Whistler GLF-100 User Manual
The Whistler Group, Inc. - Corporate Offices
3604 NW Frontage Road
Bentonville, AR 72712
1-800-531-0004
The Whistler Group, Inc. - Customer Return Center
551 North 13th Street
Rogers, AR 72756
www.whistlergroup.com
© 2010 The Whistler Group, Inc.
GolfDigest GPS is a registered trademark of Conde’ Nast Publications. All rights reserved.
P/N 505101
OWNER’S MANUAL
Model GLF-100 Golf GPS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2-3
Feature - Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-5
Important Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
GPS Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Storing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Selecting and Downloading Courses . . . . . . . . . . . . . . . . . . . . . . . . . . .10-11
Power Up and Main Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12-13
Icon Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14-15
Setting Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16-23
Unit of Measure
Time Zone
Time Format
Backlight
Auto Detect Function
Resetting Features
Delete Golf
Version
Green Range
Using the Flip Up Belt Clip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24-25
Get Ready to Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26-27
Selecting a Golf Course
Select the Front or Back 9
Select the hole
Green Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28-29
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31-32
FCC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33-34
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35-38
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Table of Contents Table of Contents
Introduction Introduction
Dear Whistler Owner,
Note: Your warranty period begins at the time of purchase. The warranty is validated only
Thank you for purchasing a Golf GPS from the Whistler Group. If you have questions
concerning the operation of this Whistler product please call:
by the dated store receipt. Record the serial number of the unit in the space provided in
the warranty section of the manual.
Customer Service
1-800-531-0004
Monday - Friday • 8:00 am - 5:00 pm CT
or visit our website
www.whistlergroup.com
Please keep the receipt in a safe place. For warranty verification purposes, a copy of your
dated store receipt must accompany any unit sent in for warranty work. If the unit is
returned without a dated store receipt, an out of warranty service charge applies.
Design and specifications could be changed without prior notice.
All intellectual property rights and copyrights for the manual, hardware, and related
software are protected by applicable law. This manual may not be copied, reprinted, or
reproduced in any manner without the written permission of the Whistler Group.
To fully acquaint yourself with the operation of your Golf GPS, we recommend reading this
entire manual or visiting our FAQ page on our website www.whistlergroup.com
Enjoy your Golf GPS.
Sincerely,
The Whistler Group, Inc.
2 3
Features Feature Descriptions
Whistler’s ergonomic and user-friendly design provides a new level of operating
3
4
5
2
1
6
8
7
10
9
11
4 5
convenience. Special features include:
1. USB Port - For connection to a PC for updates.
2. Backlit LCD Display - Offers easy-to-read display to indicate Green information.
3. GPS Antenna – Compact, high efficiency antenna receives GPS signals.
4. Power/Menu/ESC – Hold for 3 seconds to turn unit on or off. A short press enters the
Menu mode or escapes the current operation.
5. Up Button - Allows scrolling in menu mode.
6. Enter/OK/Mark Button- A short press confirms selection or switches front/back
distance to the fly distance. Hold for 3 seconds to mark a position.
7. Down Button – Allows scrolling in menu mode.
8. Battery Compartment - Compartment for 2 AAA Alkaline batteries.
9. Flip Up Belt Clip - Secures the unit to a belt. Allows the unit to flip up to be viewed
without removing the unit from the belt clip.
10. USB Cable - Connects the unit to a PC to download courses.
11. Batteries - 2 AAA batteries that power the unit.
Important Information GPS Information
Warnings
Please read the guidelines below, since failure to do so may result in mis-use of the
equipment and may be dangerous or illegal.
• It is the user’s responsibility to use this product prudently and this unit should not be used
while driving any vehicle including golf carts. Always place the unit in a secure area to
avoid any impact which could cause damage to it..
• Any damage caused by incorrect battery placement or battery leakage is not covered
under this warranty.
• Contact with rain or water should be avoided.
• Should you experience any problems with your unit , please contact Customer Service
at www.whistlergroup.com or 800-531-0004. Do not attempt any repairs on your own
as this may void the warranty.
The Global Positioning System (GPS) is operated by the government of the United States,
which is solely responsible for its accuracy and maintenance. The system is subject to
changes which could affect the accuracy and performance of all GPS equipment..
Coverage/reception levels may be adversely affected by forests and/or buildings. Optimal
usage will be gained in wide open areas.
Note: Powering up, the unit will begin its search for satellites. During this time it may take
several minutes in order to receive satellite signals. It may take longer to receive signals if it
has been off for 4 or more hours, or if you traveled more than 100 miles away from when
the unit last received a satellite lock. When the unit has a lock, the clock will appear.
6 7
Storing Battery Installation
Observing correct polarity (+)
and (-), insert batteries as
shown.
Reinstall battery compartment
cover.
Remove the battery compartment cover by sliding the cover to the edge of the unit and lifting up.
Storing
When the unit is not in use please consider the following steps:
1). When not using the GPS, please store it in a dry place and remove the batteries.
2). Do not place it in direct sunlight or extremely hot temperatures.
Note: As with all battery operated devices, remove the batteries when this unit will not be
used for an extended period of time. Damage caused by leaky or improperly charged
batteries is not covered under warranty.
Note:
•
DO NOTmix battery types as this can damage the batteries.
• Use Alkaline batteries for best battery life.
Important: Ni-Cd batteries are not recommended. These batteries will not provide enough capacity to
be useful.
8 9
Selecting and Downloading Courses Selecting and Downloading Courses
11
Please note: Golf course map data is provided by GolfDigest GPS. In order to register the
GPS unit and receive the two free courses, you will exit Whistler’s website and enter a third
party website. From here you may purchase additional golf courses at any time. The GLF100 unit can store up to 32 courses.
Instructions for Registering the GolfDigest GPS Whistler GLF-100
1) Visit www.whistlerupdates.com and select “Golf Registration”.
Please note that you will be leaving Whistler’s site and going to GolfDigestGPS’ website when you click this link. You
are now at www.golfdigestgps.com and they will handle the golf course downloads and PC Software requirements
for your Golf GPS unit.
2) Select the “GolfDigest GPS Golf GPS Device” section for the PC Software requirements
for your Golf GPS unit.
3) Select "Download GolfDigest GPS MapManager" to download and install the
application program and device drivers.
4) Before proceeding, DO NOT turn your GPS device on. Open GolfDigest GPS
MapManager by clicking on the desktop icon. Once open, connect
your device via its USB cable to your PC.
Note: Batteries do not need to be installed to load maps.
5) When prompted, enter your email address and a password to create a
GolfDigest GPS account.
10
6) Complete the Registration form and submit.
7) Map Search will open for you to search and select your two free maps by adding
them to your shopping cart and checking out. Your first two maps will appear as free
maps in the shopping cart. Additional maps can be purchased for a separate fee.
8) After completing your free map selections/additional
purchase(s), your map(s) will appear in your
GolfDigest GPS MapManager's upper left Maps
window.
9) Select maps to download to your device by checking the appropriate boxes and
clicking the Download Maps button on the toolbar or by selecting the
“File->Download Maps” menu item. Downloaded maps will appear in your GolfDigest
GPS MapManager lower left device window.
10) You are now ready to begin enjoying your
GolfDigest GPS by Whistler!
