Whynter BWR-171DS, DWR-401DS User Manual
Whynter Elite Seamless Stainless Steel Door Dual Zone Built-in
Wine Refrigerators
Model # : BWR-171DS & BWR-401DS
INSTRUCTION MANUAL
BWR-171DS BWR-401DS
Congratulations on your new Whynter product. To ensure proper operation, please read this Instruction Manual carefully before
using this product. Keep this manual in a safe place for future reference.
Table of Contents
Safety Precautions
Parts
Product Features
Installation
Operation and Controls
Storage
Care and Maintenance
Troubleshooting
PAGE
3 - 4
5
6
7 - 9
10 - 12
13 - 14
15
16 - 17
Warranty Information
18
2
Safety Precautions
Your safety and the safety of others are very important to us.
APPLIANCE SAFETY
To reduce the risk of fire, electrical shock, or injury when using your appliance, follow
these basic precautions
This is the Safety Alert Symbol. This symbol alerts you to potential hazards
that may result in serious injury. All safety messages will follow the Safety
Alert Symbol and either the words” DANGER” or “WARNING”.
Danger means that failure to heed this safety
statement may result in severe injury or death.
Warning means that failure to heed this safety
statement may result in extensive product dam-
age, serious injury, or death.
Caution means that failure to heed this safety
statement may result in minor or moderate injury,
or property or equipment damage.
All safety messages will alert you to know what the potential hazard is, tell you how to reduce the
chance of injury, and let you know what can happen if the instructions are not followed.
IMPORTANT SAFEGUIDES
Before the appliance is used, it must be properly positioned and installed as
described in this manual, please read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the appliance, follow basic precaution,
including the following:
Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and do not use an
extension cord.
Do not use if the power supply cord is damaged. If damaged, it must be replaced by a qualified electrician.
It is recommended that a separate circuit, serving only your appliance be provided. Use receptacles that cannot
be turned off by a switch or pull chain.
Never clean appliance parts with flammable fluids or harsh chemicals. These fumes can create a fire hazard or
explosion.
3
Safety Precautions
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of the appliance or any
other appliance.
Before proceeding with cleaning and maintenance operations, make sure to unplug the appliance.
Do not connect or disconnect the electric plug with wet hands.
Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in this
manual. All other servicing should be referred to a qualified technician.
This appliance is CFC- and HFC-free and contains small quantities of Isobutane (R600a) which is environ-
mentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the greenhouse
effect. Care must be taken during transportation and setting up of the appliance that no parts of the cooling
system are damaged. Leaking coolant can ignite and may damage the eyes.
In the event of leakage:
- Avoid open flames and anything which creates a spark
- Disconnect from the mains
- Air the room in which the appliance is located for several minutes and contact the Service Department
for advice
FOLLOW WARNING CALL OUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL
Use two or more people to move and install the appliance. Failure to do so can result in injury.
To ensure proper ventilation for your appliance, the front of the appliance must be completely unobstruct-
ed. Choose a well-ventilated area with temperatures above 60°F (16°C) and below 90°F (32°C). This appliance must be installed in an area protected from the element, such as wind, rain, water spray or drips.
The appliance should not be located next to ovens, grills or other sources of high heat.
The appliance must be installed with all electrical connections in accordance with state and local codes.
The fuse (or circuit breaker) size should be 15 amperes.
It is important for the appliance to be leveled in order to work properly. For a stable installation, make sure
the appliance is placed on a flat, level and solid surface.
Ensure that the surface on which the appliance is placed is strong enough to hold the appliance and the
items stored inside.
This appliance is not intended for use by young children or physically-challenged persons without supervi-
sion/assistance. Young children must be supervised to ensure safety around this or any appliance.
Do not use solvent-based cleaning agents of abrasives on the interior. These cleaners may damage or
discolor the interior.
Keep fingers out of the “pinch point” areas. Clearance between the doors and between the doors and
cabinet are necessarily small. Be careful closing doors when children are in the area.
This wine refrigerator is designed to store wine bottles. If food is stored inside, ensure that there is suffi-
cient airflow between items. Please note that the temperature range for this wine refrigerator is optimized
for wine and beverage storage. Perishable food items may require a different storage environment.
Do not place hot food or beverages into the appliance.
Close the wine refrigerator door immediately after putting in any items to keep the internal temperature
relatively constant.
Avoid placing any objects on top of the appliance.
This is an electrical appliance, to avoid injury from electrical shock do not operate the unit with wet hands,
while standing on a wet surface or while standing in water. Do not use outdoors or in wet conditions.
When positioning or moving the appliance, ensure that it is not turned up side down or unleveled greater
than 45°
Never pull the power cord to disconnect it from the outlet. Grasp the plug and pull it from the outlet.
Never lift, carry or drag the appliance by the power cord.
This appliance is designed for household, non-commercial use only. Any other use will void the warranty.
Do not plug into the power outlet before set up is completed.
Do not move this appliance without emptying it and securing the door in a closed position.
4
Parts
BWR-171DS
BWR-401DS
1. Door Handle 4. Door
2. Shelves 5. Cabinet
3. Control Panel 6. Leveling Legs
7. Boom Grille
5
Product Features
Capacity: 17 standard 750ml wine bottle capacity for BWR-171DS
Upper Zone Capacity: 6 bottles
Lower Zone Capacity: 11 bottles
Capacity: 40 standard 750ml wine bottle capacity for BWR-401DS
Left Zone Capacity: 20 bottles
Right Zone Capacity: 20 bottles
Dual zones for storing different wine varietals
Stainless seamless steel glass door with sleek black cabinet
Luxurious curved handlebar
Open-door and malfunction warning system
Temperature memory function
Sabbath mode function
Tempered double-pane gray-smoked glass for enhanced UV protection
Adjustable thermostat for both zones
Soft white LED Interior Light with Function mode and Showcase mode
Powerful fan-circulated compressor cooling
Reversible door swing (only for BWR-171DS)
Fahrenheit and Celsius degree optional temperature indicators
5 removable pull-out sliding shelves for BWR-171DS
11 removable pull-out sliding shelves for BWR-401DS
Environmentally friendly refrigerant
TECHNICAL DATA
MODEL : BWR-171DS BWR-401DS
Capacity 17 standard wine bottles 40 standard wine bottles
Voltage 115V/60Hz 115V/60Hz
Current 1.0A 1.0A
Input Power 100W 100W
Power Consumption 0.9kWh/24h 1.1kWh/24h
Temperature Control Range
Net Weight 67 lbs 107 lbs
Gross Weight 71.5 lbs 116 lbs
Unit Dimensions
Upper Zone : 41ºF-50ºF/5ºC-10ºC
Lower Zone : 50ºF-72ºF/10ºC-22ºC
12” W x 33"H x 23"D (25”w/ handle
and 33” when open)
Left Zone: 41ºF-72ºF/5ºC-22ºC
Right Zone: 41ºF-72ºF/5ºC-22ºC
24” W x 33" H x 23” D (25”w/ han-
dle and 33” when open)
Packaging Dimensions 13" W x 35" H x 25" D 26" W x 35" H x 25“D
Refrigerant R600a R600a
6
