Thank you for your purchase of this WHYNTER product. Please read this Instruction Manual carefully before using product
to ensure proper use. Keep this manual in a safe place for future reference.
MODEL# : WC-321DD
WHYNTER 32 Bottle French Door Dual Temperature Zone
Freestanding Wine Cooler
SB/W
Instruction Manual
TABLE OF CONTENTS
Parts and Features …………………….………...3
Technical Data ……………………………………4
Important Safety Instructions……………………5 - 6
Installation …………………………………………7
Operations …………………………………………8 - 9
Care and Maintenance……………………………9
Troubleshooting……………………….................10 - 11
Warranty …………..………………………............12
1. Parts and Features
1. INTERIOR LIGHT 2. FAN MASK
3. WINE RACK 4. STAND
5. DOOR HINGE 6.TEMPERATURE DISPLAY
7.TEMPERATURE CONTROLLER 8. DOOR FRAME
9. TEMPERED GLASS DOOR 10.HANDLE BAR
Model no.
WC-321DD
Capacity
100L (32 standard wine bottles)
Voltage
110v
Current
3.0 Amp
Input power
210W
Power
Consumption(KW.h/24h)
1.5(59°F)
Max Temperature
Difference
﹥64°F
Temperature Control
Range
46-66 °F
Net weight
69.5 lbs
Gross weight
75 lbs
Product size(W×H×D)
20.67" x 32.28" x 20.08” (21.68” with
handle installed)
Packing size(W×H×D)
24” × 35” × 23.5”
2. Technical Data
3. Important Safety Instructions
To reduce the risk of fire, electrical shock, or injury when using your
appliance, follows these basic precautions
Do not use if the power supply cord is damaged. If damaged, it must be replaced
by a qualified electrician.
This wine cooler is not intended for use by young children or physically-
challenged persons without supervision/assistance. Young children must be
supervised to ensure safety around this or any appliance.
Ensure the unit is unplugged before cleaning or when not in use.
To clean the unit, use only mild detergents or glass cleaning products. Never use
harsh detergents or solvents.
Do not use this wine cooler with an extension cord or power board. Please
ensure that the appliance is plugged directly into the electrical outlet.
When positioning the wine cooler, ensure that there is at least a 4” clearance at
the sides and a 6” clearance at the back. This will allow for adequate ventilation
of any heat generated by the freestanding wine cooler.
This cooler is designed to store wine bottles. If food is stored inside, ensure that
there is sufficient airflow between items. Please note that the temperature range
for this cooler is optimized for wine and beverage storage. Perishable food items
may require a different storage environment.
Do not place hot food or beverages into the wine cooler.
Close the cooler door immediately after putting in any items to keep the internal
temperature relatively constant.
Keep appliance away from any heat source or direct sunlight.
For a stable installation, make sure the appliance is placed on a flat, level and
solid surface.
Ensure that the surface on which the wine cooler is placed is strong enough to
hold the wine cooler and the items stored inside.
Avoid placing any objects on top of the wine cooler.
The wine cooler is an electrical appliance. To avoid injury from electrical shock
do not operate the Wine Cooler with wet hands, while standing on a wet surface
or while standing in water. Do not use outdoors or in wet conditions.
When positioning or moving the appliance ensure that it is not turned upside
down or greater than 45° or more off level.
Never pull the cord to disconnect it from the outlet. Grasp the plug and pull it from
the outlet.
Never lift or carry the wine cooler by the power cord.
This wine cooler is designed for household, non-commercial use only. Any other
use will void the warranty.
Do not plug into the power outlet before set up is completed.
An empty cooler can be a hazardous for children or small pets. If disposing of the
cooler remove gasket seals, latches, lids or the entire door from your unused
appliance, or take other action to ensure the cooler is harmless.
Do not cut or remove the ground prong from the power cord.
Do not move this appliance without emptying it and securing the door in a closed
position.
Warning
Improper use of the grounded plug can result in the risk of electrical shock. If the
power cord is damaged, have it replaced by a qualified electrician.
4. Installation
Before using your wine cooler
Remove the exterior and interior packaging material
Stand the unit upright for approximately 2 hours before connecting to the power
source. This will reduce the possibility of a malfunction in the cooling system from
handling during transportation.
Clean the interior surface with a soft cloth and warm water.
Place your appliance on a floor that is strong enough to support the appliance when
it is fully loaded.
Do not place the appliance in an enclosed space or under direct sunlight or sources
of heat (stove, heater, radiator, etc.). Direct sunlight may affect the acrylic coating
and heat sources may increase the ambient temperature and electrical consumption.
Extreme cold or hot ambient temperatures may also cause the appliance to
malfunction.
Allow up to 24 hours of operation for the wine bottles to reach the desired
temperature.
Electrical Connection
This appliance should be properly grounded for your safety. The power cord of this unit
is equipped with a 3-pin plug to minimize the possibility of electrical shock. Do not under
any circumstances cut or remove the ground wine from the power cord supplied.
Use of extension cords is not recommended.
This unit requires a standard 110V-60HZ electrical outlet with 3-pin plug.
To prevent accidental injury, the power cord should be secured behind the wine
refrigerator and not left exposed or dangling.
5. Operations
Temperature Setting
It is recommended that you install the wine cooler in a place where the ambient
temperature is between (60- 80°F). If the ambient temperature is above or below
recommended temperatures, the performance of the unit may be affected. For example,
placing in extreme cold or hot conditions may cause interior temperature to fluctuate
thus the set temperature may not be achievable.
You can set the wine cooler temperature by pressing the “ ” UP and “ ” DOWN buttons
on the control panel.
Temperature control range: 46-66 ºF
Generally for red wines, the temperature range should be between 57ºF – 61ºF and for
white wines, the temperature range should be 50ºF - 54ºF. This is based on an ambient
room temperature of 77ºF.
Interior Light
You can turn on and off the interior light by pressing the “Light” button. The “Light”
button on the left side controls the upper zone light and the “Light” button on the right
side controls the lower zone light.
Handle Bars
Your wine cooler comes with a towel bar style handle. To install the handle, you will
need a Phillips-head screwdriver.
Open the door of the wine cooler.
Located the two screw holes on the inside of the door (they may be partially
obscured by the door seal so you may need to remove the door seal)
Insert the screws into the screw holes until they stick out of the front of the door.
Line up the holes in the handle with the screws and give each screw about 2-4
full turns into the handle bar.
Now the turn the screws in all the way, and your handles are installed.
Replace seal into door frame.
Bottle Capacity
This wine cooler is designed to store 6 bottles in the upper zone and 15 bottles in the
lower zone. The bottle capacity listed for your wine cooler is an estimated maximum
capacity based on a standard 750ml wine bottle. For other size bottles, the capacity will
vary.
Leveling Legs
Your wine cooler comes with four leveling legs. To adjust these legs, carefully lean the
wine cooler to one side (make sure it is emptied and the door is secured) and unscrew
the legs to make them longer. Screw the legs tighter to make them shorter. This wine
cooler is not designed to operate without the leveling legs
Wine Racks
The individual wine racks have a slight difference between the top and a bottom of the
racking. If you are having trouble fitting the maximum number of bottles of wine in the
wine cooler, try flipping the wine racks over to accommodate the shape of the bottle.
Air Filter
Your wine cooler has a washable air filter over the air intake in the back. Periodically,
this air filter should be cleaned. Remove the air filter and gently wash it in a solution of
mild detergent and water. Make sure it is completely dry before installing it back to the
air intake.
Energy Saving Tips
Do not locate the wine cooler in direct sunlight or any heat generating sources. Let any
warm items cool before placing them in the wine cooler.
6. Care and Maintenance
Cleaning your wine cooler
Unplug the wine cooler.
Remove all items from the wine cooler.
Wipe the inside and outside surface with a mild soap.
Wash the wine racks with a mild soap.
Dry any moist parts with a soft cloth.
Moving your wine refrigerator
Unplug the wine cooler.
Remove all items from the wine cooler.
Securely tape the door of the wine cooler.
Turn the leveling legs (tightly shorten) up to the base to avoid damage.
Be sure the wine cooler stays in the upright position during transportation.
The ideal packaging for the wine cooler is its original packaging. Please keep the original
packaging and repack the wine cooler if you need to transport the unit.
7. Troubleshooting
Symptoms
Possible causes
Solutions
The wine cooler
does not turn on.
There is a power failure.
The cooler is not plugged in.
A house fuse has blown or the
circuit breaker is tripped.
Ensure the cooler is plugged in and the power outlet
has power.
Replace the broken fuse or reset the breaker.
The wine cooler is
not reaching the
desired
temperature.
The cooler is placed too close to
a heat source.
The cooler does not have
sufficient ventilation.
The door is opened too frequently
or for a long period of time.
Keep the cooler away from sunshine or other heat
sources.
Make sure the wine cooler has at least 4” of
ventilation on the sides and 6” at the back.
Close the door tightly and do not open the door too
frequently or for a long period of time.
Frost forming inside
the wine cooler.
The environment is too humid.
The ambient temperature is too
low.
The door is opened too frequently
or for a long period of time.
Although this unit uses an auto-defrost system, under
certain conditions, manual defrosting may required. If
frost builds up, try running the cooler on a warmer
temperature setting.
Close the door tightly and do not open the door too
frequently or for a long period of time.
Unplug the unit to allow the frost to melt.
The wine cooler
turns on and off
frequently.
The ambient temperature is too
low or high.
The door is being opened often.
The door is not completely
closed.
The door gasket is not sealing
properly.
The cooler does not have the
suggested ventilation.
Decrease or increase the ambient temperature.
Minimize the number of times the door is opened.
Make sure the door is tightly closed.
Make sure the door gasket is properly sealed.
Make sure the cooler has at least 4” on the sides and
6” in the back for clearance.
The wine cooler
makes too much
noise.
If the noise is from the fan, it may
be normal operating noise.
The unit is not level.
Popping or cracking noises are
coming from the unit.
The fan makes normal fan noises.
Make sure the cooler is on a hard and level surface.
Do not place the wine cooler on carpet.
Some popping or cracking noises are normal. They
are caused by expansion and contraction of the
inside walls due to temperature changes.
You can solve many common problems by referring the troubleshooting suggestions
listed below.
The door will not
shut properly.
The unit is not level.
The door gasket is dirty.
The door gasket is malformed.
The shelves are incorrectly
installed.
Make sure the cooler is on a level surface.
Clean the door gasket.
Make sure the door gasket is properly sealing.
Correctly install the shelves.
ONE YEAR LIMITED WARRANTY &
THREE YEAR WARRANTY ON COMPRESSOR
This WHYNTER freestanding wine cooler is warranted, to the original owner within the 48
continental states, for one year from the date of purchase against defects in material and
workmanship under normal use and service. Should your WHYNTER wine cooler prove
defective within one year from the date of purchase, return the defective part or unit, freight
prepaid (within two months of purchase; after two months to one year, customer will be
responsible for freight cost to Whynter’s service department), along with an explanation of the
claim to Whynter LLC. Please package the wine cooler carefully in its original packaging
material to avoid damage in transit. Please retain the original box and packaging material.
Under this warranty, Whynter will repair or replace any parts found defective. This warranty is
not transferable. After the expiration of the warranty, the cost of labor and parts will be the
responsibility of the original owner of the unit.
THIS WARRANTY DOES NOT COVER:
Acts of God, such as fire, flood, hurricanes, earthquakes and tornadoes.
Damage, accidental or otherwise, to the wine cooler while in the possession of
a consumer not caused by a defect in material or workmanship;
Damage caused by consumer misuse, tampering, or failure to follow the care and
special handling provisions in the instructions.
Damage to the finish of the case, or other appearance parts caused by wear.
Damage caused by repairs or alterations to the product by anyone other than
authorized by the manufacturer.
Freight and Insurance cost for the warranty service.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR OR
REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST
PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. WHYNTER SHALL NOT BE LIABLE FOR CONSEQUENTIAL
OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY
BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSE- QUENTIAL DAMAGES, OR LIMITATIONS ON
THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS
WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM
STATE TO STATE.
Whynter LLC via email at service@whynter.com or call
Product contents and specifications may change without notice.
To obtain service or information, contact
866-WHYNTER.
Copyright © 2012 Whynter LLC
www.Whynter.com
Loading...
