Whynter UDF-0831SS INSTRUCTION MANUAL
Whynter 8.3 cu.ft. Energy Star Digital Upright Stainless Steel Deep Freezer/Refrigerator
Model # : UDF-0831SS
INSTRUCTION MANUAL
Congratulations on your new Whynter product. To ensure proper operation, please read this Instruction Manual carefully before
using this product. Keep this manual in a safe place for future reference.
Table of Contents
2
Safety Precautions
3 - 4
Parts and Accessories
5
Product Features / Technical Data
6
Installation
7 - 8
Operation and Controls
Cleaning and Maintenance
Troubleshooting
PAGE
9 - 11
12 - 13
14 - 15
Warranty Information
16
Safety Precautions
3
WARNING
• Read all instructions before using the appliance.
• Never clean appliance parts with flammable fluids. The fumes can create a fire hazard. Do not use an exces-
sively wet cloth, industrial solvents, and oil-based products to clean this appliance.
• To clean the upright refrigerator/deep freezer, use only mild detergents. Never use harsh chemicals or sol-vents.
• Do not store or use gasoline or any other flammable vapors and liquids in the vicinity of this or any other appli-
ance. The fumes can create a fire hazard.
• Do not abuse, sit on, or stand on the appliance.
• This appliance is not intended for use by persons (including children with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety
• Children should be supervised to ensure that they do not play with the appliance.
• Ensure the upright refrigerator/deep freezer is unplugged before cleaning or if not in use
TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY WHEN
USING YOUR APPLIANCE, FOLLOW THESE BASIC PRECAUTIONS:
• If the power cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualifi
son in order to avoid a hazard.
per
• Use the upright refrigerator/deep freezer only for its intended function. This appliance is designed for house-hold,
non-commercial use only. Any other use will void the warranty.
• Do not plug this upright refrigerator/deep freezer into the power source before setup is completed.
• An empty upright refrigerator/deep freezer can be dangerous for children and small animals. If disposing of t
ight refrigerator/deep freezer, remove gaskets, latches, and the entire upright refrigerator/deep freezer door
upr
from your unused appliance so that children or small animals cannot be trapped inside.
• The upright refrigerator/deep freezer is an electrical appliance. To avoid serious injury from electrical shock,
operate the upright refrigerator/deep freezer with wet hands, while standing on a wet surface, or whil
not
s
tanding in water.
• To avoid the risk of shock, the product should never be used in bathrooms, shower rooms, or in any other
steamy or wet areas.
• During installation, the power supply must not be excessively or dangerously bent or flattened.
• Do not tamper with controls.
• Make sure the power plug is placed fully and firm into the power source. If the wall receptacle you intend to us
s not adequately grounded or protected by a time delay fuse or circuit breaker, have a qualified electrician install
i
an outlet that is appropriate to local electrical codes and requirements.
• Do not use multiple socket or an extension cord as it may overheat and become a risk of fire. Please ensure that
the upright refrigerator/deep freezer is plugged directly into the electrical outlet.
ed
he
do
e
e
• The cord should be secured behind the unit and should not be left exposed or dangling
• Make sure the power plug is clean before usage.
• Make sure hands are dry when connecting the power plug. The appliance is equipped with a three-prong
grounded plug on the power cord for your protection. Never modify, remove or attempt to repair the power pl
ourself.
y
• Never pull the power cord to disconnect the unit from an outlet. Grasp the plug directly and pull it from the outlet.
• Never lift or carry the upright refrigerator/deep freezer by the power cord.
• Keep the power cord away from heated surfaces.
• Do not repair, disassemble and/or modify the appliance by yourself.
• Always turn off the appliance when cleaning or transporting.
ug
Safety Precautions
4
• Transport the appliance in an upright position only.
• Always place the appliance on even and hard and level surface.
• Close the freezer door immediately after putting in any items to maintain the internal temperature of the unit.
• Avoid placing the freezer near external heat sources or direct sunlight.
• Make sure the freezer is placed on a flat, level, and solid surface.
• Place your appliance on a hard and level floor that is strong enough to support it when it is fully loaded.
• Do not turn the freezer upside down, on its side, or 45° or more off level.
• Keep fingers out of the “pinch point” areas; clearances between the doors and between the doors and cabinet
are necessarily small. Be careful closing doors when children are in the area
• Do not touch the cold surfaces in the freezer compartment when hands are damp or wet, skin may stick to these
ex
tremely cold surfaces
• Do not move this freezer without securing the door in a closed and latched position.
• Do not refreeze frozen foods which have thawed completely
• Performance may vary based on operational and ambient conditions.
ELECTRICAL CONNECTION
The power cord of this appliance is equipped with a 3-prong (grounding) plug which mates with a standard 3prong (grounding) wall outlet to minimize the possibility of electric shock hazard from this appliance. Have the
wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly grounded. Where a
standard 2-prong wall outlet is encountered, it is your personal responsibility and obligation to have it replaced
with a properly grounded 3-prong wall outlet. Do not use an adapter. The freezer should always be plugged into
its own individual electrical outlet which has a voltage rating that matches the rating plate.
A 115 Volt AC, 60 Hz, 15- or 20-amp fused, grounded electrical supply is required. This provides the best performance and also prevents overloading house wiring circuits which could cause a fire hazard from overheated
wires. Never unplug your freezer by pulling on the power cord. Always grip plug firmly and pull straight out from
the outlet. Repair or replace immediately all power cords that have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage along its length or at either end. When moving the freezer
away from the wall, be careful not to roll over or damage the power cord
EXTENSION CORD
Because of potential safety hazards, it is strongly recommended that you do not use an extension cord with this
appliance. However, if you must use an extension cord, it is absolutely necessary that it be a UL/CUL-Listed, 3wire grounding type appliance extension cord having a grounding type plug and outlet and that the electrical rating of the cord be 15 amperes and 115 volts. Failure to follow these instructions can result in fire, electric shock,
or death.
THE MANUFACTURER DISCLAIMS ANY RESPONSIBILITY IF THE ABOVE INSTRUCTIONS ARE NOT FOLLOWED.
Parts and Accessories
5
5
2 1
3
4
8
6
7
9
BOTTOM REAR SECTION
10 11
1. Door Handle 5. Door Hinge Cover
9. Slide-out Wire
Basket (1)
2. Control Panel
3. Leveling Leg 7. Air Outlet
4. Leveling Leg
6. Door Handle
8. Sliding Cabinet
Shelves (6)
10. Compressor
11. Drip tray
