Owner's Guide
LALA
VV
LA
LALA
ADORAADORA
V
ADORA
VV
ADORAADORA
Manual del Usuario
Models SWX703CQ/S
SWS1233CQ/S
SWS1339CC
SWS1649CQ/S
Contents
Important Safety Instructions ... ..............................................2
Washing Procedures ................ ...........................................3-4
Stain Removal ......................................................................5
Common Washing Problems .................................................6
Care and Cleaning ...............................................................7
Avoid Service Checklist ......................................................8-9
Español........................................................................ 10-20
Instrucciones Importantes de Seguridad............................... 10
Procedimientos para el Lavado.........................................11-13
Cómo Remover Manchas.................................................13-14
Problemas Comunes del Lavado........................................ 15
Limpieza y Cuidado.............................................................16
Lista de Control de Averías..............................................17-18
Garantia........................................................................19-20
.
Product Registration
Thank you for choosing this
washer. This owner's guide will
explain proper operation and care.
Register Your Product
The self-addressed PRODUCT
REGISTRATION CARD should be
filled in completely, signed and
returned.
Registro del Producto
Le agradecemos que haya seleccionado esta lavadora. En este manual
del usuario encontrará las intrucciones
apropiadas para su funcionamiento y
cuidado.
Registre su Producto
La TARJETA DE REGISTRO DEL
PRODUCTO ya dirigida debe ser
llenada, firmada y enviada.
Read and Save These Instructions
Record Your Model and Serial Numbers
Record below the model and serial numbers found on the washer
serial plate located on the underside of the washer lid. Keep these
numbers for future reference.
Anote su Número de Modelo y de Serie
Anote a continuación los números de serie y de modelo que se
encuentran en la placa de series de la lavadora ubicada en el reverso
de la tapa de la lavadora. Guarde estos números para futura
referencia.
Model Number:
Número de Modelo:
Serial Number:
Número de Serie:
Purchase Date:
Fecha de compra:
1
P/N 134437100D (0504)
This Owner's Guide
Grounding type
w
grounding plug
provides general
operating instructions for
your washer. It also
contains information
about features for
several other models.
Your washer may not
have every feature
included here.
Use the washer only as
instructed in this Owner's
Guide and the
Operating Instructions
card included with your
washer.
Avoid fire hazard or
electrical shock. Do
not use an adaptor
plug or extension
cord or remove
grounding prong
from electrical
power cord. Failure
to follow this
warning can cause
serious injury, fire or
death.
all receptacle
Grounding type
wall receptacle
Use this way ONLYUse this way ONLY
Use this way ONLY
Use this way ONLYUse this way ONLY
Do not under
Do not under
any circumstances
any circumstances
cut, remove,
cut, remove,
or bypass
or bypass
the grounding prong
the grounding prong
from this plug
from this plug.
Power supply
Power supply
cord with 3-prong
cord with 3-prong
grounding plug
CORRECTCORRECT
CORRECT
CORRECTCORRECT
Do not use or mix
liquid chlorine bleach with
other household chemicals
such as toilet cleaners, rust
removers, acid or products
containing ammonia. These
mixtures can produce
dangerous fumes which can
cause serious injury or death.
Note: The instructions
appearing in this
Owner's Guide are not
meant to cover every
possible condition and
situation that may
occur. Common sense
and caution must be
practiced when
installing, operating
and maintaining any
appliance.
Important Safety Instructions
Read all instructions before using this washer.
Prevent Fire
etc. Do not store these items on or near the washer. These substances give off vapors or chemical reactions that could ignite or explode.
that could ignite or explode.
GAS IS EXPLOSIVE. If the hot water system has not been used for such a period, before using the washer, turn on all hot water faucets and let the
water flow from each for several minutes. This will release any accumulated hydrogen gas. Hydrogen gas is flammable; do not smoke or use an open
flame during this time.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors
or liquids in the vicinity of this or any other appliance.
Protect Children
grow, teach them the proper, safe use of all appliances.
with rugs, bedspreads or plastic sheets can become airtight chambers.
Prevent Injury
person in accordance with local codes. Installation instructions are packed in the washer for installer's reference. Refer to INSTALLATION INSTRUCTIONS
for detailed grounding procedures. If the washer is moved to a new location, have it checked and reinstalled by a qualified service person.
and polarized 3-prong outlet. The third grounding prong must never be removed. Never ground the washer to a gas pipe. Do not use an
extension cord or an adaptor plug.
• Do not combine laundry products for use in 1 load unless specified on the label.
• Do not mix chlorine bleach with ammonia or acids such as vinegar.
• All repairs and servicing must be performed by an authorized servicer unless specifically recommended in this Owner's Guide. Use only
• Do not tamper with controls.
• Do not install or store the washer where it will be exposed to the weather.
shock or injury.
knob and allow the tub to coast to a complete stop before reaching inside.
SAVE THESE INSTRUCTIONS
To reduce the risk of fire, electrical shock, or injury to persons when using this washer, comply with the basic warnings listed below.
Failure to comply with these warnings could result in serious personal injuries.
Do not wash items that have been previously cleaned in, soaked in, or spotted with gasoline, cleaning solvents, kerosene, cooking oils, waxes,
Do not put oily or greasy rags or clothing on top of the washer. These substances give off vapors that could ignite the materials.
Do not add gasoline, cleaning solvents, or other flammable or explosive substances to the wash water. These substances give off vapors
Under certain conditions, hydrogen gas may be produced in a hot water system that has not been used for 2 weeks or more. HYDROGEN
Failure to comply with these warnings could result in fire, explosion, serious bodily injury and/or damage to the rubber or plastic parts of the washer.
Do not allow children to play on or in the washer. Close supervision of children is necessary when the washer is used near children. As children
Destroy the carton, plastic bag and other packing materials after the washer is unpacked. Children might use them for play. Cartons covered
Keep laundry products out of children's reach. To prevent personal injury, observe all warnings on product labels.
Before the washer is removed from service or discarded, remove the washer lid to prevent accidental entrapment.
Failure to comply with these warnings could result in serious personal injuries.
To prevent shock hazard and assure stability during operation, the washer must be installed and electrically grounded by a qualified service
If the power cord is damaged, it should be replaced by the manufacturer, service technician or a qualified person to prevent any risk.
To prevent personal injury or damage to the washer, the electrical power cord of the washer must be plugged into a properly grounded
Follow package directions when using laundry products. Incorrect usage can produce poisonous gas--resulting in serious injury or death.
To prevent serious personal injury and damage to the washer:
authorized factory parts.
ALWAYS disconnect the washer from the electrical supply before attempting any service or cleaning. Failure to do so can result in electrical
To prevent injury, do not reach into the washer while parts are moving. Before loading, unloading or adding items, push in the cycle selector
Failure to comply with these warnings could result in serious personal injuries.
This washer is equipped with an electrical overload protector. The motor will stop if it becomes overheated. The washer will automatically restart
after a cool down period of up to 30 minutes, if the washer has not been manually turned off during this time.
2
Printed in U.S.A.
WW
ashing Prashing Pr
W
ashing Pr
WW
ashing Prashing Pr
Sort laundry into loads that can be
ocedurocedur
ocedur
ocedurocedur
washed together.
eses
es
eses
• Follow the guidelines below for preparing the wash load.
• Read the Operating Instructions card for operating your specific model.
• Always read and follow fabric care and laundry product labels.
To reduce the risk of fire, electrical shock, or injury to persons, read
Important Safety Instructions, pages 2-3, before operating this washer.
1. Sort laundry into loads that can be washed together.
Sort items by recommended water temperatures, wash time, and agitate/spin
speeds.
• Separate white, light, and colorfast items from dark and noncolorfast items.
• Separate items which shed lint from items which attract lint. Permanent
press, synthetic, knit and corduroy items will pick up lint from towels, rugs
and chenille bedspreads.
• Separate heavily soiled items from lightly soiled items.
• Separate lacy, sheer and loosely knit items from sturdy items.
2. Prepare items for washing.
• Empty pockets.
• Brush off lint and dirt. Shake out rugs and beach towels.
• Close zippers, fasten hooks, tie strings and sashes, and remove nonwashable
trims and ornaments.
• Remove pins, decorative buttons, belt buckles, and other objects which
could be damaged. This also helps protect other items in the wash load.
• Mend rips and tears to prevent further damage during washing.
• Place delicate items such as bras, shoulder pads, hosiery, and belts in a mesh
bag to prevent tangling during the wash cycle.
• Turn knit items inside out to prevent pilling.
Empty pockets.
Place delicate items in a mesh bag.
3. Pretreat stains and heavy soil.
See Stain Removal, pages 6-7, for details.
4. Add a measured amount of detergent to the wash tub
before adding the laundry load.
Follow detergent manufacturer's directions. The amount required depends on
type of detergent, load size and soil level, and water hardness.
5. If desired, add liquid bleach to Bleach Dispenser (some models).
• Before adding the wash load, add liquid bleach to bleach dispenser located
in left front corner under the lid:
• 3/4 cup (180 ml) for small loads
• 1 cup (240 ml) for large loads
• 1-1/4 cups (300 ml) for extra-large loads.
• Then add 1 cup (240 ml) water to flush the dispenser.
• Do not use powdered bleach in the bleach dispenser.
For models without a bleach dispenser, dilute the recommended amount of
liquid chlorine bleach in 1 quart (.95 L) water. Add it to wash water after
a few minutes of agitation. Do not pour bleach directly on wash load.
Bleach Dispenser (some models)
3
Washing Procedures(continued)Washing Procedures(continued)
Washing Procedures(continued)
Washing Procedures(continued)Washing Procedures(continued)
Do not load items above
top row of holes in wash tub.
Built-In Fabric Softener Dispenser
(some models)
6. Add laundry load to washer.
• Dry load level should not be higher than top row of holes in wash tub.
Do not overload washer.
• Do not put items on top of agitator or wrap them around it. Load items
evenly.
• Combine large and small items in a load. Load large items first. Large items
should not be more than half the total wash load.
• When washing a single heavy item, add 1 or 2 towels to balance the load.
7. If desired, add liquid fabric softener to Fabric Softener
Dispenser
For models with a built-in dispenser (see picture to the left):
1. Add liquid softener to the dispenser, following fabric softener label directions.
2. Add water to bring liquid level to fill line on dispenser cap.
3. Remove the dispenser from the agitator after each use. Rinse both cap and
cup with warm water. Replace dispenser in the agitator.
NOTE: To separate cap from cup, put thumb into dispenser and push against side
of cup (see picture to the left). After cleaning, push cap and cup firmly together.
Replace dispenser by lining up the ribs and grooves and snapping it into position.
Fabric softener will be flushed from area under the built-in fabric softener
dispenser when Large Load Water Level is selected. If a build-up of fabric softener
occurs, clean with hot water. DO NOT REMOVE SERVICE CAP.
For models with a removable dispenser (see picture below to the left):
1. Attach fabric softener dispenser to top of agitator by pressing down gently.
2. Add softener to the dispenser, following fabric softener label directions.
3. Add water to bring liquid level to top of the peg in the center of the cup.
4. Remove the dispenser from the agitator after each use. Rinse both lid and
bowl thoroughly with warm water. Reassemble and place dispenser on
agitator or store it nearby.
For models without a fabric softener dispenser, follow fabric softener label
directions. Add diluted fabric softener to the final rinse. Do not pour fabric
softener directly on the wash load.
(some models).
Built-In Fabric Softener Dispenser
(some models)
Removable Fabric Softener Dispenser
(some models)
8. Set cycle selector knob and washer controls according to
type, size, and soil level of each load, and detergent used.
See Operating Instructions card for your specific model controls.
9. Start the washer.
Close the washer lid and pull out the cycle selector knob. The washer will not
agitate or spin with the lid open.
• To stop the washer, push in the cycle selector knob.
• Do not stop and restart washer during a spin when using the fabric softener
dispenser.
• To change a cycle, push in the cycle selector knob. Turn it clockwise to the
desired setting. Pull out the knob to restart the washer.
10.Remove items when the cycle is completed.
For your safety, the lid locks when the tub is spinning. It will remain locked for
about 1 minute after the tub stops spinning.
• To open the lid during a spin, push in the cycle selector knob and wait about
1 minute for the lid lock to release. Do not force open the locked lid.
Place washed items in automatic dryer, line dry, or dry flat as directed by fabric
care label. Excess wrinkling, color transfer or odors may develop in items left in
the washer after the cycle has ended.
To avoid serious personal injury, do not operate washer if safety lid
lock is missing or damaged.
4
Stain RemovalStain Removal
Stain Removal
Stain RemovalStain Removal
Do not combine stain removal products.
Follow fabric care label instructions.
Safe Stain Removal ProceduresSafe Stain Removal Procedures
Safe Stain Removal Procedures
Safe Stain Removal ProceduresSafe Stain Removal Procedures
basic warnings listed below:
• Read and comply with all instructions on stain removal products.
• Keep products in their original labeled containers and out of children's reach.
• Thoroughly wash any utensil used.
• Do not combine stain removal products, especially ammonia and chlorine bleach.
• Never wash items which have been previously cleaned in, washed in, soaked in or spotted
• Never use highly flammable solvents, such as gasoline, inside the home. Vapors can
For successful stain removal:
• Remove stains promptly.
• Determine the kind of stain, then follow recommended treatment in the stain removal
• To pretreat stains, use a prewash product, liquid detergent, or a paste made from
• Use cold water on unknown stains because hot water can set stains.
• Check care label instructions for treatments to avoid on specific fabrics.
• Check for colorfastness by testing stain remover on an inside seam.
• Rinse and wash items after stain removal.
To reduce the risk of fire or serious injury to persons or property, comply with the
Dangerous fumes may result.
with gasoline, dry cleaning solvents or other flammable or explosive substances because
they give off vapors that could ignite or explode.
explode on contact with flames or sparks.
chart on the next page.
granular detergent and water.
STAINSTAIN
STAIN
STAINSTAIN
Adhesive tape, chewing gum,
rubber cement
Baby formula, dairy products,
egg
Beverages (coffee, tea, soda,
juice, alcoholic beverages)
Blood
Candle wax, crayon
Chocolate
Collar or cuff soil, cosmetics
Dye transfer on white fabric
Grass
Grease, oil, tar (butter, fats,
salad dressing, cooking oils,
car grease, motor oils)
Ink
Mildew, scorch
Mud
Mustard, tomato
Nail polish
Paint, varnish
Perspiration
Rust, brown or yellow
discoloration
Shoe polish
Urine, vomit, mucus, feces
TREATMENTTREATMENT
TREATMENT
TREATMENTTREATMENT
Apply ice. Scrape off excess. Place stain face down on paper towels. Saturate with prewash stain remover or
nonflammable dry cleaning fluid.
Use product containing enzymes to pretreat or soak stains. Soak for 30 minutes or more. Wash.
Pretreat stain. Wash using cold water and bleach safe for fabric.
Rinse with cold water. Rub with bar soap. Or, pretreat or soak with product containing enzymes. Wash using
bleach safe for fabric.
Scrape off surface wax. Place stain face down between paper towels. Press with warm iron until wax is absorbed.
Replace paper towels frequently. Treat remaining stain with prewash stain remover or nonflammable dry cleaning
fluid. Hand wash to remove solvent. Wash using bleach safe for fabric.
Pretreat or soak in warm water using product containing enzymes. Wash using bleach safe for fabric.
Pretreat with prewash stain remover or rub with bar soap.
Use packaged color remover. Wash using bleach safe for fabric.
Pretreat or soak in warm water using product containing enzymes. Wash using bleach safe for fabric.
Scrape residue from fabric. Pretreat. Wash using hottest water safe for fabric. For heavy stains and tar, apply
nonflammable dry cleaning fluid to back of stain. Replace towels under stain frequently. Rinse thoroughly. Wash
using hottest water safe for fabric.
Some inks may be impossible to remove. Washing may set some inks. Use prewash stain remover, denatured
alcohol or nonflammable dry cleaning fluid.
Wash with chlorine bleach if safe for fabric. Or, soak in oxygen bleach and hot water before washing. Badly
mildewed fabrics may be permanently damaged.
Brush off dry mud. Pretreat or soak with product containing enzymes.
Pretreat with prewash stain remover. Wash using bleach safe for fabric.
May be impossible to remove. Place stain face down on paper towels. Apply nail polish remover to back of stain.
Repeat, replacing paper towels frequently. Do not use on acetate fabrics.
WATER BASED: Rinse fabric in cool water while stain is wet. Wash. Once paint is dry, it cannot be removed. OIL
BASED AND VARNISH: Use solvent recommended on can label. Rinse thoroughly before washing.
Use prewash stain remover or rub with bar soap. Rinse. Wash using nonchlorine bleach in hottest water safe for
fabric.
For spots, use rust remover safe for fabric. For discoloration of an entire load, use nonchlorine bleach. Do not use
chlorine bleach because it may intensify discoloration.
LIQUID: Pretreat with a paste of granular detergent and water. PASTE: Scrape residue from fabric. Pretreat with
prewash stain remover or nonflammable dry cleaning fluid. Rinse. Rub detergent into dampened area. Wash using
bleach safe for fabric.
Pretreat or soak in product containing enzymes. Wash using bleach safe for fabric.
5
Common WCommon W
Common W
Common WCommon W
ashing Prashing Pr
ashing Pr
ashing Prashing Pr
oblemsoblems
oblems
oblemsoblems
Many washing problems involve poor soil and stain removal, residues of lint and scum, and fabric damage. For satisfactory washing
results, follow these suggestions provided by The Soap and Detergent Association.
PROBLEMPROBLEM
PROBLEM
PROBLEMPROBLEM
Blue stains
Discoloration,
graying
Greasy, oily stains
Holes, tears, or
snags
Lint
POSSIBLE CAUSESPOSSIBLE CAUSES
POSSIBLE CAUSES
POSSIBLE CAUSESPOSSIBLE CAUSES
•Detergent or liquid fabric softener
did not dissolve or disperse.
•Not enough detergent.
•Wash water temperature too low.
•Incorrect sorting.
•Not enough detergent.
•Undiluted liquid fabric softener
poured directly on fabric.
•Incorrect use of chlorine bleach.
•Unfastened zippers, hooks,
buckles.
•Rips, tears and broken threads.
•Overloading the washer.
•Degradation of fabric.
•Incorrect sorting.
•Tissues left in pocket.
•Overloading the washer.
•Not enough detergent.
•Undissolved detergent has left
residue.
•Static cling is attracting lint.
•Load washed too long.
SOLUTIONSSOLUTIONS
SOLUTIONS
SOLUTIONSSOLUTIONS
•If caused by detergent, mix 1 cup (240 ml)
white vinegar with 1 quart (.95 L) water
in a plastic container. Soak item 1 hour.
Rinse.
•If caused by fabric softener, rub stains
with bar soap. Wash.
•Rewash with correct amount of
detergent and hottest water safe for
fabric. Add bleach safe for fabric.
•Treat with prewash stain remover or
liquid detergent.
•Increase detergent and water
temperature. Rewash.
•Rub fabric softener stains with bar soap.
•May be irreversible if rips, tears and seams
cannot be mended.
•Reduce load size. Rewash using correct
water temperature, water level, and
amount of detergent.
•Add nonprecipitating water conditioner
to wash water.
• Add liquid fabric softener to final rinse.
•Dry load in dryer.
•Remove lint with lint brush or roller.
PREVENTIVE MEASURESPREVENTIVE MEASURES
PREVENTIVE MEASURES
PREVENTIVE MEASURESPREVENTIVE MEASURES
•Add detergent before wash load. Then
start washer.
•Dilute fabric softener with water.
•Sort items by soil level and color.
•Use correct amount of detergent, hottest
water and bleach safe for fabric.
•Use correct amount of detergent and
hottest water safe for fabric.
•Do not pour liquid fabric softener
directly on fabric. See package directions
or Washing Procedures for proper
diluting.
•Never pour chlorine bleach directly on
fabric.
•Check condition of items before washing.
See Washing Procedures for preparing
and loading the wash load.
•See Washing Procedures for sorting and
preparing the wash load.
•Do not overload washer.
•Use correct amount of detergent, water
temperature and water level.
Pilling
(Fibers break off,
ball up and cling to
fabric)
Residue or powder
on dark items;
Stiff, harsh fabrics.
Wrinkling
Yellow buildup of
body soil on
synthetic fabrics
Yellow or brown
rust stains
•Pilling is normal with synthetic and
permanent press fabrics. This is due
to abrasion from normal wear.
•Undissolved detergent.
•Some nonphosphate granular
detergents can combine with hard
water minerals to form a residue.
•Overloading the washer.
•Agitation time too short.
•Wash water temperature too low.
•Not enough detergent.
•Iron or manganese in water supply,
water pipes, or water heater.
•Use a lint brush or shaver to remove pills.
•Reduce load size.
•Add dissolved detergent to tub . Rewash
load.
•Mix 1 cup (240 ml) white vinegar to 1
gallon (3.8 L) warm water in plastic
container. Soak item. Rinse and rewash.
•Reduce load size.
•Rinse in cold water with liquid fabric
softener.
•Soak in detergent booster or product
containing enzymes.
•Wash in hot water (120°F/49°C) using full
permanent press cycle. Increase
detergent. Add bleach safe for fabric.
•Or, treat with color remover.
•To restore discolored load of whites, use
rust remover safe for fabric.
Do not use chlorine bleach to remove
rust stains. It may intensify
discoloration.
•Use fabric softener in the washer to
lubricate fibers.
•When ironing, use spray starch or fabric
finish on collars and cuffs.
•Turn items inside out to reduce abrasion.
•Increase water temperature using hottest
water safe for fabric.
•Do not overload washer.
•Use liquid detergent or use nonprecipitating
water conditioner with nonphosphate
granular detergent.
•Do not overload washer.
•Remove items from washer as soon as cycle
is completed.
•Use liquid fabric softener.
•Wash synthetics frequently using water at
least 100°F (37°C ) and correct water level.
•Use nonprecipitating water softener.
•Before washing, run hot water for a few
minutes to clear lines.
•Drain water heater occasionally.
•For an ongoing problem, install an iron filter
in your water supply system.
6
CarCar
e and Cleaninge and Cleaning
Car
e and Cleaning
CarCar
e and Cleaninge and Cleaning
Use care with laundry
products. They can damage finish on
the washer.
Inside
• Remove items from the washer as soon as the cycle ends. Excess wrinkling, color
transfer, and odors may develop in items left in the washer.
• Dry the washer top, the area around the lid opening, and the underside of the
lid. These areas should always be dry before the lid is closed.
• Before cleaning the washer interior, unplug the electrical power cord to avoid
electrical shock hazards.
• When extremely soiled items have been washed, a dirty residue may remain on
the tub. Remove this by wiping the tub with a nonabrasive household cleanser.
Rinse thoroughly with water.
• The agitator or tub may become stained from fabric dye. Clean these parts with
a nonabrasive household cleanser. This prevents dye transfer to future loads.
Outside
• When washing is completed, wipe top and sides of washer with a damp cloth.
Turn water faucets off to prevent pressure build-up in the hoses.
• As needed, clean the cabinet with mild soap and water. Never use harsh, gritty
or abrasive cleansers. If top or lid becomes stained, clean with diluted chlorine
bleach [1/2 cup (120 ml) in 1 quart (.95 L) water]. Rinse several times with clear
water.
Follow Winterizing
Instructions for cold
weather care.
• Remove glue residue from tape or labels with a mixture of warm water and mild
detergent. Or, touch residue with the sticky side of the tape or label.
• Before moving the washer, place a strip of cardboard or thin fiberboard under
the front leveling legs to prevent floor damage.
Winterizing Instructions
If the washer is stored in an area where freezing can occur or moved in freezing
temperatures, follow these winterizing instructions to prevent damage to the washer:
1. Turn off water supply faucets.
2. Disconnect hoses from water supply and drain water from hoses.
3. Plug electrical cord into a properly grounded electrical outlet.
4. Add 1 gallon nontoxic recreational vehicle (RV) antifreeze to empty wash tub.
Close lid.
5. Set cycle selector knob at a spin setting. Pull out knob and let washer spin for
1 minute to drain out all water. Not all of the RV antifreeze will be expelled.
6. Push in knob, unplug electrical power cord, dry tub interior, and close lid.
7. Store washer in an upright position.
8. To remove antifreeze from washer after storage, run empty washer through a
complete cycle using detergent. Do not add wash load.
7
AA
void Servoid Ser
A
void Ser
AA
void Servoid Ser
ChecklistChecklist
Checklist
ChecklistChecklist
vicevice
vice
vicevice
Before calling for service, review this list. It may save both time and expense. The list includes
common concerns that are not the result of defective workmanship or materials in this washer.
OCCURRENCEOCCURRENCE
OCCURRENCE
OCCURRENCEOCCURRENCE
NOISENOISE
NOISE
NOISENOISE
"Clunking" or gear
sounds.
Rattling and clanking
noise.
Squealing sound or hot
rubber odor.
Thumping sound.
Vibrating noise.
POSSIBLE CAUSEPOSSIBLE CAUSE
POSSIBLE CAUSE
POSSIBLE CAUSEPOSSIBLE CAUSE
A certain amount of "clunking" or gear
sounds are normal in a heavy-duty
washer.
Foreign objects such as coins or safety
pins may be in tub or pump.
Belt buckles and metal fasteners are
hitting wash tub.
Washer is overloaded.
Heavy wash loads may produce a
thumping sound.
Washer is not resting firmly on floor.
Shipping bolt and block have not been
removed during installation.
SOLUTIONSOLUTION
SOLUTION
SOLUTIONSOLUTION
This is normal.
Stop washer and check tub. If noise continues after
washer is restarted, objects may be in pump. Call your
authorized servicer.
To prevent unnecessary noise and damage to tub,
fasten fasteners and turn items inside out.
Do not overload washer. Stop washer and reduce
load.
This is usually normal. If sound continues, washer is
probably out of balance. Stop washer and redistribute
wash load.
Move washer so it rests firmly on floor. Adjust leveling
legs. See INSTALLATION INSTRUCTIONS for details.
See INSTALLATION INSTRUCTIONS for removing
shipping bolt and block.
OPERATINGOPERATING
OPERATING
OPERATINGOPERATING
Washer does not start.
Washer won't spin.
Wash load unevenly distributed in tub.
Electrical power cord may not be plugged
in or connection may be loose.
House fuse blown, circuit breaker tripped,
or a power outage has occurred.
Water supply faucets are not turned on.
Cycle selector is not in correct position.
Motor is overheated.
Lid is not completely closed.
Heavily soiled items.
Stop washer and rearrange wash load.
Make sure plug fits tightly in wall outlet.
Reset circuit breaker or replace fuse. Do not increase
fuse capacity. If problem is a circuit overload, have it
corrected by a qualified electrician. If problem is a
power outage, call local electric company.
Turn on water supply faucets.
Move indicator clockwise slightly. Pull out knob.
Washer motor will stop if it becomes overheated. It
will automatically restart after a cool down period of
up to 30 minutes (if washer has not been manually
turned off).
Close lid completely.
Wipe tub with a nonabrasive household cleanser, then
rinse. Shake or brush excess dirt and sand from items
before washing.
8
OCCURRENCEOCCURRENCE
OCCURRENCE
OCCURRENCEOCCURRENCE
WATERWATER
WATER
WATERWATER
POSSIBLE CAUSEPOSSIBLE CAUSE
POSSIBLE CAUSE
POSSIBLE CAUSEPOSSIBLE CAUSE
SOLUTIONSOLUTION
SOLUTION
SOLUTIONSOLUTION
Residue left in tub.
Wash load too wet after
spin.
Water does not enter
washer or it enters
slowly.
Water level does not
cover load.
Washer is overloaded.
Load is out of balance.
Drain hose is kinked.
Water supply is not adequate in area.
Water supply faucets are not completely
open.
Water is being used elsewhere in the house.
Water inlet hoses are kinked.
Improper water level selection (for models
with
water level/load size control).
Washer is overloaded.
Do not overload washer. See Washing
Procedures.
Rearrange load to allow proper spinning.
Straighten drain hose.
Check another faucet in the house. Wait until
water supply and pressure increase.
Fully open hot and cold faucets.
Water pressure must be at least 30 psi (260 kPa).
Avoid running water elsewhere while washer is
filling.
Straighten hoses.
Select higher water level/load size.
Do not overload washer. When control is set at
highest fill level, dry load level should not be
higher than top row of circular holes in wash tub.
Warm or hot water is not
hot enough.
Water in washer does not
drain or drains slowly.
Water leaks.
Incorrect wash and rinse
temperatures.
Water is entering washer
but tub does not fill.
Hot water heater is set too low or is a distance
from washer.
Hot water is being used elsewhere in the
house.
Drain hose is kinked or clogged.
Fill hose connection at faucet or washer.
House drain pipes are clogged.
Oversudsing.
Hot and cold water hoses are connected to
wrong supply faucets.
Drain hose standpipe is incorrect height.
Measure hot water temperature at nearby faucet
with candy or meat thermometer. Water
temperature should be at least 130°F (70°C).
Adjust water heater as necessary.
Avoid using hot water elsewhere before or during
washer use. There may not be enough hot water
available for proper cleaning. If problem persists,
your hot water system may be unable to support
more than 1 use at a time.
Clean and straighten the drain hose.
Check and tighten hose connections. Install rubber
sealing washers provided.
Unclog drain pipes. Contact plumber if necessary.
Use less detergent.
Connect hot water hose to hot water faucet and
cold water hose to cold water faucet.
Standpipe must be a minimum of 33" (83.82 cm)
high to prevent siphoning. See INSTALLATION
INSTRUCTIONS.
9
Loading...
