Whynter T-1, T-1A User Manual

HOME

ICE MACHINE

USER

INSTRUCTION

MANUAL

MODEL SNO

T-1 / T-1A

T-1 Version 08/05 1

Introduction
This instruction manual covers the operation of versions of the Whynter – SNO
Home Ice Machine Model T-1 and T-1A.

Please read these instructions carefully and retain them for future reference.
The appliance must be connected to a (nominally) 110V AC 60Hz. earthed

electrical supply and be protected with a fuse.
The Home Ice Machine produces 12 ice cubes every cycle of 12 to 18 minutes

approximately depending on which size of cube is selected. It is equipped with a
clear Function Display panel which includes SELECT buttons for ice cube size
selection (S – small, M – medium and L – large), START and STOP buttons and
a WATERTANK condition monitor which gives a visual warning when the
appliance is running low on water. The unit has a separate mains electricity
ON/OFF switch in the lower right hand side panel.

It is recommended that the appliance is operated with small (S) cube size
whenever conditions permit.

The T1-A unit has a dual mode design – “Standard” and “Direct Water Supply”
mode. In Direct Water Supply mode, the machine can be connected directly to a
mains water supply. This added function allows the water tank to automatically
refill when empty.

T-1 Version 08/05 2

E D F C B A K

L G H

J

Parts Overview

A Ice Cube Drawer B Water Tank
C Water Level Indicator D Function Display
E Cover with Window F On/Off Switch

T-1 Version 08/05 3

Referencing images on Page 3
A Ice Cube Drawer B Water Tank

C Water Level Indicator D Function Display
E Cover with Window F On/Off Switch
G Mains Water Input H Mains Water Control Float
I Water Level Detector J Water Tank Removable Lid
K Mains Lead L Mains Lead Socket

Detail of Function Display:

T-1 Version 08/05 4
