Widex 6358 Quick Manual
6300
TECHNICAL SUPPORT
Tel: 0191 224 3174
Fax: 0191 224 4938
Email: tech@videxuk.com
Web: www.videxuk.com
beep!
beep!
OVERVIEW RECEIVING A CALL
OPEN THE DOOR
During a call
During a
conversation
To answer an incom ing call press the t alk button . The LED beh ind
the talk sy mbol
will illum inate to indicate the v ideophone is
switche d ON. A conversatio n can now begin.
Press the lo ck button to
open the door.
Privacy ON/OFF
button
Privacy LED
Service button
Door Open LED
Brightness Display adjustment
Speech Volume adjustment
LCD Colour ScreenMicrophone
Talk (answer call),
Camera Recall
button
Talk (ON/OFF) LED
Call Tone Volume adjustment
Speaker
QG_6358_V.1.0_06/16
ART. 6358
6300 Series Hands Free Videophone incorporating a 3.5” Hi-Res full colour
active matrix LCD monitor specic for “6 wire" videokits (CVK4K, CVR4KV and
CVK8K range).
It includes 4 buttons: "answer call/camera recall", "door open", "service"
and "privacy".
3 LEDs indicate the call is answered, privacy is activated and door open.
Programmable privacy duration time and number of rings.
Intercommunicating call and door call.
Adjustments: speech volume control, call tone volume switch (3 levels),
picture hue, contrast and brightness controls.
6358
Colour Hands Free Videophone
QUICK GUIDE
The LED beh ind the lock
symbol
will
illuminate to indicate that
the door is open (if the LD
terminal was connected
during the installation).
Door Open
button,
intercommunicating
button
Door Open
button,
intercommunicating
button
zZz
zZz
zZz
zZz
zZz
zZz
beep!
beep!
zZz
zZz
beep!
beep!
zZz
zZz
beep!
beep!
PRIVACY FUNCTION
CAMERA RECALL
When th e
system is in
standby
When th e
system is in
standby
CALL TONE VOLUME ADJUSTMENT
BRIGHTNESS DISPLAY ADJUSTMENT
During a c all, a
conversation or in
camera recall mode
In every
situation
In every
situation
During an i ncoming call,
with the pr ivacy enable d, the
videop hone will not ring a nd
no pictu re will be displayed .
Press the pr ivacy button to e nable the privac y
functi on. The red LED beh ind the privac y symbol
will illum inate to indicate tha t the privacy is en abled.
The priv acy functio n will automatical ly switch OFF
after th e programmed tim e expires or by pres sing the
privacy button
again.
When the conversation
time (set up during the
installation) has ended,
the videophone stops
all communi cation and
the syste m returns to the
standby condition.
Push the ser vice button to activa te the secondar y
service (if this was set up du ring the installati on). To set
up the func tion of the ser vice button, pl ease contact
Videx Technical.
Press the ta lk button (camera recall bu tton) as
many times as t he ID value of the doo r panel (e.g. if
recalling th e picture from do or ID 2, press this but ton
twice, for d oor ID 3 press this but ton 3 times etc.). The L ED
behind th e talk symbol
will illuminate to indicate
the vide ophone is switch ed ON. The display w ill show
the pict ure from the camer a on the relevant ou tdoor
station r ecalled.
Move the sw itch, under the cal l tone symbol to
adjust th e call tone volume le vel. Move to the lef t for a
low call ton e level, to the centre f or a medium call ton e
level and to t he right for a high cal l tone level.
Turn the roller u nder the brightn ess control symb ol
to adjust th e brightness of the p icture. Any
adjustm ent to the left wil l reduce the bright ness and
any adjustm ent to the right will i ncrease the brigh tness.
During 'C amera Recall' it i s possible:
To start a conver sation;
To push the lock b utton
to open the d oor;
To push the ser vice button
to activa te the
secondary service.
Press the ta lk button
to end the conve rsation.
SERVICE BUTTON
During a conversation
or in camera recall mode
Turn the roller u nder the speech c ontrol symbol to
adjust th e volume of speech . Any adjustment to th e left
will redu ce the speech volum e and any adjustmen t to
the right wi ll increase the spe ech volume.
SPEECH VOLUME ADJUSTMENT
