Whynter BWR-408SB 24 inch Built-In 46 Bottle Undercounter Stainless Steel Wine
Refrigerator with Reversible Door, Digital Control, Lock and Carbon Filter
BWR-408SB
Table of Contents
PAGE
Safety Precautions
Parts
Product Features
Installation
Operation and Controls
Storage
Care and Maintenance
Troubleshooting
Warranty Information
3 - 4
5
6
7 - 9
10 - 11
12 - 13
14
15 - 16
17
2
Safety Precautions
To reduce the risk of fire, electrical shock, or injury when using your appliance, follow these basic
precautions:
APPLIANCE SAFETY
Your safety and the safety of others are very important to us.
This is the Safety Alert Symbol. This symbol alerts you to potential hazards that may serious
injury. All safety messages will follow the Safety Alert Symbol and either the word "DANGER"
All safety messages will alert you to know what the potential hazard is, tell you how to reduce the chance
of injury, and let you know what can happen if the instructions are not followed.
or "WARNING"
WARNING
CAUTION
Danger means that failure to heed this safety
statement may result in severe injury or death.
Warning means that failure to heed this safety
statement may result in extensive product damage,
serious injury, or death.
Caution means that failure to heed this safety
statement may result in minor or moderate injury, or
property or equipment damage.
IMPORTANT SAFETY GUIDELINE
Before the appliance is used, it must be properly positioned and installed as described in
this manual, please read the manual carefully. To reduce the risk of fire, electrical shock
or injury when using the appliance, follow basic precaution, including the following:
•
Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and do not
use an extension cord.
•
Do not use if the power supply cord is damaged. If damaged, it must be replaced by a qualified electrici an.
•
It is recommended that a separate circuit, serving only your appliance be provided. Use receptacles that
cannot be turned off by a switch or pull chain.
•
Never clean appliance parts with flammable fluids or harsh chemicals. These fumes can create a fire hazard or
explosion.
•
Do not store flammable materials or liquids near the appliance.
•
Before proceeding with cleaning and maintenance operations, make sure to unplug the appliance.
•
Do not connect or disconnect the electric plug with wet hands.
3
Safety Precautions
• Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in this manual.
All other servicing should be referred to a qualified technician.
• This appliance is CFC- and HFC-free and contains small quantities of Isobutane (R600a) which is environmentally
friendly, but flammable. It does not damage the ozone layer, nor does it increase the greenhouse effect. Care must
be taken during transportation and setting up of the appliance that no parts of the cooling system are damaged.
Leaking coolant can ignite and may damage the eyes.
In the event of leakage:
- Avoid open flames and anything which creates a spark
- Disconnect from the mains
- Air the room in which the appliance is located for several minutes and contact the Service Department for
advice
FOLLOW WARNING CALL OUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL
• Use two or more people to move and install the appliance. Failure to do so can result in injury.
• To ensure proper ventilation for your appliance, the front of the appliance must be completely unobstructed.
• Choose a well-ventilated area with temperatures above 60°F (16°C) and below 90°F (32°C).
• This appliance must be installed in an area protected from the elements, such as wind, rain, water spray or drips.
• The appliance should not be located next to ovens, grills or other sources of high heat.
• The appliance must be installed with all electrical connections in accordance with state and local codes.
• The fuse (or circuit breaker) size should be 15 amperes.
• It is important for the appliance to be leveled in order to work properly. For a stable installation, make sure the
appliance is placed on a flat, level and solid surface.
• Ensure that the surface on which the appliance is placed is strong enough to hold the appliance and the items
stored inside.
• Do not use solvent-based cleaning agents of abrasives on the interior. These cleaners may damage or discolor the
interior.
• Keep fingers out of the “pinch point” areas. Clearance between the door and cabinet are relatively small. Be
careful closing the door when children are in the area.
• This wine refrigerator is designed to store wine bottles. If food is stored inside, ensure that there is sufficient
airflow between items. Please note that the temperature range for this wine refrigerator is optimized for wine
storage. Perishable food items may require a different storage environment and is not recommended.
• Do not place hot food or beverages into the appliance.
• Close the wine refrigerator door immediately after placing items inside to keep the internal temperature relatively
constant.
• Avoid placing any objects on top of the appliance.
• This is an electrical appliance, to avoid injury from electrical shock do not operate the unit with wet hands, while
standing on a wet surface or while standing in water. Do not use outdoors or in wet conditions.
• When positioning or moving the appliance, ensure that it is not turned upside down or unleveled greater than
45°. If the appliance does not remain in an upright position, allow it to sit upright for a minimum of 4 hours to
allow the refrigerant to settle.
• Never pull the power cord to disconnect it from the outlet. Grasp the plug and pull it from the outlet.
• Never lift, carry or drag the appliance by the power cord.
• This appliance is designed for household, non-commercial use only. Any other use will void the warranty.
• Do not plug into the power outlet before set up is completed.
• Do not move this appliance without emptying it and securing the door in a closed position.
4
Parts
BWR-408SB
1
2
6
3
10
4
7
5
8
9
11
13
Keys
1. Control Panel Temperature
Control /Light
2. Top Hinge
3. Shelves (5)
4. Door Gasket
5. Front Vent
6. Stainless Steel Door
7. Handle
8. Cylinder lock
9. Four Adjustable Legs
10. Interior Light
5
12
11. Keys
12. Drip Tray (Rear)
13. Activated Carbon
Filter (inside cabinet)
Product Features
Our Whynter Built-In Under-Counter Stainless Steel Wine Refrigerator offers premium quality and innovative design ideal
for your wine collecting needs. Whether for the enthusiast or the connoisseur, this single zone compressor wine
refrigerator provides premium and advanced wine storage functionality. The Whynter BWR-408SB can hold up to 46
standard 750ml wine bottles.
The powerful compressor cooling process offers optimum temperatures (low 40ºF to mid 60ºF) for red, white, and
sparkling wines. The front ventilation design of this unit allows for flush with cabinet installation or simply freestanding
usage. The premium appeal of this wine refrigerator features a substantial stainless steel trimmed door accented with a
luxurious curved handlebar.
Designed with intuitive use in mind, this refrigerator comes equipped with a sleek touch screen control that lets you set
the temperature to anywhere from 40ºF – 65ºF / 5ºC – 18ºC.
FEATURES
• Capacity: 46 bottles standard 750ml wine bottle
• Built-in or Freestanding installation
• Stainless steel glass door with sleek black cabinet
• Touch screen control with temperature range from 40°F – 65°F
• Environmentally friendly refrigerant
• Activated carbon filter eliminates odors
• Luxurious curved handlebar
• Tempered double-pane glass
• Soft interior LED lighting with on/off switch
• Internal fan-forced circulation for even temperature distribution throughout the cabinet
• Reversible door swing
• Fahrenheit and Celsius degree optional temperature indicators
• 5 removable pull-out sliding shelves
• Cylinder lock and two keys
TECHNICAL DATA
Model:
Capacity :
Voltage:
Power Consumption:
Temperature Range:
Net Weight:
Gross Weight:
Unit Dimension:
Packaging Dimension:
Refrigerant:
46 standard 750ml wine bottles
23. 5" W x 22.25" D x 32.25" H
27.25" W x 27.5" D x 35.5" H
BWR-408SB
115V /60Hz
85W / 0.9A
40°F - 65°F
104 lbs
122 lbs
R600a
