Whistler 1565 User Manual

If you have questions concerning the op­eration of this Whistler product please call customer technical service:
1-800-531-0004
Hours:
Monday - Friday
9:00 am - 5:00 pm EST
INTRODUCTION
Dear Whistler Owner, For many of us, a vehicle is more than just transportation. It
can be a mobile office, communications or entertainment center, or simply an expression of our personality. Whistler Corporation recognizes this and has created a selection of products we call “Enhanced Driving Tools”. These products are designed to make the time you spend in your vehicle more productive, more fullfilling, safer, or just simply more fun. Our mission is to provide products that improve your driving experience though keeping you...
IN TOUCH • IN COMFORT • IN CONTROL
Your new Whistler 1560/1565 laser/radar detector detects all ra­dar , laser and safety radar systems, plus offers Whistler’s exclusive Safe Driving System
. This comprehensive safety system detects the Safety Warning System™ keeping you informed of road haz­ards and adverse weather . Plus, Whistler’s unique Stay Aler t™ fea­ture tests driver’ s alertness on long solo trips. Whistler’ s 1560/1565 also offers a digital display with safety message icons to keep you informed while you drive.
T o fully acquaint yourself with the operation of the Whistler 1560/ 1565 and to better understand the differences between detect­ing radar , laser and safety radar signals, we recommend reading this entire manual.
Enjoy the Whistler 1560/1565 and please drive safely. Sincerely, WHISTLER CORPORATION
1
TABLE OF CONTENTS
Topic Page Model Features Summary 3 - 5 Installation 6 - 8
• Mounting Guidelines
• Dash/Visor/Windshield Mounting
• Power Connection And Fuse Replacement
Operation 9 - 14
• Power On And Self-Test
• Feature Engaged Confirmation
• Audio Level Adjustment
• Auto Quiet/Mute Modes
• City Modes
• Dim/Dark Mode
• Stay Alert
• Engaging/Disengaging VG-2 Detection
• Teach/Tutorial Mode
• Auxiliary Jack
Radar, Laser And VG-2 Alerts 15 - 18
• Speed Radar Audio/Visual Alerts
• Pulse Protection
• Safety Radar Audio/Visual Alerts
• Laser Audio/Visual Alerts
• VG-2 Audio/Visual Alerts
• Alert Priority
• Reset Features/Care Maintenance
Troubleshooting Guide 19 Are Detectors Legal? 20 Speed Monitoring Technologies 21 - 22
• Radar Facts
• Laser Facts
• Other Speed Detection Systems
• Radar Detector Detectors
Warranty Information 23 - 25 Specifications 26 Accessories 27
®
2
WHISTLER FEATURES
Whistler 1560/1565
10
9
7
8
1
2
3
VOL
DARK
PWR
4
6
MUTE
CITY
5
Whistler’ s ergonomic and user -friendly design provides a new level of operating convenience. Special features include:
1. Bracket Release Button - Provides quick and easy re­lease of the mounting bracket.
2. Power Jack - Provides connection for the power cord.
3. Speaker - Provides distinct audio warnings for X, K, Ka band
radar , safety radar, laser, VG-2 and Stay Alert.
4. Power/Volume Button - Turns unit on/off and adjusts audio level.
5. High Visibility Digital Display - Provides distinct visual confirmation of signals detected, signal strength, and indicates engaged modes of operation.
6. MUTE Button - Pressing MUTE before a signal is detected engages Auto Quiet Mode which automatically reduces the au­dio level after the initial warning to a low audio level setting. Press­ing MUTE during a radar/laser encounter silences audio alerts, while allowing visual alerts to keep you informed.
3
WHISTLER FEATURES
7. CITY/CITY 1 Button - Reduces the annoyance of
false alerts typically encountered in urban driving areas.
8. DARK Button - Reduces illumination of display to “dim” or “dark” settings.
9. Auxiliary Jack - Provides easy connection of the WHIS­TLER 1400 EXTERNAL SPEAKER, Part Number 202180 or WHISTLER MOTORCYCLE HELMET SPEAKER, Part Num­ber 202698 (see page 27). Any other speaker may damage the unit and void your warranty.
10. Laser Antenna (Rear) - An integrated optical waveguide
provides superior detection of laser signals transmitted from behind.
13
13
11 12
11
12
11. Laser Antenna (Front) - High gain optical lens array
provides increased sensitivity and field of view for leading­edge laser detection.
12. Radar Antenna - Compact, high-efficiency antenna re­ceives radar signals.
13. Mounting Bracket Location - Slot holds mounting bracket firmly.
4
WHISTLER FEATURES
Accessories
Accessories included are highly functional and easy to use. Coiled Power Cord - Connects to the unit’s power jack and
your vehicle’s lighter socket. Windshield Bracket - Allows installation of unit on your
vehicle’s windshield.
®
Velcro
dashboard.
Fasteners - Designed to secure the unit on a level
5
INSTALLATION
Mounting Guidelines
• Mount the unit as low as possible near the center of the windshield.
• Do not mount your unit behind wipers, ornaments, mirrored sunscreens, etc. These obstructions have metal surfaces which can affect radar and laser signals and reduce critical warning time. (Regular tinted glass does not affect reception.)
• Some newer windshields have an Instaclear™ or Electriclear™ type coating, which affect radar signals. Con­sult your dealer or the owner’s manual supplied with your vehicle to determine if your windshield has this coating.
• Avoid placing unit in direct contact with windshield.
• To reduce the possibility of theft, conceal your unit when not in use.
Windshield Mounting
• Install the two suction cups and rubber bumper onto the bracket by fitting them into their holes.
• Press the suction cups onto the windshield at the location you have chosen.
• Slide the detector onto the bracket until it locks into place.
• If necessary, the unit may be leveled by bending the wind­shield bracket. Press the bracket release button and remove the detector before bending.
6
INSTALLATION
IMPORTANT : Some newer cars have a plastic safety coat­ing on the inside of the windshield. The windshield bracket may leave permanent marks on this type of surface. To find out if your vehicle has this type of windshield, check the owner’s manual or ask your dealer. We recommend that you do not leave the suction cup bracket on the win­dow in direct sunlight. If the detector is removed, this may cause blistering of the dash in some vehicles.
Dash Mounting
• Make sure the mounting location you have chosen is relatively level and is clean and dry . Clean with isopr opyl alcohol if neces­sary to remove any waxes or polishes.
• Separate the Velcro ing off each strip and adhere one piece to the dash and the other piece to the bottom of the unit, taking care not to
cover the serial number.
®
fastener strips. Peel the paper back-
Be careful not to place the Velcro® over the unit’s serial number. If the Velcro® is removed, the serial number may be pulled off the unit. Units without serial num­bers are not covered under warranty.
7
INSTALLATION
Visor Mounting (optional accessory)
• Slide the visor bracket into the bracket mounting slot.
• Clip the visor bracket onto the visor making sure it is rela­tively level and has a clear view of the road.
Slide on visor
Insert into bracket mounting slot
Power Connection
• Plug the small end of the power cord into the unit’s power jack.
• Plug the large end into the vehicle’s cigarette lighter.
Fuse Replacement
The lighter socket plug is equipped with a replaceable 2 amp 3AG fuse located behind the silver tip. To replace the fuse, carefully unscrew the tip of the plug. (IMPORTANT: Unscrew slowly . The tip contains a spring which may fly out when disas­sembling.) Insert the new fuse with the spring and screw on the tip. With use, screw cap on plug may loosen. Retighten
occasionally .
Unscrew the tip of the lighter socket plug carefully when replacing the 2 amp fuse.
8
