Whynter WC-211DZ User Manual 2

Thank you for your purchase of this WHYNTER product. Please read this Instruction Manual carefully before using product
to ensure proper use. Keep this manual in a safe place for future reference.

MODEL# : WC-211DZ

WHYNTER 21 Bottle Dual Temperature Zone Freestanding

Wine Cooler

SB/W

Instruction Manual

TABLE OF CONTENTS

Parts and Features …………………….………...3
Technical Data ……………………………………4

Important Safety Instructions……………………5 - 6
Installation …………………………………………7
Operations …………………………………………8 - 9
Care and Maintenance……………………………9

Troubleshooting……………………….................10 - 11

Warranty …………..………………………............12

1. Parts and Features

1. DOOR HINGE 2. INTERIOR LIGHT

3. TEMPERATURE CONTROLLER 4. TEMPERATURE DISPLAY

5. FAN MASK 6. WINE RACK

7. STANDS (NOTE: STAND UNDER THE FRONT DOOR HIGNE IS SMALL
THAN THE OTHE 3 STANDS)

8.DOOR FRAME

9. TEMPERED GLASS DOOR 10.HANDLE BAR

Model no.

WC-211DZ

Capacity

60L (21 standard wine bottles)

Voltage

110v

Current

1Amp

Input power

140W

Power
Consumption(KW.h/24h)

1.2(59°F)

Max Temperature
Difference

﹥64°F

Temperature Control
Range

Up Zone 7-18℃(44-66 ºF)

Lower Zone 10-18℃(50-66 ºF)

Net weight

45 lbs

Gross weight

50 lbs

Product size(W×H×D)

13.4” × 32.3” × 20.8” (21.7” with

handle installed)

Packing size(W×H×D)

15” × 33.5” × 21.6”

2. Technical Data
