Whirlpool WRC36DB Quick Start Guide

Quick Start Guide / Guide de démarrage rapide

W10687103A

COOLVOX™ KITCHEN SOUND SYSTEM SAFETY

You can be killed or seriously injured if you don't immediately

You

can be killed or seriously injured if you don't

follow

All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.

This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word “DANGER” or “WARNING.”

These words mean:

follow instructions.

instructions.

DANGER

WARNING

State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the State of California to cause birth defects or other

reproductive harm.

UL Certificate Number - 14-111498

2

SOUND SYSTEM OVERVIEW

A B C

†®BLUETOOTH is a registered trademark of Bluetooth SIG, Inc.

CoolVox CoolVox

Accept

■ Designed for the top of the refrigerator; low profile to fit

underneath cabinets, reducing countertop clutter.

■ Angled speakers fill the kitchen with sound.

■ Intelligent equalization (EQ) technology: Digital signal

processing (DSP) to optimize system dynamics and bass
impact.

■ Bi-amplification: the woofers and mid-range to high-range

speakers are independently driven by digital Class D
amplifiers for exceptional richness and clarity of sound.

■ Advanced transducers: Specially designed woofers produce

extended bass performance with minimal distortion. Mid­range to high-range speakers project musical details over a
wide listening area.

A. Status LED

B. Power/Pair C. Volume

Amber ­Standby Mode

Blinking Blue ­Pairing Mode

Solid Blue ­Connected

■ Seamless Bluetooth

®†

connectivity and NFC pairing option for

Androids.

■ Drivers: Four mid-range to high-range speakers and two

woofers

■ Power: mid-range to high-range: 4 x 6 watts @ 1% THD

■ Woofers: 2 x 10 watts @ 1% THD

■ Frequency response: 70Hz – 20kHz

■ Interface: Bluetooth

■ Power supply input voltage: 100 – 240V AC, 50-60 Hz

■ Dimensions: 29" x 8¹⁄₂" x 1¹⁄₂" ( 737 mm x 216 mm x 38 mm)

■ Weight: 4.3 lb (1.95 kg)

®

A2DP music streaming

SET UP AND OPERATION

1. Remove the CoolVox™ kitchen sound system from its

packaging and remove all film.

2. Place the sound system on top of the refrigerator with the

front edge aligned with the front of the refrigerator cabinet.

3. Plug the power cord into the wall outlet. The status LED (A)
will glow amber.

4. Pair and Play.
The sound system pairs easily with your smart phone, tablet,

or other Bluetooth device. It has a range of approximately
30 ft (9 m), so you can enjoy the sound you want without
wires.

■ Press and release the Power/Pair button (B) on the control

panel. The Status LED (A) will flash blue.

■ Select the CoolVox™ kitchen sound system from your

device.

■ The Status LED (A) will glow solid blue when the sound

system is properly paired with your Bluetooth device.

■ You are now ready to play your music through CoolVox.

Use the controls of your Bluetooth-enabled device to
start, stop, or pause the audio.

NOTES:

■ If another device is already paired with the CoolVox™ sound

system, press and hold the Power/Pair button (B) on the
control panel for 3 seconds to cancel the existing pairing.
Then, re-pair with different device by performing Step 4.

■ The CoolVox™ sound system will remember the six devices

most recently used, so it is even simpler to reconnect.

3

TROUBLESHOOTING

Operation

PROBLEM POSSIBLE CAUSES SOLUTIONS
The CoolVox™ sound

system will not operate

There is no sound
coming from the
CoolVox sound system,
and status LED is not lit.

Power cord not plugged into
wall outlet

Switch controlling wall outlet is
turned off

Fuse blown or circuit breaker tripped Reset a tripped circuit breaker. Replace any blown fuses.

Check electrical supply. Plug the power cord’s 2-pronged plug into
a wall outlet. The Status LED (A) will glow amber if power is
present.

Move wall outlet switch to ON position

NOTE: If problems continue, contact an electrician.

Interference with radio
and/or television
reception

Mobile Device is not Bluetooth paired Pair the BlueTooth source. See “Set Up and Operation.” The

Mobile Device is not sending audio Consult User’s Manual for phone or tablet
Determine whether or not CoolVox™

sound system is causing the
interference by turning it off and then
back on. If the interference stops and
then resumes, try to correct the
interference by one or more of these
measures.

CoolVox™ sound system is available for pairing when the Status
LED (A) flashes blue. Pairing is accomplished when the Status LED
glows constant blue.

■ Reorient or relocate receiving antenna.

■ Increase the separation between the CoolVox™ sound system

and the receiver

■ Connect the CoolVox™ sound system into an outlet on a

circuit different from that to which the receiver is connected.

■ Consult the dealer or an experienced radio/TV technician for

assistance.

Bluetooth

PROBLEM POSSIBLE CAUSES SOLUTIONS
Bluetooth Not Paired

Mobile device does not
list CoolVox™ sound
system as a Bluetooth
music source.

There is no power to CoolVox™ sound
system.

Mobile device is not Bluetooth
compatible

Mobile device’s Bluetooth feature is
not enabled

Check electrical supply. Plug the power cord’s 2-pronged plug into
a wall outlet. The Status LED (A) will glow (amber or blue) if power
is present.

Obtain audio source material from a Bluetooth compatible device

Enable Bluetooth feature using menus on mobile device.
NOTE: Many mobile devices ship with the Bluetooth feature
disabled to improve battery life.

Bluetooth pairing is
intermittent; audio
“cuts out” sporadically

Mobile device instructs
me to enter a Bluetooth
passcode

4

CoolVox™ sound system is currently
paired with another (muted) Bluetooth
music source. This is indicated by the
Status LED (A) glowing constant blue.

Mobile device too far away, or signal is
blocked

Cancel any existing pairing by initiating a re-pairing session. Press
and hold the CoolVox sound system Power/Pair button (B) for
3 seconds. The Status LED (A) will change from constant blue
(paired) to flashing blue (unpaired and available to be paired).
While Status LED flashes blue, CoolVox™ sound system is
available for pairing with new mobile device. When new pairing is
accomplished, the Status LED returns to constant blue.
NOTE: The Status LED (A) glows amber when the CoolVox™
sound system is in standby mode.

Move mobile device closer to CoolVox™ sound system.
Line-of-sight pairing range is at least 30 ft (9 m) without walls or
windows.

Enter passcode 0000 on mobile device if requested. The
CoolVox™ sound system Status LED (A) will flash blue when
re-pairing can be attempted.
