6272

Colour Screen Videophone

QUICK GUIDE

OVERVIEW RECEIVING A CALL

OPEN THE DOOR

ART. 6272

6200 Series Videophone incorporating a 3.5” Hi-Res full colour active matrix
LCD monitor specic for the "6 Wire Bus" 2200 Digital System.

It includes 4 buttons: "camera recall", "door open" and 2 "service"buttons.

2 LEDs indicate the privacy is activated and door open.

Programmable number of rings (3 or 6) with up to 9 melodies.

Adjustments: call tone volume (2 levels) and privacy switch. Picture hue,
contrast and brightness controls.

During a call

During a

conversation

To answer an incom ing call pick up the ha ndset.

Press the lo ck button to

open the door.

The LED beh ind the lock

symbol

will

illuminate to indicate that

the door is open (if the DOL

terminal was connected

during the installation).

Door Open button

Service button 1

Door Open LED

Brightness Display adjustment

Call Tone Volume adjustment

& Privacy switch

Camera Recall button

LCD Colour Screen Handset

Service button 2

Privacy LED

zZz

zZz

zZz

zZz

zZz

zZz

beep!

beep!

zZz

zZz

beep!

beep!

zZz

zZz

beep!

beep!

SERVICE BUTTONS

PRIVACY FUNCTION

CAMERA RECALL

When th e

system is in

standby

When th e

system is in

standby

CALL TONE VOLUME ADJUSTMENT BRIGHTNESS DISPLAY ADJUSTMENT

During a c all, a

conversation or in

camera recall mode

In every

situation

In every

situation

During an incoming

call, with t he privacy

switch ON , the

videophone will not

ring and no p icture

will be displayed.

To set up the func tion of the ser vice buttons, pl ease

contact V idex Technical.

Move the pri vacy switch to th e left (towards the pri vacy

symbol

) to enable th e privacy func tion. The LED

behind th e privacy sym bol

will illuminate to

indicate t hat the privacy f unction is swi tched ON.

To switch OFF the pr ivacy funct ion and enable the

call tone, m ove the privacy s witch back to the rig ht

(towards the call ton e level symbol

). The priva cy

functi on will be disable d and the call tone e nabled.

When the conversation

time (set up during the

installation) has ended,

the videophone stops

all communi cation and

the syste m returns to the

standby condition.

Push the req uired service b utton or to

activa te the secondar y service (if this was se t up during

the installat ion).

Pick up the han dset and then push t he camera recal l
button

as many times a s the ID value of the do or

panel (e.g. if recalling t he picture fro m door ID 2, press this

button t wice, for door ID 3 pre ss this button 3 time s etc.).

The vide ophone display w ill show the pictu re from the

camera on t he relevant outd oor station rec alled.

Move the sw itch, under the cal l tone symbol to

adjust th e call tone volume le vel. Move to the centre

for a low cal l tone level and to the ri ght for a high call

tone level.

Turn the roller u nder the brightn ess control symb ol

to adjust th e brightness of the p icture. Any

adjustm ent to the left wil l reduce the bright ness and

any adjustm ent to the right will i ncrease the brigh tness.

During 'C amera Recall' it i s possible:

To start a conver sation;

To push the lock b utton

to open the d oor;

To push the ser vice button

or to activa te

the relevant secondary service.

Hang up the h andset to end the conve rsation.
