WIDO V1 PRO
ELECTRIC FOLDING ALL TERRAIN BIKE
USER GUIDE
MODEL: EBIKE1 V1.0 (2019)
WARNING: FOR YOUR OWN SAFETY AND THAT OF YOUR EQUIPMENT, MAKE SURE TO READ THIS
MANUAL AND TAKE THE PRECAUTIONS DETAILED. FAILURE TO FOLLOW WARNING NOTICES AND
INSTRUCTION MAY RESULT IN DAMAGE, INJURY OR DEATH.
2
WIDO V1 PRO - USER GUIDE
CONTENTS
CONTENTS | 3
SAFETY INFORMATION | 4
GETTING TO KNOW THE BIKE | 6
ASSEMBLY / UNFOLDING YOUR BIKE | 8
FOLDING YOUR BIKE | 10
BIKE SPECIFICATION | 11
BATTERY & CHARGING | 11
BIKE DISPLAY PANEL | 14
ADJUSTING THE BIKE TO FIT | 14
RIDE CHECKLIST | 16
MAINTENANCE | 16
PRODUCT REPLACEMENT | 17
GENERAL TIPS | 18
TROUBLESHOOTING | 20
CONTACT | 21
DECLARATION OF CONFORMITY | 22
3
SAFETY INFORMATION
If unfamiliar with any aspect of this user guide we recommend that you take your bike
and & manual to a local bike shop for inspection, assembly and further instructions.
Alternatively, our customer services team are always happy to help.
• It is extremely important that you follow the safety guidelines contained in this
manual in order to ensure maximum safety for you as well as maximum durability of
your bike.
• Before you ride this bike for the first time, please be absolutely sure that it has
been correctly assembled. You will find step by step instructions in this manual. But
if for any reason you are not completely certain, please bring it to your nearest
bicycle shop.
• Key steps that must be checked or completed with absolute certainty (to include
secure fastening) are pedals, saddle height, handlebar (both rotation and height)
and wheels.
• Please ensure all safety latches, including quick releases and rings, are locked in
place and snug without any movement.
• Please ensure all bolts (including the front/rear wheels and saddle bolt) are properly
tightened.
• If you are unfamiliar with cycling, we suggest that you take a cycling course that
includes riding safely.
• Test your brakes prior to using the bike every time. In wet or icy conditions, use
extra caution.
• Frequently check your tire pressures. They should be approximately between 4 and
6.5 bar (58 and 94 psi).
Low tire pressures will result in damage to the tires and rims. It can shorten the
lifespan of your bike as well as cut your ride short if you suer from a flat tire.
• We recommend you to always wear a helmet when riding any bicycle.
• Please observe all trac regulations and bicycle laws, including any applicable
lighting laws.
• Don’t drink and ride. Even a small amount of alcohol can impair your judgement,
lowering your ability to remain safe on the bike.
• Weather and night time operation can be tricky. Please use extra caution in
inclimate, icy or snowy weather and at night.
• Don’t lend your bicycle to anyone who is unfamiliar with it. If you choose to loan
your Wido bike to anyone, make sure they have also read and fully understand this
owner’s manual.
• E-bikes are not toys. All riders must be at least 16 years old.
• This bike is meant to be ridden by a single person. Total max. recommended weight
of rider, including all items such as backpack, is 120 kg (18st 12lbs).
• This bicycle can be ridden on most terrain but it is intended for riding primarily on
the street & cycle paths. Be extra careful if you decide to use it on other surfaces.
• It is advisable to be extremely cautious when riding in trac. Cars are not used to
the speed at which an e-bike can travel, as compared to a regular bike.
4
WIDO V1 PRO - USER GUIDE
• Since it is impossible to anticipate every situation or condition which can occur
while on the bike, this manual makes no representation about the safe use of
the bicycle under all conditions. There are risks associated with the use of any
bicycle.
• When you need to replace the battery, please either dispose of it properly or send
it back to us or your local bike shop to ensure that it is properly recycled.
• Warning: Do NOT take apart OR repair parts by yourself. Please go to your local
bike shop that has experience with e-bikes. If In doubt, please contact the
Wido support team.
If you have any further questions about the operation of this Wido e-bike, please consult
your local e-bike dealer or contact the Wido support team who will be happy to help.
5
GETTING TO KNOW THE BIKE
897
17
1
15
18
15
11
2
3
26
5
13
12
4
10
20
6
22
23
19
25
14
21
24
6
KEY COMPONENTS
1. Saddle
2. Seatpost
3. Seatpost quick release
4. Disc brake
5. Tire
6. Spoke
7. Motor
8. Cassette
9. Rear derailleur
10. Chain
11. Handlebar lock mechanism
12. Pedal
13. Crankset
14. Charging hole
15. Key for battery lock
16. Display/control panel
17. Handlebar
18. Brake lever
19. Handlebar stem
20. Disc brake caliper
21. Battery
22. Gear shifters
23. Bell
24. Kickstand
25. Carry & folding handle
26. Bike folding/lock mechanism
(HIDDEN)
WIDO V1 PRO - USER GUIDE
7
ASSEMBLY/UNFOLDING YOUR BIKE
If you have diculty assembling your bike, we recommend you take your bike and &
manual to a local bike shop for inspection, assembly and further instructions. Alternatively,
our customer services team are always happy to help.
If something appears to be wrongly assembled - even if you have followed these
instructions, please contact us or a trained/professional bike specialist before riding
your bike. We recommend taking your bike to your local bike shop to have it thoroughly
checked.
UNFOLDING THE HANDLEBAR
Straighten the handlebar stem (19) until it is perpendicular to the ground and lock the
handlebar locking mechanism (11) in place with a few twists. The Wido V1 Pro handlebar is a
fixed height handlebar.
IMPORTANT: Make sure the handlebar stem fits tightly into the handlebar locking
mechanism, and is securely fastened. Failure to do so could result in loss of control of
your bike and could cause serious injury.
19
11
8
