless steel

Thanks to its wide selection of tips, the Professional ESD precision tweezers handle even tricky work eﬀortlessly, for example on sensitive semiconductors.

Optimised spring tension and precise symmetry for a ﬁrm, secure grasp

Tweezers are important tools for any electronics technician to enable the necessary work to be carried out safely in the often small, conﬁned structures of PCBs.

Wiha Professional ESD.

ESD safe

•

Suitable for work at ESD workstations in accordance with IEC 61340-5-1, surface resistance 10

100% anti-magnetic

•

- 109ohms

High-quality alloy made of chromium-nickel stainless steel with a high nickel content

Symmetrical

•

Exactly harmonised, precision tips for precise work

Acid-resistant and stainless

•

For an extra long service life

Non-glare surface

•

Enables optimal work

278

Safety note: Wiha ESD electronic tweezers are non-insulating, and are therefore not suitable for work on live parts.

EN_s230-281_Zangen_2012 15.02.12 17:44 Seite 279

www.wiha.com

Universal tweezers.

ZP 01 0 14

Standards: IEC 61340-5-1. Tip form: Straight with a strong tip. Design: Smooth gripping surfaces, gripping surfaces without grooves.

Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: Universal tweezers for all current electronics applications.

Order-No. 32318 130 AA 19 10

Universal tweezers Professional ESD.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

- 109ohms.

Precision tweezers.

ZP 06 0 14

Standards: IEC 61340-5-1. Tip form: Straight with long, rugged tip - "American shape". Design: Smooth gripping surfaces, gripping surfaces without grooves.

Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: Precision tweezers for gripping and holding electronic components.

Order-No. 32347 130 GG 19 10

Precision tweezers Professional ESD.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

- 109ohms.

ZP 46 0 14

Standards: IEC 61340-5-1. Tip form: Straight with approx. 4 mm wide, round tip. Design: Fine-tooth gripping surface, grooved gripping surface.

Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: Universal tweezers for all current electronics applications.

Order-No. 32343 145 40 29 10

Universal tweezers Professional ESD.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

- 109ohms.

Wiha Info

A variety of different tweezers are required for electronics applications.

Simply contact us if you require different models for other applications.

ZP 07 1 14

Standards: IEC 61340-5-1. Tip form: Straight with approx. 1 mm wide tip. Design: Smooth gripping surfaces, gripping surfaces without grooves.

Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: Precision tweezers for gripping and holding electronic components.

Order-No. 32325 130 PSF 18 10

ZP 09 0 14

Standards: IEC 61340-5-1. Tip form: Straight with a very slim and extra-ﬁne tip. Design: Smooth gripping surfaces, gripping surfaces without grooves.

Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: Precision tweezers for gripping and holding electronic components.

Order-No. 32326 135 SS 13 10

Precision tweezers Professional ESD.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

Precision tweezers Professional ESD.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

- 109ohms.

279

EN_s230-281_Zangen_2012 15.02.12 17:45 Seite 280

Wiha Professional ESD.

For high standards when it comes to precision and safety.

Precision tweezers.

ZP 11 0 14

Standards: IEC 61340-5-1. Tip form: Straight with a rugged and medium-ﬁne tip. Design: Smooth gripping surfaces, gripping surfaces without grooves.

Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: Precision tweezers for gripping and holding electronic components.

Order-No. 32327 120 00 21 10

Precision tweezers Professional ESD.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

- 109ohms.

Precision tweezers.

ZP 18 0 14

Standards: IEC 61340-5-1. Tip form: Straight with a needle-ﬁne tip. Design: Smooth gripping surfaces, gripping surfaces without grooves.

Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: Precision tweezers for gripping and holding electronic components.

Order-No. 32334 110 5 13 10

Precision tweezers Professional ESD.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

- 109ohms.

ZP 15 0 14

Standards: IEC 61340-5-1. Tip form: Straight with ﬂat, round tip, approx. 2 mm wide. Design: Smooth gripping surfaces, gripping surfaces without grooves.

Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: Precision tweezers for gripping and holding electronic components.

Order-No. 32329 120 2a 16 10

ZP 16 0 14

Standards: IEC 61340-5-1. Tip form: Straight with a rugged tip. Design: Smooth gripping surfaces, gripping surfaces without grooves.

Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: Precision tweezers for gripping and holding electronic components.

Precision tweezers Professional ESD.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

Precision tweezers Professional ESD.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

- 109ohms.

ZP 20 1 14

Standards: IEC 61340-5-1. Tip form: Round curved with a ﬁne tip. Design: Smooth gripping surfaces, gripping surfaces without grooves.

Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: Precision tweezers for gripping and holding electronic components.

Order-No. 32335 120 7a 15 10

ZP 20 2 14

Standards: IEC 61340-5-1. Tip form: Round curved with short, straight, 3 mm long ﬁne tip. Design: Smooth gripping surfaces, gripping surfaces without grooves.

Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: Precision tweezers for gripping and holding electronic components.

Precision tweezers Professional ESD.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

Precision tweezers Professional ESD.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

- 109ohms.

Order-No. 32346 110 3c 14 10

280

Order-No. 32336 120 7abb 15 10

EN_s230-281_Zangen_2012 15.02.12 17:45 Seite 281

www.wiha.com

SMD tweezers.

ZP 24 0 14

Standards: IEC 61340-5-1. Tip form: Straight with a curved 45° angle ﬂat, narrow tip.

esign: Smooth gripping surfaces, gripping surfaces without grooves.

Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: SMD special tweezers for horizontal gripping of components.

Order-No. 32338 120 12 15 10

SMD tweezers Professional ESD.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

- 109ohms.

SMD tweezers.

ZP 50 0 14

Standards: IEC 61340-5-1. Tip form: Curved at a 35° angle with an approx. 2 mm wide tip,

Design: Smooth gripping surface, grooved gripping surface.

Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: SMD special tweezers for gripping and holding horizontally-designed

Order-No. 32344 117 59 14 10

SMD tweezers Professional ESD.

ormed gripping end for 0.8 mm dia.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

- 109ohms.

components.

ZP 25 2 14

SMD tweezers Professional ESD.

Standards: IEC 61340-5-1. Tip form: Straight with ﬂat, wide tip and diagonal alignment

of the front gripping edge.

Design: Smooth gripping surfaces, gripping surfaces without grooves.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

- 109ohms. Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: SMD special tweezers for horizontal gripping of components.

Order-No. 32340 120 13 16 10

ZP 25 3 14

SMD tweezers Professional ESD.

Standards: IEC 61340-5-1. Tip form: Curved at a 30° angle with a ﬂat, wide tip and straight alignment

of the front gripping edge.

Design: Smooth gripping surfaces, gripping surfaces without grooves.

Non-glare black coated, anti-static. Anti-magnetic and acid-resistant. Surface resistance 10

- 109ohms. Material: Special alloyed, non-rusting, chromium-nickel stainless steel. Application: SMD special tweezers for horizontal gripping of components.

Order-No. 32337 120 8b 16 10

ZP 99 0 140 02

SMD tweezer set Professional ESD, 4 pcs. Dissipative tools, electrostatically discharging.

Design: ESD tools manufactured according to IEC 61340-5-1.

All tweezers are ESD-safe (anti-static) via a special ESD coating, acid-resistant, non-rusting and 100% anti-magnetic. Surface resistance 10

- 109ohms.

Case: No danger to electronic components with use of ESD-safe materials.

Tough, space-saving metal box.

Content: Universal tweezers, pointed, 130 mm (ZP 01 0 14 series)

Precision tweezers, angular-wide tips, 130 mm (ZP 07 1 14 series) SMD tweezers, ﬂat gripping surfaces, 120 mm (ZP 25 2 14 series) SMD tweezers, gripping surface with radius, 117 mm (ZP 50 0 14 series)

Application: Hand assembly of PCBs with SMD components or re-work activities.

Order-No. Series 32349 ZP 99 0 140 02 1

Safety note: Wiha ESD electronic tweezers are non-insulating, and are therefore not suitable for work on live parts.

281

Wiha Tools Pliers User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
