6066-930 Supreme Sink Shelf ©2010 Whitmor
1 ea.
F
A
D
4 ea.
B
1 ea.
C
1 ea.
E
4 ea.
F
16 ea.
C
F
A
D
1) Place 2 plastic sleeves (F) onto the bottom of a
chrome leg (D) as pictured above.
Repeat this on all 4 legs
2)Slide part B onto the top of all 4 legs down
over the plastic sleeves
3)Place 2 plastic sleeves (F) onto the top of
a chrome leg (D) as you did in step 1
Repeat this on all 4 legs
4)Slide part (A) onto the top of all 4 legs over the plastic sleeves
5)Screw feet (E) onto each leg
6)Place Part (C) onto top.
D
E
D
E
B
Part Reference
A
B
C
D
E
F
F5340
F5341
F5342
F5343
F5344
F5345
D
D
E
E
8680 Swinnea Road • Suite 103 • Southaven, MS • 38671
NEED HELP? For help with assembly, or if you are missing a part,
please call Whitmor’s Customer Service Department, 1-888-944-8667
between 8 a.m. and 4:30 p.m. (Central Standard Time) Monday
through Friday. Or email: customer_service@whitmor.com
Rev.#3 | 4.07.10 Printed in China
